Lightolier Calculite ProSpec PA4A7050 Manuel utilisateur

Ceilin Cutout: 21 1/16" L x 6 3/16" W

Orderin Information: AR 70 Series A

Cat. No. Lamp Ceilin Trim Aperture Finish

PA4A705EBL (4) 50W AR 70 Overlap Black with White Flange

PA4A705EWL (4) 50W AR 70 Overlap White with White Flange

PA4A705EBTL (4) 50W AR 70 Trimles Black

PA4A705EWTL (4) 50W AR 70 Trimles White

PA4A705EBL = (Flanged) Black/White

PA4A705EWL = (Flanged) White

PA4A705EBTL = (Trimless) Black

PA4A705EWTL = (Trimless) White

Top View

Flanged Trimless

17"

34 1/8"

13"

31 3/8" L X 10" W

O.C. O.C.

O.C.

20" L X 5" W

Depth

83/4"

123 4

12, 13

Calculite®ProSpec®Linear Downlight PA4A7050

Page 1 o 2 4 Light AR 70 Series A

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Features

1. Aperture Frame: Provides clean support or lamp holders and overlapping

lange or trimless installation. Extruded aluminum. Rigidly welded together

on all corners.

2. Media Cartrid e: Allows convenient loading and removal o up to two

accessories (including lamp cover glass; lamp cover glass may be replaced

with solid glass accessory). Easily installed and removed or lamping with a

simple twisting motion. Constructed o die-cast aluminum.

3. Cross Blade Louver: Extruded aluminum. 1" deep, provides additional

shielding and can be easily removed.

4. Adjustable Rin : Allows 360° horizontal and 35° (on width) and 45° (on

length) vertical adjustment.

5. Tortiontite Sprin : For easy installation o aperture rame.

6. Housin : Die- ormed 22 ga. steel. Finish: Black.

7. Mountin Brackets: Adjustable vertically rom outside o housing.

8. Thermal Protector: Meets NEC, UL , and CSA requirements.

9. Lampholder: double contact bayonet base with 250°C #18 gauge Te lon®

leads.

10.Junction Box: 14 ga. steel, 4" x 3 1/2" x 2" box. Allows inspection rom

below.

11.Lamp and Accessory Support: .032" steel, lared or easy entry o Media

Cartridge.

12.Lens Retainin Rin : .093" spring steel rod. Holds accessories in place.

13.Lamp Guard: Heat-resistant clear glass. Lamp manu acturers requirement.

14.Transformer Housin : Die- ormed 18 ga. steel.

Electrical

Electronic Transformers: O er reliable operation and are accessible rom

below or servicing. 12V Secondary.

Dimmin Controls: Use only dimmers speci ically designed or use with

electronic trans ormers. Low Voltage ixtures may produce audible sound when

used with dimmers, which may be objectionable in acoustically critical areas.

Electrical (continued)

UL/cUL listed or through branch circuit wiring with maximum o (8) no. 12 AWG,

90°C.

Finish

All painted inishes are powder coated baked enamel.

Options & Accessories

Accessories: 2 1/2" dia. series, ilters, lenses, screens and louvers. (2)

accessories maximum, including lamp cover glass. Lamp guard glass may be

replaced with solid glass accessory.

Labels

UL/cUL (Suitable or Damp Location), I.B.E.W.

Te lon®is a registered trademark o E.I. DuPont.

Add a “1” or 120v or “2” or 277v at the end o the catalog number or voltage

Li htolier a Genlyte Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details o design, materials and inish.

Li htin Performance Data

Aimin An le: 0° 30° 45° or 60° Horizontal 30° 45° or 60° Vertical

Data are based on bare lamp photometrics.

Dashed lines in beam spreads indicate narrow

axes o oval shaped beams.

FC is initial ootcandles at center o beam.

Land Ware to the point that the candlepower

drops 50% o maximum.

LBeam length

BBeam width

CDistance to center o beam

DDistance

AAiming angle

FC Foot candles

Lamp data shown is typical, and is based on

bare lamp photometrics. Contact lamp

manu acturers or availability and

per ormance.

D FC LW DC FC LW DC FC LW DC FC LW

Lamps Beam Spread CBCP Rated

(To 50% CBCP) Lie (Hrs.)

Lamp 0° Aimin An le 30° Aimin An le 45° Aimin An le 60° Aimin An le

8’ 234 1.4’ 1.4’

12’ 104 2.1’ 2.1’

16’ 59 2.8’ 2.8’

20’ 38 3.5’ 3.5’

7’ 4.0’ 199 1.6’ 1.4’

10’ 5.8’ 97 2.3’ 2.0’

13’ 7.5’ 58 3.0’ 2.6’

16’ 9.2’ 38 3.7’ 3.2’

3’ 5.2’ 208 2.1’ 1.0’

4’ 6.9’ 117 2.9’ 1.4’

5’ 8.7’ 75 3.6’ 1.7’

6’ 10.4’ 52 4.3’ 2.1’

5’ 5.0’ 212 1.8’ 1.2’

