Leica DM IRM Manuel utilisateur

Leica

DM IRM

Inverted Research Microscope

for Material Testing

Instructions

Issued in 1998 by:

Leica Microsystems Wetzlar GmbH

Ernst-Leitz-Straße

D-35578 Wetzlar (Germany)

Responsible for contents:

MQM Marketing, Product Management Tel. +49 (0) 64 41-29 2239

Fax +49 (0) 64 41-29 24 64 or 22 55

e-mail Klaus.Luthardt@lmw.leica.com

Copyrights

All rights to this documentation and the software

it describes are owned by Leica Microsystems

Wetzlar GmbH. Copying of text and illustrations –

in full or in part – by printing, photostat, microfilm

or other techniques, including electronic systems,

is only permitted subject to the express written

consent of Leica Microsystems Wetzlar GmbH.

The information contained in the following docu-

mentation represents the latest stage of techno-

logy and knowledge. We have composed the

texts and illustrations with great care. However,

as it is impossible to eliminate the risk of error

completely, we cannot accept any kind of liabili-

ty for the correctness of the contents of this

manual. Nevertheless, we are always grateful to

be notified of any errors.

The information in this manual may be altered

without prior notice.

Contents

1 Important notes

on this manual . . . . . . . . . . . . . . . . . . . 6

2 Intended application,

short description, technical data

of the microscope . . . . . . . . . . . . . . . . 7–8

3 Assembly

3.1 Unpacking, installation site,

safety . . . . . . . . . . . . . . . . . . . . . . . . . . 9–11

3.2 Assembling the lamp mount,

mirror housing, lamphousing,

illumination telescope

. . . . . . . . . . . . 12–13

3.3 Assembling and changing

the incident light lamps . . . . . . . . . . . 14–18

3.4 Assembling the x/y stage . . . . . . . . . 19–20

3.5

Assembling the tubes

and eyepieces

. . . . . . . . . . . . . . . . . . . 21–23

3.6 Inserting the objectives . . . . . . . . . . . 24

3.7 Inserting reflectors and

fluorescence filter cubes . . . . . . . . . . 25–26

3.8 Inserting the ICR prism

turret and ICR prisms . . . . . . . . . . . . . 27

3.9 Inserting the polarisers

and analysers . . . . . . . . . . . . . . . . . . . 28–29

3.10 Assembling the transmitted

light illumination column and

the condensers . . . . . . . . . . . . . . . . . . 30–35

4 Start-up and

operation

4.1 Coaxial coarse

and fine focusing . . . . . . . . . . . . . . . . . 36–37

4.2 Observation tubes . . . . . . . . . . . . . . . . 38–39

4.3 Tube module 1x, magnification

changer 1x, 1.5x (B) . . . . . . . . . . . . . . 40

4.4 Lateral photo/TV exit . . . . . . . . . . . . . 41

4.5 Optical outfits . . . . . . . . . . . . . . . . . . . 42–46

4.6 Eyepiece graticules . . . . . . . . . . . . . . 47–49

4.7 Switching on and adjusting

the 12V 100W halogen lamp . . . . . . . 50

4.8 Centring the 12V 100W, Hg 50W,

Hg 100W and Xe 75W . . . . . . . . . . . . 51–53

4.9 Centring the aperture and

field diaphragm . . . . . . . . . . . . . . . . . . 54

4.10 Using light filters . . . . . . . . . . . . . . . . . 55–56

4.11 Examinations in incident light

brightfield, bright- and

darkfield, polarisation contrast,

interference contrast . . . . . . . . . . . . . 57–61

4.12 Examinations in incident

light fluorescence . . . . . . . . . . . . . . . . 62

4.13 Examinations in transmitted light . . . 63–64

4.14 Length measurements . . . . . . . . . . . 65

5 Accessories

5.1 Working with the

slide overlay device and

macro device . . . . . . . . . . . . . . . . . . . . 66–68

5.2 Connecting TV cameras and

photomicro equipment . . . . . . . . . . . 69–70

6 Care and maintenance,

wearing and spare parts . . . . . . . . . . 71–72

7 Conformity declaration . . . . . . . . . . . 73

This manual is divided into 7 main chapters:

1 Important notes

2 Description and technical data of the micro-

scope

3 Assembly of the microscope

4 Start-up and operation

5 Accessories

6 Care and maintenance

7 Conformity declaration

There are 6 basic variants of the Leica DMIRM

microscope, which can be configured individual-

ly.

Information on equipping the microscope further

can be found in this manual or the supplied

”Optics“ data sheet.

Some accessories such as photomicrography

have their own separate manuals.

This manual is an integral part of the product and

must be read carefully before you start using the

microscope.

Text symbols and their meaning:

Special safety information is indi-

cated by the symbol on the left

and is given a grey background.

As for e.g. mechanical and electrical

hazards, laser, UV light, heat, danger

of explosion

Warning of hot surface

Explanatory note

Caution! Operation errors can dam-

age the microscope and/or its acces-

sories

Not part of all configurations/

option

Numbers with an arrow, e.g. -> p. 20

refer to a particular page in this

manual.

