LENCO MMS-201 Manuel utilisateur

MMS-201

MP3 Player Speaker Box Set

User manual

English

For information and support, www.lenco.eu

1. Basic controls and interfaces of the player

Item

Description Item Description

1 Speaker

(Mono)

9 Button

(Volume Up)

2 Button

(Play/ Pause, Power On/Off)

10 LCD Display

3 MENU Button (Menu / Enter) 11 Memory Card Slot

(SD Card)

4 REC Button

(Record, Record Stop and Save)

12 USB Port

(for USB Disk)

5 MODE Button

(Change mode)

13 Mini USB Port

(PC Connection / Charge)

6 Button

(Back, Fast-Backward, Down)

14 Battery Compartment

7 Button

(Next, Fast-Forward, Up)

15 Line In Jack

8 Button

(Volume Down)

16 Earphone

2. Detachable Rechargeable Battery

The player comes with a detachable rechargeable lithium battery. When using the device for

the first time, charging it for 3 - 4 hours or until the battery icon is show the battery is in full.

Battery Is In Full

A. Install the Rechargeable Battery:

•Open the cover door of battery compartment which located at the back of the player. And then

place the rechargeable lithium battery into battery compartment.

•Make sure contact plate is inserted into the pins connector correctly.

•Close the cover door.

Note: The player continues to use battery power after it’s been turned to off, if unit isn’t used for a

while, the battery might need to be charged.

B. Charging the Battery:

You can charge the player battery in two ways:

•Connect player to your computer.

•Use the USB power charger. (not included)

C. Connection and Charging:

•Once you have connected player with computer / Power charger, then you will see the

“Connecting Mode” or any one of the “Mode” screen on LCD display.

•In connect / mode screen, you can see the bar levels are running in battery icon, the battery is

in charging.

•The battery icon will show “Full” when the charging is completed. Disconnect the USB cable

when it is done.

Connecting Mode Screen

Important: The battery cannot be charged when your computer is in sleep mode. The USB port on

most keyboards does not provide enough power to charge the player. Connect player direct to a

USB port on your computer only to prevent charging problem.

3. Insert Micro SD Memory Card / USB Disk

MMS-201 is design without an internal memory, it need to have a USB disk or a SD memory

card insert into the USB port or the card slot. Upload your desired music files to the USB disk / SD

memory card direct from the computer then insert to player.

Important: When both SD card and / or the USB disk have inserted to device and the device is

connected to the computer by uses the USB cable; only a “Removable Driver” of SD card can be

detected and use for data transfer with the computer. Due to the same data pins are used as sharing

in-between the mini USB and the computer, the USB disk is cannot be detected and use for data

transfer.

•“Card/USB is pulled” message will show when you remove the SD memory card / USB disk

from player.

•“Format Error” message may show when you insert the SD memory card / USB disk in not

good way or incorrectly. Take them out and plug them in again.

•“No file in disk” message will show, if you do not put Micro SD memory card / USB disk into

the player’s memory card slot / USB port, when you want to change mode to music play.

Note: The player functional may dead halt if you plug and unplug the card or USB incorrectly.

Power reset the player by take out the rechargeable battery if happened.

4. Connecting and Disconnecting

Connect the player to your computer to upload music files to your player, or to download

recorded voice memos to your computer, when the SD memory card or USB disk is in use.

A. Connecting the player

•Plug the USB cable to the Player’s mini USB port and into a USB port on your computer, then

the computer will detect and install the driver automatically. Once the installation is complete

the player will be displayed in “My Computer” or for MAC users on the desktop.

•Now the player is ready for music files upload / download with your computer.

•Transfer the music files by using the computer mouse use drag and place, or copy and paste, in

between the player and your computer. Disconnect it when you’re done.

Note: The player will disconnect with PC and go into clock display mode or operation mode, when

press / Pressing “MENU” button if in connecting mode. Unplug the USB cable and plug it in again

to return to connecting mode if you want.

B. Disconnecting the player

•Do not disconnect the player while it’s uploading or downloading files with your computer.

•Windows system PC, disconnect the player by clicking the “Safely Remove Hardware” icon in

the Windows system tray.

•Mac system PC, disconnect the player by dragging the player icon on the desktop to the Trash.

•Now it is safe to unplug the USB cable.

Note: If you do not “Safely remove hardware” before disconnecting, data can be lost!

5. Getting Started

A. Turning the player ON and OFF

•Press and hold button to turn the player “On and Off”.

