Lightspeed 705iR Manuel utilisateur

705iR

Portable Audio System

Lightspeed Technologies, Inc.

11509 SW Herman Rd

Tualatin, OR 97062

800.732.8999

www.lightspeed-tek.com User Manual

AC-MN705

MK-MN0020908-1

DAILY REDMIKE USE

TURN ON THE REDMIKE

CHARGE BATTERIES

Speak in a natural voice. A normal conversational speech

level will provide an adequate signal. It is not necessary to

increase the intensity of your voice—the audio system provides

adequate amplication (approximately 5 – 10 dB) above

ambient room noises.

Avoid wearing jewelry that may rub or bump against

the microphone.

Turn the REDMIKE off during private conversations with a

student, parent, or other classroom visitor. You can also cover

the LED lens on top of the REDMIKE to block the signal.

Recharge batteries each night. When recharged nightly,

operating time (actual usage) for the transmitters will last

through a typical school day.

START OF THE DAY

Turn the

microphone

ON using the

ON/OFF switch

on the side of

the REDMIKE

and speak

normally. Set

the channel

switch to A.

Return the

REDMIKE to

the cradle

charger and

recharge the

REDMIKE at

the end of

the day.

Remove the REDMIKE

from the charger and

place it around your

neck. Adjust the neck

strap so the top of the

microphone rests just

below your collarbone.

705iR User Manual

705iR User Manual | i

705iR User Manual

CONGRATULATIONS!

Congratulations on your purchase of the 705iR Portable Infrared

Audio System! Please take a moment to review this manual, as it will help

you operate this easy-to-use system, and maximize your investment by

caring for and maintaining each component.

The 705iR is a lightweight, multi-purpose, portable audio system powered

by rechargeable batteries or AC power. It is designed to allow teachers to

speak in normal conversational tones and yet be heard clearly by every

student in the classroom.

The 705iR comes standard with the REDMIKE™ pendant-style

classroom microphone. The system may be used with two microphones

accommodating team teaching or student interaction. The second

microphone can be an additional REDMIKE, LT-71 or the HM-70 handheld

microphone.

705iR User Manual

ii | 705iR User Manual

705iR User Manual

1. Read Instructions—All safety and

operation instructions should be read

before this Lightspeed product is

operated.

2. Retain Instructions—The safety and

operating instructions should be kept

for future reference.

3. Heed Warnings—All warnings on

this Lightspeed product and in these

instructions should be followed.

4. Follow Instructions—All operating

and other instructions should

be followed.

5. Water and Moisture—This

Lightspeed product should not be

used near water.

6. Heat—This Lightspeed product should

be situated away from heat sources

such as radiators, etc.

7. Power Sources—This Lightspeed

product should be connected

to a power supply only of the

type described in the operation

instructions or as marked on this

Lightspeed product.

8. Power Cord Protection—Power

supply cords should be routed so that

they are not likely to be walked upon

or pinched by items placed upon or

against them.

9. Object and Liquid Entry—Care should

be taken so that objects do not fall

onto and liquids are not spilled into

the Lightspeed product.

10.Damage Requiring Service—This

Lightspeed product should be serviced

only by qualied service personnel.

The user should not attempt to service

this Lightspeed product.

11.Prevent Electric Shock—Do not use

this polarized plug with an extension

cord, receptacle or other outlet unless

the blades can be fully inserted to

prevent blade exposure.

SAFETY INSTRUCTIONS AND CERTIFICATIONS

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED PERSONNEL

RISK OF ELECTRIC SHOCK DO NOT OPEN

The lightning ash with arrowhead symbol

within an equilateral triangle is intended to

alert the user to the presence of uninsulated

“dangerous voltage” within the product’s

enclosure, that may be sufcient magnitude to

constitute a risk of electric shock.

The exclamation point within an equilateral

triangle is intended to alert the user to

the presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

CAUTION

705iR User Manual

705iR User Manual | iii

705iR User Manual

TABLE OF CONTENTS

705iR PORTABLE CLASSROOM AUDIO SYSTEM

Safety Instructions and Certications ........................................................................ii

SECTION 1: System Overview ................................................................................. 1

System Components ............................................................................................. 2

705iR Controls and Connections............................................................................ 3

REDMIKE Controls and Connections ...................................................................... 5

Cradle Charger Connections.................................................................................. 6

Optional LT-71 Controls and Connections .............................................................. 7

Optional HM-70 Controls and Connections ............................................................ 8

