Ledj LEDJ225 Manuel utilisateur
www.prolight.co.uk
OUTDOOR TRI PAR
USER MANUAL
Order code: LEDJ225
Outdoor Tri Par Safety
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!
CAUTION!
INPUT VOLTAGE OF 110~240V
SAFETY INSTRUCTIONS
Every person involved with the installation, operation & maintenance of this
equipment should:
- Be competent
- Follow the instructions of this manual
CAUTION! TAKE CARE USING THIS EQUIPMENT!
HIGH VOLTAGE-RISK OF ELECTRIC SHOCK!!
Before your initial start-up, please make sure that there is no damage caused during
transportation. Should there be any, consult your dealer and do not use the
equipment.
To maintain the equipment in good working condition and to ensure safe operation, it is necessary
for the user to follow the safety instructions and warning notes written in this manual.
Please note that damages caused by user modications to this equipment are not
subject to warranty.
Outdoor Tri Par Safety
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused
by the non-observance of this manual or any unauthorised modication to the
equipment.
• Never let the power-cable come into contact with other cables. Handle the power-cable
and all mains voltage connections with particular caution!
• Never remove warning or informative labels from the equipment.
• Do not open the equipment and do not modify the equipment.
• Do not connect this equipment to a dimmer-pack.
• Do not switch the equipment on and off in short intervals, as this will reduce the
system’s life.
• Do not expose to ammable sources or gases.
• Always disconnect the power from the mains when equipment is not in use or before
cleaning! Only handle the power-cable by the plug. Never pull out the plug by pulling the
power-cable.
• Make sure that the available voltage is between 220v/240v.
• Make sure that the power-cable is never crimped or damaged. Check the equipment and
the power-cable periodically.
• If the equipment is dropped or damaged, disconnect the mains power supply immediately.
Have a qualied engineer inspect the equipment before operating again.
• If your product fails to function correctly, discontinue use immediately. Pack the unit
securely (preferably in the original packing material), and return it to your Prolight dealer
for service.
• Only use fuses of same type and rating.
• Repairs, servicing and power connection must only be carried out by a qualied
technician. THIS UNIT CONTAINS NO USER SERVICEABLE PARTS.
• WARRANTY; One year from date of purchase.
OPERATING DETERMINATIONS
If this equipment is operated in any other way, than those described in this manual,
the product may suffer damage and the warranty becomes void.
Incorrect operation may lead to danger e.g.: short-circuit, burns, electric shocks,
lamp failure etc.
Do not endanger your own safety and the safety of others!
Incorrect installation or use can cause serious damage to people and property.
You should nd inside the LEDJ carton the following items:
1, Outdoor Tri Par 2, Instruction manual 3, Power cable
Technical Specications:
DMX channels: 6
12 x Ultra Bright 3W Tri-colour LEDs
IP rated power in/out sockets
IP rated DMX in/out sockets
400Hz icker free
IP rating: IP-65
Beam angle: 25 degrees
Power supply: 110~240V - 50~60Hz
Power consumption: 68W
Dimensions: 260 x 240 x 209mm
Weight: 3.7Kgs
Operating modes: 1, Static colour
2, Colour change
3, Colour fade
4, Master/slave
5, DMX
Overview:
1, DMX input
2, DMX output
3, LED display
4, Power input
5, Power output
6, Mode selection button
7, Enter button
8, Function up button
9, Function down button
Outdoor Tri Par Technical specications
Operation:
There are 5 different operation modes to choose from:
1) Static colour mode 2) Colour change mode 3) Colour fade mode
4) Master/slave 5) DMX mode
1, Static colour mode
Mode button - Press the “MODE” button under the LED display, to show “C000”, then press the
“ENTER” button to choose one of the static colours using the “UP” and “DOWN” buttons.
The “C1” represents Red, “C2” = Green, “C3” = Blue and “CF” = strobe.
The two digits after it are the brightness 00 to 99 or in “CF” they are the strobe speed.
Examples: If you set C1, C2 and C3 to zero, the Outdoor Tri Par will have no LEDs on (blackout).
If you set C1 to 99 and C2 and C3 to zero, the Tri Par will be 100% Red.
NOTE: For static selection of Red, Green, and Blue, ensure that the unwanted
colours are set to “00”.
2, Colour change mode
Mode button - Press the “MODE’ button until the LED display shows “J000”, then press the
“ENTER” button to choose one of the colour changing modes using the “UP” and “DOWN” buttons.
