DEMO MANUAL DC1228A

Description

LT3573

Isolated Monolithic

Flyback Converter

Demonstration circuit 1228A is an isolated flyback con-

verterfeaturingtheLT

3573.Thisdemocircuitisdesigned

for a 5.0V output from a 10V to 30V input. The maximum

output current is 1A when the input voltage is higher than

20V. No third winding or opto-isolator is required for

regulation. The part senses the isolated output voltage

directly from the primary-side flyback waveform.

The LT3573 operates with input supply voltages from 3V

to 40V, and can deliver an output power up to 7W with

no external power devices. The LT3573 utilizes bound-

ary mode operation to provide a small magnetic solution L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Linear

Technology Corporation. All other trademarks are the property of their respective owners.

performance summary

with improved load regulation. The LT3573 can be used

in industrial, automotive and medical applications where

an isolated output is required.

The LT3573 data sheet gives a complete description of

the part, operation and application information. The data

sheet must be read in conjunction with this quick start

guide for demonstration circuit 1228A.

Design files for this circuit board are available at

http://www.linear.com/demo/DC1228A

Specifications are at TA= 25°C

PARAMETER CONDITION MIN TYP MAX UNITS

Input Voltage Range 10 30 V

Output Voltage VOUT VIN = 10V to 30V 4.75 5 5.25 V

Maximum Output Current IOUT VIN = 10V to 20V

VIN = 20V to 30V 0.7

1.0 A

Switching Frequency VIN = 12V, IOUT = 0.7A

VIN = 24V, IOUT = 1A 169

238 kHz

kHz

Voltage Ripple VOUT VIN = 24V, IOUT = 1A 100 mV

Efficiency VIN = 24V, IOUT = 1A 84 %

dc1228af

DEMO MANUAL DC1228A

Quick start proceDure

Demonstration circuit 1228A is easy to set up to evalu-

ate the performance of the LT3573. Refer to Figure 1 for

proper measurement equipment setup and follow the

procedure below:

NOTE: When measuring the input or output voltage ripple,

care must be taken to avoid a long ground lead on the

oscilloscope probe. See Figure 2 for proper scope probe

technique.

1. With power off, connect the input power supply to VIN

and GND.

2. Turn on the power at the input.

NOTE: Make sure that the input voltage does not exceed

30V.

3. Check for the proper output voltages.

NOTE: If there is no output, temporarily disconnect the

load to make sure that the load current is not set too

high.

4. Once the proper output voltage is established, adjust

the load current within the operating range and observe

the output voltage regulation, ripple voltage, efficiency

and other parameters.

dc1228af

DEMO MANUAL DC1228A

Figure 2. Measuring Input or Output Ripple

Figure 1. Proper Measurement Equipment Setup

VIN OR VOUT GND

Quick start proceDure

dc1228af

DEMO MANUAL DC1228A

parts List

ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER

Required Circuit Components

1 1 C2 CAP., X7R, 4.7µF 50V, 1210 MURATA, GRM32ER71H475K

2 1 C4 CAP., X7R, 47µF 10V, 1210 MURATA, GRM32ER71A476K

3 1 C7 CAP., X7R, 0.1µF 16V, 0402 TDK, C1005X7R1C104MT

4 1 C8 CAP., NPO, 100pF 50V,0402 AVX, 04025A101JAT2A

5 2 C12, C9 CAP., X7R, 1µF 50V, 0805 MURATA, GRM21BR71H105K

6 1 C10 CAP., X7R, 0.22µF 25V, 0603 MURATE, GRM188R71E224K

7 1 C11 CAP., X7R, 4700pF 25V, 0402 AVX, 04023C472KAT2A

8 1 C13 CAP., NPO, 10pF 50V, 0402 AVX, 04025A100JAT2A

9 1 D1 DIODE, SCHOTTKY BARRIER RECTIFIER 3.0A DIODES INC., B340A-13-F

10 1 D2 DIODE, SWITCHING, SOD323 DIODES INC., 1N4148WS-7-F

11 1 D3 DIODE, SCHOTTKY MINI, SOD323 CENTRAL SEMI., CMDSH-3

12 1 R3 RES., CHIP 357k 1/16W 1%, 0402 VISHAY, CRCW0402357KFKED

13 1 R6 RES., CHIP 93.1k 1/16W 1%, 0402 VISHAY, CRCW040293K1FKED

14 1 R7 RES., CHIP 84.5k 1/16W 1%, 0402 VISHAY, CRCW040284K5FKED

15 1 R8 RES., CHIP 2k 1/10W 1%, 0805 VISHAY, CRCW08052K00FKEA

16 1 R9 RES., CHIP 20k 1/16W 1%, 0402 VISHAY, CRCW040220K0FKED

17 1 R10 RES., CHIP 10k 1/16W 1%, 0402 VISHAY, CRCW040210K0FKED

18 1 R11 RES., CHIP 6.04k 1/16W 1%, 0402 VISHAY, CRCW04026K04FKED

19 1 R15 RES., CHIP 12.4k 1/16W 1%, 0402 VISHAY, CRCW040212K4FKED

20 1 T1 XFMR, 750370047 WÜRTH, 750370047

21 1 U1 IC., LT3573EMSE, MSE16 LINEAR TECH., LT3573EMSE

Additional Demo Board Circuit Components

1 1 C1 CAP., ELECTROLYTIC, 22µF 50V, C-SANYO-CE-BS-6.3X6.0 SANYO, 50CE22BS

2 0 C5 CAP., 22µF 50V, C-SANYO-CE-BS-6.3X6.0 OPT SANYO, 50CE22BS

3 0 C14 CAP., 1206 OPT OPT

4 0 C19 CAP., X7R, 4.7µF 50V, 1210 OPT MURATA, GRM32ER71H475K

5 0 C20 CAP., X7R, 0.01µF 50V, 0603 OPT AVX, 06035C103KAT

6 0 FB1 BEAD, 1206 OPT TAIYO YUDEN, FB MJ3216HS800

7 0 L1 IND, PWR, L-CDRH4D22/HP OPT SUMIDA, CDRH4D22HPNP-100MC

8 0 R2 RES., 0603 OPT OPT

9 1 R4 RES., CHIP 499Ω 1/10W 1%, 0805 VISHAY, CRCW0805499RFKEA

Hardware: For Demo Board Only

1 5 E1, E2, E3, E5, E6 TP, TURRET, 0.094" MILL-MAX, 2501-2-00-80-00-00-07-0
