DEMO MANUAL DC1632A

DESCRIPTION

LTC3839EUH

Fast Transient

Step-Down DC/DC Converter

Demonstration circuit 1632A is a single output 1.5V/40A

dual phase synchronous buck converter operating with

a switching frequency of 300kHz over an input voltage

range of 4.5V to 14V. The controlled on-time valley current

mode architecture of the LTC3839 allows for a fast load

step response (see Figure 4). The load step response can

be tested with the on-board load step circuit and a bench

pulse generator.

Other features of the board include remote sensing, sel-

ectable light load operating modes of forced continuous

mode (FCM) and discontinuous mode (DCM), a PLLIN

pin for synchronizing to an external clock, a CLKOUT

pin, an EXTVCC pin to reduce losses in the controller, and L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Linear

Technology Corporation. All other trademarks are the property of their respective owners.

PERFORMANCE SUMMARY

RUN and TRACK/SS pins. Up to 12-phase operation can

be achieved by daisy-chaining the CLKOUT and PLLIN

signals of multiple boards and programming the relative

phase with the PHASMD jumper.

The demo board uses a high density, two sided drop-in

layout. The entire converter, excluding the bulk output and

input capacitors, fits within a compact 1.6˝ ×1.2˝ area

on the board. The package style for the LTC3839EUH is a

32-lead 5mm ×5mm QFN with an exposed ground pad.

Design files for this circuit board are available at

http://www.linear.com/demo

(TA= 25°C)

PARAMETER CONDITIONS VALUE

Minimum Input Voltage 4.5V

Maximum Input Voltage 14V

Output Voltage VOUT I

OUT = 0A to 40A, VIN = 4.5V to 14V 1.5V ± 2%

VOUT Maximum Output Current, IOUT VIN = 4.5V to 14V, VOUT = 1.5V 40A

Nominal Switching Frequency 300kHz

Efficiency (see Figures 2 and 3) VOUT = 1.5V, IOUT = 40A, VIN = 12V 90.7% Typical

Downloaded from Arrow.com.

dc1632af

DEMO MANUAL DC1632A

QUICK START PROCEDURE

Figure 1. Proper Measurement Equipment Setup

Demonstration circuit 1632A is easy to set up to evalu-

ate the performance of the LTC3839EUH. Please refer to

Figure 1 for proper measurement equipment setup and

follow the procedure below.

1) With power off, connect the input supply, load and me-

ters as shown in Figure 1. Preset the load to 0A and VIN

supply to 0V. Place jumpers in the following positions:

JP1 RUN ON

JP3 MODE FCM

2) Adjust the input voltage to be between 4.5V and 14V.

VOUT should be 1.5V ±2%.

3) Next, apply 40A load and re-check VOUT.

4) Once the DC regulation is confirmed, observe the output

voltage ripple, load step response, efficiency and other

parameters.

Note 1. Use the BNC connector labeled VOUT to measure

the output voltage ripple.

Note 2. Do not apply the load from the VO_SNS+ pin to

the VO_SNS– pin. This may damage the converter. These

pins are only intended to monitor the voltage across the

bulk output capacitors at COUT1-4.

Load Step Testing (Optional)

Demonstration circuit 1632A provides a simple load step

circuit consisting of a MOSFET and sense resistor for each

rail. To apply a load step, follow the steps below.

1) Pre-set the amplitude of a pulse generator to 0.0V and

the duty cycle to 5% or less.

2) Connect the scope to the VOUT BNC connectors for

the rail under test with a coax cable. To monitor the

load step current, connect the scope probe across the

ISTEP± pins.

3) Connect the output of the pulse generator to the PULSE

GEN pin and connect the return to the GND pin.

4) With the converter running, slowly increase the ampli-

tude of the pulse generator output to provide the desired

load step pulse height. The scaling for the LOAD STEP

signal is 5mV/Amp.

VIN

SUPPLY IOUT

LIN

VOUT*

VIN

* MONITOR THE VOLTAGE ACROSS COUT5 FOR

ACCURATE EFFICIENCY MEASUREMENTS.

VOUT

LOAD

–

Downloaded from Arrow.com.Downloaded from Arrow.com.

dc1632af

DEMO MANUAL DC1632A

QUICK START PROCEDURE

Figure 2. Efficiency Curves for the DC1632A in FCM

LTC3839 1.5V/40A Converter FCM, fSW = 300kHz

0 5 10 15 20 25 30 35 40 45

EFFICIENCY (%)

LOAD CURRENT (A)

Qtop = Inﬁneon BSC050NE2LS

Qbottom = Inﬁneon BSC010NE2LS

L = Coiltronics FP1308R3-R44-R

(0.44μH, DCR = 0.18m Ω±20%)

RSENSE = 2mΩ

VIN = 12V

VIN = 5V

100

0.01 0.10 1.00 10.00 100.00

EFFICIENCY (%)

LOAD CURRENT (A)

FCM

DCM

Qtop = Inﬁneon BSC050NE2LS

Qbottom = Inﬁneon BSC010NE2LS

L = Coiltronics FP1308R3-R44-R

(0.44μH, DCR = 0.18m Ω±20%)

