LENCO XEMIO-857 Manuel utilisateur

XEMIO-857

MP4 PLAYER / TOUCH SCREEN

User manual

English

For information and support, www.lenco.eu

1. Basic controls and interfaces of the player

Item

Description Item

Description

1 Microphone (mono) 7 Button

2 Power On/Off, Hold (Key Lock) 8 Memory Card Slot (Micro SD Card)

USB Port (PC Connection / Charge)

9 TFT Display (Touch Function)

4 MButton (Exit, Back to desktop menu) 10 Reset (Built-In Tact Switch)

5 Earphone Output Jack (3.5mm Stereo)

11 Mini Speaker (mono)

6 Button

2. Internal Battery

The player has an internal battery. When using the unit for the first time, charge it for 3 hours

or until the battery icon is show the battery is in full.

Note: The player continues to use battery power after it’s been turned to off, if unit isn’t used for a

while, the battery might need to be charged.

3. Connection and Charging

•Once you have connected player with computer / Power charger, then you will see the

“Opening” > “Connect” or “Charging” screen.

•In connect screen, the battery is in charging at background.

•In charging screen, the bar levels are running in battery icon, the battery is in charging.

•The battery icon will show “Full” when the charging is completed. Disconnect it when it is

done.

Connect Screen Charging Screen Battery Is In Full

Important: The battery cannot be charged when your computer is in sleep mode. The USB port on

most keyboards does not provide enough power to charge the player. Connect player direct to a

USB port on your computer only to prevent charging problem.

4. Connecting and disconnecting the player

Connect the player to your computer to upload media files to your player; or to download

recorded voice memos to your computer.

Connecting the player

•Plug the USB cable to the Player’s mini USB port and into a USB port on your computer, then

the computer will detect and install the driver automatically. Once the installation is complete

the player will be displayed in “My Computer” or for MAC users on the desktop.

•Now the player is ready for music files upload / download with your computer.

•Transfer the media files by using the computer mouse use drag and place, or copy and paste, in

between the player and your computer. Disconnect it when you’re done.

Disconnecting the player

•Do not disconnect the player while it’s uploading or downloading files with your computer.

•Windows system PC, disconnect the player by clicking the “Safely Remove Hardware” icon in

the Windows system tray.

•Mac system PC, disconnect the player by dragging the player icon on the desktop to the Trash.

•Now it is safe to unplug the USB cable.

Note: If you do not “Safely remove hardware” before disconnecting, data can be lost!

5. File Storage

Player will create some default folders, in the internal flash memory, when you use it. However,

for best result, this is recommended you to put files of different types to store under different

directories.

For example, music file should be stored under MUSIC dir. Record file stored under RECORD

directory. Picture files under PICTURES directory. Video files VIDEO directory. Text files TXT

directory. The corresponding application may unable to find the file If it is not saved in this way.

6. Getting Started

This player is equipped with a touch screen so you can choose the items or functions by

tapping the related icons or files.

Turning the player ON and OFF

•Slide the power switch to “ON/OFF” position and hold it for 3 seconds to turn the player On

and Off.

•When the player is turning to On, first the opening screen and then desktop menu will appears

to use, the “generating database” message are display at same time. Now the player is ready to

use.

•Turn OFF the player when you’re not uses it for a longer period.

Desktop Menu

Every time you turn on the player, you will see the opening screen followed by the desktop

menu which contains applications of your player. Tap one of the application icons to open it.

Desktop Menu

Player Applications

Icon caption Description

Music

Listen to your songs. Create play list. Listen songs in Artists / Albums /

Genre play lists from your music library.

Video

View your favorite Video / Movie files.


View your favorite photos and watch them use slide show function.

Text

Watch your favorite book. Add tag and pick tag. Selecting favorite page

to view.

NOTE: This function only supports .txt files.

Record

Record voice memos with built-in microphone. Playback them on player

or save them to your computer.

Explorer

Browse all type of supported media files and direct selects your favorite

media file to play. Manage to delete those unwanted media files direct

from the player.

Radio

Listen to the radio stations. Set region, search stations by auto / manual

search function, preset / delete stations and FM record.

Game

Provides a little bit of fun.

Settings

Adjust player’s setting; Set time, OSD languages, Display light up time

and brightness, Set power off mode and more……

General Icon / Button Function In Operation Interface

Button / Icon Description

Return to upper directory

Browse particular application file

Return to desktop menu

Delete file or file folder

Return to previous operation interface

M Button Exit application and back to desktop menu

Button Volume up

Button Volume down

7. Music Mode

•Tap the “Music” icon; you will now enter the music mode menu as below.

Play / Pause / Stop Music file

•To play music, tap / icon and icon will change into , the music is playing.

•To pause the play, tap icon and it will change into , the music is pause.

•The icon will change into after songs playing are finished as per your default setting.

