LevelOne FPC-0104TX Manuel utilisateur
FPC-0104TX
10/100Mbps Fast Ethernet 56K Modem
PC Card
User’s Manual
First Edition (September, 1998)
Second Edition (May, 1999)
II
Document No. M-LF560MA-rev2.0
Printed in Taiwan
-III-
FCC REGULATORY STATEMENTS
FCC Certification
10/100 Fast Ethernet + 56K Fax/Modem PC Card
FCC ID: MQ4PLM56
Made in Taiwan
The United States Federal Communication Commission (FCC) and the Canadian Department of
Communications have established certain rules governing the use of modems and other
electronic equipment.
FCC Part 68 Registration
This high speed FPC-0104TX 10/100Mbps Fast Ethernet 56K Modem PC Card complies with
FCC Part 68 rules, and the use of this modem is subject to the following restrictions:
1. The FCC has established rules which permit this device to be directly connected to the
telephone network. Standardized jacks are used for these connections. This equipment should
not be used on party lines or coin phones.
2. If this device is malfunctioning, it may also be causing harm to the telephone network; this
device should be disconnected until the source of the problem can be determined and until
repair has been made. If this is not done, the telephone company may temporarily disconnect
service.
3. The telephone company may make changes in it's facilities, equipment, operation and
procedures; if such changes affect the compatibility or use of this device, the telephone
company is required to give adequate notice of the situation with the FCC.
4. If the telephone company requests information on what equipment is connected to their
lines, inform them of:
a. The telephone number to which this unit is connected.
b. The Ringer Equivalence Number (REN).
c. The USOC jack required.
d. The FCC Registration number.
Items (b) and (d) are indicated on the label. The Ringer Equivalence Number (REN) is used to
determine how many devices can be connected to your telephone line. In most areas, the sum of
the REN's of all the devices on any one line should not exceed 5.0. If too many devices are
attached, they may not ring properly.
FCC Part 15 Registration
This device complies with Part 15 of FCC rules. Operation is subject to the following two
conditions:
1) This device may not cause harmful interface, and
2) This device must accept any interface received, including interface that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
IV
radiate radio frequency energy, and if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
(1) Reorient or relocate the receiving antenna.
(a) Increase the distance between the equipment and receiver
(b) Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
(2) Consult an experienced radio/TV technician for help.
-V-
TABLE OF CONTENTS
1. INTRODUCTION
1.1 ABOUT THIS MANUAL
1.2 ABOUT THIS PRODUCT
1.2.1 SPECIFICATIONS
1.2.2 FEATURES
1.3 SYSTEM REQUIREMENTS
1.4 CONTENTS INCLUDED IN THE PACKAGE
2.INSTALLATION
2.1 HARDWARE INSTALLATION
2.2 INSTALLING THE SOFTWARE
2.2.1 NOVELL NETWARE
2.2.2 MICROSOFT LAN MANAGER
2.2.3 PACKET DRIVER
2.2.4 WINDOWS FOR WORKGROUPS 3.11
2.2.5 WINDOWS NT 3.51 & 4.0
2.2.6 WINDOWS 95,WINDOWS 98
2.2.7 ARTISOFT LANTASTIC 6.0
3. MODEM BASICS
3.1 UNDERSTANDING AT COMMANDS
3.2 DIALING & ANSWERING TECHNIQUES
4. DRIVERS INFORMATION
4.1 NOTES for NDIS DRIVER
4.2 NOTES for PACKET DRIVER
4.3 NOTES for WINDOWS WORKGROUPS
5. QUESTIONS & ANSWERS
6. APPENDIX A: NDIS2 & ODI DRIVERS for WFW 3.11
7. APPENDIX B: UNINSTALLATION in WIN 98/95
8. APPENDIX C: AT COMMAND SET
-1-
1. INTRODUCTION
1.1. ABOUT THIS MANUAL
This manual will explain how to install and use the FPC-0104TX 10/100Mbps Fast
Ethernet 56K Modem PC Card.