RSENSE = 2mΩ

Figure 3. Efficiency Curves for the DC1632A in FCM and DCM

LTC3839 1.5V/40A Converter FCM & DCM, VIN = 12V, fSW = 300kHz

Figure 4. Load Step Response of the DC1632A at VIN = 12V. COUT = 4×Sanyo

2R5TPE330M9 || 2×100μF X5R 6.3V 1206, L1, 2 = 0.44μH, fSW=300kHz

40A

20A

20μsec/DIV

LOAD STEP

10A/DIV

1.5V(AC)

50mV/DIV

106mVP-P

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

dc1632af

DEMO MANUAL DC1632A

PARTS LIST

ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER

Required Circuit Components

1 2 C13, C5 CAP, X5R 1μF 16V 10% 0603 AVX 0603YD105KAT2A

2 3 C2, C7, C12 CAP, X5R 0.1μF 25V 10% 0603 AVX 06033C104KAT2A

3 2 C3, C11 CAP, X7R 1000pF 16V 0603 AVX 0603YC102KAT2A

4 1 C4 CAP, X5R 4.7μF 16V 10% 0805 AVX 0805YD475KAT2A

5 1 C6 CAP, NPO 68pF 25V 10% 0603 AVX 06033A680KAT2A

6 1 C8 CAP, X7R 470pF 16V 5% 0603 AVX 0603YC471JAT2A

7 1 C9 CAP, X5R 0.01μF 25V 10% 0603 AVX 06033C103KAT2A

8 1 CIN1 CAP, 180μF 16V SANYO 16SVP180MX

9 2 CIN3, CIN4 CAP, X5R 22μF 16V 1210 MURATA GRM32ER61C226KE20L

10 4 COUT1, COUT2, COUT3, COUT4 CAP, 330μF 2.5V SIZE 7343 SANYO 2R5TPE330M9

11 2 COUT6, COUT5 CAP, X5R 100μF 6.3V 1206 MURATA GRM31CR60J107ME 39L

12 2 D1,D2 DIODE, SCHOTTKY SOD-323 CENTRAL SEMI CMDSH-4E TR

13 2 L1,L2 IND, 0.44μH COILTRONICS FP1308R3-R44-R

14 2 Q1,Q3 MOSFET, N CHANNEL POWERPAK SO-8 INFINEON BSC050NE2LS

15 2 Q2,Q4 MOSFET, N CHANNEL POWERPAK SO-8 INFINEON BSC010NE2LS

16 3 R11, R29, R33 RES, CHIP 10k 1% 0603 VISHAY CRCW060310K0FKEA

17 1 R15 RES, CHIP 22.1k 1% 0603 VISHAY CRCW060322K1FKEA

18 1 R13 RES, CHIP 137k 1% 0603 VISHAY CRCW0603137KFKEA

19 2 R14, R12 RES, CHIP 2.2 1% 0603 VISHAY CRCW06032R20FKEA

20 1 R22 RES, CHIP 15k 1% 0603 VISHAY CRCW060315K0FKEA

21 6 R3, R7, R23, R28, R35, R25 RES, CHIP 0 0603 VISHAY CRCW06030000Z0EA

22 1 R32 RES, CHIP 100k 1% 0603 VISHAY CRCW0603100KFKEA

23 6 R4, R5, R17, R19, R26, R27 RES, CHIP 10 1% 0603 VISHAY CRCW060310R0FKEA

24 2 RS1, RS2 RES, CHIP 0.002 1W 1% 2512 VISHAY WSL25122L000FEA

25 1 U1 IC LTC3839EUH QFN 5mm ×5mm LINEAR TECH. LTC3839EUH#PBF

Additional Circuit Components

1 0 CIN2 CAP, SVP-F8, OPT

2 0 CIN5, CIN6, CIN7, CIN8 CAP, 1210, OPT

3 0 C1, C10 CAP, 0603, OPT

4 0 COUT9-COUT12 CAP, SIZE 7343, OPT

5 0 Q5-Q8 POWERPAK SO-8, OPT

6 1 Q9 N-Channel MOSFET, TO-252 VISHAY SUD50N03-12P-E3

7 0 R1, R2, R6, R16, R18, R21,

R31, R8, R9, R10, R20, R24

RES, CHIP 0603, OPT

8 1 R33 RES, CHIP 10k 1% 0603 VISHAY CRCW060310K0FKEA

9 1 R34 RES, CHIP 0.005 1W 1% 2010 VISHAY WSL20105L000FEA

Hardware

1 16 E1-E16 TESTPOINT, TURRET .095" MILL-MAX 2501-2-00-80-00-00-07-0

2 1 JP1 2mm SINGLE ROW HEADER 3 PIN SAMTEC TMM-103-02-L-S

3 2 JP3, JP2 2mm SINGLE ROW HEADER 4 PIN SAMTEC TMM-104-02-L-S

4 6 E17-E22 JACK, BANANA KEYSTONE 575-4

5 1 J1 CONN, BNC, 5PINS CONNEX 112404

6 4 (STAND-OFF) STAND-OFF, NYLON 0.25" KEYSTONE 8831 (SNAP ON)