7’ 7.0’ 108 2.5’ 1.7’

9’ 9.0’ 65 3.2’ 2.2’

11’ 11.0’ 44 3.9’ 2.7’

15000 2000

50W AR70

SP (T-H) 10°

4’ 125 2.1’ 2.1’’

6’ 56 3.2’ 3.2’

8’ 31 4.3’ 4.3’

10’ 20 5.4’ 5.4’

3’ 1.7’ 144 2.2’ 1.9’

5’ 2.9’ 52 3.7’ 3.1’

7’ 4.0’ 27 5.1’ 4.3’

9’ 5.2’ 16 6.6’ 5.6’

1’ 1.7’ 250 2.7’ 1.1’

2’ 3.5’ 63 5.5’ 2.1’

3’ 5.2’ 28 8.2’ 3.2’

4’ 6.9’ 16 10.9’ 4.3’

3’ 3.0’ 79 3.5’ 2.3’

4’ 4.0’ 44 4.6’ 3.0’

5’ 5.0’ 28 5.8’ 3.8’

6’ 6.0’ 20 6.9’ 4.5’

2000 2000

50W AR70

FL (T-H) 30°

8’ 211 1.4’ 1.4’

12’ 94 2.1’ 2.1’

16’ 53 2.8’ 2.8’

20’ 34 3.5’ 3.5’

7’ 4.0’ 199 1.6’ 1.4’

10’ 5.8’ 97 2.3’ 2.0’

13’ 7.5’ 58 3.0’ 2.6’

16’ 9.2’ 38 3.7’ 3.2’

3’ 5.2’ 188 2.1’ 1.0’

4’ 6.9’ 105 2.9’ 1.4’

5’ 8.7’ 68 3.6’ 1.7’

6’ 10.4’ 47 4.3’ 2.1’

5’ 5.0’ 191 1.8’ 1.2’

7’ 7.0’ 97 2.5’ 1.7’

9’ 9.0’ 59 3.2’ 2.2’

11’ 11.0’ 39 3.9’ 2.7’

13500 2000

50W AR70

SP GOLD (T-H) 10°

4’ 125 2.1’ 2.1’’

6’ 56 3.2’ 3.2’

8’ 31 4.3’ 4.3’

10’ 20 5.4’ 5.4’

3’ 1.7’ 144 2.2’ 1.9’

5’ 2.9’ 52 3.7’ 3.1’

7’ 4.0’ 27 5.1’ 4.3’

9’ 5.2’ 16 6.6’ 5.6’

1’ 1.7’ 225 2.7’ 1.1’

2’ 3.5’ 56 5.5’ 2.1’

3’ 5.2’ 25 8.2’ 3.2’

4’ 6.9’ 14 10.9’ 4.3’

3’ 3.0’ 71 3.5’ 2.3’

4’ 4.0’ 40 4.6’ 3.0’

5’ 5.0’ 25 5.8’ 3.8’

6’ 6.0’ 18 6.9’ 4.5’

1800 2000

50W AR70

FL GOLD (T-H) 30°

15’ 222 1.3’ 1.3’

20’ 125 1.7’ 1.7’

25’ 80 2.2’ 2.2’

30’ 56 2.6’ 2.6’

10’ 5.8’ 325 1.2’ 1.0’

15’ 8.7’ 144 1.7’ 1.5’

20’ 11.5’ 81 2.3’ 2.0’

25’ 14.4’ 52 2.9’ 2.5’

8’ 8.0’ 276 1.4’ 1.0’

12’ 12.0’ 123 2.1’ 1.5’

16’ 16.0’ 69 2.8’ 2.0’

20’ 20.0’ 44 3.5’ 2.5’

5’ 8.7’ 250 1.8’ 0.9’

8’ 13.9’ 98 2.6’ 1.4’

11’ 19.1’ 52 3.9’ 1.9’

14’ 24.2’ 32 4.9’ 2.4’

50000 2000

50W AR111

NSP (T-H) 5°

6’ 83 3.2’ 3.2’

8’ 47 4.3’ 4.3’

10’ 30 5.4’ 5.4’

12’ 21 6.4’ 6.4’

5’ 2.9’ 78 3.7’ 3.1’

7’ 4.0’ 40 5.1’ 4.3’

9’ 5.2’ 24 6.6’ 5.6’

11’ 6.4’ 16 8.1’ 6.6’

3’ 3.0’ 118 3.5’ 2.3’

5’ 5.0’ 42 5.8’ 3.6’

7’ 7.0’ 22 8.1’ 5.3’

9’ 9.0’ 13 10.4’ 6.8’

2’ 3.5’ 94 5.5’ 2.1’

3’ 5.2’ 42 8.2’ 3.2’

4’ 6.9’ 23 10.9’ 4.3’

5’ 8.7’ 15 13.7’ 5.4’

3000 2000

50W AR111

FL (T-H) 30°

60°

Calculite®ProSpec®Linear Downlight PA4A7050

Page 2 o 2 4 Light AR 70 Series A

Job Information Type:

Li htolier a Genlyte Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details o design, materials and inish.