The colour change programmes are as follows:
1, “J300” = RGB, 2, “J700” = 7 colour, 3, “JF00” = Strobe,
Now press the “ENTER” button again and you can then select the colour change speed using the
“UP” and “DOWN” buttons. The speed settings are from 00-99 (00 = slow, 99 = fast)
3, Colour fade mode
Mode button - Press the MODE button until the LED display shows “F000”, then press the
“ENTER” button to choose one of the colour fading modes using the “UP” and “DOWN” buttons.
The colour fade programmes are as follows:
1, “F300” = RGB, 2, “F700” = 7 colour, 3, “FF00” = Strobe,
Now press the “ENTER” button again and you can then select the colour fade speed using the
“UP” and “DOWN” buttons. The speed settings are from 00-99 (00 = slow, 99 = fast)
4. Master/slave mode
Link the units together using a 3-pin DMX cable, then press the “MODE” button to select one of the
above modes. On the Slave units press the mode button until the LED display shows “SLAV”. The
Slave units will then follow in sequence with the Master unit.
Note: To conrm the setting in any of the above mode always press the “ENTER” button a
nal time so that the LED display stops ashing.
Outdoor Tri Par Operation
5, DMX addressing mode
To access the DMX address mode, press the “MODE” button until the LED display shows “A001”,
and use the “UP and “DOWN” buttons to select the desired DMX address and press the
“ENTER” button to conrm the setting. Then follow the DMX channel assignment and function
table below.
6 Channel DMX chart
Outdoor Tri Par Operation
Channel
1
2
3
4
5
6
Value
000-255
000-255
000-255
000-255
0-4
5-84
85-169
170-255
0-255
Function
Master dimmer
Red (0 - 100%)
Green (0 - 100%)
Blue (0-100%)
No function
Colour macro
Colour jump
Colour fade
Strobe
Outdoor Tri Par DMX Set up
DMX-512:
• DMX (Digital Multiplex) is a universal protocol used as a form of communication between
intelligent xtures and controllers. A DMX controller sends DMX data instructions form the
controller to the xture. DMX data is sent as serial data that travels from xture to xture via the
DATA “IN” and DATA “OUT” XLR terminals located on all DMX xtures (most controllers only have
a data “out” terminal).
DMX Linking:
• DMX is a language allowing all makes and models of different manufactures to be linked together
and operate from a single controller, as long as all xtures and the controller are DMX compliant.
To ensure proper DMX data transmission, when using several DMX xtures try to use the
shortest cable path possible. The order in which xtures are connected in a DMX line does not
inuence the DMX addressing. For example; a xture assigned to a DMX address of 1 may be
placed anywhere in a DMX line, at the beginning, at the end, or anywhere in the middle. When a
xture is assigned a DMX address of 1, the DMX controller knows to send DATA assigned to
address 1 to that unit, no matter where it is located in the DMX chain.
DATA Cable (DMX cable) requirements (for DMX operation):
• The Outdoor Tri Par can be controlled via DMX-512 protocol. The DMX address is set on the
back of the unit. Your unit and your DMX controller require a 3-pin XLR connector for data input/
output (gure 1).
Figure 1
Also remember that DMX cable must be daisy chained and cannot be split.
Further exterior extension
DMX cables can be purchased
from all LEDJ dealers.
Please quote:
LEDJ140 - 1M
LEDJ142 - 2M
LEDJ143 - 5M
LEDJ144 - 10M
DMX cables can be purchased
from all LEDJ dealers.
Please quote:
LEDJ91 - 1M
Notice:
• Be sure to follow gures 2 & 3 when making your own cables. Do not connect the cable’s shield
conductor to the ground lug or allow the shield conductor to come in contact with the XLR’s outer
casing. Grounding the shield could cause a short circuit and erratic behaviour.
Special Note: Line termination:
• When longer runs of cable are used, you may need to use a terminator on the last unit to
avoid erratic behaviour.
Using a cable terminator (part number CABL90) will decrease the possibilities of erratic
behaviour.
5-Pin XLR DMX Connectors:
• Some manufactures use 5-pin XLR connectors for data transmission in place of 3-pin. 5-Pin
XLR xtures may be implemented in a 3-pin XLR DMX line. When inserting standard 5-pin
XLR connectors in to a 3-pin line a cable adaptor must be used. The Chart below details the
correct cable conversion.
Termination reduces signal transmission problems
and interferance. it is always advisable to connect a
DMX terminal, (resistance 120 Ohm 1/4 W) between
pin 2 (DMX-) and pin 3 (DMX+) of the last fixture.
Outdoor Tri Par DMX Set up
