EtherFast®10/100 USB

Network Adapter

ow you can connect to any 10, 100, or

10/100Mbps hub or switch without hav-

ing to open your PC. The EtherFast

10/100 USB Network Adapter from Linksys

allows you to instantly connect to a network

from a USB-enabled desktop or notebook PC

with Windows 98. The Plug-and-Play compati-

ble device attaches to any USB-enabled PC or

hub via a USB Type B receptacle. Connect a

standard Category 5 network cable into the

other end the EtherFast 10/100 USB Network

Adapter, install the included network software

drivers, and go. You'll be networked in no time.

The EtherFast 10/100 USB Network Adapter is

bus-powered -- it draws power from the host PC

and requires no external power cords. The

10/100 USB Network Adapter features an maxi-

mum of 12Mbps throughput (the maximum

throughput supported by USB), easy-to-read

LEDs, compact design, a 1-year limited warran-

ty, and free world-class technical support

• One B-type (Female) USB Port For a Standard

USB Cable

• One RJ-45 10/100BaseTX Port For a

Category 3 or 5 Cable

• 32K Memory Buffer

• Powered by the Host PC -- No External Power

Supply Needed

• Compact Design-Perfect for Use with

Notebook PCs

• RJ-45 Network Port Connects to Any 10, 100,

or 10/100Mbps Hub or switch

• Easy-to-Read Link and Activity LED

Indicators

• Plug-and-Play Compatible with Windows 98

for Easy Installation

• Free Technical Support

• 1-Year Limited Warranty

 Connect to Any Ethernet or Fast Ethernet

Network from Your Computers USB Port

 Perfect Solution for Desktop or Notebook

Computers

Windows 98 Plug-and-Play Compatible

Free Technical Support and Software

Upgrades

Free Technical Support

1-Year Limited Warranty

EEtthheerrFFaasstt1100//110000UUSSBBNNeettwwoorrkkAAddaapptteerr

((UUSSBB110000TTXX))

Use your PC’s USB Port to Connect to

Any 10BaseT or 10/100 Network

NetworkWithUSB!

Features

Benefits

Specifications

Standards IEEE 802.3, IEEE 802.3u, USB Spec. v 1.0

Protocol CSMA/CD

Ports 1 10BaseT/100BaseTX RJ-45 Port

1 USB Type B (female) Port

Transfer Rate 10Mbps or 100Mbps Auto-Sensing

Memory Buffer 32KB

Cabling Network: UTP/STP Category 5

100 meters (328 feet) Maximum

USB: Standard Shielded USB Cable

5 meters (16.4 feet) Maximum

Topology Star

LEDs Link (10Mbps or 100Mbps), Activity

Environmental

Dimensions 3.2” x 2.1” x 1.0”

Unit Weight 2.0 oz.

Power Input 5V Bus Power from USB Host Controller

or Hub

Certifications FCC Class B

CE Mark, Commercial

UL and CSA Listed

Operating Temp. 32ºF to 104ºF (0ºC to 40ºC)

Storage Temp. -4ºF to 158ºF (-20ºC to 70ºC)

Operating Hum. 10% to 85% Non-Condensing

Storage Hum. 5% to 90% Non-Condensing

Package Contents

USB Network Adapter

• One EtherFast 10/100 USB

Network Adapter

• One USB Cable

• One Driver Diskette

• One User Guide and

Registration Card

(Model No.: USB100TX)

Sales (800) 546-5797

Support (800) 326-7114

Fax (949) 261-8868

Email [email protected]

Web www.linksys.com
