Wireless Networking at Up To 4X the Range and 12X the Speed!

Wireless-N

USB Network Adapter Product Data

Model WUSB300N

The Wireless-N USB Network Adapter is the simple way to add

wireless connectivity to your notebook or desktop computer.

Just connect it to your PC’s USB port and enjoy incredible high-

speed wireless network access, at unheard-of distances.

The Wireless-N USB Network Adapter uses the very latest

wireless networking technology, Wireless-N (draft 802.11n). By

overlaying the signals of multiple radios, Wireless-N’s “Multiple

In, Multiple Out” (MIMO) technology multiplies the effective data

rate. Unlike ordinary wireless networking technologies that

are confused by signal reﬂections, MIMO actually uses these

reﬂections to increase the range and reduce “dead spots” in the

wireless coverage area. The robust signal travels farther,

maintaining wireless connections up to 4 times farther than

standard Wireless-G.

With Wireless-N, the farther away you are, the more speed

advantage you get. It works great with standard Wireless-G

and -B equipment, but when both ends of the wireless link are

Wireless-N, the throughput can be increased even more by

using twice as much radio band, yielding speeds up to 12 times

as fast as standard Wireless-G.

Once you’re connected, you can keep in touch with your e-mail,

access the Internet, and share ﬁles and other resources such

as printers and network storage with other computers on the

network, wherever you wander. At home, you can surf the

web or use instant messaging to chat with friends while sitting

out on the patio. You’ll also be able to connect with any of the

growing number of public hotspots springing up in coffee shops,

airport lounges, hotels and convention centers. Your wireless

connection is protected by industrial-strength WPA2 encryption.

The included Setup Wizard will walk you through conﬁguring the

adapter to your network’s settings, step by step.

The incredible speed of Wireless-N makes it ideal for media-

centric applications like streaming video, gaming, and Voice

over IP telephony, and gives you plenty of headroom to run

multiple media-intense data streams through the network at the

same time, with no degradation in performance. Get connected

to Wireless-N, Wireless-G, and Wireless-B networks with the

Wireless-N USB Network Adapter from Linksys.

Wireless networking at incredible speeds Reach all areas of the home or ofﬁce Surf, work, or play without running wires

WIRELESS

Wireless-N

USB Network Adapter

Features

High-speed Wireless-N (draft 802.11n)

networking for your desktop or

notebook PC

MIMO technology uses multiple radios

to create a robust signal that travels

up to 4 times farther and reduces dead

spots

Up to 12 times faster than Wireless-G,

but can also connect to Wireless-G and

-B networks

Performance Investment Protection:

Compatibility with Wireless-B (802.11b)

and Wireless-G (802.11g) Standards

Easy to use Setup Wizard

Supports up to 256-bit WEP, WPA and

WPA2 Encryption Security

USB 2.0 Hi-Speed Interface

Plug-and-Play Operation Provides Easy

Setup

Compatible with Microsoft Windows

2000, and XP

•

Speciﬁcations

Model WUSB300N

Standards IEEE 802.11b, IEEE 802.11g, Draft IEEE 802.11n, USB

1.1, USB 2.0

Ports USB Port

LEDs Power, Link/Act

Modulations 802.11b: CCK, QPSK, BPSK

802.11g: OFDM

Wireless-N: BPSK, QPSK, 16-QAM, 64-QAM

RF Pwr (EIRP) in dBm 802.11b: 14±1dBm (Typical)

802.11g: 14±1dBm (Typical)

Wireless-N: 14±1dBm (Typical)

Receive Sensitivity in dBm 11Mbps @ -86dBm (Typical)

54Mbps @ -68dBm (Typical)

Wireless-N @ -62dBm (Typical)

Power Consumption TX: <480mA (Maximum)

RX: <390mA (Maximum)

Security features WEP, WPA and WPA2 Encryption Security

Security key bits Up to 256-bit encryption

Environmental

Dimensions 2.24˝ x 0.39˝ x 3.98˝ (57mm x 10mm x 101mm)

Weight 1.02 oz (0.029 kg)

Certiﬁcation FCC, Wi-Fi (802.11b/g)

Operating Temp. 0º C ~ 55º C (32º F ~ 131º F)

Storage Temp. -20º C ~ 80º C (-4º F ~ 176º F)

Operating Humidity 10% ~ 85% Non-Condensing

Storage Humidity 5% ~ 90% Non-Condensing

Linksys

A Division of Cisco Systems, Inc.

121 Theory

Irvine, CA 92617 USA

E-mail: sales@linksys

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional

Ofﬁces throughout the world. For a complete

list of local Linksys Sales and Technical Support

contacts, visit our Worldwide Web Site at

www.linksys.com.

Minimum Requirements Package Contents

600 MHz or Faster PC

256 MB of RAM Memory

CD-ROM Drive

Available USB Port (USB 2.0 port required for fastest

speeds)

Windows 2000 with Service Pack 4 or XP with Service

Pack 2 (or later)

•

Wireless-N USB Network Adapter

USB Extension Cable

USB Extension Base

Setup CD-ROM with User Guide

Quick Installation

•

Model WUSB300N

Check the product package and contents for speciﬁc features supported. Speciﬁcations are subject to change without notice. Linksys is a registered trademark or trademark of

trademarks or registered trademarks of their respective holders.

WUSB300N-DS-WPA-61102-Rev_NC-BW
