Lilin IPR7424 Manuel utilisateur

66-IPR7428CSE

MERIT LILIN ENT. CO., LTD

http://www.meritlilin.com

D/N 1080P HD Vari-Focal Infrared IP Camera

IPR7424/7428ESX & LR7424/7428EX

Instr uction Man ua l

IMPORTANT SAFEGUARDS

GRAPHIC SYMBOL EXPLANATION

The lightning flash with arrowhead symbol, within an equilateral

triangle, is intended to alert the user to the presence of

uninsulated "dangerous voltage" within the product's enclosure

that may be of sufficient magnitude to constitute a risk of electric

The exclamation point within an equilateral triangle is intended

to alert the user to the presence of important operating and

maintenance (servicing) instructions in the literature

shock to persons.

accompanying the unit.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION：

TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK)

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

CAUTION

RISK OF EXPLOSION IF BATTERY IS REPLACED

BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING

TO THE INSTRUCTIONS

CAUTION

Do not drop or strike this equipment.

Do not install the equipment near any naked flames or heat

sources.

Do not expose this unit to rain or excessive moisture, avoid

smoke and dust.

Do not cover cloth or to install this unit in poorly ventilated

places.

Do not continue to operate if there appears to be fault.

Do not touch the power connection with wet hands.

Do not damage the power cord or leave it under pressure.

Sensitive electronics inside are vulnerable to excessive shock.

Excessive heat could damage this unit.

Please the camera in an environmental housing for protection.

If the camera gets wet, unplug it and have it checked by

qualified service personnel.

This may lead to overheating.

If the unit ceases to function, contact qualified service

personnel for help.

Risk of short circuit or electric shock.

Risk of fire or shock circuit.

CONGRATULATIONS

Thank you for purchasing this 2 Megapixel HD Infrared

IP Camera. You now own one of the many fine network products

we manufactured. This product has been carefully inspected

under rigid quality control and should reach you in perfect

condition. With reasonable care, it will provide years of reliable

performance.

We recommend that you read this installation and operation

manual thoroughly before installing and operation your new

system.

Here you will find all the information you need to set up and use

the system. If any questions are not answered in the manual,

please contact your dealer.

Before proceeding, please read and observe all instructions and

warnings contained in this manual. Retain this manual with the

original bill of sale for future reference and, if necessary, warranty

service.

When unpacking your new camera, check for missing or damaged

items. If any item is missing, or if damage is evident,

I . Contact your dealer for

assistance.

D/N 1080P

DO NOT

NSTALL OR OPERATE THIS PRODUCT

IPR7424/7428ESX & LR7424/7428EX series is an 2 Megapixel

HD Infrared IP Camera, built-in H.264 AVC(Advanced

Video Coding) video compression. H.264 AVC video compression

engine supports high definition video quality, 1080P(1920x1080)

resolution, bandwidth efficiency with PPPoE and DDNS.

Also it provides higher bit rate of internet and diverse alarm

functions such as movement video detection e-mail or FTP.

Moreover, IPR7424/7428ESX & LR7424/7428EX series can do

remote surveillance with iPad, iPhone or Android cell phone. The

software R&D engineer can use HTTP protocol(HTTPAPI) or

ONVIF protocol to develop related software, and integrate them

with existing application software system.

IPR7424/7428ESX & LR7424/7428EX series is ideal solution for

remote video monitoring via internet.

D/N 1080P

Executive Summary

PART DESCRIPTION & DIMENSION

Unit: mm

SUN SHIELD

TOP COVER

BOTTOM CHASSIS

BRACKET

PAN ADJUSTMENT SCREW

TILT ADJUSTMENT SCREW

WINDOW

105

109

200

231

160

FIG. 1 FIG. 2

INSTALLATION

1. Take out the bracket from the box first. Put the power cable and network cable through

the bracket and then fix it to the wall (FIG.1 & FIG.2).　

2. Secondly, take out the camera body and open the top cover with screw driver (FIG.3).

FIG. 3

3. Put the power cable and network cable through the bracket rubble first and then go

through the bottom of camera body (FIG.4). Plug and fix the power cable to the

terminal and plug the network cable to RJ-45 connector of the IP camera (FIG.5).

FIG. 4 FIG. 5

L N

Note :

When using two-cord

power cable, please

connect them to

"Live" and "Neutral".

Live

Earth

Neutral

4. Next, use the provided M5.0x10 screws (silver-2pcs) to fix the camera body on the

bracket with screw driver (FIG.6).　

5. Loosen the pan and tilt adjustment screw on the bracket to turn the camera body to

the desired angle and then tighten the screw (FIG.7).　

F I G . 6

F I G . 7

6. First, adjust the lens on focus and zoom to form the optimal video image after that

tighten the screws (FIG.8).　

F O C U S o r Z O O M

Z O O M o r F O C U S

F I G . 8

F I G . 9

7. Replace the top cover and tighten the screws (FIG.9 & FIG.10).

F I G . 1 0

SYSTEM OVERVIEW

Top View Input/Output Device

Component Description

Alarm In/Out & Audio

In/Out Connector

SD Card Connector

RJ-45 Jack

Video Out Jack

Load Default Button

AUDIO OUT

AUDIO IN

GND

DIN

COM

+5V OUT

GND

1. 2Megapixel D/N 1080P HD

Vari-Focal Infrared IP Camera　

2. Instruction Manual

3. CD Software Pack

IPD552EX2.2/4.2 N/P

H.264 HD IP Cameras

INSTRUCTION MANUAL

PRODUCTION COMPONENTS

For connecting IPR7424/7428ESX & LR7424/7428EX series to the network, please

follow one of the system architectures:

(1). Use DC12V power adapter and network switch connected to a network.

SYSTEM ARCHITECTURES

4. L-type Hex Key Wrench

2 Megapixel D/N 1080P

HD Vari-Focal IR IP Camera

LAN LAN / Internet

Non-PoE Switch

AC24V or AC100~240V

D/N 1080P HD Vari-Focal Infrared IP Camera

IPR7424/7428ESX & IPR7424/7428ELSX

Instruction Manual
