Lilin UFG1122 Mode d’emploi

4K Ultra HD IP Camera

Start Guide

Ultra Series IP Camera Start Guide Page2

Summary

LILIN 4K Ultra HD IP cameras are one of our Ultra family that use the latest compression technologies, which

allow Triple Streaming of H.264 and JPEG in different resolutions. LILIN’s Triple Streaming technology

transmits digital video at various bit rates and frame rates to suit both high and low bandwidth network

environments.

The Ultra series cameras are equipped with progressive-scan, megapixel CMOS sensors that provide superior

video quality. LILIN’s digital signal processing (DSP) technologies support Wide Dynamic Range (WDR), 3D

noise reduction, Backlight Compensation (BLC), adjustable shutter speed, and privacy masking features.

The built-in intelligent video analytics engine enables audio and motion detection. Other useful features include

two-way audio, SD card recording, mobile device live access, email notification with JPEG snapshots, and

JPEG-to-FTP upload.

The Ultra series cameras, with their latest technologies, provide megapixel H.264 video, outstanding DSP

capacities, built-in video analytics, and built-in PoE support. All cameras in the Ultra family are ONVIF

compliant.

The powerful combination of LILIN Navigator software and IP cameras will maximize your system performance

and deliver an integrated system solution for your migration to IP videos.

Ultra Series IP Camera Start Guide Page3

Key Features

Capability of recording at 15 FPS

Supports dual encoding formats (H.264 and JPEG)

Triple Streaming technology, 3 concurrent streams available

Sense Up+ provides enhanced videos even in low light conditions

Day/night video quality scheduling

Audio and motion detection for notification via email or FTP

Supports 3D DNR, WDR, BLC, adjustable shutter speed, and privacy masking

Two-way audio (select models only)

Bit rate and frame rate on-the-fly adjustment

Supports Android, iPad, and iPhone mobile live monitoring

Supports dynamic DNS (DDNS) and network time protocol (NTP)

Supports PCM/G.711

Supports ONVIF protocol

Supports LILIN Navigator

Trademark Acknowledgments

Microsoft, Windows 2000, Windows XP, Windows Vista, Windows 7, ActiveX, and Internet Explorer

are registered trademarks of Microsoft Corporation in the U.S. and/or other countries.

Java and all Java-based trademarks and logos are trademarks or registered trademarks of Sun Microsystems,

Inc. in the United States and other countries. Flash, Macromedia, and Macromedia Flash Player are either

trademarks or registered trademarks of Adobe Systems Incorporated in the United States and/or other

countries.

Linux and DynDNS are registered trademarks of the respective holders.

Intel, Pentium, and Intel® Core™ 2 Duo are registered trademarks of Intel Corporation.

FFmpeg is a trademark of Fabrice Bellard, originator of the FFmpeg project.

QuickTime and the QuickTime logo are trademarks or registered trademarks of Apple Computer, Inc., used

under license there from.

Other names of companies and their products mentioned in this manual may be trademarks or registered

trademarks of their respective owners.

Other References

Ultra Series IP Camera Start Guide Page4

Mobile devices

For mobile surveillance, refer to the detail page of LILINViewer on Apple App Store or Google Play.

LILIN Universal ActiveX Control

Sample codes and documents are included in the product CD and can be downloaded from our company

website.

LILIN HTTP API

For non-ONVIF integration, see the LILIN HTTP API document. HTTP API is used in all LILIN IP cameras.

Caution

Do not drop or damage the equipment

Do not install the equipment near fire or heat sources

Keep the equipment from rain, moisture, smoke, or dust

Do not cover the opening of the cabinet with cloth and/or plastic or install the unit in poorly ventilated

places. Allow 10cm between this unit and its surroundings

Do not continue to operate the unit under abnormal conditions such as smoke, odor, or loss of signal

whilst power is turned on

Do not touch the power cord with wet hands

Do not damage the power cord or leave it under pressure

To avoid unnecessary magnetic interference, do not operate this unit near magnets, speaker systems,

etc.

All connection cables should be grounded properly

Ultra Series IP Camera Start Guide Page5

Chapter 1 System Overview

Chapter 1-1 System Requirements

LILIN’s 4K Ultra HD H.264 video compression technology provides high compression rate and superior video

quality. However, video performance highly depends on CPU power and network bandwidth for video

streaming. The following sections specify the system requirements for using a 4K Ultra HD H.264 IP camera.

