Leica DMS1000 Manuel utilisateur

Leica DMS1000

User Manual

Leica DMS1000 User Manual 2

Contents

General Notes

General Notes 5

Important Safety Notes 6

Symbols Used 7

Safety Instructions 8

Introduction

Congratulations! 11

Standard Delivery and Optional Accessories 12

System Overview 13

Overview of the Instrument 14

Eﬀective Displayed Section 15

Assembly

LeicaDMS1000 with Incident Light Base 17

Incident Light Base and Focusing Column 17

Microscope Carrier and LeicaDMS1000 18

LeicaDMS1000 with Transmitted Light Base 19

Transmitted Light Base and Focusing Column 19

Microscope Carrier and LeicaDMS1000 20

LeicaDMS1000 with Swing-arm Stand 21

Baseplate and Vertical Column 21

Safety Ring and Horizontal Arm 22

Microscope Carrier and LeicaDMS1000 23

Objective and Illumination 24

Standard Objective 24

Objective with Telecentric Optics 25

Illumination: Leica LED3000 RL 27

Illumination: Leica LED3000 NVI 29

Illumination: Leica LED5000SLI, Leica LED3000SLI 30

Installation

HD Mode (Standalone) 33

Cables and Terminals, Activating HD Mode (Standalone) 33

PC Mode 34

Connecting a Computer, Installing Software, Activating PC Mode 34

Limitations in PC Mode 35

Startup Procedure

LeicaDMS1000 37

Switching on the LeicaDMS1000 37

Switching on the Illumination 38

Focusing, Adjusting the Resistance of the Focus Drive 39

Changing Magniﬁcation, Click-stop Feature 40

Remote Control 41

Pairing Cameras With Remotes 43

Conﬁguring the Front Button or Footswitch 44

Leica DMS1000 User Manual 3

Contents (Continued)

Operation

Operation in HD Mode (Standalone) 47

Checking Cables and Terminals 47

Switching on the LeicaDMS1000 48

Information about SD Memory Cards 49

Capturing Images without a Computer 50

Displaying Images and Videos without a Computer 51

White Balance 52

PC Mode 53

Checking Cables, Terminals and Software 53

Switching on the LeicaDMS1000 54

Additional Use of an HD Monitor in PC Mode 55

User Menu

Calling up the User Menu 57

Automatic White Balance 58

Manual White Balance 59

Exposure 60

Resolution 61

Camera Settings 63

User-deﬁned Settings 65

Setting the Overlay (SETUP OVERLAY) 67

Scalable Display 69

Conﬁguring Predeﬁned Illumination Scenarios 70

Service

Care, Maintenance, Contact Persons 72

Spare Parts 75

Speciﬁcations

Technical Data 77

Optical Data – Field of View 81

Optical Data – Magniﬁcation and Depth of Field 82

Dimensional Drawings 84

LeicaDMS1000 84

LeicaDMS1000 with Incident Light Base 85

LeicaDMS1000 with Incident Light Base 86

LeicaDMS1000 with Transmitted Light Base 87

LeicaDMS1000 with Swing-arm Stand 88

Leica DMS1000 User Manual General Notes 4

General Notes

Leica DMS1000 User Manual General Notes 5

General Notes

Safety concept

Before using your Leica microscope for the ﬁrst

time, please read the "Safety Concept" booklet

included with your instrument. It contains addi-

tional information on handling and care.

Use in clean rooms

The LeicaDMS1000 digital microscope system

can be used in clean rooms without any

problems.

Cleaning

ODo not use any unsuitable cleaning agents,

chemicals or techniques for cleaning.

ONever use chemicals to clean colored

surfaces or accessories with rubberized

parts. This could damage the surfaces,

and specimens could be contaminated by

abraded particles.

OIn most cases, we can provide special solu-

tions on request. Some products can be

modiﬁed, and we can oﬀer other accesso-

ries for use in clean rooms.

Servicing

ORepairs may only be carried out by Leica

Microsystems-trained service technicians.

Only original Leica Microsystems spare

parts may be used.

Responsibilities of person in charge of

instrument

OEnsure that the Leica microscope is oper-

ated, maintained and repaired by autho-

rized and trained personnel only.

Leica DMS1000 User Manual General Notes 6

Important Safety Notes

User Manual

The Leica DMS1000 can be conﬁgured in a

variety of ways in the Leica product range.

You can ﬁnd information on individual system

components on the interactive CD-ROM

together with all relevant user manuals in addi-

tional languages. Keep this CD-ROM in a safe

place, where it is available to the user. User

manuals and updates are also available for

you to download and print from our website

www.leica-microsystems.com.

