LG 98UM3E-B.AUS Manuel utilisateur

OWNER’S MANUAL

LG Digital

Signage

(MONITOR SIGNAGE)

www.lg.com

Please read this manual carefully before operating your set and retain it

for future reference.

98UH5E

98UM3E

ENGLISH

TABLE OF CONTENTS

IMPORTANT PRECAUTIONS.........3

- Electrical Power Related Precautions....................3

- Precautions In Installing the Product.....................5

- Precautions for Moving the Product......................6

- Precautions for Using/Cleaning the Product.....7

- Product Disposal (Only, Hg lamp used LCD

Monitor).................................................................................7

LICENSES.......................................8

ASSEMBLY AND PREPARATION ..9

- Optional Accessories....................................................10

- Parts and Buttons.........................................................11

- Connecting IR and Light Sensor............................12

- Portrait Layout................................................................13

- Connecting the Eye-Bolt Bracket.........................14

- Attaching the LG Logo Bracket .............................15

- Installing on a Wall........................................................16

REMOTE CONTROL .................... 18

MAKING CONNECTIONS........... 20

- Connecting to a PC.......................................................20

- External Device Connection.....................................20

- Connecting Multiple Monitors................................22

- Using the Input List......................................................23

TROUBLESHOOTING.................. 24

PRODUCT SPECIFICATIONS...... 27

ENGLISH

WARNING: This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may

cause radio interference.

IMPORTANT PRECAUTIONS

Please read these safety precautions carefully before using the product.

WARNING

Failure to follow those warnings may result in death, serious injury or damage to the product or other property.

CAUTION

If you ignore the caution message, you may be slightly injured or the product may be damaged.

WARNING

•Indoor Use Only.

Electrical Power Related Precautions

WARNING

•Use only the power cord supplied with the unit or another manufacturer’s authorized cord.

- Failure to do so may result in fire or electrical shock or damage to the product.

•Use only a properly grounded plug and receptacle.

- If you do not you may be electrocuted or injured. Or the product might be damaged.

•Do not use a damaged or loose plug.

- This may cause electrical shock or fire.

•Operate the display only from a power source(i.e. voltage) indicated in the product specification.

- Otherwise the product can be damaged, fire can occur or you may be electrocuted. If you are not sure what type of

power supply you have, consult a certified electrician.

•In the presence of thunder and lightning, never touch the power cord and signal cable because it can be very

dangerous.

- It can cause electric shock.

ENGLISH

•Do not connect several extension cords, electrical appliances or electrical heaters to a single outlet. Use a power strip

with a grounding terminal designed for exclusive use with the computer.

- A fire can break out due to overheating.

•Do not touch the power plug with wet hands. Additionally, if the cord pin is wet or covered with dust, dry the power

plug completely or wipe dust off before plugging in the cord.

- You may be electrocuted due to excess moisture.

•If you don’t intend to use the product for a long time, unplug the power cable from the product.

- Layers of dust can cause a fire, or insulation deterioration can cause electric leakage, electric shock or fire.

•Insert the power plug firm so it cannot come loose.

- A loose connection can cause fire.

•Hold the plug when pulling out the power cable. Do not pull the plug out by the wire. Do not bend the power cord

with excessive force or put heavy objects on the power cord.

- The power line can be damaged, which may cause electric shock or fire.

•Do not insert metal or other conductive materials into the product openings. Additionally, do not touch the power

cable right after plugging into the wall input terminal.

- You may be electrocuted.

•Use an appliance coupler as a disconnect device.

•Please make sure the device is installed near the wall outlet to which it is connected and that the outlet is easily

accessible.

•Do not unplug the power cord while the product is in use.

- Electrical shock can damage the product.

•As long as this unit is connected to the AC wall outlet, it is not disconnected from the AC power source even if the

unit is turned off.

ENGLISH

Precautions In Installing the Product

WARNING

•Keep away from heat sources like heaters or open flames.

- Electrical shock, fire, malfunction or deformation may occur.

