LINK-MI LM-TV06-4K2K Manuel utilisateur
LM-TV06-4K2K
4K video wall controller
User
Manual
Catalog
1.Installation Instructions ……………1
2.Product Brief ……………………………2
3.Controller Installed …………………3
4.Remote Control Settings ………………6
5.Pressing Setting ………………………7
6.Specifications……………………………7
1
1th Installation Instructions
For the safety of you and your equipment, please be sure to read the safety
instructions carefully before using this device.
If you use in the event of doubt, please read this manual first. Detailed
description of the equipment operating in the body. If you still have questions, please
contact us, we will give you a satisfactory answer as soon as possible.
This specification is subject to version changes, without prior notice, please
understand.
Equipment installation, please note the following:
1. Power supply:
This device uses 100-240V AC input voltage ,In order for the device to work properly.
2. Power:
Equipment is required when moving or other jobs that require power, to turn off all the
power, pull the plug, in order to ensure the safety of you and your equipment.
3. Cable:
Not in power cable, signal lines, communication lines, such as cable, cables were
crushed or squeeze should be avoided to prevent danger of leakage or short circuit.
4. Signal cable connections:
Plug from the device, pull the signal line, the device need to power down, so as not to
damage the device. Charge plug damage is not covered under warranty.
5. Openings:
Outer surface of the device may be cooling holes, do not plug the hole, so as to avoid
heat accumulation and damage equipment or cause a fire risk.
6. Equipment installation:
Reasonable placement of equipment, such as loading standard rack, chassis, Cabinet, or
placed on a solid, flat work surface to prevent equipment fell.
7. Environment:
Equipment working environment, pay attention to dust, moisture, especially to prevent
liquids from soaking and splashed into the device.
8. Maintenance:
All repair work should be done by professional maintenance personnel without training
do not attempt to repair the device yourself. To prevent the risk of electric shock, do
not open the housing.
2
2th Product Brief
1. Overview :
LM-TV-4K2K Series is a high performance UHD Ultra HD 4K Image splicer, user-
customizable 2 To 12 Image stitching. Its main function is to M × N splicing display
unit displays a 3840×2160@60HZ of super high definition image. Products using advanced
image processing technology, the input signal can support HDMI2.0, that is 3840×
2160@60HZ, will not appear, even when playing fast animation delay, dropped frames are
like.
Support 1 HDMI2.0、 1 mobile signal、 1 DP1.2 Enter , Maximum resolution support
3840×2160@60HZ; HDMI Signal outputs, each output is a fixed rate 1920×1080@60HZ.
Other more detailed feature descriptions, please refer to the product
specifications.
4K and 1080P difference
The same size, higher sharpness
3
3.Panel Description
3th Controller Installed
1 .Open the package
Check host attachments. Include the host, the power cord, remote control, warranty card
and instructions.
2.Installation machine
2.1 . TV sets:
4
LCD TV or other display device setting input signal to HDMI State. Display unit has
multiple HDMI input ports, make sure that connection splicer HDMI lines corresponding
to the port;
2.2 .Stitching device connected to the TV:
When in place of picture mosaic, by HDMI Line equipment Output With LCD TV HDMI
Input connection, please note that TV must correspond with the splicing processor is
connected to the port. Output pictures for the following equipment:
Each of the LCD unit with the splicer is connected to the output port, location boxes
indicate LCD, digital output port, each mosaic mode in the following illustration each
LCD is connected with the corresponding port:
5
2.3 . Input signal connections
Product support 1 HDMI 、 1 mobile signal 、 1 DP Input, all input embedded audio
input or binding, users can access all the signals on demand, or access part of the
signal, interface functions and interface pictures are as follows:
mobile signal : Support HDMI1.4 Signal input, maximum support 3840×2160@30HZ HDMI
Signal input can be backwards compatible; through a mobile signal Go HDMI Lines can
also be compatible with mobile signal Output image output device, such as mobile signal
Enabled mobile phones or Tablet;
HDMI : Support HDMI2.0 Signal input, enter the maximum resolution supported 3840×
2160@60HZ;
DP Support maximum resolution support 3840×2160@60HZ;
2.4 . Audio connection
A-OUT Splicer audio output, can purchase an ordinary computer audio and A-OUT
Connections;
2.5 . Power on boot
6
After the above cable connect the power, the power indicator light, equipment in
good working condition;
System topology
4th Remote Control Settings
Stitching device and the display unit are attached, connected to power the red
power light is on, the device works, by remote control or key makes it easy to set up
your equipment, or the chassis configuration.
1. set up the remote control:
1.1 . Call menu
Press the remote control MENU Key, the following pop-up menu;
1.2 . Select the submenu
Continuous press MENU Keys moves the cursor stays in the different submenu, submenu
that stays as red text, press OK Key to select the menu entries, it becomes green text
to the selected menu function sets the corresponding submenu.
1.3 . Change the product settings
After menu changes to green, with remote control Or keys to change product
parameters or properties, press the return key to save the setting and exit the
menu.
2. signal source selection
LM-TV12-4K2K Signal source menu option: Auto-select, D0: DP 、 D1:HDMI 、 D2:mobile
signal
2.1 . Automatic selection:
Through the remote control handle menu "signal source" set to "automatic
selection", in the case of equipment had no access to other sources, you can
7
automatically insert the signal source and the signal source identification
automatically display splicing unit.
2.2. Manual selection:
Can be used for a single source or multiple sources at the same time connected to
the device, by manually switching the signal source on the remote control display
screen displays an image.
3. split mode
Through the submenu you can choose many kinds of stitching patterns, such as 1x2、
1x3、1x4、2x2 Mode, typically split mode before leaving the factory is set up, no need
to debug.
4. Board, card ID -Flip
By selecting "card ID "Number, in the menu" flip "setting the ID Whether an image
needs to be rotated, 180 Degrees.
5. the language
Menu can be selected by remote control: English , Simplified Chinese, traditional
Chinese, three different menu display language.
5th Pressing Setting
Through the chassis control functions with the remote control button function
control, this section explains the function of each button, as follows:
Menu Key :The following pop-up menu, repeatedly press strike Menu Button makes the
cursor stays in the different submenus;
Select/ :The Red menu parameters are modified;
Save/exit: To save the modified parameters and exit the menu;
HDMI: Key to change to the device HDMI Input signal source port;
mobile signal: Key to change to device mobile signal port input signal source;
DP: Key to change to device DP ports input signal source;
8
6th Specifications
Name
Spec
HDMI input
Interface
HDMI A type（HDMI2.0 support HDCP2.2）
Resolution
Up to 3840×2160@60Hz
mobile signal input
Interface
HDMI A type（HDMI1.4 support HDCP2.0 and mobile signal）
Resolution
Up to 3840×2160@30Hz
DP input
Interface
DP1.2
Resolution
Up to 3840×2160@60Hz
Audio output
Fit for output video
HDMI output
1920×1080@60Hz
Input Port
HDMI×1,mobile signal×1,DP×1
Output Port
HDMI× 6
Controller
Remote ,button
Power supply
Input：AC 100-240V
Operating Temperature
0℃~60℃
Storage Temperature
-20℃~70℃
Humidity
＜75%
Dimension
441mm(L)x239mm(W)x44mm(H)
