Lexmark Prospect Pro200 Series Quick

Reference Guide

April 2009 www.lexmark.com

Important Message About Cartridge Recycling!

Please Read Before Opening Your Inkjet Cartridge Box

At Lexmark, we take our commitment to the environment seriously, and we encourage our customers to participate in our easy, no-cost method

for returning empty Lexmark cartridges to Lexmark for proper recycling. We will insure that cartridges are properly handled with zero waste to

landfills.

Go to www.lexmark.com/recycle. Follow instructions to request postage-paid bags. Bags usually arrive

within 7–10 days.

Place the empty Lexmark-branded inkjet cartridge(s) in the postage-paid return bag, and then seal the bag.

If you’re sending single-color tanks, we recommend that you send at least two at a time to maximize the

environmental benefits.

Mail the bag to Lexmark’s recycling partner. The bag is pre-addressed.

Visit www.lexmark.com/recycle to learn more about recycling.

Lexmark-branded cartridges are always made with all new parts, though components may contain recycled material. For warranty returns, call

1-800-332-4120.

This patented printer is licensed for, and designed to work with, only genuine Lexmark inkjet cartridges for the life of the patented printer. You

agree to: (1) use only genuine Lexmark inkjet cartridges with this printer except as otherwise provided below, and (2) pass this license/agreement

to any subsequent user of this printer. The patented Lexmark inkjet cartridges and their contents are licensed subject to a restriction that they may

be used only once. After this single use, the license to use the print cartridges and their contents terminates, and you agree to return them only to

Lexmark for recycling. Replacement inkjet cartridge(s) sold without these terms are available through www.lexmark.com and may be refilled by

you, or a third party, as the only cartridge alternative to be used with the licensed printer.

Important safety information

Connect the power cord to a properly grounded electrical outlet that is near the product and easily accessible.

Do not place or use this product near water or wet locations.

Use only the power supply and power cord provided with this product or the manufacturer's authorized replacements.

Use only the telecommunications (RJ-11) cord provided with this product or a 26 AWG or larger replacement when connecting this product to the

public switched telephone network.

CAUTION—POTENTIAL INJURY: Do not cut, twist, bind, crush, or place heavy objects on the power cord. Do not subject the power cord to

abrasion or stress. Do not pinch the power cord between objects such as furniture and walls. If any of these things happen, a risk of fire or

electrical shock results. Inspect the power cord regularly for signs of such problems. Remove the power cord from the electrical outlet before

inspecting it.

CAUTION—SHOCKHAZARD: Do not use the fax feature during a lightning storm. Do not set up this product or make any electrical or cabling

connections, such as the fax feature, power cord, or telephone, during a lightning storm.

Contents

Important safety information.........................................................2

About your printer.............................................................................5

Finding information about the printer...........................................................................................................................5

Minimizing your printer's environmental impact......................................................................................................5

Printer models.........................................................................................................................................................................6

Printer features.......................................................................................................................................................................7

Understanding the parts of the printer..........................................................................................................................7

Using the printer control panel........................................................................................................................................9

Using memory cards and flash drives..........................................................................................................................12

Ordering and replacing ink cartridges.........................................14

Ordering ink cartridges.....................................................................................................................................................14

Replacing ink cartridges....................................................................................................................................................15

Maintaining ink cartridges...............................................................................................................................................16

Using the printer software.............................................................18

Minimum system requirements.....................................................................................................................................18

Installing the printer software........................................................................................................................................18

Using the Windows printer software............................................................................................................................19

Using the Macintosh printer software.........................................................................................................................21

Printing...............................................................................................22

Printing a document..........................................................................................................................................................22

Printing on both sides of the paper (duplexing) automatically.........................................................................22

Printing photos using the printer control panel......................................................................................................24

Printing documents from a memory card or flash drive (Windows only).......................................................24

Canceling print jobs............................................................................................................................................................25

Copying...............................................................................................26

Tips for copying....................................................................................................................................................................26

Making copies.......................................................................................................................................................................26

Copying photos....................................................................................................................................................................26

Making a duplex copy automatically...........................................................................................................................27

Canceling copy jobs...........................................................................................................................................................27

Contents

Scanning.............................................................................................28

Tips for scanning..................................................................................................................................................................28

Scanning to a local or network computer..................................................................................................................28

Scanning to a flash drive or memory card..................................................................................................................29

Scanning directly to e-mail using the printer software.........................................................................................29

Scanning to a PDF...............................................................................................................................................................30

Canceling scan jobs............................................................................................................................................................30

Troubleshooting...............................................................................31

Notices................................................................................................38

Edition notice........................................................................................................................................................................38

Contents

About your printer

Finding information about the printer

The Quick Reference Guide contains basic instructions on how to accomplish common printer tasks like printing,

copying, and scanning. It also includes information on troubleshooting common printer setup problems.

For additional information about the printer, see the following:

What are you looking for? Find it here

Initial setup instructions •Quick Setup Sheet

•Hardware Setup Wizard1

Additional setup and instructions for using the

printer

Comprehensive User'sGuide installed automatically with the printer

software.1

After installing your printer, you can access the User's Guide from

the printer program folder:

For Windows users

1Click or Start.

