LevelOne Wireless Router

(WBR-6003) Setup User’s Guide

1

HKBN_SETUP_ROUTER_LEVELONE_ENG_230315

1 Get to know LevelOne (WBR-6003) Wireless Router.........................................................2

A. Tech Specs - Connections and Expansion .................................................................2

B. Minimum System Requirements (bb500/ FibreHome500/ bb1000/ FibreHome1000).2

2 Connecting to LevelOne Router..........................................................................................3

3 Switching your broadband Internet service to HKBN..........................................................9

4 Factory default reset of LevelOne Router.........................................................................11

2

HKBN_SETUP_ROUTER_LEVELONE_ENG_230315

Get to know LevelOne (WBR-

6003) Wireless Router

1 Get to know LevelOne (WBR-6003) Wireless Router

A. Tech Specs - Connections and Expansion

B. Minimum System Requirements (bb500/ FibreHome500/ bb1000/ FibreHome1000)

To ensure that you have a fast and stable network, please refer to the following as a

recommended minimum system requirement:

Central Processing Unit (CPU)

Intel Core2 Duo P8700/2.5 (3 GHz or above)

System Memory

4GB or above

Hard disk

64GB SATA II SSD (Min. I/O speed of 200MB/s)

Network Adaptor

100/1000M Network Adaptor

Status LED

WAN LED

Wireless LAN LED

LAN LED

LAN

Port

WAN

port

AC

Socket

3

HKBN_SETUP_ROUTER_LEVELONE_ENG_230315

Connecting to LevelOne Router

2 Connecting to LevelOne Router

Make sure you have a LAN cable connected from the HKBN wall plate/ONT to the WAN port

of your LevelOne Router (WBR-6003). Using a second LAN cable, connect it from the Router

LAN port to the computer LAN port. Once finished, switch on the power supply for the router

and turn on the computer.

Open your Internet browser, and input [http://192.168.1.1 ] into the address-bar then press

[Enter]. Enter [admin] as the default password, click [Login]

4

HKBN_SETUP_ROUTER_LEVELONE_ENG_230315

Connecting to LevelOne Router

2Connecting to LevelOne Router

Choose [Wizard] and click [Enter]

Click [Next] to begin setup.

5

HKBN_SETUP_ROUTER_LEVELONE_ENG_230315

Connecting to LevelOne Router

2Connecting to LevelOne Router

Input [admin] under[Old Password]. Create anewpassword under [NewPassword] and input

again under [Reconfirm], click [Next].

Choose [Auto Detecting WAN Type], click [Next].

6

HKBN_SETUP_ROUTER_LEVELONE_ENG_230315

Connecting to LevelOne

Router

2Connecting to LevelOne router

Select [Obtain an IP address from ISP automatically. (Dynamic IP Address)], click [Next].

In the [Dynamic IP Address] page, click [Next] again.

7

HKBN_SETUP_ROUTER_LEVELONE_ENG_230315

Connecting to LevelOne Router

2Connecting to LevelOne Router

Select [Enable] under Wireless function, then create a [Network ID(SSID)], then choose [Auto]

under [Channel]. Click [Next] to continue.

Choose [WPA-PSK/ WPA2-PSK] under [Security], click [Next].

8

HKBN_SETUP_ROUTER_LEVELONE_ENG_230315

Connecting to LevelOne Router

2Connecting to LevelOne Router

Choose [ASCII] under [Preshare Key Mode], then create a wireless password under

[Preshare Key], click [Next].

Confirm all settings displayed in the [Summary] page are correct, click [Apply Settings]. The

device will automatically reboot to apply the settings made. Click [Next] then [Finish] to

complete the setup.

9

HKBN_SETUP_ROUTER_LEVELONE_ENG_230315

Switching your broadband

Internet service to HKBN

3Switching your broadband Internet service to HKBN

After logging in to the router through your browser, select [Advanced Setup] then click [Enter].

Select [Primary Setup] on the left-hand side. Click [Change] under [WAN Type].