•When the player is turned On, first the opening screen and then it will enter to “Radio / Music

/ Line In” mode which is available.

•Example, the player will enter to Radio mode, if no SD memory card and USD disk is in use.

•When you turn Off the player, the last status will be recorded and the last status shall be recall,

when you start up the player again.

Note: The last status memory will be changed if you have take away the SD memory card and / or

USB disk.

B. Change Function Mode

•Press the “MODE” button to change to “FM Radio or Music” function mode here is in easily

way.

C. Auto Mode

•The player has designed “Auto Mode” function, the player will direct switch to related mode,

when you plug in the source of SD memory card, USB disk or Line In cable. This means that

the mode will change according to the last source have plugged.

D. Enter to Clock Display and Mode Menu

•In function mode, press and hold the “MENU” button to enter to clock display and mode menu,

then you will see the clock is displaying.

Clock Display

•In clock display mode, press “MENU / / / ” button will enter to mode menu.

•Then you can find “Calendar / Music / Recorder / FM Radio / System” mode menu here to

choose. Press / button to select your desired mode and press “MENU” button to

enter.

Mode Menu

Note: In menu mode, Press button to back to previous item / menu, press “MENU” button to

enter the selected item. Press and hold “MENU” button to return to “Clock Display” mode.

E. Mode Menu

Calendar

•In mode menu, choose “Calendar” to view the Year, Month, Date and Time” in one screen.

Music

•In mode menu, choose “Music” to enter to music mode.

Recorder

•In mode menu, choose “Recorder” to enter to record mode.

FM Radio

•In mode menu, choose “FM Radio” to enter to radio mode.

System

You might need to set some settings for player’s system, such as date and time…etc.

•In Clock Display mode, press “MENU” button to enter to mode menu.

•In mode menu, press / button to select “System”, a system settings menu is appears

to use.

a. System Time

•In system settings menu, choose “System Time” by using / button and then press

“MENU” button, a date & time setting screen appears to use.

•Press “MENU” button to change the highlight to year, and then adjusting the number to

current year by pressing the / button.

•And, repeating the adjusting methods by “MENU” and / button again for finished

those items; Month, Date, Hour, Minute and seconds setting adjustment.

•Finally, you need to press the MENU button to confirm the adjustment and back to system

menu.

b. Backlight

You can set the backlight to illuminate the screen for a certain amount of time as you desired

or make the backlight to always ON when every time you turn ON the player.

•In system settings menu, choose “Backlight”, a level bar with number appear, choose “0

(always On) / 3 / 6 / 9 / 12 / 15 / 18 / 21 / 24 / 27 / 30 (seconds)” as you desired by using

“MENU” and / buttons.

•Choose “0” to prevent the LCD backlight from turning to off. Choosing this option will

decrease battery performance.

c. Language

This player can use difference languages.

•In system settings menu, choose “Language” and then choose your desired OSD language.

d. Tool

In system setting menu, choose “Tool”, then you will see the tool menu is appear to use.

Power Off Set (Sleep)

The “Power Off Set” provides sleep function, countdown timer, to turn Off the device as you

desired time which set.

•In Tool menu, choose “Power Off Set”, a levels bar with number menu appear, then choose

“10 / 20 / 30 / 40 / 50 / 60 / 70 / 80 / 90 / 100 / 110 / 120 (minutes)” as you want by using

MENU and / buttons.

Alarm

In tool menu, choose “Alarm”, then you will see the alarm menu is appears to use.

- Alarm Off / Alarm On-

•Once you choose “Alarm”, then you will see either one of them “Alarm Off / Alarm On” is

display. It will switch to “Alarm Off / Alarm On”, when every time you’re choosing one of

them and press MENU button.

•The “Alarm Off” is disabling the alarm wake up function.

•The “Alarm On” is enabling the alarm wake up function by the selectable alarm signal

“default ringing tone” or your desired MP3 file.

- Time –

•Choose “Time” to set the alarm time as you want.

- Cycle -

•Choose “Cycle” > choose “Every Day / One Time / Cycle”, the alarm wake up cycle as you

want.

- Alarm Signal - (wake up sound by ringing tone / music file)

•Choose “Alarm Signal” > choose “Ring Embedded / Card Folder / USB Folder / Exit” as you

want.

•Choose “Ring Embedded” to have the default ring tone signal as wake up sound.

