MODEL CD-52

OPERATING INSTRUCTIONS

PLEASE READ CAREFULLY BEFORE USE

PROGRAMMABLE

COMPACT DISC PLAYER

CD52(22C-0E7)022100 NL v.1 E

PLAYS ALL MUSIC COMPACT DISCS

BASS BOOST SYSTEM

6 DIGIT LCD VISUAL DISPLAY

TRACK REPEAT & DISC REPEAT

AC ADAPTOR INCLUDED

DELUXE STEREO HEADPHONES INCLUDED

USES 2 SIZE AA BATTERIES (NOT INCLUDED)

AUX OUT JACK - CONNECTS TO YOUR STEREO SYSTEM

(PATCH CORD NOT INCLUDED)

INTRODUCTION

Your new Lenoxx Sound model CD-52 portable compact disc player, uses the latest

technology to give you crisp clean sound from all your compact discs.

Please read these operating instructions completely to take advantage of all the features

of this set.

ACCESSORIES INCLUDED

AC ADAPTOR STEREO HEADPHONES

LOCATION OF CONTROLS

1. CD DOOR OPEN BUTTON

2. CD DOOR

3. BACKWARD SKIP / SEARCH BUTTON ( )

4. FORWARD SKIP / SEARCH BUTTON ( )

5. STOP AND POWER OFF BUTTON

6. REPEAT/RANDOM BUTTON

7. LCD VISUAL DISPLAY

8. PROGRAM BUTTON

9. PLAY/PAUSE AND POWER ON BUTTON

10. AC ADAPTOR JACK

11. AUX OUT JACK (for home stereo connection)

12. VOLUME CONTROL

13. PHONES JACK (headphone jack)

14. BATTERY DOOR

15. BASS BOOST SWITCH

POWER SOURCES

1.Using with Batteries

TIPS ON BATTERY USE

Reversing polarities will damage the batteries and possibly your set. Be sure to

follow polarity ( + and - ) as indicated.

Do not mix different types together (Alkaline, Carbon-Zinc, Nickel-Cadmium etc.),

or old batteries with new ones.

When not in use for an extended period of time, or while internal batteries will not

be used, remove them to prevent possible acid leakage or corrosion resulting in

damage to your player.

When the batteries have become discharged, they must be disposed of in a safe

manner that complies with all applicable laws.

Installation of batteries should only be done by an adult (for safety).

WHEN THIS SYMBOL FLASHES IN THE DISPLAY

If the alkaline batteries are weak and discharged, this symbol   flashes in the

display, then the power automatically turns off. If this occurs, replace the alkaline

batteries (also if display does not show anything, the batteries are dead).

ALKALINE BATTERY LIFE

Bear in mind that battery life expectancy is based upon volume and bass listening

levels. Maximum battery power consumption happens at maximum settings. Typical

life for 2 size AA alkaline batteries is above 8 hours of continuous use.

Insert two size AA alkaline batteries

according to the + and - markings in

the battery compartment.

NOTE: You may use rechargeable batteries on this set. However, because

rechargeable batteries generally have lower voltage (1.2 volts instead of

1.5 volts). Your playing time will be much less than normal fresh alkaline

batteries.

2.Using AC Power

Your player may be powered from any household 120V AC outlet, using the AC

adaptor included. Insert the adaptors small connector plug into the DC 4.5V Jack

marked on player (on the right side of the set), and plug the adaptor into

an AC outlet.

NOTE: If the AC Adaptor is connected, and regular batteries are installed, the

player automatically switches to the AC Adaptor power and the batteries

are not used.

CAUTION:

To prevent electric shock, do not use this AC Adaptor with an extension cord or

outlet, unless it can be fully inserted without exposing any part of the blades. Do

not use any other AC adaptor to power this set or you may damage your set.

CONNECTING TO HOME STEREO SYSTEMS

The AUX OUT jack is made to accept a stereo mini plug (3.5mm). Simply connect the

cables mini plug to the AUX OUT jack on your player, and the other appropriate end

usually RCA JACKS to the CD/AUX INPUTS of your home stereo.

YOUR

CD PLAYER

TO AUX IN JACKSTO AUX OUT JACK

YOUR STEREO

SYSTEM

OPTIONAL CABLE

3.5mm TO RCA JACKS

CD PLAYING

4Adjust the Volume.

1Load the Disc.

2Connect the Headphones.

3Press the PLAY/PAUSE button.