Chapter 1-2 Software Requirements

Merit LILIN Universal ActiveX software components or QuickTime are required for a web browser to display

JPEG or H.264 4K Ultra HD video. When you first log in to our IP camera, you may see a prompt box:

Click Install and follow the onscreen instructions to install necessary components.

Ultra Series IP Camera Start Guide Page6

Chapter 2 Before Accessing IP Cameras

Before accessing the IP cameras, make sure that the camera’s RJ-45 network connector, audio cable, and

power cable are properly connected. To set the IP address, consult your network administrator. The default IP

address for each IP camera is 192.168.0.200. Users can use the default IP address to verify the camera’s

network connection.

Chapter 2-1 Configuring IP Addresses using the IPScan Utility

To configure the IP address of your cameras, download IPScan from our official website:

http://www.meritlilin.com/webe/html/download. Or, you can execute the IPScan installer from the installation CD

directly. To change the IP address, subnet mask, gateway, or HTTP port of your cameras, follow the steps

below:

Run the IPScan utility

Click Refresh. All available devices will be listed on the screen

Select the device item from the device list

To edit or modify IP address, subnet mask, gateway, or HTTP port, use the box

Click Apply for the changes to take effect

Click Refresh again to verify the changed settings

Chapter 2-2 Configuring IP Addresses through HTML Connection

To change an IP address on a webpage, type the default IP address (192.168.0.200) into the browser address

bar and follow the steps below:

Log in to the H.264 4K Ultra HD IP camera using the default username admin and default password

pass

Click Setup→Network to edit or modify IP address, subnet mask, gateway, or HTTP port

Click Submit for the changes to take effect.

Ultra Series IP Camera Start Guide Page7

Chapter 2-3 Web Browser Settings & Software Components Required

Make sure your Internet browser allows signed ActiveX plug-in to run on your PC. Set Download Signed

ActiveX plug-in controls to Prompt and enable Run ActiveX control and plug-in. You can set this in Internet

Explorer→Tools→Internet Options→Security→Custom Settings.

Once completed, you can access the IP camera’s live video by entering the default IP address into your web

browser. A security warning dialog box will appear. Click OK to download the ActiveX directly from the IP

camera.

Chapter 2-4 Login

You can log in to the camera as administrator or guest.

Default usernames and passwords are:

Administrator

Viewer

Username

admin

guest

Password

pass

guest

Then press Submit to log in.

Ultra Series IP Camera Start Guide Page8

Chapter 3 H.264 4K Ultra HD IP camera network features

When logged in as an administrator, two main features are available: 1) camera operations and 2)

configurations.

Chapter 3-1 IP Camera Operations

1. Profile switching menu—Switching from one profile to another

2. ActiveX display screen—Display RTSP H.264 or JPEG network video

3. Quick control panel—IP camera control panel

4. Setup menu—IP camera setup menu

The ActiveX control provides an ePTZ (electronic Pan, Tilt, and Zoom) feature. To perform an ePTZ operation,

hold and drag your mouse across the screen.

Ultra Series IP Camera Start Guide Page9

Move your cursor to the PIP window and drag inside it to perform ePan and eTilt actions. The scroll wheel can

be used to zoom in and zoom out.

Right-click to exit the ePTZ mode.

Chapter 3-2 IP Camera Main Controls

The quick control panel buttons are described below:

Chapter 3-2-1 Two-way Audio

For models supporting two-way audio, click the microphone icon to speak to a remote site. Click the icon

again to turn the microphone off.

Snapshot: Take a snapshot of the video

Recording: Start recording

Speaker on/off (for audio models only)

Microphone on/off (for audio model only)

Alarm output on/off (for alarm model only)

Ultra Series IP Camera Start Guide Page10

Click the speaker icon to monitor the audio of a remote site. Click the icon again to turn the speaker off.

Chapter 3-2-2 Record to a Local PC

To record to a local PC, right-click anywhere on the screen. Choose Setting to specify the recording paths and

recording sizes, and choose Recording On to start recording.

Note: Only audio-ready IP camera models support this feature.
