DEMO MANUAL DC2166A

Description

LTM4639

Low VIN 20A DC/DC

µModule Step-Down Regulator

Demonstration circuit 2166A features the LT M

4639EY,

a20A high efficiency, switch mode step-down power

µModule

regulator. The input voltage range is from

2.375V to 7V. The output voltage range is 0.6V to 5.5V.

Derating is necessary for certain VIN, VOUT, frequency and

thermalconditions. The DC2166AofferstheTRACK/SSpin

allowing the user to program output tracking or soft-start

period.Theboardoperatesincontinuousconductionmode

in heavy load conditions. For high efficiency at low load

currents, the MODE jumper (JP3) selects pulse-skipping

mode for noise sensitive applications or Burst Mode

operation in less noise sensitive applications. There is an L, LT, LTC, LTM, µModule, Burst Mode, Linear Technology and the Linear logo are registered

trademarks of Linear Technology Corporation. All other trademarks are the property of their

respective owners.

BoarD photo

on board boost circuit using LT1935 to provide control

power to LTM4639 when VIN is less than 4.5V. LTM4639

has on board diode connected PNP transistors to monitor

its internal temperature. A temperature sensor LTC2997

converts the internal temperature to an analog voltage out-

put. The LTM4639 data sheet must be read in conjunction

with this demo manual prior to working on or modifying

demo circuit DC2166A.

Design files for this circuit board are available at

http://www.linear.com/demo/DC2166A

Downloaded from Arrow.com.

dc2166af

DEMO MANUAL DC2166A

Quick start proceDure

Demonstration circuit DC2166A is an easy way to evalu-

ate the performance of the LTM4639EY. Please refer to

Figure 1 for proper measurement equipment setup and

follow the procedure below:

1. Place jumpers in the following positions for a typical

application:

RUN TRACK/SS MODE

VOUT

SELECT CPWR SELECT

ON SOFT-START CCM 1.0V BOOST

2. With power off, connect the input power supply, load

and meters as shown in Figure 1. Preset the load to 0A

and VIN supply to 3.3V.

3. Turn on the power supply at the input. The output volt-

age should be 1.0V ± 1.5% (0.985V to 1.015V).

4. Vary the input voltage from 2.375V to 7V and adjust

the load current from 0A to 20A. Observe the output

voltage regulation, ripple voltage, efficiency, and other

parameters.

performance summary

PARAMETER CONDITIONS/NOTES VALUE

Input Voltage Range 2.375V to 7V

Output Voltages 1.0V, 1.2V, 1.5V, 1.8V ± 1.5%

Maximum Continuous Output Current Derating is necessary for certain operating conditions.

See data sheet for details.

20ADC

Operating Frequency 500kHz

Efficiency VIN = 3.3V, IOUT = 20A 83.2% (VOUT1 = 1.0V) (Figure 2)

85.3% (VOUT1 = 1.2V) (Figure 2)

87.7% (VOUT1 = 1.5V) (Figure 2)

89.1% (VOUT1 = 1.8V) (Figure 2)

Load Transient VIN = 3.3V, VOUT = 1.0V, ISTEP = 0A to 10A 156mV (Figure 4)

5. (Optional) For optional load transient test, apply an

adjustable pulse signal between IOSTEP_CLK and GND

test points. The pulse amplitude sets the load step cur-

rent amplitude. Keep the pulse width short (<1ms) and

pulse duty cycle low (<5%) to limit the thermal stress

on the load transient circuit.

6. (Optional) LTM4639 can be synchronized to an external

clock signal. Place the JP3 jumper on EXTCLK and apply

a clock signal (0V to 5V, square wave) on the CLKIN

test point.

7. (Optional) The outputs of LTM4639 can track another

supplybysettingJP1to EXT. TRACK. If tracking external

voltage is selected, the corresponding test point TRACK

need to be connected to a valid voltage signal.

Downloaded from Arrow.com.Downloaded from Arrow.com.

dc2166af

DEMO MANUAL DC2166A

Quick start proceDure

–

LOAD

–

Figure 1. Measurement Setup of DC2166A

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

dc2166af

DEMO MANUAL DC2166A

Quick start proceDure

60.0

65.0

70.0

75.0

80.0

90.0

85.0

95.0

100.0

0.0 5.0 10.0 15.0 20.0

EFFICIENCY (%)

LOAD CURRENT (A)

VOUT = 1.8V

VOUT = 1.5V

VOUT = 1.2V

VOUT = 1V

60.0

65.0

70.0

75.0

80.0

85.0

90.0

95.0

0.0 5.0 10.0 15.0 20.0

EFFICIENCY (%)

LOAD CURRENT (A)

