Linksys WCF54G - Wireless-G Compact Flash Card Instructions d'utilisation d'origine

A Division of Cisco Systems, Inc.

Model No.

Quick Installation

Model No.

Wireless

WCF54G

CompactFlash Card

Wireless-G

Package Contents

• Wireless-G CompactFlash Card

• Setup Wizard CD-ROM with Drivers and User

Guide

• Quick Installation guide

• Registration Card

AConnect your PDA to your PC.

Make sure you have the

Microsoft ActiveSync software

installed on your PC. Refer to

your PDA’s documentation for

information on Microsoft

ActiveSync software.

BInsert the Setup CD-ROM into

your PC’s CD-ROM drive and

the screen in Figure B should

appear automatically.

If this screen does not appear

automatically, you can access

it by clicking the Start button

and choosing Run. In the drop-

down box, type d:\setup.exe (if

“d” is the letter of your CD-ROM

drive) and click OK.

CClick the Install button to start

the Setup Wizard.

DThe following screen displays

the License Agreement. Read

the agreement, then if you

agree, click Next to continue..

EWhen asked if you want to

install the Linksys Wireless-G

CompactFlash Card using the

default application install

directory, (Fig. E) click Yes to

continue.

FWhen asked to check your

mobile device screen to see if

additional steps are necessary

to complete this installation,

click OK.

GThe Congratulations screen will

appear when the installation is

complete. Click Exit to exit the

Setup Wizard.

2.4

802.11g

Setting up the PDA

AThe Installation has com-

pleted successfully screen will

appear on your PDA. Click OK,

BDisconnect the PDA from your

PC.

CInsert the Wireless-G Compact-

Flash Card into your PDA in the

direction shown in Figure C.

DPocket PC 2002 users will see

the screen in Figure D. Click

OK.

EThe Wireless Network Monitor

icon will appear on the desk-

top of your PDA.

2Installing the CompactFlash Card

IMPORTANT: Do not insert the Card into the PDA

until instructed to do so or the setup will not work.

BOn the Settings screen, if your

wireless network does not have

Wireless Security-WEP, click OK,

then go to step D.

If your wireless network has

Wireless Security-WEP, click

Authentication.

CWhen the screen appears,

Check the box for Data

encryption (WEP Enabled)

and uncheck the box for The

Key is provided for me auto-

matically. Enter the Network

key in the field and click OK.

DThe next screen will show that

the PDA is connected to the

wireless network. Click OK.

The installation of the Wireless-G

CompactFlash Card is complete.

DIf your wireless network has

Wireless Security-WEP, check

Wireless Security (WEP). Then

select Use Hexadecimal (0-9,

A-F) and enter the WEP key in a

Key field. Click Next.

EPower Management is a

power saving mode. To enable

power management, select

On. Click Finish, then you will

return to the Select Profile

screen. Click OK.

The installation of the Wireless-G

CompactFlash Card is complete.

Quick Installation

Model No.

3Connecting to a Wireless Network

ATo connect to a wireless net-

work, click the Wireless Net-

work Monitor icon at the

bottom of your desktop.

BThe Status screen will appear.

Click Configure Wireless Net-

works near the bottom of the

screen.

Continue to the section for the

Pocket PC operating system that

your PDA uses.

Pocket PC 2002

ASelect the default profile and-

click Edit.

BSelect Access Point from the

drop-down menu for Wireless

Mode. Click Next.

CEnter the name of your wireless

network in the SSID field. You

can click Scan to search for

an existing wireless network

name. Click Next.

For additional information or troubleshooting help, refer to the User Guide on the Setup CD-ROM. You

can also call or email for further support.

24-hour Technical Support 800-326-7114 (toll-free from US or Canada)

E-mail Support [email protected]

Website http://www.linksys.com or

http://support.linksys.com

RMA (Return Merchandise Authorization) http://www.linksys.com/support

FTP Site ftp://ftp.linksys.com

Sales Information 800-546-5797 (800-LINKSYS)

Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S.

wcf54g-qi-40816NC BW

Pocket PC 2003

ASelect your wireless network

from the list and click

Connect.