SECTION 2: Set-up................................................................................................... 9

Unpacking Your System .................................................................................................... 10

Positioning the 705iR ........................................................................................................ 11

SECTION 3: Initial Set-up, Charging and Optional Features ................................12

Initial Set-Up: REDMIKE ........................................................................................13

Initial Set-Up: Optional LT-71 ................................................................................14

Initial Set-Up: Optional HM-70 ..............................................................................15

Charging the 705iR...............................................................................................16

Charging the REDMIKE .........................................................................................17

Charging the Optional LT-71 .................................................................................18

Charging the Optional HM-70 ...............................................................................19

Output to Personal FM Transmitter .......................................................................20

SECTION 4: Troubleshooting, Daily Use and Warranty.........................................21

Troubleshooting Guide..........................................................................................22

Daily Use Instructions...........................................................................................23

Tips on Classroom Audio ......................................................................................24

Warranty Statement .............................................................................................24

System Specications ..........................................................................................25

Individual Components and Optional Accessories ................................................26

User Notes............................................................................................................27

705iR User Manual

1 | 705iR User Manual

SECTION 1

System Overview

705iR User Manual

705iR User Manual | 2

SYSTEM COMPONENTS

Keep ALL packaging materials. If the system must be returned, using the

original packing material will be quick, convenient and prevent damage.

705iR Receiver/Amplier,

Power Supply, and Carry Bag

REDMIKE Classroom

Microphone

Optional LT-71

LightMic and

Charger Cable

Optional HM-70 Handheld

Microphone and Charger Cable

Charging Cradle and Power Supply

LT- 71

Helpful Hint

705iR

CHA CHB TREBLE BASS AUX AUX

POWER IN OUT

705iR User Manual

3 | 705iR User Manual

705iR CONTROLS AND CONNECTIONS

Top Panel

1. CH A POWER: This knob turns on

the power for the 705iR and

controls the Channel A volume.

We recommend using Channel A if

you are using a single microphone

for your system. Turn the knob

clockwise to increase volume.

2. The LED light located above the

CH A POWER knob turns red

momentarily when the system

power is turned ON.

When a transmitter/microphone

set to Channel A is turned on, the

Channel A LED glows green to

indicate your transmitter’s signal is

being received by the amplier.

3. CH B VOLUME: This knob controls

the volume for Channel B. You must

rst turn the 705iR ON with the

CH A POWER knob, then turn the

CH B VOLUME knob clock-wise to

increase volume. Use Channel B

when using a second microphone.

4. The LED above CH B VOLUME

turns green to indicate a signal is

being received from a microphone/

transmitter set to Channel B.

5. TREBLE: This knob controls the

high-frequency sound of the 705iR.

Classroom Audio System.

6. BASS: This knob controls the low-

frequency sound of the 705iR.

7. AUX IN VOLUME: This knob

controls the volume level of an

external audio source that is

plugged into the AUX IN jack. An

example would be a computer, iPod,

or CD player.

8. AUX INPUT JACK: This 3.5 mm jack

is used to connect to an external

audio source.

9. AUX OUTPUT JACK: This 3.5 mm

jack provides a line-level audio

output that can be connected

to a personal FM system or tape

recorder.

10. AUX OUT VOLUME: This knob

controls the audio level going to

external equipment when plugged

into the AUX OUT jack. For example,

a personal FM transmitter or tape

recorder.

1 2 3 4 5 6 7 8 9 10

705iR User Manual

705iR User Manual | 4

705iR CONTROLS AND CONNECTIONS (cont’d)

Rear Panel

11. TRANSMITTER CHARGING

JACKS: This connector is used to

connect the charging cable to the

optional LightMic transmitter or

the optional HM-70 handheld

microphone for daily battery

recharging.

12. EXTERNAL IR SENSOR JACK:

This jack is provided for

connection of an additional

sensor (for larger or

odd-shaped rooms).

13. CHARGING LED: This LED glows

red when the 705iR battery is

charging and glows green when

fully charged.

14. DC POWER INPUT JACK:

This input connects to the 16 V

AC/DC adaptor that comes with

the 705iR. The adaptor is used to

either charge the internal battery

pack or power the 705iR with

AC power.

EXT SENSOR

www.Lightspeed-tek.com

800-732-8999

DC POWER

CHARGER OUT

705iR User Manual

5 | 705iR User Manual

1. POWER BUTTON: Press this button

to turn the REDMIKE ON, press

again to turn it OFF (mute).

