LG AX585 Manuel utilisateur

Quick Start Guide

LGmobilephones.com/Rhythm

Playing Music and

Changing EQ Settings

Transferring

Music

Transmitting Music

to an FM Radio

Bluetooth®

Pairing

Taking a Picture/

Recording a Video

Getting to Know Your Phone

Volume

Up/Down

Speaker

microSD™

Port

Self-Portrait Mirror

Camera Speaker

Unlock Key

Left Soft Key

(Celltop)

Music Key

Talk Key

Voicemail

Key

Shift Key

Micro USB/

Charging

Port

Power/End

Key

Speakerphone

Key

Space Key

Microphone

External Control Wheel

with Center Touch LCD

Play/Pause

Key

Camera Key

Clear &

Back Key

Right Soft Key

(Messaging)

BACK

Playing Music and Changing EQ Settings

Keep your music with you 24/7. Complete with a customizable

equalizer, Rhythm gives you great audio and quick access to

your tunes.

1. With the slide closed and the phone unlocked, insert

a microSD card* containing music into your phone.

2. Press and hold on the right side of the phone.

3. Touch to view the music player.

4. Touch the Right Soft Key for Options.

5. Scroll with the External Control Wheel to highlight

Equalizer (6), and then touch the Center Touch LCD

for OK.

6. Choose from equalizer settings such as Natural Sound,

Flat, Live, Virtual Bass, Comfort, and Clear.

*microSDcardsoldseparately.

Note: You can play music in the back-

ground while performing other tasks on

Rhythm. Once you have exited the music

player with Background Music enabled,

touch to return to the player.

Transferring Music

It’s easy to take your favorite songs on the go with

Rhythm. Transfer music from your PC to your

phone in a ash.*

1. With the slide closed and the phone unlocked,

insert a microSD card* into your phone.

2. Touch the Center Touch LCD to enter the main menu,

and then select Settings (9) > Memory (9) > Card Memory (3).

3. Touch the Right Soft Key for Format, and then select Yes (1).

4. Touch .

5. Connect a USB cable* between Rhythm and your PC.

6. Touch the Center Touch LCD to select

USB Mass Storage (2).

7. The PC will recognize the phone as a Removable Disk

and a screen will appear. Drag and drop music les on

your PC into the My_Music folder.

8. When done, disconnect the phone.

*microSDcardandUSBcablerequired.Soldseparately.

Transmitting Music to an FM Radio

Want to play your tunes for everyone to hear? Rhythm’s cool FM

transmitter lets you broadcast your music to an FM receiver (such

as your car stereo) up to 10 feet away.

1. With the slide closed and the phone unlocked, insert a

microSD card* containing music into your phone.

2. Press and hold on the right side of the phone.

3. Touch to view the music player.

4. Touch the Right Soft Key for Options.

5. Scroll with the External Control Wheel to highlight

Music Transmitter (7), and then touch the

Center Touch LCD for OK.

6. Select On (1). If needed, you can also change the

channel of the FM transmitter from this menu.

*microSDcardrequired.Soldseparately.

Note: For best audio results, try to nd an unused FM channel

on the radio with no commercial channels on either side of it.

Bluetooth® Pairing

Forget having a tangled mess of cables and cords. With

Bluetooth technology on Rhythm, you can connect wirelessly

to headsets, speakers, computers, and more.

1. Set your Bluetooth accessory into pairing mode.*

2. With the slide open and the phone unlocked, touch the

Center Touch LCD to enter the main menu.

3. Select Settings (9) > Bluetooth (6) > Paired Devices (1).

4. Touch the Left Soft Key for Search. If Bluetooth is off, you’ll

be prompted to turn it on.

5. Select New Search (1).

6. Once your Bluetooth device has been found, highlight it and

touch the Center Touch LCD for Pair.

7. Enter the passcode* (typically “0000” – 4 zeroes), and then

touch the Center Touch LCD for OK.

8. Select Yes (1) to connect with the device.

Optional Accessories

Maximize your phone with these cutting-edge accessories at LGmobilephones.com/Rhythm.

*RefertoyourBluetoothaccessory’susermanualfor

informationaboutinitiatingpairingmodeandthepasscode.

Taking a Picture/Recording a Video

Thanks to Rhythm’s integrated 1.3 megapixel camera/camcorder, you can take

pictures and record videos with ease. You’ll never miss out on the

action with Rhythm in your pocket.

1. With the slide closed and the phone unlocked,

press and hold on the right side of the

phone to activate the camera viewnder.

Press and select Record Video (2) to

activate the camcorder.

2. Rotate the phone horizontally.

3. Press the Right Soft Key for Options to

access customizable features.

4. Press to take the picture or

start/stop recording.

5. Touch the Center Touch LCD to send the

photo/video to someone.

Optional Accessories

Maximize your phone with these cutting-edge accessories at LGmobilephones.com/Rhythm.

of LG Electronics, Inc. All other marks are proprietary to their respective

owners. All phone images are simulated. microSD™ is a trademark of SanDisk.

The Bluetooth® trademark and logos are owned by the Bluetooth SIG, Inc.

and any use of such marks by LG Electronics is under license.

Bluetooth Headset

(HBM-760)

Bluetooth Headset

(HBM-770)

Bluetooth Stereo Speakers

Bluetooth Solar Car Kit Portable Stereo Speakers Vehicle Power Charger

XX%

Cert no. XXX-XXX-XXX