This operating manual describes the special

functions of the Leica DMS1000 digital micro-

scope system and contains important instruc-

tions for its operational safety, maintenance,

and accessories.

The "Safety Concept" booklet contains addi-

tional safety information regarding the service

work, requirements and the handling of the

microscope, accessories and electrical accesso-

ries as well as general safety instructions.

You can combine individual system articles with

articles from external suppliers (e.g. cold light

sources, etc.). Please read the User Manual and

the safety instructions from the supplier.

Before installing, operating or using the instru-

ments, read the user manuals listed above. In

particular, please follow all safety instructions.

To maintain the unit in its original condition and

to ensure safe operation, the user must follow

the instructions and warnings contained in

these user manuals.

Leica DMS1000 User Manual General Notes 7

Symbols Used

Warning! Safety hazard!

•This symbol indicates especially impor-

tant information that is mandatory to

read and observe.

Failure to comply can cause the following:

OHazards to personnel

OFunctional disturbances or damaged

instruments

Warning of hazardous electrical voltage

This symbol indicates information that

must be read and observed.

Failure to comply can cause the following:

OHazards to personnel

OFunctional disturbances or damaged

instruments

Danger due to hot surface

This symbol warns against touching hot

surfaces, e.g. those of light bulbs.

Important information

This symbol indicates additional informa-

tion or explanations that are intended to

provide clarity.

Leica DMS1000 User Manual General Notes 8

Safety Instructions

Description

OThe individual modules fulﬁll the highest

requirements for observation and docu-

mentation with the LeicaDMS1000 digital

microscope system.

Intended Use

ORefer to "Safety Concept" booklet

Non-intended use

ORefer to "Safety Concept" booklet

Never use the LeicaDMS1000 or its components

for surgical procedures (such as eye surgery)

since it is not intended for such use.

The instruments and accessories described in

this User Manual have been tested for safety and

potential hazards. The responsible Leica aﬃliate

must be consulted whenever the instrument is

altered, modiﬁed or used in conjunction with

non-Leica components that are outside of the

scope of this manual!

Unauthorized alterations to the instrument or

noncompliant use shall void all rights to any

warranty claims.

Place of use

ORefer to "Safety Concept" booklet

OElectrical components must be placed at

least 10 cm away from the wall and from

ﬂammable substances.

OAvoid large temperature ﬂuctuations, direct

sunlight and vibrations. These conditions

can distort measurements and micro-

graphic images.

OIn warm and warm-damp climatic zones,

the individual components require special

care in order to prevent the build-up of

fungus.

Responsibilities of person in charge of

instrument

ORefer to "Safety Concept" booklet

Ensure that:

OThe Leica DMS1000 digital microscope

system and accessories are operated, main-

tained and repaired by authorized and

trained personnel only.

OAll operators have read, understood and

observe this User Manual, and particularly

the safety regulations.

Leica DMS1000 User Manual General Notes 9

Safety Instructions (Continued)

Repairs, service work

ORefer to "Safety Concept" booklet

OOnly original Leica Microsystems spare

parts may be used.

OBefore opening the instruments, switch oﬀ

the power and unplug the power cable.

OAvoid contact with powered electrical

circuits, which can lead to injury.

Transport

OUse the original packaging for shipping or

transporting the individual modules of the

Leica DMS1000 digital microscope system

and the accessory components.

OIn order to prevent damage from vibrations,

disassemble all moving parts that (accord-

ing to the user manual) can be assembled

and disassembled by the customer and

pack them separately.

Integration in third-party products

ORefer to "Safety Concept" booklet

Disposal

ORefer to "Safety Concept" booklet

Legal regulations

ORefer to "Safety Concept" booklet

EC Declaration of Conformity

ORefer to "Safety Concept" booklet

Health risks

Workplaces with microscopes facilitate and

improve the viewing task, but they also impose

high demands on the eyes and holding muscles

of the user. Depending on the duration of unin-

terrupted work, asthenopia and musculoskel-

etal problems may occur. For this reason, appro-

priate measures for reduction of the workload

must be taken:

OOptimal arrangement of workplace, work

assignments and work ﬂow (changing tasks

frequently).

OThorough training of the personnel, giving

consideration to ergonomic and organiza-

tional aspects.

The ergonomic optics concept and the design

of the LeicaDMS1000 digital microscope system

aim to limit the strain on the user to the lowest

possible level.

Leica DMS1000 User Manual Introduction 10