Change Next / Previous and Fast-Forward / Fast Backward

•Tap icon to play next file.

•Tap icon to play previous file.

•Tap and hold icon to play fast-forward.

•Tap and hold icon to play fast-backward.

•Or, drag the playing progress bar to adjust the progress.

Change Volume

•Press or press and hold / button to increase / decrease volume levels.

•Or, direct tag the volume bar to adjust the volume levels.

Change Play Mode

•Tap / icon to switch to the in-order play / shuffle play.

Change EQ Mode

•Tap / / / / / / icon to switch the EQ mode.

Repeat Mode

•Tap / / / / icon to switch the repeat mode.

Note: Icon(s) = Repeat File Once, = Repeat File, = Repeat All, = Repeat

All Once, = Intro (10 seconds)

Choose Songs in All Music / ID3 List / Play List / Tag List

In music mode:

•Tap icon, a submenu is appears to choose.

•Tap “All Music” to enter the play list containing all audio files. Then choose a desired file to

play.

•Tap “ID3 List” > “Artist” to enter the play list sorted by artist. Tab on the artists name to

display a playlist containing all songs from this artist. Then choose you desired file to play.

•Tap “ID3 List” > “Album” to enter the play list sorted by the album name. Tab on the album

name to display a playlist containing all songs from this album. Then choose you desired file to

play.

•Tap “ID3 List” > “Genre” to enter the play list sorted by the genre name. Tab on the genre

name to display a playlist containing all songs from this album. Then choose you desired file to

play.

•Tap “Play List” then choose “My Music List 1 / 2 / 3 / 4 / 5” to enter to your desired play list

which you have created and then choose a file to start the play. Those songs in play list will

play one by one.

•Tap “Tag List”, your tag music / voice file list is appears for choose, and then choose your

desired file to play.

Note: “All Music” and “ID3 List” functions are works only for music file(s) which have stored at

(Main Dir) internal memory.

Change / Choose Music Folder (From Flash / Card Memory)

•Tap icon, a sub-menu is appears to choose.

•Tap “Main Dir / Card Dir”, a list screen appears to use. Choose a folder name which contains

music file and choose your desired file to play. If you choose a folder name which have no

supported music file, then the list will be show blank. Choose another folder.

•And then choose a file you want to play.

•Tap icon to back to music mode.

Note: “Card Dir” will not show folder and file when the Micro SD card is not installed to player.

Add Play List

This player allows you to add the current playing music, if you want to put it group together,

into the play list. Then you can play this group in next when you choose song(s) by using the tag list

function which is mentioned above.

•Tap icon, a sub-menu is appears to choose.

•Tap “Add List” and then choose “My Music List 1 / 2 / 3 /4 /5” where you like them to group.

The submenu will disappears and the music is stored into you desired list number.

Add Tag List

This player also allows you to add tag in the current playing music / voice, if you want to mark

the track time, into the tag list. Then you can playback and recall the marked track time of music /

voice file(s) in next when you choose song(s) by using the play list function which is mentioned

above.

•Tap icon, a sub-menu is appears to choose.

•Tap “Add Tag”, a “marked” pop up window appears for 1 – 2 seconds. The playing file name

with track time is marked and saved into tag list. And now you can add another tag in same

song or add tag for other play song if you want.

View File Information

•Tap icon, an information screen is appears to view, all the information of file will

displayed if they have included in file.

•Tap icon to back to music mode.

Lyric / Artist and Album info Display

This player can be display the lyrics at the middle area of the TFT screen if the playing music

file is included lyrics information. However, the Artist and Album information will be displayed if

no lyrics are available in the playing music.

8. Video Mode

Play Video

•Tap “Video” icon to enter video mode. Tap “Main Dir / Card Dir” which will appears, when

the Micro SD Card is in used. A list screen appears to use. Choose a file to start the play. Or,

•Choose a folder name which contains Video file and choose your desired file to play. If you

choose a folder name which have no supported Video file, then the list will be show blank.

Choose another folder.

•Tap a video file to start the play.

Video Mode Interface

To Call the Video Tools Menu

•Tap any where on the touch screen, the video tools menu will display to use for 3 seconds.

•Tap icon to back to file list screen.

Use Play / Pause

In video tools menu:

•To pause the play, tap icon and it will change into , the video is pause.

•To play the video again, tap icon and icon will change into , the video is continues

to play.

Change Next / Previous and Fast-Forward / Fast Backward

In video tools menu:

•Tap icon to play next file.

•Tap icon to play previous file.

•Tap and hold icon to play fast-forward.

•Tap and hold icon to play fast-backward.

•Or, drag the playing progress bar to adjust the progress.

Change Volume

•Press or press and hold / button to increase / decrease volume levels and the video tools

menu also is appear in screen to use for 3 seconds.

•You also can direct tag the volume bar to adjust the volume levels

before the video tools menu is disappear.

