LEGRAND Galion K8/H251-HK Manuel utilisateur

5. CONNECTION

5.1 Terminals

Terminal capacity: 2 ×1

2 ×1.5 mm²

1 ×2.5 mm²

1 ×4 mm²

Recommended screwdriver size: 4 mm flat blade

Recommended stripping length: 12 mm

Recommended terminal tightening torque: 0.5Nm

5.2 Circuit diagrams

mm²

2 824 17/17m

K8/H251-HK

87045 Limoges Cedex

Telephone: (+33) 05 55 06 87 87 - Fax:(+33) 05 55 06 88 88

Technical data sheet:F02862EN/01 Updated: 11/11/2021 Created: 20/08/2019

GalionTM

Black touch plate push+DND/CUR sign

Cat. No(s): 2 824 17/17m

K8/H251-HK K8/H252-HK

2 824 17/17m

K8/H251-HK K8/H252-HK

1. USE

To ring and to display the messages: "Do not disturb" or "Please

clean up my room".

(Supplied with M3.5 screws for BS boxes. Flush mounting or Surface

mounting.)

3. PREPARATION

3.1 General preparation

2. RANGE

Designation

Black touch plate

push+DND/CUR

sign

Black touch plate

push+DND/CUR

+wait sign

3 A - 220VAC

2 824 17/17m

Cat. No. Weight

(g)

Characteristics

1/2

- flushing

mounting

box:

- surface

mounting

box:

CONTENTS

1. Use.......................................1

2. Range...................................1

3. Pr ep aration .. ....... ....... .. ....... 1

4. Overall dimensions.................1/2

5. Connection...........................2

6. Technical characteristics......2

7. Cleaning.................................2

8. Conformity - Approvals..................2

4. OVERALL DIMENSIONS

Profile Size: 86×88 mm

Distance of installation hole: 60.3 mm

Minimum depth of the box>35 mm

K8/H251-HK

K8/H252-HK

99.8

28.5

9.2

Technical data sheet:F02862EN/01 Updated: 11 Created: /11/2021 20/08/2019

2/2

6. TECHNICAL CHARACTERISTICS

6.1 Material characteristics

Plate: Poly(methyl methacrylate)

Frame: Polycarbonate

Base: Polycarbonate

Self-extinguishing:

+ 850° C / 30 s for insulating parts holding live parts in place

+ 650° C / 30 s for other parts made of insulating materials

6.2 Electrical characteristics

6.3 Climatic characteristics

Storage temperatures: -10℃ to +70℃

Operating temperatures: -5℃ to +50℃

6.4 Mechanical characteristics

Impact test: Ik04

Protection against liquids: Ip20

7. CLEANING

Surface cleaning with a soft, slightly damp cloth.

Do not use: acetone, tar remover, trichloroethylene

8. CONFORMITY - APPROVALS

Voltage: 230V~

Current: 3A

Frequency: 50/60Hz

Conform to IEC 60669-2-1.

Black touch plate push+DND/CUR sign

GalionTM

Cat. No(s): 2 824 17/17m

K8/H251-HK K8/H252-HK

K8/H252-HK