Numbers in brackets, e.g. (1.2) refer

to illustrations, in this example Fig. 1,

item 2.

Important notes on this manual

(1.2)

→ S. 20

Fig. 1 Leica DM IRM inverted microscope

1Lamphousing 106Z with Hg 100W lamp, 2Mirrorhousing for 2

lamphousings, 33-plate x/y stage 247 x 230 mm, adjustment

range x–y 60 x 40 mm with coaxial drive, 4Aperture diaphragm

adjustment, 5Aperture diaphragm centration screws, 6Field

diaphragm adjustment, 7Field diaphragm centering buttons,

8Quintuple objective nosepiece, non-interchangeable, with

M32 x 0.75 mm objective thread, 9ICR prism dial, 10 Reflector

dial, 11 Coaxial coarse and fine drive, 12 Lateral TV port,

13 Mains switch for integrated 12V 100 W switch mode power

supply, 14 Brightness adjustment of 12V 100 W lamp, 15 Trino-

cular tube HCI 3T 22, 45° viewing angle, 16 Switch lever for split-

ting light beam 100%/100 % or 50%/50%, 17 Adapter tube for

photo/TV connection, 18 Analyser slot

Intended application, short description

and technical data of the microscope

Fig. 2 Leica DM IRM inverted microscope

1Lamphousing 107 for left-handed operation, 2Collector

adjustment for lamp centration, 3Lamp centration screws,

4Lamp mount for 1 lamphousing, 5Switch lever for light filters,

63-plate x/y stage 247 x 230 mm, x–y adjustment range 60 x 40

mm with coaxial drive, 7Switch lever for lateral TV port, 80% TV

or 100% TV, 8Tube lens module 1x or magnification changer 1x,

1.5x, 9Quintuple objective nosepiece, non-interchangeable

with M32 x 0.75 mm objective thread, 10 Coaxial coarse and fine

drive, 11 Binocular tube HCI B 22 with 45° viewing angle,

12 Clamp screw for changing and securing the tube, 13 Incident

light polariser slot, 14 HC PLAN 10x/22 eyepieces

1 2 3

11 1314

17 14

643

1398

Intended application:

The Leica DM IRM is designed for metallographi-

cal test laboratories for material control and

research of opaque and transparent industrial

materials.

For indoor use only

Ambient temperature: 10°C–36°C

Relative humidity: 0–80% up to 30°C

Integrated power supply

Mains voltage: 90–250V

Frequency: 50–60 Hz

Power consumption: max. 160W

Fuses: T 4 A

Overvoltage category: II

Contamination class: 2

The following variants of the Leica DM IRM

microscope are available:

Leica DMIRM with tube optics oo/1x HC

with lateral photo/TV exit

100% vis–20%vis/80%TV Order no. 571004

Leica DMIRM with tube optics oo/1x HC

with lateral photo/TV exit

100% vis–100%TV Order no. 571005

Leica DMIRM with tube optics oo/1x, 1.5x HC

(magnification changer)

with lateral photo/TV exit

100% vis–20%vis/80%TV Order no. 571006

Leica DMIRM with tube optics oo/1x, 1.5x HC

(magnification changer)

with lateral photo/TV exit

100% vis–100%TV Order no. 571007

Leica DMIRM with tube optics oo/1x, 1.5x, B

(magnification changer with Bertrand lens)

with lateral photo/TV exit

100% vis–20%vis/80%TV Order no. 571008

Leica DMIRM with tube optics oo/1x, 1.5x B

(magnification changer with Bertrand lens)

with lateral photo/TV exit

100% vis–100%TV Order no. 571009

Fig. 3 Back view of microscope

1Lamphousing mount, 212V 100 W socket, 3Mains socket,

4Potential equalisation socket, 5Cover for transmitted light

arm

Fig. 4 Side view of microscope

1Switch rod for lateral photo/TV port 100% vis/20 % vis–80%

photo/TV or 100% vis/100 % photo/TV, 2Adjustment wheel for

tube lens 1x, 1.5 x Bertrand lens

234

3.1 Unpacking, installation site, assembly

tools, safety information

Unpacking:

Please compare the delivery carefully with the

packing note, delivery note or invoice.

We strongly recommend that you keep a copy of

these documents with the manual, so that you

have information on the time and scope of the

delivery later when ordering more equipment or

when the microscope is serviced.

Make sure that no small parts are left in the

packing material.

Some of our packing material has symbols indi-

cating environment-friendly recycling.

n.b.!

When lifting the microscope out of the packaging

do not touch any movable, mechanical compo-

nents.

When putting the microscope on the desk and

adjusting its position, make sure not to damage

the sensitive damping feet on the underneath of

the microscope.

n.b.!

Do not connect microscope and peripherals

to mains yet (see section 3.2, Assembly)

Installation site

Make sure that the workplace is free from oil and

chemical fumes. Vibrations, direct sunlight and

major temperature fluctuations should be avoi-

ded. For ergonomic microscopy we recommend

a stable desk (about 70–80 cm high) and a com-

fortable, adjustable chair.