•The Card Folder item will exist when SD memory card is in use. Choose “Card Folder” >

folder and WMA/MP3 file which you want it as wake up sound.

•The USB folder item will exist when USB disk is in use. Choose “USB Folder” > folder and

WMA/MP3 file which you want it as wake up sound.

•Choose Exit to exit from Alarm Signal menu and back to previous menu.

•Press MENU button to turn Off the activated wake up ringing tone / music sound.

- Volume - (wake up sound level)

•Choose “Volume” to set wake up alarm signal / sounds level, a levels bar with number menu

appear, adjust the volume level what you want.

- Exit -

•Choose this to exit from Alarm menu and back to previous menu.

Note: The alarm duration time is 10 minutes.

Time FM Set

- Close Time FM / Open Time FM - (wake up by FM Radio)

•Once you choose “Time FM Set”, then you will see either one of them “Open Time FM /

Close Time FM” is display. It will switch to “Open Time FM / Close Time FM”, when every

time you’re choosing one of them and press MENU button.

•The “Open Time FM” is enabling the timer function to turn On the FM radio as alarm ring

sounds.

•The “Close Time FM” is disabling the timer function.

- Close FM Record / Open FM Record – (FM radio Timer Record)

•Once you choose “Time FM Set”, then you will see either one of them “Open FM Record /

Close FM Record” is display. It will switch to “Open FM Record / Close FM Record”,

when every time you’re choosing one of them and press MENU button.

•The “Open FM Record” is enabling the timer function to turn On the FM radio and FM record

function.

•The “Close FM record” is disabling the timer function.

- FM Time –

•To set the alarm time for FM radio, choose FM Time > choose “Hour and Minute” what time

as you desired to turn On the FM radio.

- Tuner Region-

•Choose “Tuner Region” > choose “Common Band / Japan Band”, and then selects the known

frequency of radio station which will be recording, and will be used as wake-up radio station of

“Time FM Set”, when the set alarm time coming.

- Exit-

•Choose this to exit from Time FM Set menu and back to previous menu.

Exit

•Choose “Exit” to exit Tool menu.

e. Contrast

•In system menu, choose “Contrast”, a level bar with number appear, choose “1 – 15” as you

desired by using “MENU” and / buttons.

f. Firmware Version

•Choose “Firmware Version” to view the firmware information.

g. Default Setting

•Choose “Default Setting” to enter to reset function, a confirm dialog box is appear, press

/ buttons to select “Yes / No”.

•Choose “Yes” to confirm and all changed system settings will back to factory default. Choose

“No” to cancel.

h. Exit

•Choose “Exit” to back to Clock Display mode.

6. Music Mode

•Press the “MODE” button to switch to the “Music” mode, the music will player automatically.

A. Play / Pause Music file

•Press button to pause the playing music.

•Press button again to play if in pause mode.

B. Change Next / Previous and Fast-Forward / Fast Backward

•Press button to play next file.

•Press button to play previous file.

•Press and hold button to play fast-forward.

•Press and hold button to play fast-backward.

C. Change Volume

•Press / pressing the / button to increase / decrease volume levels.

D. Lyric / ID3 info Display

•The ID3 information of the title, artist and album are displaying on LCD screen, when the

playing of normal music.

•The lyrics are displays automatically, when the lyrics file is available and synchronize with the

playing music.

7. Music Submenu in Music Playing Mode

•Press MENU button to call up the music submenu, and then the submenu “Cycle Mode / EQ

Settings / Repeat Mode / Back / Exit” is appear to use. (for 8 – 10 seconds)

•Press / button to choose one of them and then press MENU button to entering.

A. Cycle Mode:

•Choose cycle mode, then choose “Normal / Repeat One / Folder / Repeat Folder / Repeat

All / Intro” as you want.

B. EQ Settings:

•Choose EQ mode, then choose “Natural / Rock / Pop / Classic / Soft /Jazz / DBB” as you

want.

C. Repeat Mode: (Repeat A – B)

•Choose replay mode, then a letter “A” is flashing at a icon in LCD, then press button to

select the starting point of track “A”.

•And then a letter “B” is flashing once “A” is selected, use button again to select the

ending point of track “B” which you want by using button. And now the A – B distance of

track is repeating. (it will repeat for few time and then will back to normal play)

•To create another A – B distance of track to repeat, press button again and then again. a

new created A – B distance of track is repeating.

•To cancel the repeat A – B function, press the MEMU / button.