2Click All Programs or Programs, and then select the printer

program folder from the list.

3Select View User's Guide.

For Macintosh users

1From the Finder desktop, double-click the printer folder.

2Double-click User's Guide.

Help using the printer software Software Help installed automatically with the printer software.1

Click Help from any printer software program or application.

The latest supplemental information, updates,

online technical support, and telephone support

Support Web site—support.lexmark.com

1Available on the installation software CD and on the Lexmark Web site at www.lexmark.com/publications/.

Minimizing your printer's environmental impact

We are committed to protecting the environment and are continually improving our printers to reduce their

environmental impact. By selecting certain printer settings or tasks, you may be able to reduce your printer's

environmental impact even further.

Conserving energy

•Activate Eco-Mode. This feature sets the screen brightness to low and sets the printer to change to Power Saver

mode after the printer is left idle for 10 minutes.

•Select the lowest Power Saver timeout. The Power Saver feature puts the printer in a minimum-power standby

mode after the printer has been idle for a set amount of time (the Power Saver timeout).

About your printer

•Share your printer. Wireless/network printers allow you to share a single printer among multiple computers,

thus conserving energy and other resources.

Conserving paper

•Activate Eco-Mode. On selected printer models, this feature sets the printer to automatically print on both sides

of the paper (duplex) for copy and fax jobs and for printing in Windows.

•Print more than one page image on one side of the paper. The “Pages per sheet” feature allows you to print

multiple pages on one sheet. You can print up to 8 page images on one side of a sheet of paper.

•Print on both sides of the paper. Duplexing lets you print on both sides of the paper manually or automatically

(depending on your printer model).

•Preview print jobs before printing. Use the preview features found in Toolbars, the Print or Print Preview dialog,

or the printer display (depending on your printer model).

•Scan and save. To avoid printing multiple copies, you can scan documents or photographs and save them to a

computer program, application, or flash drive for presentation.

•Use recycled paper.

Conserving ink

•Use Quick Print or Draft Mode. These modes can be used to print documents using less ink than normal and

are ideal for printing documents that are mostly text.

•Use High Yield cartridges. Inks in High-Yield cartridges allow you to print more pages with fewer cartridges.

•Clean the printhead. Before replacing and recycling your ink cartridges, try using the “Clean Printhead” and

“Deep Clean Printhead” features. These features clean the printhead nozzles to improve the quality of your prints.

Recycling

•Return ink cartridges for reuse or recycling through the Lexmark Cartridge Collection Program. To return

an ink cartridge, go to www.lexmark.com/recycle. Follow the instructions to request a postage-paid bag.

•Recycle the product packaging.

•Recycle your old printer instead of throwing it away.

•Recycle paper from discarded print jobs.

•Use recycled paper.

To read the Lexmark Environmental Sustainability Report, see www.lexmark.com/environment.

Printer models

The installation software CD that came with your printer works for the following printer models:

•Lexmark Pro205

•Lexmark Pro207

•Lexmark Pro208

About your printer

Printer features

Your printer comes with full features that will help you manage and accomplish printing and imaging tasks:

•Wireless. Print and scan from virtually anywhere in your home or office over a secure wireless network, as well

as share the printer among multiple computers.

•Print. Print high quality documents and PDFs faster from a computer, from a USB flash drive, or from a Bluetooth

device. Built-in two-sided printing lets you save money and the environment.

•Copy. Copy documents and photos with one-touch, computer-free black or color copying.

•Scan. Scan thick books, reports, and other multiple-page documents easily with the high resolution flatbed

scanner and the Automatic Document Feeder.

•Fax. Do multiple-page, standalone black and color faxing at 33.6 Kbps modem speed. Other fax features include

99 speed dials, automatic redial, junk fax blocking, and caller ID.

•Photo printing. Print photos directly from digital memory cards, PictBridge-enabled digital cameras, and USB

flash drives. Select photos to print using the proof sheet for computer-free printing.

•Eco-Mode. Save energy and paper by activating Eco-Mode. It automatically dims the printer display light, puts

the printer into Power Saver mode after 10 minutes of inactivity, and prints on both sides of the paper for copy

and fax jobs and for printing in Windows.

Understanding the parts of the printer

Use the To

1Paper support Load paper.

2Paper guide adjustment lever Adjust the paper guides.

3Wi-Fi indicator Check wireless status.

4Memory card slots Insert a memory card.

5PictBridge and USB port Connect a PictBridge-enabled digital camera, Bluetooth

adapter or a flash drive to the printer.

About your printer

Use the To

6Card reader light Check card reader status. The light blinks to indicate that a

memory card is being accessed.

7Paper exit tray Hold paper as it exits.

8Printer control panel Operate the printer.

9Automatic Document Feeder (ADF) paper guide Keep paper straight when feeding it into the ADF.

Note: Adjust the paper guide on the ADF tray to the width of

the original document.

10 ADF output tray Hold documents as they exit from the ADF.

11 ADF tray Load original documents in the ADF. Recommended for

scanning, copying, or faxing multiple-page documents.