2. POWER/LOW BATTERY INDICATOR:

A BLUE light indicates the REDMIKE

is on and fully charged. A RED light

indicates a charge is needed.

3. BATTERY COMPARTMENT: To

access the battery compartment,

slide the door downward.

The battery should only be

replaced by a Lightspeed AA

rechargeable sensing battery

(part # BA-NH2A27).

4. AUDIO/MICROPHONE INPUT: Use this

input to plug in a laptop, MP3 player

or other audio source to wirelessly

transmit audio to be played through

the system. Alternatively, an external

microphone can be connected.

5. CHANNEL SELECT SWITCH (CH A/B):

This switch allows for selection between

Channel A or B. If you are using a single

microphone, we recommend using

Channel A.

6. CHARGER CONTACTS (+ -): These

contacts interface with the charging

tabs in the BC-RMCC cradle charger

for daily charging. Simply place the

REDMIKE in the charger.

REDMIKE CONTROLS AND CONNECTIONS

705iR User Manual

705iR User Manual | 6

1. CHARGE INDICATORS: The light

glows RED while the REDMIKE is

charging. When fully charged, the

light will glow GREEN.

2. DC POWER PORT: Connect the DC

power cord here.

3. OPTIONAL CHARGING PORT: Plug the

charging cord for the optional LT-71 or

the HM-70 microphones here.

CRADLE CHARGER CONTROLS AND CONNECTIONS

Table des matières

Autres manuels Lightspeed Système stéréo

Lightspeed

Lightspeed 800 Series Manuel utilisateur

Lightspeed

Lightspeed 850iR Manuel utilisateur

Lightspeed

Lightspeed TOPCAT Manuel utilisateur

Lightspeed

Lightspeed Lightspeed Manuel utilisateur

Lightspeed

Lightspeed Mobile PA Manuel utilisateur

Lightspeed

Lightspeed TOPCAT Manuel utilisateur

Lightspeed

Lightspeed 955 Access Manuel utilisateur

Lightspeed

Lightspeed Access Link Manuel utilisateur

Lightspeed

Lightspeed 975 Manuel utilisateur

Lightspeed

Lightspeed Redcat media Manuel utilisateur

Lightspeed

Lightspeed flexcat Manuel utilisateur

Lightspeed

Lightspeed Cat 855 Manuel utilisateur

Lightspeed

Lightspeed 820iR Manuel utilisateur

Lightspeed

Lightspeed Redcat media Manuel utilisateur

Lightspeed

Lightspeed Redcat media Manuel utilisateur

Lightspeed

Lightspeed 975 Manuel utilisateur

Lightspeed

Lightspeed Activate System Manuel utilisateur

Lightspeed

Lightspeed TOPCAT Manuel utilisateur

Lightspeed

Lightspeed 820iR Manuel utilisateur

Lightspeed

Lightspeed Redcat media Manuel utilisateur

Lightspeed

Lightspeed CAT 860 Manuel utilisateur

Lightspeed

Lightspeed 955Access Manuel utilisateur

Lightspeed

Lightspeed 880iR Manuel utilisateur

Lightspeed

Lightspeed 800IX Manuel utilisateur

Manuels Système stéréo populaires d'autres marques

LG CM3330B Manuel utilisateur

Sony

Sony SS-CEP50 Manuel utilisateur

Cetacea Sound

Cetacea Sound CVS-II Manuel utilisateur

Aiwa

Aiwa XR-H66MD Manuel utilisateur

Denon

Denon UCD-250 Manuel utilisateur

Sanyo

Sanyo DC-MX41i Manuel utilisateur

Sharp

Sharp CD-ES600V Manuel utilisateur

Exibel

Exibel BDX600-UK Manuel utilisateur

Sanyo

Sanyo DC-F320 Manuel utilisateur

Philips

Philips FWM583X Manuel utilisateur

Sharp

Sharp CD-C462 Manuel utilisateur

Onkyo

Onkyo CBX 300 - CD / MP3 Clock Radio Manuel utilisateur

Aiwa

Aiwa XR-EM70 Manuel utilisateur

Cyrus

Cyrus Lyric Manuel utilisateur

Philips

Philips MCM159/98 Manuel utilisateur

Philips/Magnavox

Philips/Magnavox Magnavox FW 62C Manuel utilisateur

RCA

RCA RS3965SB Manuel utilisateur

Sharp

Sharp XL-UH240 Manuel utilisateur
