Lexmark MX610 Series Manuel utilisateur

Lexmark MX610 MFP

Machine Type 7016-630, -670, -675

Service Manual

•Start diagnostics

•Maintenance

•Safety and notices

•Trademarks

•Index

October 19, 2012 www.lexmark.com

P/N 12G2272

Parts catalog

Legend

The following column headings are used in the parts catalog:

•Asm‑index—Identifies the assembly and the item in the diagram. For example, 3‑1 indicates Assembly 3 and item

1 in the table.

•Part number—Identifies the unique number that correlates with the part.

•Units/mach—Refers to the number of units actually used in the base machine or product.

•Units/option—Refers to the number of units in a particular option.

•Units/FRU—Refers to the number of units in a particular FRU.

•Description—A brief description of the part.

The following abbreviations are used in the parts catalog:

•NS (not shown) in the Asm‑index column indicates that the part is procurable but is not pictured in the illustration.

•PP (parts packet) in the Description column indicates that the part is contained in a parts packet.

7016

Parts catalog

384

Assembly 1: Covers

7016

Parts catalog

385

Assembly 1: Covers

Asm-index P/N Units/mach Units/FRU Description Removal procedure

1 40X9102 1 1 Output expander cover N/A

2 40X9096 1 1 Exit rear door N/A

3 40X9084 1 1 Diverter cover N/A

4 40X9087 1 1 Rear cover N/A

5 40X9090 1 1 Right cover N/A

6 40X9100 1 1 Memory access door (MFP) N/A

7 40X8086 1 1 550‑sheet tray N/A

8 40X9148 1 1 Cartridge plunger N/A

9 40X9101 1 1 Name plate cover N/A

10 40X9095 1 1 Front bin cover N/A

11 40X9131 1 1 MPF tray cover N/A

12 40X9068 1 1 Front access cover (MPF) N/A

13 40X9086 1 1 Left cover N/A

14 40X9126 1 1 Bin full sensor cable N/A

15 40X9092 1 1 Bin full sensor N/A

16 40X9127 1 1 IR sensor lens N/A

7016

Parts catalog

386

Assembly 2: Imaging

11 12

7016

Parts catalog

387

Assembly 2: Imaging

Asm-index P/N Units/mach Units/FRU Description Removal procedure

1 40X9108 1 1 ADF separator roller “ADF separator roll removal ” on page 312

2 40X9054 1 1 ADF input tray “ADF input tray removal” on page 315

3 40X9093 1 1 ADF assembly “ADF unit removal” on page 316

4 40X9094 1 1 Flatbed “Flatbed assembly removal” on page 324

5 40X9051 1 1 MPF USB cable “USB cable removal” on page 322

6 40X9053 1 1 USB cable bracket “USB cable bracket removal” on page 262

7 40X9097 1 1 Scanner front cover “Scanner front cover removal” on page 315

8 40X9088 1 1 Cave light lens “Cave light lens removal” on page 263

9 40X9080 1 1 Speaker cable “Speaker cable removal” on page 325

10 40X9050 1 1 MPF wireless cable “USB wireless cable removal” on page 323

11 40X9079 1 1 Speaker “Speaker removal” on page 262

12 40X9129 1 1 ADF left hinge “ADF left hinge” on page 324

13 40X5804 1 1 Flatbed cushion (legal) “Flatbed cushion removal ” on page 314

14 40X9110 1 1 Restraint pad “Restraint pad removal” on page 327

15 40X9142 1 1 ADF top cover (legal) “ADF top cover assembly” on page 320

16 40X9117 1 1 High end ADF cable “ADF cable removal” on page 321

7016

Parts catalog

388

Assembly 3: Control panel

7016

Parts catalog

389

Assembly 3: Control panel

Asm-index P/N Units/mach Units/FRU Description Removal procedure

1 40X9089 1 1 LCD top cover N/A

2 40X7861 1 1 7" LCD “Display removal” on page 266

3 40X9125 1 1 Control panel cover (MX610de) “Control panel cover removal” on

page 265

3 40X9132 1 1 Control panel cover (MX611de) “Control panel cover removal” on

page 265

3 40X9133 1 1 Control panel cover (MX611dhe) “Control panel cover removal” on

page 265

4 40X9120 1 1 Keypad assembly cover “Keypad assembly removal” on

page 268

5 40X9052 1 1 UICC cable N/A

6 40X9130 1 1 UICC “UICC removal” on page 260

7 40X9085 1 1 UICC video cable N/A

8 40X9115 1 1 Interface PCBA “Interface card removal” on page 264

7016

Parts catalog

390

Assembly 4: Electronics 1

7016

Parts catalog

391

Assembly 4: Electronics 1

Asm-index P/N Units/mach Units/FRU Description Removal procedure

1 40X8079 1 1 Laser scanning unit “Laser scanning unit (LSU) removal” on page 310

2 40X8343 1 1 Fuser, 100 V “Fuser removal” on page 302

2 40X8023 1 1 Fuser, 110 V “Fuser removal” on page 302

2 40X8024 1 1 Fuser, 220 V “Fuser removal” on page 302

3 40X8274 1 1 Cooling fan “Cooling fan removal” on page 238

4 40X9134 1 1 Controller board “Controller board removal” on page 239

5 40X7592 1 1 Tray present sensor “Tray present sensor removal” on page 237

6 40X8280 1 1 Front input guide “Front input guide removal” on page 276

7 40X8300 1 1 MPF solenoid “MPF solenoid removal” on page 225

8 40X8301 1 1 Reverse solenoid “Reverse solenoid removal” on page 230

7016

Parts catalog

392