1234

Push

here

Disc

Label side up Slide right to open

To PHONES jack

Stereo headphones

PLAY/PAUSE

button

TRACK NUMBER

CURRENTLY

PLAYING

ELAPSED PLAYING

TIME OF THE

CURRENT TRACK

TOTAL TRACKS TOTAL PLAYING

TIME ON THE CD

VOLUME CONTROL

MAXIMUM MINIMUM

Other Operations

Operation Press Display window shows

To pause play

To release pause

and resume play

TRACK NUMBER

CURRENTLY PLAYING

PLAYING TIME

FLASHES

TRACK NUMBER

CURRENTLY PLAYING

PLAYING TIME

ADVANCES

To stop

To skip to the next track(s)

To skip to the previous track(s)

once (or repeatedly)

To go ahead at high speed

(search)

Keep depressed and release when the

desired music section of the disc is found.

To go back at high speed

(search) Keep depressed and release when the

desired music section of the disc is found.

BASS BOOST switch

This switch enhances the low frequency (bass)

sounds at low listening levels. Switch this ON or

OFF to suit your taste.

TOTAL TRACKS TOTAL PLAYING TIME

PLAY/PAUSE

button

PLAY/PAUSE

button

STOP button

To turn off the power STOP button once and wait 30 seconds, or press

STOP button twice

BASS BOOST switch

Single Track Repeat

Plays one song over and over till you press STOP.

During play, select the song you want to repeat with

either of the SEARCH buttons ( or ), then press

the REPEAT/RANDOM button once, the symbol

REPEAT

appears in the display.

The song currently playing will repeat over and over,

until you press STOP.

All Tracks Repeat

Repeats all songs in order over and over, till you press

STOP.

During play, press the REPEAT/RANDOM button twice,

the symbol

REPEAT ALL

will show in the display.

All songs will keep playing in sequence 1, 2, 3, etc. and

when finished, will start all over again until you press the

STOP button.

REPEAT, INTRO AND RANDOM PLAY

You may have repeat, intro or random play using the REPEAT/RANDOM button.

Press the REPEAT/RANDOM button several times, and the display will show the

followings in turn:

REPEAT 1 --> REPEAT ALL --> INTRO --> SHUFF (RANDOM) --> NORMAL PLAY

Intro Play

This plays the first 10 seconds of every song in

sequential order.

1. During play, press the REPEAT/RANDOM button

three times, the word

INTRO

will flash in the display.

2. Press the PLAY button, the word

INTRO

will stop

flashing and the first 10 seconds of each song on the

CD will play in sequential order.

3. When you find a song you like, press the PLAY button,

normal play will be resumed, that song (and the

following songs) will play NORMALLY.

Random Play

This plays the songs on the disc in a random order.

1. During play, press REPEAT/RANDOM button four

times, the word

SHUFF

will flash.

2. Press the PLAY button, this will play all of the songs

in random order selected by the CD player. The word

SHUFF

will be steady on.

3. Press the SEARCH button to skip to the next

random song.

REPEAT 1

REPEAT ALL

X 2

INTRO

SHUFF

X 3

X 4

The tracks (songs) on the disc can be programmed (arranged in advance) to play in

any order you prefer (up to 20 tracks can be programmed).

Programming Example:

Program Number 1 2 3 4 5 6 7 8

Track Number (song number) 3 5 8 1 2 4 1 1

etc.

PROGRAM PLAY

During programming, the word

PROG

flashes in the display. To program songs to play

in your preferred order, follow steps below:

1.During play, press the PROGRAM

button.

The word

PROG

will flash in the display.

Program number

2.Press the SEARCH button ( or )

to select track number 3 (example).

PROG

and track number 03 will flash in the

display.

Track number

3.Press the PROGRAM button. Track 3 is

now programmed.

Program #2 will now show in the

display, ready for your next selection of

track.

4.Repeat steps 2 and 3 to program other

tracks till you finish (up to 20 selections).

5.After programming is finished, press

PLAY to begin programmed play.

PROG

changes to be steady on in

the display, and music begins to play in

the order you programmed.

NOTE:

- The player will stop automatically after

all programmed tracks have been

played.

- To quit programmed play, press STOP

button once. Then you may press PLAY

button to re-start normal play.

Your programming will be lost:

When the alkaline batteries are

exhausted or removed, or the AC

ADAPTOR is disconnected.

When the power is shut off or the CD

DOOR is opened.

PROG

Cleaning the cabinet

Wipe with a soft cloth. If the cabinet is

very dirty, dampen (not dripping wet) the

cloth with a weak solution of soapy water,

and then wipe clean.

