LG 20MP48A Manuel utilisateur
www.lg.com
IPS LED MONITOR MODEL
Please read this manual carefully before operating
your set and retain it for future reference.
Owner's Manual
IPS LED MONITOR
(LED MONITOR*)
*LG LED Monitors are LCD Monitors with LED Backlighting.
22MP48A
22MP48D
22MP48HQ
23MP48D
23MP48HQ
20MP48A 24MP48HQ 27MP48HQ
2
ENG
ENGLISH
TABLE OF CONTENTS
CONTENTS
3LICENSE
4ASSEMBLING AND PREPAR-
ING
4 Unpacking
6 Parts and buttons
7 Parts and buttons
8 Moving and Lifting the Monitor
9 Setting up the Monitor set
9 - Attaching the Stand Base
10 - Mounting on a table
11 - Using the cable holder
13 - Mounting on a wall
14 USING THE MONITOR SET
14 Connecting to a PC
14 - D-SUB connection
14 - DVI-D connection
15 - HDMI connection
15 Connecting to AV Devices
15 - HDMI connection
16 Connecting to External Devices
16 - Peripheral device connection
17 CUSTOMIZING SETTINGS
19 Customizing Settings
19 - Menu Settings
21 -Picture
22 -Color
23 -Display
23 -Audio
24 -Others
25 READER Setting
26 FUNC. Setting
26 -SMART ENERGY SAVING
27 -Picture Mode
28 -Color Weakness
29 TROUBLESHOOTING
31 SPECIFICATIONS
41 Factory Support Mode
(Preset Mode, D-SUB/DVI/HDMI PC)
42 HDMI Timing(Video)
42 Indicator
43 PROPER POSTURE
43 Proper posture for using the Monitor set.
3
ENG
ENGLISH
LICENSE
LICENSE
Each model has different licenses. Visit www.lg.com for more information on the license.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC
in the United States and other countries.
22MP48HQ 23MP48HQ
The following content is only applied to the monitor which is sold in Europe market and which needs to
meet the ErP Directive:
*This monitor is set to be turned off automatically in 4 hours after you turned on display if there is no adjust-
ment to display.
*To make this setting be disabled, change the option to ‘Off’ in OSD menu of “Automatic Standby”.
24MP48HQ 27MP48HQ
4
ENG
ENGLISH
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual product
and accessories.
CD(Owner's Manual) /
Card
( Depending on the country ) ( Depending on the country )
Power Cord AC-DC Adapter
AC-DC Adapter
or
D-SUB Cable
( This cable is not included in all
countries. )
HDMI Cable
Stand Body Stand Base
( This cable is not included in all
countries. )
DVI-D Cable
( This cable is not included in all
countries. )
Stand Body Stand Base Cable holder
5
ENG
ENGLISH
ASSEMBLING AND PREPARING
yDo not use any unapproved accessories to ensure the safety and product life span.
yAny damages or injuries by using unapproved accessories are not covered by the warranty.
yThe accessories supplied with your product may vary depending on the model.
yProduct specifications or contents in this manual may be changed without prior notice due to upgrade
of product functions.
CAUTION
NOTE
6
ENG
ENGLISH
ASSEMBLING AND PREPARING
HDMI IN
READER
READER
Parts and buttons
Power Indicator
yLighting On: Turned on
yLighting Off: Turned off
Connection panel (See p.14~16)
Button (See p.17~18)
(Power Button)
yThe button is located at the bottom of the monitor.
NOTE
22MP48A
22MP48D
22MP48HQ
23MP48D
23MP48HQ
7
ENG
ENGLISH
ASSEMBLING AND PREPARING
Parts and buttons
Power Indicator
yLighting On: Turned on
yLighting Off: Turned off
Connection panel (See p.14~16)
Button (See p.17~18)
(Power Button)
yThe button is located at the bottom of the monitor.
NOTE
20MP48A 24MP48HQ 27MP48HQ
8
ENG
ENGLISH
ASSEMBLING AND PREPARING
Moving and Lifting the Monitor
When moving or lifting the monitor, follow these
instructions to prevent the monitor from being
scratched or damaged and to ensure safe trans-
portation regardless of its shape or size.
yAs far as possible, avoid touching the moni-
tor screen. This may result in damage to the
screen or some of the pixels used to create
images.
yIt is advisable to place the monitor in the
original box or packing material before at-
tempting to move it.
yBefore moving or lifting the monitor, discon-
nect the power cord and all cables.
yHold the top and bottom of the monitor frame
firmly. Do not hold the panel itself.
yWhen holding the monitor, the screen should
face away from you to prevent it being
scratched.
yWhen moving the monitor, avoid any strong
shock or vibrations to the product.
yWhen moving the monitor, keep it upright,
never turn the monitor on its side or tilt it
sideways.
CAUTION
9
ENG
ENGLISH
ASSEMBLING AND PREPARING
Attach the Stand Body to the monitor set.
Attach the Stand Base.
Tighten the screw to the right with a coin.
Setting up the Monitor set
Attaching the Stand Base
1Place the Monitor set with the screen side
down on a flat and cushioned surface.
Lay a foam mat or soft protective cloth
on the surface to protect the screen from
damage.
CAUTION
2
Stand Base
Stand Body
1
2
3
22MP48A
22MP48D
22MP48HQ
23MP48D
23MP48HQ
Stand Base
Stand Body
Stand Base
Stand Body
1
2
3
4
Insert the Cable Holder.
Attach the Stand Body to the monitor set.
Attach the Stand Base to Stand Body.
Tighten the screw to the right.
yYou can disassemble the stand in the
reverse order of the assembly.
NOTE
10
ENG
ENGLISH
ASSEMBLING AND PREPARING
Mounting on a table
1Lift and tilt the Monitor set into its upright
position on a table.
Leave a 10 cm (minimum) space from the wall
for proper ventilation.
2Connect the AC-DC Adapter and Power Cord
to a wall outlet.
3Press (Power) button on the bottom switch
panel to turn the power on.
10 cm
10 cm
10 cm
10 cm
Unplug the power cord before moving the
Monitor to another location. Otherwise electric
shock may occur.
CAUTION
or
22MP48A
22MP48D
22MP48HQ
23MP48D
23MP48HQ
or
or
