EtherFast®3124

24-Port 10/100

Ethernet Switch

ith its advanced switching technology, the EtherFast®

3124 24-Port 10/100 Ethernet Switch will boost your

network performance with much more than just full

duplex data transfer and dedicated bandwidth. It features non-

blocking,wire-speed switching that forwards packets as fast as

your network can deliver them. Also included are Address

Learning and Aging to prevent data transfer errors and Data

Flow Control to help prevent packet collisions.

The EtherFast 3124 is rack mountable and includes an

Expansion Slot that accepts an optional Fiber Module to let you

grow your network by linking to other switches in full duplex

mode up to 2000 meters (6560 feet) away.

No matter how intensive your network demands, the EtherFast

3124 24-Port 10/100 Ethernet Switch's advanced chipset sup-

ports your needs with an affordable and efficient networking

solution you can count on.

• 24-Port 10/100 Full Duplex,Autosensing Ports

• Run Blazing Speeds of up to 200Mbps at Full Duplex

• Perfect for Running 10BaseT, 100BaseTX and 100BaseFX

Hardware Together Seamlessly

• Optional 100BaseFX Fiber Optic Module Sends Data Up to

2000 Meters (6560 feet) Away in Full Duplex Mode

• Data Flow Control Filters Out Faulty Data Packets

• Auto MDI/MDI-X

• Supports aging function, 802.3x Pause Frame for full duplex

• Broadcast storm control avoids unnecessary bandwidth

absorption

EtherFast®3124 24-Port 10/100 Ethernet Switch

Model No.: EF3124

High-speed 10/100 Switching

with Linksys reliability and Fiber Expandability

Features

Benefits

• 24 Autosensing 10/100 full duplex, auto

MDI/MDI-X ports

• Optional 100BaseFX Fiber Optic Module con-

nects multiple switches at high speed as your

network grows

• Run blazing speeds up to 200Mbps

• Address Learning and Data Flow Control for

transmission reliability

Instant EtherFast®Series

Package ContentsSpecifications

Model Number EF3124

Standards IEEE 802.3, IEEE 802.3u, IEEE 802.1p,

IEEE 802.3x

Ports 24 10/100 Auto-Negotiation RJ-45 Ports,

One Fiber Module Expansion Port

Cabling Type UTP/STP Category 5 or Better

LEDs Power, Link/Activity (per port),

Full Duplex (per port)

Environmental

Dimensions 7.09" x 1.75" x 16.93"

(180 mm x 44.5 mm x 430 mm)

Unit Weight 6.61 lbs. (3 kg)

Power 100-240V AC, 50-60 Hz

Certifications FCC Class A, CE

Operating Temp. 32ºF to 122ºF (0ºC to 50ºC)

Storage Temp. -40ºF to 158ºF (-40ºC to 70ºC)

Operating Humidity 20% to 95%, Non-Condensing

Storage Humidity 20% to 95%, Non-Condensing

• EtherFast®24-Port Switch

• AC Power Cable

• User Guide and Registration Card

• Mounting kit containing:

Four rubber feet for mounting the switch on

a table

Two mounting brackets

Six screws for attaching the brackets to the

switch

DS-ef3124-122402NC KL

Linksys

World Headquarters:

17401 Armstrong Ave.

Irvine, CA 92614 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional

Offices throughout the world. For a complete

list of local Linksys Sales and Technical

Support contacts,visit ourWorldwideWeb Site

www.linksys.com