Cleaning the lens

A dirty lens will cause sound skipping. If

the lens is very dirty, the player may not

work. We suggest using a special

cleaning disk (not included) available in

most music and Hi-Fi stores. However, if

you do not have one, you may use a cotton

swab very slightly dampened with alcohol

to clean the lens.

MAINTENANCE

To remove the Disc

Open the CD DOOR by sliding the DOOR

OPEN button, hold the disc by the edge

while slightly pressing on the center

spindle as illustrated, then lift it from the

edge to release and remove.

Cleaning the Discs

Fingerprints should be carefully wiped

from the surface of disc with a soft cloth.

Unlike conventional records, compact

discs have no grooves to collect dust

and microscopic dirt, so gently wiping

them with a soft cloth should remove

most particles. Wipe in a straight

motion from the center to the edge.

Handling Compact Discs

Dirty, scratched or warped discs may

cause skipping or noise.

Handle the disc only by the edges. To

keep clean, do not touch its surface.

Never use thinner, benzine, record

cleaner or antistatic spray on a compact

disc. Such chemicals can damage its

plastic surface.

Discs should be stored in their cases

after use to avoid scratches.

Do not expose discs to direct sunlight,

high humidity, high temperatures, or

dust, etc. Prolonged exposure to

extreme temperatures can warp the disc

(such as leaving the discs in your car

during summertime).

Do not stick or write anything on either

side of disc. Sharp writing instruments,

or the inks used in some felt-tip pens, may

damage its surface.

NOTE

Always press the STOP button and wait

for the disc to stop rotating before sliding

the DOOR OPEN button to remove the

disc.

Autres manuels pour CD-52

Autres manuels Lenoxx Lecteur CD

Lenoxx

Lenoxx Durabrand CD-56 Manuel utilisateur

Lenoxx

Lenoxx CD-210 Manuel utilisateur

Lenoxx

Lenoxx Durabrand CD-565 Manuel utilisateur

Lenoxx

Lenoxx Durabrand CD-62 Manuel utilisateur

Lenoxx

Lenoxx CD-895 Manuel de l'opérateur

Lenoxx

Lenoxx CD-155 Manuel utilisateur

Lenoxx

Lenoxx CDR-190 Manuel utilisateur

Lenoxx

Lenoxx CDR-1906 Manuel utilisateur

Lenoxx

Lenoxx CD-85 Manuel de l'opérateur

Lenoxx

Lenoxx CD-89 Manuel de l'opérateur

Lenoxx

Lenoxx CD-89 Manuel de l'opérateur

Lenoxx

Lenoxx CD815 Manuel utilisateur

Lenoxx

Lenoxx CD-85 Manuel de l'opérateur

Lenoxx

Lenoxx Street Beat KC-720 Manuel utilisateur

Lenoxx

Lenoxx Durabrand CD-62 Manuel de l'opérateur

Lenoxx

Lenoxx CD-155 Manuel utilisateur

Lenoxx

Lenoxx CD-968 Manuel utilisateur

Lenoxx

Lenoxx CD-87 Manuel de l'opérateur

Lenoxx

Lenoxx CD-625 Manuel de l'opérateur

Lenoxx

Lenoxx CD-61 Manuel de l'opérateur

Lenoxx

Lenoxx CD-511 Manuel utilisateur

Lenoxx

Lenoxx CD-78 Manuel utilisateur

Lenoxx

Lenoxx CD-50 Manuel utilisateur

Lenoxx

Lenoxx Durabrand CD-565 Manuel de l'opérateur

Manuels Lecteur CD populaires d'autres marques

RCA

RCA RP-7923 Manuel utilisateur

Pioneer

Pioneer DEH-P3550MP XM Manuel utilisateur

Philips

Philips AZ1207 Manuel utilisateur

Philips

Philips CD582 Manuel utilisateur

Philips

Philips AZ 6821 Manuel utilisateur

Lasonic

Lasonic MSU-2020 Manuel utilisateur

THOMSON

THOMSON RCD150 Manuel utilisateur

Denon

Denon DCD-1420 Manuel utilisateur

Panasonic

Panasonic SJ-MR100 Manuel utilisateur

Onkyo

Onkyo DX-7210 Manuel utilisateur

Sony

Sony MZ-R3 Manuel utilisateur

Denon

Denon DVM-4800 Manuel utilisateur

JBL

JBL MR-32 Manuel utilisateur

RCA

RCA RCD152 Manuel utilisateur

Technics

Technics SL-PS770A Manuel utilisateur

Clarion

Clarion compact disc Manuel utilisateur

Sony

Sony MZ-M10 Manuel utilisateur

Philips

Philips Expanium AZ 1538 Manuel utilisateur