Note: Do not load postcards, photos, small items, or thin media

(such as magazine clippings) into the ADF. Place these items on

the scanner glass.

12 ADF Scan, copy, or fax multiple-page letter-, legal-, and A4-size

documents.

13 Paper feed guard Prevent items from falling into the paper slot.

14 Paper guides Keep paper straight when feeding.

Use the To

1Top cover Access the scanner glass.

2Scanner glass Scan and copy photos and documents.

3Power supply with port Connect the printer to a power source.

About your printer

Use the To

4Duplex unit •Print on both sides of a sheet of paper.

•Remove paper jams.

5EXT Port Connect additional devices (telephone or answering machine) to the printer and the

telephone line. Use this port if you do not have a dedicated fax line for the printer, and

if this connection method is supported in your country or region.

Note: Remove the plug to access the port.

6LINE Port Connect the printer to an active telephone line (through a standard wall jack, DSL filter,

or VoIP adapter) to send and receive faxes.

7USB port Connect the printer to a computer using a USB cable.

Warning—Potential Damage: Do not touch the USB port except when plugging in or

removing a USB cable or installation cable.

8Printhead Install, replace, or remove ink cartridges.

9Scanner unit •Access the ink cartridges and printhead.

•Remove paper jams.

Using the printer control panel

The following diagrams explain the sections of the printer control panel:

About your printer

Use the: To

1Power button •Turn the printer on and off.

•Switch to Power Saver mode.

Note:When the printer is on, press to switchto Power

Saver mode. Press and hold for three seconds to turn

off the printer.

2Copy button Access the copy menu and make copies.

3Scan button Access the scan menu and scan documents.

4Fax button Access the fax menu and send faxes.

5Photo button Access the photo menu and print photos.

6Back button •Return to the previous screen.

•Exit from one menu level to a higher one.

7Select button •Select menu options.

•Save settings.

•Feed or eject paper. Press and hold button for 3seconds

to feed or eject paper from the printer.

8Arrow buttons Choose a menu or submenu item that appears on the

display.

9Display

Note: The display is turned off in Power Saver mode.

View:

•Printer status

•Messages

•Menus

About your printer

Autres manuels pour Prospect Pro205

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Lexmark Imprimante tout-en-un

Lexmark

Lexmark Clinical Assistant X646dte Manuel utilisateur

Lexmark

Lexmark MX710 Series Manuel utilisateur

Lexmark

Lexmark CS632 Manuel utilisateur

Lexmark

Lexmark INTERACT Interact S605 Manuel utilisateur

Lexmark

Lexmark X548DTE Manuel utilisateur

Lexmark

Lexmark MX6500E Instructions d'installation et d'entretien

Lexmark

Lexmark X544DN Manuel utilisateur

Lexmark

Lexmark CX410 series Manuel utilisateur

Lexmark

Lexmark X925 Manuel utilisateur

Lexmark

Lexmark MX510de Series Manuel utilisateur

Lexmark

Lexmark x9350 Manuel utilisateur

Lexmark

Lexmark CX410E Manuel utilisateur

Lexmark

Lexmark OptraImage 443 Manuel utilisateur

Lexmark

Lexmark MX822 Manuel utilisateur

Lexmark

Lexmark CS943 Manuel utilisateur

Lexmark

Lexmark X912e Manuel utilisateur

Lexmark

Lexmark X940E Manuel utilisateur

Lexmark

Lexmark 5300 Manuel utilisateur

Lexmark

Lexmark CS417dn Manuel utilisateur

Lexmark

Lexmark X950 Series Manuel utilisateur

Lexmark

Lexmark X422 Fiche d'information produit

Lexmark

Lexmark X502N Instructions d'utilisation et de sécurité

Lexmark

Lexmark X364dw Manuel utilisateur

Lexmark

Lexmark All in One Printer Manuel utilisateur

Manuels Imprimante tout-en-un populaires d'autres marques

Triumph Adler

Triumph Adler DC 2016 Manuel

Epson

Epson WorkForce WF-2510 Guide de l'utilisateur

Epson

Epson Stylus Scan 2000 Manuel d'installation et d'exploitation

Epson

Epson PictureMate Snap PM 240 Mode d’emploi

Konica Minolta

Konica Minolta bizhub C35 Manuel utilisateur

Brother

Brother MFC-J430w Manuel utilisateur

Konica Minolta

Konica Minolta BIZHUB 558 Manuel utilisateur

Brother

Brother MFC-9760 Manuel utilisateur

Sharp

Sharp MX-2310U Mode d’emploi

Aficio

Aficio 200 Manuel utilisateur

Canon

Canon ImageCLASS 2300 Manuel

Ricoh

Ricoh Pro C900 Manuel utilisateur

Brother

Brother Business Smart MFC-J4510dw Manuel utilisateur

Epson

Epson Stylus CX8400 Series Manuel utilisateur

Oce

Oce VarioLink 5022 Manuel utilisateur

Copystar

Copystar CS 4551ci Manuel utilisateur

Konica Minolta

Konica Minolta Magicolor 4650EN Manuel utilisateur

Brother

Brother MFC-9840CDW Manuel utilisateur