D. Exit:

•Choose “Exit” to back to music mode screen

8. Music Submenu in Music Stop Mode

•Press MENU button to call up the music submenu, and then the submenu “Card Folder / USB

/ Delete / Delete All / Exit” is appear to use. (for 8 – 10 seconds)

•Press / button to choose one of them and then press MENU button to entering.

A. Card Folder:

•Choose Card folder to changes / selects where the folder and file is going to play.

B. USB Folder:

•Choose USB folder to changes / selects where the folder and file is going to play.

C. Delete File:

•Choose delete file to delete the current music file, a dialog box appears to confirm. And then

press / to choose “Yes / No” then press MENU button.

D. Delete All:

•Choose delete all to delete all music files, a dialog box appears to confirm. And then press

/ to choose “Yes / No” then press MENU button.

E. Exit:

•Choose exit to back to music mode screen

Note: The sub-item of the “Card Folder / USB Folder” will not appear, if no USB / SD memory

card has plugged onto the related port / slot.

9. FM Radio

A. FM Antenna and Earphone

•This player in-built a high performance “Coil Antenna” for FM radio us, so you can receives

FM radio stations available if they are in normal signal strength.

•In the case that some FM stations under an area of low signal strength, you can try to use

earphone, plug it into earphone jack, acts like an antenna that can enhance the FM signal. But,

you can only enjoy FM radio sounds from earphone.

B. Radio Function

•Press the “MODE” button to switch to the “Radio” mode.

Autres manuels pour MMS-201

Autres manuels LENCO Lecteur MP3

LENCO

LENCO XEMIO-SPORT-232 Manuel utilisateur

LENCO

LENCO XEMIO-244 Manuel utilisateur

LENCO

LENCO WATER PROOF SPHERICAL USB Manuel utilisateur

LENCO

LENCO XEMIO-732 R Manuel utilisateur

LENCO

LENCO XEMIO-732 R Manuel utilisateur

LENCO

LENCO XEMIO-654 Manuel utilisateur

LENCO

LENCO Xemio-645 Manuel utilisateur

LENCO

LENCO Xemio 756 Manuel utilisateur

LENCO

LENCO XEMIO-149 Manuel utilisateur

LENCO

LENCO Xemio-154PK Manuel utilisateur

LENCO

LENCO Xemio-861BU Manuel utilisateur

LENCO

LENCO XEMIO-107 Manuel utilisateur

LENCO

LENCO Xemio-659MIX Manuel utilisateur

LENCO

LENCO Xemio-668 Manuel utilisateur

LENCO

LENCO XEMIO- 955 Manuel utilisateur

LENCO

LENCO SCD-39 USB Manuel utilisateur

LENCO

LENCO MP CARD Manuel utilisateur

LENCO

LENCO Xemio-1000 Manuel utilisateur

LENCO

LENCO XEMIO-115 Manuel utilisateur

LENCO

LENCO XEMIO-261 Manuel utilisateur

LENCO

LENCO XEMIO-633 Manuel utilisateur

LENCO

LENCO SCD-651 Manuel utilisateur

LENCO

LENCO CD-200 Manuel utilisateur

LENCO

LENCO XEMIO-119 Manuel utilisateur

Manuels Lecteur MP3 populaires d'autres marques

Blaupunkt

Blaupunkt Compact Drive MP3 Manuel utilisateur

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manuel utilisateur

Meizu Electronic Technology

Meizu Electronic Technology E5 Manuel utilisateur

Naxa

Naxa NMV-173NX Manuel utilisateur

Philips

Philips PSA250 Manuel utilisateur

Zipy

Zipy go! Waving Manuel utilisateur

Sylvania

Sylvania SMPK4068 Manuel utilisateur

Sony

Sony NW-MS7 - Memory Stick Walkman Manuel utilisateur

Irradio

Irradio RF-42UC Manuel utilisateur

NABAIJI

NABAIJI SWIM MUSIC 100 Manuel utilisateur

Laser

Laser MP3-A9-4GB Manuel utilisateur

Samsung

Samsung YP-T7F Manuel utilisateur

Savant

Savant SMS-1001-00 Guide de référence rapide

Trevi

Trevi XP 71 BT Manuel utilisateur

AGPtek

AGPtek C2 Manuel utilisateur

MobiBlu

MobiBlu DAH-1500i Manuel utilisateur

Denver

Denver MPS-201 Manuel utilisateur

Steren

Steren MP3-002 Manuel utilisateur