1.2. ABOUT THIS PRODUCT
The FPC-0104TX 10/100Mbps Fast Ethernet 56K Modem PC Card is a multifunction
communication device that lets you perform multiple communication tasks at the
same time:
(1) transmit and receive data up to 56,000 bps
(2) send and receive FAXes from computers or FAX machines
(3) connect to an 10/100 Fast Ethernet LAN
And it uses only one PCMCIA socket while it can provide the functions listed
above.
The FPC-0104TX 10/100Mbps Fast Ethernet 56K Modem PC Card is a credit-card-
size Type II PCMCIA adapter that complies with the PCMCIA 2.1 and JEIDA 4.1
standards and works with computers that incorporate a compatible interface.
It is Bell, ITU-T (formerly CCITT) and Hayes AT commands compatible, allowing it
to be used worldwide with today's popular communication software programs. You
will be able to send and receive faxes with any Group 3 fax machine. Using standard
phone lines and 10/100 Fast Ethernet, the data communication functions of the
10/100 Fast Ethernet + 56K Fax/Modem PC Card will enable you to successfully
access to the servers on 10/100 Fast Ethernet LAN and hook up to the Internet,
transmit E-Mail, send and receive information and communicate with other PCs,
Bulletin Board Services (BBS) or on-line computer networks such as CompuServe
and America On line.
1.2.1. Specifications
PC Card Interface
PCMCIA Type II.
Dimension
3.37” X 2.128” X 0.197” or
85.6 mm X 54 mm X 5 mm
-2-
Weight
60 g
Power
+5V ±5%
Network
IEEE 802.3 10BaseT, 10Mbps.
IEEE 802.3u 100BaseTX, 100Mbps.
NE2000 compatible.
Modem
V.90, K56flex 56Kbps, V.34+ 33.6Kbps, V.34 28.8Kbps, V.32bis 14.4Kbps.
V.42bis/V.42, MNP 2-5 data compression and error correction.
AT command set.
Fax Group 3, V.17 14400bps, V.29 9600bps
Fax Service Class 1 compliant.
Modem COM Port
COM2, COM3, COM4
IRQ
3, 4, 5, 7, 9, 10, 11, 12, 15
I/O Address
220, 300, 320, 340
Features
1. Compatible with most notebook computers and PCMCIA Card and Socket
Service drivers.
2. Integrated PC Card
3. Easy to install and play.
4. Support most of the popular Network Operating Systems.
5. Include popular 56K Fax/Modem communication programs.
6. Hot swappable.
7. Feature concurrent use of 10/100 Fast Ethernet LAN and 56K Fax/Modem.
8. NE2000 compatible.
1.3. SYSTEM REQUIREMENTS
•An IBM compatible PC or notebook computer with 386SX or faster processor
•At least one type II PCMCIA socket
•PCMCIA release 2.1 compliant Card Services and Socket Services
•Drivers and utilities provided with this product
•Driver software loaded on your PC
•Data and/or fax communications software.
-3-
1.4. CONTENTS INCLUDED IN THE PACKAGE
•FPC-0104TX 10/100Mbps Fast Ethernet 56K Modem PC Card
•RJ 11 Phone Cable
•Quick Installation Guide
•Driver Diskettes for PC and Apple/Macnitosh
•Manual Diskette
•Windows-based 56K Fax/Modem application program (CD-ROM)
-4-
2. INSTALLATION
This chapter describes how to install the FPC-0104TX 10/100Mbps Fast Ethernet
56K Modem PC Card. Installation procedures also cover many popular Network
Operating Systems.
2.1. HARDWARE INSTALLATION
1. Hold the card label up and insert the card into the computer's PCMCIA slot
with the 68 pin connector facing the computer.
2. Connect the RJ-45 (8-pin) plug to the LAN and the RJ-11 (6-pin) plug to the
telephone wall outlet.
2.2. INSTALLING THE SOFTWARE
For Non-Windows 95/98 & Non-Windows NT System
Plug the driver diskette into the floppy drive and set the current drive to the floppy
drive (A:\). Then runINSTALL to install the dirver.
