LevelOne GEL-2060 Guide rapide

GEL-2060

MAC Address Table Attribute Configuration

Table of Contents

http://www.level1.com -- I -

Table of Contents

Chapter 1 Configuring MAC Address Attribute ..................................................................................................................... 1

1.1 MAC Address Configuration Task List ................................................................................................................... 1

1.2 MAC address Configuration Task .......................................................................................................................... 1

1.2.1 Configuring Static Mac Address ................................................................................................................ 1

1.2.2 Configuring MAC Address Aging Time ...................................................................................................... 1

1.2.3 Displaying MAC Address Table ................................................................................................................. 2

1.2.4 Clearing Dynamic MAC Address............................................................................................................... 2

MAC Address Table Attribute Configuration

http://www.level1.com -- 1 -

Chapter 1 Configuring MAC Address Attribute

1.1 MAC Address Configuration Task List

Configuring Static Mac Address

Configuring Mac Address Aging Time

Configring VLAN-shared MAC Address

Displaying Mac Address Table

Clearing Dynamic Mac Address

1.2 MAC address Configuration Task

1.2.1 Configuring Static Mac Address

Static MAC address entries are MAC address entries that do not age by the switch and

can only be deleted manually. According to the actual requirements during the

operation process, you can add and delete a static MAC address. Use the following

command in privileged level to add and delete a static MAC address.

Command

Purpose

configure

Enters the global configuration mode.

[no] mac address-table static mac-addr

vlan vlan-id interface interface-id

Adds/deletes a static MAC address entry.

Mac-addr indicates the MAC address.

Vlan-id indicates the VLAN number. Valid

value is from 1~4094.

Interface-id indicates the interface name.

exit

Returns to EXEC mode.

write

Saves configuration.

1.2.2 Configuring MAC Address Aging Time

When a dynamic MAC address is not used during the specified aging time, the switch

will delete this MAC address from the MAC address table. The aging time of the switch

MAC address can be configured in terms of needs. The default aging time is 300

seconds.

Configure the aging time of MAC address in the privileged mode as follows:

Command

Purpose

configure

Enters the global configuration mode

MAC Address Table Attribute Configuration

http://www.level1.com -- 2 -

mac address-table aging-time [0 |

10-1000000]

Configures the aging time of MAC address.

0 indicates no-age of the MAC address.

Valid value is from 10 to 1000000 in seconds.

exit

Returns to the management mode.

write

Saves configuration.

1.2.3 Displaying MAC Address Table

Since debugging and management are required in operation process, we want to know

content of the switch MAC address table. Use the show command to display content of

the switch MAC address table.

Command

Purpose

show mac address-table {dynamic

[interface interface-id | vlan vlan-id] | static}

Displays content of the MAC address table.

Dynamic indicates the MAC address that

acquires dynamically.

Vlan-id indicates the VLAN number. Valid

value is from 1 to 4094.

Interface-id indicates the interface name.

Static indicates the static MAC address table.

1.2.4 Clearing Dynamic MAC Address

The acquired MAC addresses need to be cleared in some circumstances.

Use the following command to delete a dynamic MAC address in privileged mode:

Command

Purpose

clear mac address-table dynamic [address

mac-addr | interface interface-id | vlan

vlan-id]

Deletes a dynamic MAC address entry.

Dynamic indicates the MAC address that

dynamically acquires.

Mac-addr is the MAC address.

Interface-id indicates the interface name.

Vlan-id indicates the VLAN number. Valid

value is from 1 to 4094.