In video tools menu:

•Tap icon, then direct tag the volume bar to adjust the volume

levels before the video tools menu is disappear.

Change Folder

•Tap icon, a sub-menu is appears to choose.

•Tap “Main Dir / Card Dir”, a list screen appears to use. Choose a folder name which contains

video file and choose your desired file to play. If you choose a folder name which have no

supported video file, then the list will be show blank. Choose another folder.

Note: “Card Dir” will not show folder and file when the Micro SD card is not installed to player.

Add Tag List

•Tap icon, a “marked” pop up window appears for 1 – 2 seconds. The playing file name

with track time is marked and saved into tag list. And now you can add another tag in same

song or add tag for other play song if you want.

Play Tag List

•Tap icon, a sub-menu is appears to choose.

•Tap “Tag List”, your tag video file(s) list is appears for choose, and then choose your desired

file to play.

9. Photo Mode

•Tap “Photo” icon to enter to photo browse mode. Tap “Main Dir / Card Dir” which will

appears, when the Micro SD Card is in used. A list screen appears to use. Choose a file to start

the play. Or,

•Choose a folder name which contains Photo file and choose your desired file to play. If you

choose a folder name which have no supported photo file, then the list will be show blank.

Choose another folder.

•Tap a file to start the play.

•Tap icon to change icon view list to file list view list, this will get the quicker

response to list out all photo file by name for choose.

Icon View File List View

•Tap and hold on the lower / upper side position in list screen, the list files will move down / up

one by one. Chose a desired file to play.

To Call the Photo Tools Menu

•Tap any where on the touch screen of TFT display, the photo tools menu will display to use for

3 seconds.

•Tap icon to back to file list screen.

Change Next / Previous photo file

In photo tools menu:

•In photo browsing mode, tap screen to call up the photo tools menu.

•Tap icon to play next file.

•Tap icon to play previous file.

Autres manuels LENCO Lecteur MP3

LENCO

LENCO Xemio-1000 Manuel utilisateur

LENCO

LENCO Xemio-645 Manuel utilisateur

LENCO

LENCO Xemio-767 BT Manuel utilisateur

LENCO

LENCO XEMIO-955 Manuel utilisateur

LENCO

LENCO Xemio-560 Manuel utilisateur

LENCO

LENCO HELLO KITTY MP3 Manuel utilisateur

LENCO

LENCO XEMIO-760 BT Manuel utilisateur

LENCO

LENCO XEMIO-119 Manuel utilisateur

LENCO

LENCO XEMIO-360 W Manuel utilisateur

LENCO

LENCO Xemio-280 Manuel utilisateur

LENCO

LENCO Xemio-768 Manuel utilisateur

LENCO

LENCO SCD-38 USB Manuel utilisateur

LENCO

LENCO Xemio-767 BT Manuel utilisateur

LENCO

LENCO XEMIO-SPORT-222 Manuel utilisateur

LENCO

LENCO Xemio-659MIX Manuel utilisateur

LENCO

LENCO XEMIO-760 BT Manuel utilisateur

LENCO

LENCO SCR-1000 Manuel utilisateur

LENCO

LENCO SCD-651 Manuel utilisateur

LENCO

LENCO MP CARD Manuel utilisateur

LENCO

LENCO Xemio 756 Manuel utilisateur

LENCO

LENCO XEMIO-654 Manuel utilisateur

LENCO

LENCO CD-3772 MP3 Manuel utilisateur

LENCO

LENCO Xemio-154GY Manuel utilisateur

LENCO

LENCO XEMIO-261 Manuel utilisateur

Manuels Lecteur MP3 populaires d'autres marques

Blaupunkt

Blaupunkt Compact Drive MP3 Manuel utilisateur

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manuel utilisateur

Meizu Electronic Technology

Meizu Electronic Technology E5 Manuel utilisateur

Naxa

Naxa NMV-173NX Manuel utilisateur

Philips

Philips PSA250 Manuel utilisateur

Zipy

Zipy go! Waving Manuel utilisateur

Sylvania

Sylvania SMPK4068 Manuel utilisateur

Sony

Sony NW-MS7 - Memory Stick Walkman Manuel utilisateur

Irradio

Irradio RF-42UC Manuel utilisateur

NABAIJI

NABAIJI SWIM MUSIC 100 Manuel utilisateur

Laser

Laser MP3-A9-4GB Manuel utilisateur

Samsung

Samsung YP-T7F Manuel utilisateur

Savant

Savant SMS-1001-00 Guide de référence rapide

Trevi

Trevi XP 71 BT Manuel utilisateur

AGPtek

AGPtek C2 Manuel utilisateur

MobiBlu

MobiBlu DAH-1500i Manuel utilisateur

Denver

Denver MPS-201 Manuel utilisateur

Steren

Steren MP3-002 Manuel utilisateur