•Keep the packing anti-moisture material or vinyl packing out of the reach of children.

- Anti-moisture material is harmful if swallowed. If swallowed by mistake, force the patient to vomit and visit the

nearest hospital. Additionally, vinyl packing can cause suffocation. Keep it out of the reach of children.

•Do not put heavy objects on the product or sit upon it.

- If the product collapses or is dropped, you may be injured. Prevent Children from climbing or pulling on the unit.

•Do not leave the power or signal cable where someone can trip over it.

- Pedestrians may become entangled in the cables and cause the device to become damaged causing electrical shock,

fire, or serious injury.

•Install the product in a neat and dry place. Do not use near water.

- Dust or moisture can cause electrical shock, fire or product damage.

•Do not add accessories that have not been designed for this display.

•If you smell smoke or other odors or hear a strange sound from the product unplug the power cord and contact LG

Customer Service.

- If you continue to use without taking proper measures, electrical shock or fire can occur.

•If you dropped the product or the case is broken, turn off the product and unplug the power cord.

- If you continue to use without taking proper measures, electrical shock or fire can occur. Contact LG Customer

Service.

•Do not drop an object on or apply impact to the product. Do not throw any toys or objects at the product.

- It can cause injury to humans, problems to the product and damage the display.

•Keep out of reach of children and do not place toys near the product.

•Make sure the product ventilation hole is not blocked. Install the product more than 100 mm (3.9 inches) from the

wall.

- If you install the product too close to the wall, it may be deformed or fire can break out due to internal heat build-

up.

•Do not cover the product with cloth or other material (eg. plastic) while plugged in.

- The product can be deformed or fire can break out due to internal overheating.

•Place the product on a flat and stable surface that is large enough to support the product.

- If the product is dropped, you may be injured or the product may be broken.

ENGLISH

•Install the product where no Electromagnetic Interference occurs.

•Keep the product away from direct sunlight.

- The product can be damaged.

•Do not place the product on the floor.

- Small Children and others may trip over it.

•Do not install this product on a wall if it could be exposed to oil or oil mist.

- This may damage the product and cause it to fall.

•For displays with glossy bezels the user should consider the placement of the display as the bezel may cause

unwanted reflections from surrounding light and bright surfaces.

Precautions for Moving the Product

WARNING

•Make sure to turn off the product.

- You may be electrocuted or the product can be damaged.

•Make sure to remove all cables before moving the product.

- You may be electrocuted or the product can be damaged.

•When lifting or moving the product, do not hold it upside down while holding only the stand.

- This may cause the product to fall resulting in damage or injury.

•Do not shock the product when moving it.

- You may be electrocuted or the product can be damaged.

•Make sure the panel faces forward and hold it with both hands to move.

- If you drop the product, the damaged product can cause electric shock or fire.

•Do not place the product face down.

- This may damage the TFT-LCD screen.

ENGLISH

Precautions for Using/Cleaning the Product

WARNING

•Do not attempt to disassemble, repair or modify the product yourself.

- Fire or electric shock can occur.

- Contact LG Customer Service for repair.

•When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching. Do not

clean with a wet cloth or spray water or other liquids directly onto the product. An electric shock may occur. (Do not

use chemicals such as benzene, paint thinners or alcohol.)

•Keep the product away from water.

- Fire or electric shock accident can occur.

•Avoid high temperatures and humidity.

•Do not put or store flammable substances near the product.

- There is a danger of explosion or fire.

•Keep the product clean at all times.

•Take a comfortable and natural position when working with the product.

•Take a regular break when working with the product for a long time.

•Do not press on the panel with a hand or sharp object such as nail, pencil or pen, or make a scratch on it.

•Keep proper distance from the product and rest from time-to-time.

- Your vision may be impaired if you look at the product too closely or for too long.

•Set the appropriate resolution by referring to the User’s Guide.

•Keep small accessories out of the reach of children.

•Displaying a still image for long time on the monitor may leave persistent image or stain on the monitor screen. To

avoid this problem, use a screen saver and power off when this product is not used. Persistent image or stain caused

by long time usage are not covered by the warranty on this product.