VOUT = 1.8V

VOUT = 1.5V

VOUT = 1.2V

VOUT = 1V

Figure 2. Measured Efficiency at VIN = 3.3V, fSW = 500kHz, CCM

Figure 3. Measured Efficiency at VIN = 5.0V, fSW = 500kHz, CCM

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

dc2166af

DEMO MANUAL DC2166A

Quick start proceDure

VOUT: 100mV/DIV

IOUT_STEP: 13.3A/DIV

Figure 4. Measured Load Transient

VIN = 3.3V, VOUT1 = 1.0V, ISTEP = 0A to 10A

Figure 5. Thermal Image of LTM4639

VIN = 3.3V, VOUT = 1.8V, ILOAD = 20A

Ambient Temperature = 23.3°C, No Forced Air Flow

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

dc2166af

DEMO MANUAL DC2166A

parts List

ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER

Required Circuit Components

1 2 C3, C5 CAP, 1210, 22µF, 10%, 16V, X5R MURATA GRM32ER61E226KE20L

2 1 C6 CAP, 150µF, 35V, ELEC SUN ELEC 35CE150AX

3 1 C9 CAP, 0603, 0.1µF, 10%, 50V, X7R TDK C1608X7R1H104K

4 1 C10 CAP, 0603, 180pF, 10%, 10V, X7R AVX, 0603ZC181KAT2A

5 2 C11, C13 CAP, 1210, 100µF, 20%, 6.3V, X5R TDK C3225X5R0J107M

6 1 C16 CAP, 7343, 470µF, 20%, 2.5V POSCAP PANASONIC 2R5TPE470M9

7 1 C18 CAP, 0603, 1.5nF, 5%, 25V, X7R AVX 06033C152JAT2A

8 1 R13 RES, 0603, 60.4kΩ, 1%, 1/10W VISHAY CRCW060360K4FKEA

9 1 R12 RES, 0603, 90.9kΩ, 1%, 1/10W VISHAY CRCW060390K9FKEA

10 1 R9 RES, 0603, 124kΩ, 1%, 1/10W VISHAY CRCW0603124K0FKEA

11 1 R14 RES, 0603, 40.2kΩ, 1%, 1/10W VISHAY CRCW060340K2FKEA

12 1 R15 RES, 0603, 30.1kΩ, 1%, 1/10W VISHAY CRCW060330K1FKEA

13 1 R20 RES. 0603, 100kΩ, 5%, 1/10W VISHAY CRCW0603100KJNEA

14 1 U1 IC, LTM4639EY LINEAR TECH LTM4639EY#PBF

Additional Demo Board Circuit Components

1 3 C1, C2, C8 CAP, 0603, 1µF, 20%, 10V, X5R TDK, C1608X5R1A105M

2 0 C4, C12, C22, C23 CAP, 1210 OPTION OPTION

3 0 C7 CAP, 0805 OPTION OPTION

4 0 C14 CAP, 7343 OPTION OPTION

5 0 C17, C19, C20, C21, C26 CAP, 0603 OPTION OPTION

6 1 C27 CAP, 0805, 4.7µF, 20%, 10V, X7R TDK C2012X7R1A475M

7 1 C28 CAP, 0805, 22µF, 10%, 16V, X5R TDK C2012X5R1C226K

81 C29 CAP, 0603, 470pF, 10%, 10V, X7R AVX, 0603ZC471KAT2A

9 1 D1 DIODE, SCHOTTKY 30V ON SEMI NSR0230P2T5G

10 1 L1 IND, 2.2µH, 2012 TAIYO YUDEN CBC2012T2R2M

11 1 Q1 XSTR, MOSFET, N-CHANNEL 30V VISHAY SUD50N04-8M8P-4GE3

12 2 R1, R23 RES, 0603, 10kΩ, 5%, 1/10W VISHAY CRCW060310K0JNEA

13 1 R2 RES, 2512, 0.015Ω, 1%, 1W VISHAY WSL2512R0150FEA

14 1 R3 RES, 0603, 60.4kΩ, 1%, 1/10W VISHAY CRCW060360K4FKEA

15 1 R4 RES, 0603, 90.9kΩ, 1%, 1/10W VISHAY CRCW060390K9FKEA

16 0 R5, R6, R8, R11, R22 RES, 0603 OPTION OPTION

17 4 R7, R16, R17, R21 RES, 0603, 0Ω JUMPER VISHAY CRCW06030000Z0ED

18 1 R10 RES. 0603, 20kΩ, 5%, 1/10W VISHAY CRCW060320K0JNEA

19 2 R18, R19 RES, 0603, 10Ω, 5%, 1/10W VISHAY CRCW060310R0JNEA

20 1 R24 RES, 0603, 29.4kΩ, 1% 1/10W VISHAY CRCW060329K4FKEA

21 1 U2 IC, LT1935AES5 LINEAR TECH. LT1935ES5#PBF

22 1 U3 IC, LTC2997IDCB LINEAR TECH., LTC2997IDCB#PBF

Hardware

1 12 E1-E12 TESTPOINT,TURRET,. 094" MILL-MAX 2501-2-00-80-00-00-07-0

2 2 JP1, JP2 HEADER, 1 ×3 , 2mm SULINS, NRPN031PAEN-RC

3 2 JP3, JP4 HEADER, 2 ×4, DOUBLE ROW, 2mm SULINS, NRPN042PAEN-RC

4 2 JP5 HEADER, 2 ×3, DOUBLE ROW, 2mm SULINS, NRPN032PAEN-RC

5 4 J1, J2, J5, J6 JACK, BANANA KEYSTONE 575-4

6 2 J3,J4 CONN., VERT. PC-MNT, BNC 50Ω CONNEX 112404

7 5 XJP1, XJP2, XJP3, XJP4, XJP5 SHUNT SAMTEC 2SN-BK-G

84 MH1, MH2, MH3, MH4 STANDOFF, SNAP ON KEYSTONE_8834

9 2 STENCILS TOP AND BOTTOM STENCIL DC2166A
