LAUNCH TECH HTT Manuel utilisateur
Version: V1.00.000
Revised Date: 2017-11-01
Product Model: HTT
Product Name: Vehicle VIN Checking Terminal
Company Name: LAUNCH TECH. CO., LTD.
Company Address: LAUNCH TECH. CO., LTD. Launch Industrial Park,
North of Wuhe Avenue, Banxuegang, Bantian, Longgang, Shenzhen,
China
II
Vehicle VIN Checking Terminal
Copyright Information
Copyright © 2017 LAUNCH TECH. CO., LTD. All rights reserved. No
part of this publication may be reproduced, stored in a retrieval system,
or transmitted in any form or by any means, electronic, mechanical,
photocopying, recording or otherwise, without the prior written permission
of LAUNCH. The information contained herein is designed only for the use
of this unit. LAUNCH is not responsible for any use of this information as
applied to other units.
Neither LAUNCH nor its affiliates shall be liable to the purchaser of this
unit or third parties for damages, losses, costs, or expenses incurred by
purchaser or third parties as a result of: Accident, misuse, or abuse of
this unit, or unauthorized modications, repairs, or alterations to this unit,
or failure to strictly comply with LAUNCH operating and maintenance
instructions. LAUNCH shall not be liable for any damages or problems
arising from the use of any options or any consumable products other than
those designated as Original LAUNCH Products or LAUNCH Approved
Products by LAUNCH.
Trademark Information
LAUNCH is a registered trademark of LAUNCH TECH CO., LTD. (LAUNCH)
in China and other countries. All other LAUNCH trademarks, service marks,
domain names, logos, and company names referred to in this manual are
either trademarks, registered trademarks, service marks, domain names,
logos, company names of or are otherwise the property of LAUNCH or its
afliates. In countries where any of the LAUNCH trademarks, service marks,
domain names, logos and company names are not registered, LAUNCH
claims other rights associated with unregistered trademarks, service marks,
domain names, logos, and company names. Other products or company
names referred to in this manual may be trademarks of their respective
owners. You may not use any trademark, service mark, domain name, logo,
or company name of LAUNCH or any third party without permission from
the owner of the applicable trademark, service mark, domain name, logo, or
company name. You may contact LAUNCH by visiting the website at www.
cnlaunch.com, or writing to LAUNCH TECH. CO., LTD., Launch Industrial
Park, North of Wuhe Avenue, Banxuegang, Bantian, Longgang, Shenzhen,
Guangdong, P.R.China, to request written permission to use Materials on
this manual for purposes or for all other questions relating to this manual.
III
Vehicle VIN Checking Terminal
Precuations on using e-VIN
To avoid personal injury, property damage, or accidental damage to the
product, read all of the information in this section before using the product.
•Never collide, throw, or puncture e-VIN, and avoid falling, extruding and
bending it.
•Do not use e-VIN in exceptionally cold or hot, dusty, damp or dry
environments.
•Do not insert foreign objects into or place heavy objects on your device.
Sensitive components inside might cause damage.
•If the battery remains unused for a long period of time or the battery is
completely discharged, it is normal that the tool will not power on while
being charged. Please charge it for a period of 5 minutes and then turn it
on.
•DANGER: Do not attempt to replace the internal rechargeable lithium
battery. Contact the dealer for factory replacement.
•CAUTION: Please use the included power adaptor to charge your e-VIN.
No responsibility can be assumed for any damage or loss caused as a
result of using power adaptors other than the one supplied.
•Please make sure the ignition key is Off while plugging/unplugging the
diagnostic cable into/from the vehicle’s DLC.
•While the e-VIN keeps unused, please set the handset in standby or OFF
mode to conserve the battery power.
•After inspection, remember to disconnect the diagnostic cable from the
vehicle.
IV
Vehicle VIN Checking Terminal
Table of Contents
1 Foreword ................................................................................................... 1
1.1 Introduction............................................................................................. 1
1.2 Knowledge of e-VIN................................................................................ 1
1.3 Technical Parameters ............................................................................. 5
2 Wi-Fi Setting.............................................................................................. 6
2.1 Connect to a Wi-Fi network .................................................................... 6
2.2 Disconnect from a Wi-Fi network............................................................ 6
3 Preparation & Connection ......................................................................... 7
3.1 Preparation............................................................................................. 7
3.2 Connections............................................................................................ 7
4 Initial Use................................................................................................. 10
4.1 Startup & Login..................................................................................... 10
4.2 Job Menu.............................................................................................. 13
4.3 Update.................................................................................................. 13
5 Start VIN Inspection................................................................................. 15
5.1 Auto Detect........................................................................................... 16
5.2 Manually Detect.................................................................................... 18
6 Check Data.............................................................................................. 20
7 Settings.................................................................................................... 21
7.1 My Information...................................................................................... 21
7.2 Change Password ................................................................................ 21
7.3 Activate Device..................................................................................... 22
7.4 My Device............................................................................................. 22
7.5 Firmware Fix......................................................................................... 22
7.6 Print Information ................................................................................... 22
7.7 Launch Printer Connection................................................................... 23
7.8 About .................................................................................................... 24
7.9 Exit from the current account/Login...................................................... 24
8 Wi-Fi Printer (Optinal).............................................................................. 25
8.1 Introduction........................................................................................... 25
8.2 Thermal paper loading.......................................................................... 26
8.3 Using the rechargeable battery ............................................................ 28
8.4 Wi-Fi Connections ................................................................................ 29
8.5 Print Test Result ................................................................................... 30
1
Vehicle VIN Checking Terminal
1 Foreword
1.1 Introduction
e-VIN Vehicle VIN Inspection Terminal is a professional law enforcement
equipment, which has been developed and designed by LAUNCH for
Police/ forensic research institute to perform VIN enquiries. e-VIN can
read all the electronically embedded Vehicle Identication Numbers (VINs)
from all the parts in modern vehicles. The results can be checked and
compared, to see whether or not the VIN codes are registered as stolen.