•Do not use products using high voltage around the Monitor. (ex. Electrical Swatter)

- Monitor may have malfunction as its electrical shock.

•Spray water onto a soft cloth 2 to 4 times, and use it to clean the front frame;wipe in one direction only. Too much

moisture may cause staining.

WATER CHEMICALS

Product Disposal (Only, Hg lamp used LCD Monitor)

•The fluorescent lamp used in this product contains a small amount of mercury.

•Do not dispose of this product with general household waste.

•Disposal of this product must be carried out in accordance to the regulations of your local authority.

ENGLISH

LICENSES

Supported licenses may differ by model. For more information of the licenses, visit www.lg.com.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered

trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.

Manufactured under license from Dolby Laboratories. Dolby, Dolby Vision, Dolby Audio, Dolby Atmos, and the double-D

symbol are trademarks of Dolby Laboratories.

For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, the Symbol,

& DTS and the Symbol together, DTS 2.0 Channel, DTS 2.0+Digital Out, DTS-HD, and DTS Virtual:X are registered

ENGLISH

ASSEMBLY AND PREPARATION

CAUTION

•Always use genuine components to ensure safety and product performance.

•The product warranty will not cover damage or injury caused by the use of counterfeit components.

NOTE

•The accessories provided with your product may vary depending on the model or region.

•Product specifications or contents in this manual may be changed without prior notice due to upgrade of product

functions.

•SuperSign Software & Manual

- Downloading from the LG Electronics website.

- Visit the LG Electronics website (http://partner.lge.com) and download the latest software for your model.

•The warranty will not cover any damage caused by using the product in an excessively dusty environment.

ENGLISH

Optional Accessories

Without prior notice, optional accessories are subject to change to improve the performance of the product, and new

accessories may be added. The illustrations in this manual may differ from the actual product and accessories.

Speaker kit

Speakers

SP-2200

Cable Holders/

Cable Ties

Screws

Diameter4.0mm(0.1inches)x

Pitch0.7mm(0.02inches)x

Length8mm(0.3inches)

(including spring washer)

Screws

Diameter4.0mm(0.1inches)

x Pitch1.6mm(0.06inches) x

Length10mm(0.3inches)

Media Player kit

Media Player Screws

Diameter3.0mm(0.1inches)x

Pitch0.5mm(0.01inches)x

Length6mm(0.2inches)

CD (Owner’s Manual) / Cards

MP500 / MP700

NOTE

•Optional accessories are available for some models. If necessary, please purchase them separately.

•Before you attach the Media Player, connect the cable to the port.

Ce manuel convient aux modèles suivants

Table des matières

Manuels Affichage numérique populaires d'autres marques

SMART-AVI

SMART-AVI SIGNAGEPRO Manuel utilisateur

KeyWest Technology

KeyWest Technology BREEZE Manuel utilisateur

XtendLan

XtendLan XL-DSP-183C Manuel utilisateur

Dynascan

Dynascan DS861LR4 Manuel utilisateur

Classic Exhibits

Classic Exhibits SEGUE DESIGNS MOD-1363 Manuel utilisateur

protech

protech KT-7290 Manuel utilisateur

WebDT

WebDT 515A Instructions de montage

Samsung

Samsung IWJ Series Manuel utilisateur

EVERI

EVERI Enrollment Kiosk Manuel utilisateur

NCR

NCR SelfServ 90 Manuel

ViewSonic

ViewSonic EP4602 Manuel utilisateur

ViewSonic

ViewSonic EP3202r Manuel utilisateur

Samsung

Samsung OM46N Manuel utilisateur

Viessmann

Viessmann 6336 Manuel utilisateur

Osram

Osram Traxon Manuel d'instructions d'installation

Philips

Philips Signage Solutions Series BDL4990VL Manuel utilisateur

ViewSonic

ViewSonic EP5012-L Manuel utilisateur

Philips

Philips CRD01/00 Manuel utilisateur
