LELY COSMIX S Guide de configuration

Installation and Operator Manual

5.2309.8509.0 A

EN –English Original

LELY COSMIX S

Concentrate Feeder

INTENTIONALLY BLANK

5.2309.8509.0 A

TRADEMARKS, COPYRIGHT AND DISCLAIMER 1

TRADEMARKS, COPYRIGHT AND DISCLAIMER

Lely, Astronaut, Astri, Atlantis, Attis, AWS, C4C, Calm, Caltive, Commodus,

Compedes, Cosmix, Discovery, F4C, Fertiliner, Gravitor, Grazeway,

Hibiscus, Hubble, Juno, L4C, Lely Center, Lelywash, Lotus, Luna, Nautilus,

Orbiter, Quaress, Qwes, SAE, Shuttle, Splendimo, Storm, T4C, Tigo, Vector,

Viseo, Voyager, Walkway and Welger are registered trademarks of the

Lely Group.

The right of exclusive use belongs to the companies of the Lely Group. All

rights reserved. The information given in this publication is provided for

information purposes only and does not constitute an offer for sale.

Certain products may not be available in individual countries and

products supplied may differ from those illustrated. No part of this

publication may be copied or published by means of printing,

photocopying, microfilm or any other process whatsoever without prior

permission in writing by Lely Holding S.à r.l. Although the contents of this

publication have been compiled with the greatest possible care, Lely

cannot accept liability for any damage that might arise from errors or

omissions in this publication.

The English language manual is the original manual. Translations into

other languages use the English language manual as the source

document. Lely accepts no liability for discrepancies between the original

English language manual and versions in other languages. If there is a

conflict over the content and accuracy of any translated manual, the

English language manual is the authority document.

Lely Industries N.V.

Cornelis van der Lelylaan 1

3147 PB Maassluis

the Netherlands

Phone: +31 (0)88 1228221

Fax: +31 (0)88 1228222

Website: www.lely.com

INTENTIONALLY BLANK

5.2309.8509.0 A

2 TRADEMARKS, COPYRIGHT AND DISCLAIMER

5.2309.8509.0 A

LIST OF INCLUDED AMENDMENTS 1

LIST OF INCLUDED AMENDMENTS

No:

Issue Date

(yy/mm) Chapter(s) Remarks

3 15/07 All •Long distance (LD) tag functionality added: machine

5.2309.0040.x

•Installation of the rear fences changed

•Adjustment of the photocell (H/HR models) added

•Feed presence sensor removed

•Pressure reducer added to control unit

•Several other minor updates

2 11/06 3 Capacity adjusted

111/01 3 Dimensions adjusted

4Descriptions feed presence sensor and Qwes leg ID reader

added

Operation section rewritten

5Installation procedures feed presence sensor and Qwes leg ID

reader added

8Adjustment procedures Qwes leg ID reader added

Glossary of

Terms

Terms added

10/04 Initial issue

INTENTIONALLY BLANK

5.2309.8509.0 A

2 LIST OF INCLUDED AMENDMENTS

5.2309.8509.0 A

WARRANTY RESTRICTIONS 1

WARRANTY RESTRICTIONS

Excluded from this warranty are any cost or expenses due to:

•Abnormal use of the equipment which is not according to the

specifications stated in the Operator Manual or handled during the

Operators Service and Maintenance Certification program.

•The result of any intervention by technicians other than Lely service

technicians or technicians who have Lely’s approval to perform certain

duties.

•Incidents such as freezing, ice, fire, flood, inundation or any other

form of excessive water, lightning.

•Defect of the electrical system or grounding.

•Use of compressed air that does not meet the quality standards set by

Lely Industries.

•Damage to the electrical system as a result of vermin or the like.

•For USERS that have followed the Operators Maintenance and Service

Certification: Any damage resulting from abnormal use of the

equipment which is not according to the specifications stated in the

Operator Technical Training Manual is not covered by the warranty

scheme.

Warranty does not apply to consequential damage which does not

involve the machine itself.

All systems are tested. However in the event of a malfunction Lely cannot

be held responsible for consequential damage.

INTENTIONALLY BLANK

5.2309.8509.0 A

2 WARRANTY RESTRICTIONS

5.2309.8509.0 A

PREFACE 1

PREFACE

Manual Contents

This manual contains the information necessary for the correct

installation and operation of a COSMIX S Concentrate Feeder.

Study and understand this information thoroughly before configuration

of the COSMIX S. Failure to do so could result in damage to equipment.

Please consult your local Lely service provider if you do not understand

the information in this manual, or if you need additional information.

All information in this manual has been compiled with care. Lely shall not

be liable for errors or faults in this manual. The recommendations are

meant to serve as guidelines. All instructions, pictures and specifications

in this manual are based on the latest information that was available at

the time of publication. Your COSMIX S may comprise improvements,

features or options that are not covered in this manual.

Applicability

The table below shows the type numbers of COSMIX S for which this

manual is applicable.

Model designation

Model Type number

COSMIX S Concentrate Feeder Qwes ISO ACT neck 5.2309.0000.X

COSMIX S Concentrate Feeder Qwes H/HR 5.2309.0010.X

COSMIX S Concentrate Feeder Qwes ISO ACT leg 5.2309.0020.X

COSMIX S Concentrate Feeder Qwes H/HR-LD 5.2309.0040.X

Software version

The description, operation and procedures in this manual are based on

the following software versions:

•T4C version 3.1.3 or higher

•E-Link version 1.08R or higher

•ADS 3830 pcb; CMv01.05.25 or higher.

Standard Torque Loading of Parts

All the nuts, bolts and screws used on the COSMIX S Concentrate Feeder

are torque tightened to standard torque loadings applicable to the

construction materials used.

If a part has a non-standard torque loading, it is specified in the

applicable part of the manual.

5.2309.8509.0 A

2 PREFACE

Registration

The Type and Serial Number Plate is attached to the control box of the

COSMIX S Concentrate Feeder, on the top. Always include the type and

serial number of your concentrate feeder when you contact your local

Lely service provider or order spare parts.

Figure 1. Type and Serial Number Plate

We suggest you complete the table below with the type and serial

numbers of your concentrate feeder. This makes sure you can easily find

the information.

Type number

Serial number

Maintenance Authorization

Only technicians certified by Lely Industries are authorized to

do maintenance on the COSMIX S, except for the maintenance

done by the operator as indicated in the Operator Manual.If

people who are not certified by Lely Industries do maintenance

on the COSMIX S, the warranty on the COSMIX S becomes

invalid.

Before a technician does maintenance on a COSMIX S, the owner must

examine the service pass of the technician and make sure the technician

is currently certified to do maintenance on the COSMIX S.

At the end of each visit, all work done on the COSMIX S must be written

in the logbook and the logbook must be signed by the certified

technician. The logbook must always be kept near the COSMIX S for the

entire life of the product. The information in the logbook must include:

•The maintenance done

•The date of the maintenance

•The name of the technician

•The certification number of the technician.