Assembly tools

Installation and assembly of the microscope

should preferably be carried out together with a

member of Leica sales or service staff.

Only a few ordinary screwdrivers are required for

assembly, and these are supplied with the

microscope.

3 Assembling the microscope

Fig. 5 Assembly tools

1Cross-tip screwdriver*, 2Hexagonal screwdriver, 3mm,

3Centring keys, 2mm*, 4Centring keys, 1.5 mm*, 5Allen key,

3mm*, 6Allen key, 2.5mm* (short version)

Safety information

This instrument of safety class 1 has been built

and tested according to EN 61 010-1/IEC 1010-1

safety standards for electrical measurement,

control and laboratory equipment.

n.b.:

To keep the microscope in this safe condition,

it is essential to note the advice and warnings

given in this manual.

The mains plug must only be inserted into a

grounded outlet.

If an extension cord is used, it must be grounded

as well. Any interruption of the ground connector

inside or outside the microscope or disconnec-

ting the ground connector can render the micro-

scope potentially dangerous. Intentional sever-

ance is forbidden!

n.b.:

Using the ground connection, any accesso-

ries connected to the microscope which have

their own and/or a different power supply can

be given the same ground conductor poten-

tial. Please consult our servicing personnel if

you intend to connect units without a ground

conductor.

Make sure that only fuses of the specified type

and rating are used as replacements. It is forbid-

den to use mended fuses or to short-circuit the

fuse holder.

n.b.:

The instruments and accessories described in

this manual have been safety-tested and

checked for possible hazards.

Before modifying the instrument in any way or

combining it with non-Leica products not

dealt with in this manual, it is essential to con-

sult the Leica agency for your area or the main

factory in Wetzlar!

Any unauthorized alteration to the micro-

scope or use for which it was not intended will

automatically terminate any warranty claim.

n.b.:

The electric accessories of the microscope

are not waterproof. If water gets inside them,

it may cause electrical shock.

Do not put the microscope and its accessories

near a water tap or anywhere else where

water may get inside them.

n.b.:

Before changing fuses or lamps, always turn

the mains switch off and disconnect the mains

cable.

n.b.:

Protect the microscope from major tempera-

ture fluctuations. These may lead to conden-

sation which can damage the electric and

optical components.

n.b.:

Avoid skin contact when using immersion oil!

Ask the supplier for a safety information

sheet!

Table des matières

Autres manuels Leica Microscope

Leica

Leica TCS SP8 Guide de l'utilisateur

Leica

Leica DM1000 LED Manuel

Leica

Leica DVM5000 Guide de l'utilisateur

Leica

Leica DM750 M Manuel utilisateur

Leica

Leica DMIRE2 Manuel utilisateur

Leica

Leica TCS SPE Manuel utilisateur

Leica

Leica DMS1000 Manuel utilisateur

Leica

Leica M-Series Manuel utilisateur

Leica

Leica S4 E StereoZoom Manuel utilisateur

Leica

Leica SP5 confocal Manuel utilisateur

Leica

Leica S Series Manuel utilisateur

Leica

Leica MZ16 A Manuel utilisateur

Leica

Leica ATC 2000 Manuel utilisateur

Leica

Leica Sp5 WLL STED Instructions de fonctionnement

Leica

Leica DM100 Manuel utilisateur

Leica

Leica DM2700 M Manuel utilisateur

Leica

Leica Z6 APO Manuel utilisateur

Leica

Leica DM750 P Manuel utilisateur

Leica

Leica PROVIDO Manuel utilisateur

Leica

Leica SP8 AT CIAN Manuel de la liste des pièces

Leica

Leica DM E Manuel utilisateur

Leica

Leica BM E Manuel utilisateur

Leica

Leica DVM6 Manuel utilisateur

Leica

Leica Emspira 3 Manuel utilisateur

Manuels Microscope populaires d'autres marques

Thermo Scientific

Thermo Scientific Nicolet iN10 Mode d’emploi

National

National DC3-163 Manuel utilisateur

KERN Optics

KERN Optics OPE-1 Manuel utilisateur

OPTIKA MICROSCOPES

OPTIKA MICROSCOPES B-150D Manuel utilisateur

Prior

Prior Lux POL Manuel utilisateur

Opitec

Opitec Smartscoop 115615 Manuel utilisateur

KERN

KERN OPO-1 Manuel utilisateur

Topcon

Topcon SP-1P Manuel utilisateur

Motic

Motic PA43 Manuel utilisateur

MshOt

MshOt MZ62 Manuel utilisateur

KERN Optics

KERN Optics OZR-5 Manuel utilisateur

VWR

VWR VisiScope 384 Series Manuel utilisateur

Nikon

Nikon ECLIPSE E200 POL Manuel utilisateur

ThermoFisher Scientific

ThermoFisher Scientific Continuµm Manuel utilisateur

ThermoFisher Scientific

ThermoFisher Scientific Continuµm Manuel utilisateur

Olympus

Olympus SZ61 Manuel utilisateur

AO Cycloptic Manuel utilisateur

Celestron

Celestron 44345 Manuel utilisateur