The e-VIN will contribute to the investigation of stolen and cloned vehicles,
and minimize the trade in stolen parts.
1.2 Knowledge of e-VIN
2
Vehicle VIN Checking Terminal
Fig. 1-1 Front View
No. Name Description
1 Ambient light sensor
2 Charging LED Read means Charging, and Green means
Fully Charged.
3Sockt for diagnostic
cable
For connecting the DB15 female terminal
of the diagnostic cable.
4 Screen For indicating the test results.
5Power/Screen lock
button
•In Off mode, press and hold it for 3
seconds to turn the handset on.
•In On mode:
•Press it to activate the LCD if the
LCD is off.
•Press it to turn off the LCD if the
LCD lights up.
•Press and hold it for 3 seconds
and choose "Shut down" from the
pulldown list to turn it off.
•Press and hold it for 10 seconds to
perform forced shutdown.
6 Volume +/- buttons
•To adjust the volume.
•Press and hold the [Power] and
[Volume -] buttons at the same time to
take a screenshot.
7 Wrist strap
3
Vehicle VIN Checking Terminal
8
Keypad To execute the command and input the
characters.
To return to the previous screen.
A quick dial to start the VIN Inspection
APK.
To conrm an action/operation.
•Delete one character before the cursor
with short press.
•Delete all characters within one line
with long press.
Quick access to the system setting.
•To navigate to Android’s Home screen
with short press.
•To open the application list manager
with long press.
•To capture the current screen with
short press.
•To launch camera with long press.
To retrieve it in search engine.
9 Microphone
10 USB port
To connect the included power adaptor for
charging the handset or connect to the PC
for data transmission.
11 PTT(Push-To-Talk)
Key
Also known as press-to-transmit, is a
method of having conversations or talking
on half-duplex communication lines.It is
currently disabled and reserved for future
use.
4
Vehicle VIN Checking Terminal
Fig. 1-3 Rear View
No. Name Description
12 Laser scanner
It is used to quickly scan the VIN (Vehicle
Identification Number) of the tested vehicle.
It is currently disabled and reserved for future
use.
13 Camera Flash
14 Camera
15 Battery
5
Vehicle VIN Checking Terminal
16
NFC(Near Field
Communication)
module
As an optional module, it is currently disabled
and reserved for future use.
1.3 Technical Parameters
Operating System Android 7.0
CPU 8-Core processor
ROM 16GB
RAM 2GB
Screen 5 inch capacitive touch screen with a resolution
of 1280*720 pixels
Battery 4680mAh fast recharging supported
Camera Rear-facing 13 MP camera
Scan Laser Supported (It is currently disabled and reserved
for future use.)
NFC Supported (It is currently disabled and reserved
for future use.)
Wi-Fi 802.11a/b/g/n/ac
Rated Voltage 3.8V
Working Temp. -10℃~ 50℃
Storage Temp. -10℃~ 45℃
6
Vehicle VIN Checking Terminal
2 Wi-Fi Setting
Note: Once WLAN is set as ON, e-VIN will consume more power. While
WLAN keeps unused, please turn it off to conserve battery power.
e-VIN has built-in Wi-Fi that can be used to get online. Once you’re online,
you can register your e-VIN, update the diagnostic APK, browse the Internet,
get apps and send email on your network.
2.1 Connect to a Wi-Fi network
1. On the home screen, tap Settings -> WLAN.
2. Tap or slide the Wi-Fi switch to ON, e-VIN starts searching for all
available wireless LANs.
3. Choose the desired Wi-Fi access point / network:
•If the network you chose is open, you can connect directly.
•If the selected network is encrypted, you have to enter the right
security key (network password).
Once it is connected successfully, tap the Wi-Fi network from the list to view
its name, link speed, security type, IP address etc.
When this tool is in range, it will connect to the previously linked network
automatically.
2.2 Disconnect from a Wi-Fi network
1. On the home screen, tap Settings -> WLAN.
2. Tap the network with a Connected status, then tap “Disconnect”.
Table des matières
Manuels Terminal tactile populaires d'autres marques
Wincor Nixdorf
Wincor Nixdorf iPOS plus Advanced Manuel utilisateur
Ingenico
Ingenico AXIUM EX4000 Manuel utilisateur
Heisei Electronics
Heisei Electronics Q-POS 815 Manuel utilisateur
Amano
Amano MTX-15 Manuel utilisateur
FLOWBIRD
FLOWBIRD CWT Compact Touch Manuel utilisateur
Demco
Demco SP7 Manuel utilisateur
