Larson Electronics LEDP5W-12LT Manuel utilisateur

LEDP5W-12LT

Rechargeable LED Light Tower

Extends 3 to 8 Feet - 12, 5-Watt LEDs - 5 Hour Runtime

Instruction Manual

IMPORTANT

READ CAREFULLY BEFORE INSTALLING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE

REFERENCE. THE LEDP5W-12LT MUST BE WIRED IN ACCORDANCE WITH NATIONAL ELECTRICAL CODE AND

ALL APPLICABLE LOCAL CODES. PROPER GROUNDING IS REQUIRED FOR SAFETY.

WE STRONGLY ENCOURAGE ONLY A LICENSED ELECTRICIAN INSTALL, OPERATE AND MAINTAIN THIS

PRODUCT. IF YOU ARE NOT QUALIFIED OR UNFAMILIAR WITH ANY ASPECT OF THIS INSTRUCTION SHEET,

CONSULT AN ELECTRICIAN. THERE ARE NO SERVICEABLE PARTS INSIDE.

WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE

INSTALLATION OR PERFORMING ANY MAINTENANCE.

RISK OF FIRE/ELECTRIC SHOCK –DISCONNECT POWER AT BREAKER BEFORE INSTALLING OR SERVICING.

RISK OF PERSONAL INJURY –FIXTURE MAY BECOME UNSTABLE OR DAMAGED IF NOT INSTALLED PROPERLY.

RISK OF BURN –ALLOW FIXTURE TO COOL BEFORE SERVICING.

Never place spotlight face down when light is on. Doing so could burn/ignite surfaces such as seats, carpeting, etc. and

cause major property damage. Always turn spotlight off when not in use.

Avoid direct eye exposure the light source when light is on. DO NOT shine light into the face of someone else.

DO NOT touch lens of light when on or recently on. The lens/cooling fins will be hot after long periods.

DO NOT allow children to handle or operate this light.

DO NOT use this product for other than its intended use.

DO NOT operate in close proximity of combustible or flammable materials.

DO NOT attempt to operate this light if cord, plug, battery, lens or any part of the light is damaged or corroded.

The LEDP5W-12LT LED light tower is a fully portable and rechargeable unit and produces a wide flood or far reaching

spot light ideal for use on construction sites and emergency scenes. This light tower offers a long list of features including

versatile power and recharging options and provides a highly portable lighting solution that is ideal for use as flagger

illumination, utility lighting, underground illumination, and anywhere a versatile, lightweight, rechargeable LED light tower

is needed.

Larson Electronics, LLC Phone: (877) 348-9680 Fax: (903) 498-3364 www.larsonelectronics.com 1of 2

SETUP

1. Charge unit for 24 hours when new and every three months thereafter to maintain a full charge

(Charge monthly in hot weather)

2. Do not charge or use this light in hazardous location

3. Extend retractable legs if necessary for uneven terrain

4. Extend aluminum pole to desired height and tighten each pole section into position

OPERATION

1. Single head light will operate over 40 hours on a full charge

2. Dual head light will operate over 20 hours on a full charge

3. The power port provided can be used to operate a cell phone, a laptop computer, or any of

Larson Electronics’ handheld light with cigarette plug. The power port can be used a quick

charge inlet for the light from an automobile’s 12-volt power port.

4. Order Larson Electronics’ power port duel end cable for connection from vehicle to light.

1. Press the RED push button momentarily to turn the gauge on:

2. The GREEN shaded indicator bar indicates the unit is capable of normal operation.

3. The YELLOW shaded indicator bar indicates the unit needs to be recharged.

4. The RED shaded indicator bar indicates the unit must be recharged before use.

BATTERY STATUS GAUGE

LEDP5W-12LT

Larson Electronics, LLC Phone: (877) 348-9680 Fax: (903) 498-3364 www.larsonelectronics.com 2of 2

RECHARGING

1. Plug the unit into 115 VAC and note the lighted gauge indicator for battery status.

2. The unit may be recharged by using an optional accessory power port cord with two male ends.

3. Plug one end into the unit’s 12V outlet and the other end into the vehicle’s 12V power port socket. The vehicle

must be running to charge with this method.

BATTERY REPLACEMENT

This unit contains a sealed non-spill able lead acid battery. The battery must be recycled.

Contact Larson Electronics’ for replacing battery.

SAFETY AND USAGE INFORMATION

1. Read these instructions completely before using the products and save them for future reference.

2. Do not use unit to recharge dry cell batteries

3. Do not jump-start or attempt to recharge a frozen battery.

4. Charge unit in a well-ventilated area.

5. All batteries are affected by temperature changes, and the unit’s small, lightweight battery is more sensitive to

storage temperature than a standard automotive battery. Temperatures above 68F degrees (20degrees C)

decrease amperage output. The ideal storage environment for emergency use is at room temperature.

STORAGE

Unit may be stored virtually anywhere, and in any position.

THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.

SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT

SAL[email protected] OR BY PHONE AT 1-877-348-9680 FOR FURTHER ASSISTANCE.

PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.

USE AND CARE

Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.

Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of

children when not in use.Inspect for good working condition prior to storage and before re-use.

REPLACEMENT PARTS

The LEDP5W-12LT is designed to provide years of reliable performance. Should the need for replacement parts arise,

please contact Larson Electronics.
