DeWalt DCL510 Manuel utilisateur

DCL510

English (original instructions) 4

한국어 14

Figure 1

Figure 2

Figure 3

English

10.8V CORDLESS LED WORKLIGHT

DCL510

Congratulations!

You have chosen a DeWALT tool. Years of experience, thorough

product development and innovation make DeWALT one of the most

reliable partners for professional tool users.

Technical Data

DCL510

Voltage VDC 10.8

Type 1

Battery Type Li-Ion

Weight (without

battery pack) kg 0.15

Battery pack DCB125 DCB127

Battery type Li-Ion Li-Ion

Voltage VDC 10.8 10.8

Capacity A

1.3 2.0

Weight kg 0.2 0.2

Charger DCB105

Mains voltage VAC 220-240 V

Battery type Li-Ion

Approximate charging min 25 30 40 55 70

time of battery packs (1.3 Ah) (1.5 Ah) (2.0 Ah) (3.0 Ah) (4.0 Ah)

Weight kg 0.49

English

Charger DCB107

Mains voltage VAC 220-240 V

Battery type Li-Ion

Approximate charging min 60 70 90 140 185

time of battery packs (1.3 Ah) (1.5 Ah) (2.0 Ah) (3.0 Ah) (4.0 Ah)

Weight kg 0.29

Charger DCB112

Mains voltage VAC 220-240 V

Battery type Li-Ion

Approximate charging min 40 45 60 90 120

time of battery packs (1.3 Ah) (1.5 Ah) (2.0 Ah) (3.0 Ah) (4.0 Ah)

Weight kg 0.36

Deﬁnitions: Safety Guidelines

The definitions below describe the level of severity for each signal word.

Please read the manual and pay attention to these symbols.

DANGER: Indicates an imminently

hazardous situation which, if not avoided, will result in

death or serious injury.

WARNING: Indicates a potentially hazardous situation

which, if not avoided, could result in death or serious

injury.

CAUTION: Indicates a potentially hazardous situation

which, if not avoided, may result in minor or moderate

injury.

NOTICE: Indicates a practice not related to personal

injury which, if not avoided, may result in property

damage.

Denotes risk of electric shock.

Denotes risk of fire.

English

WARNING: To reduce the risk of injury, read the instruction

manual.

Safety Warnings

WARNING! Read all safety warnings and all

instructions. Failure to follow the warnings and

instructions may result in electric shock, fire and/or serious

injury.

Save all warningS and inStructionS

for future reference

WARNING!

  •DO NOT stare directly into the light source.

  •DONOTviewdirectlywithopticalinstrumentsinto

the light source.

  •DONOTpointthelightintootherpeopleseyes.

BATTERY TOOL USE AND CARE

a) Recharge only with the charger specified by the

manufacturer. A charger that is suitable for one type of battery

pack may create a risk of fire when used with another battery

pack.

b) Use tools only with specifically designated battery packs.

Use of any other battery packs may create a risk of injury

and fire.

c) When battery pack is not in use, keep it away from other

metal objects like paper clips, coins, keys, nails, screws

or other small metal objects that can make a connection

from one terminal to another. Shorting the battery terminals

together may cause burns or a fire.

d) Under abusive conditions, liquid may be ejected from the

battery, avoid contact. If contact accidentally occurs, flush

with water. If liquid contacts eyes, additionally seek medical

help. Liquid ejected from the battery may cause irritation or

burns.

English

SERVICE

a) Have your tool serviced by a qualified repair person using

only identical replacement parts. This will ensure that the

safety of the power tool is maintained.

Additional Speciﬁc Safety Rules for Worklights

WARNING: Fire hazard. Do not operate worklight or

charger near flammable liquids or in gaseous or explosive

atmospheres. Internal sparks may ignite fumes causing

personal injury.

 • Donotexposelightorchargertowetordampareas.Donot

expose light or charger to rain or snow.

 • Donotwashlightorchargerwithwaterorallowwatertogetinside

light or charger. Do not submerge light in water at any time.

 • Donotoperatewithoutlenscoverassemblyattached.

CAUTION: When not in use, place tool on its side on

a stable surface where it will not cause a tripping

or falling hazard. Some tools with large battery packs

will stand upright on the battery pack but may be easily

knocked over.

Markings on Tool

The following pictograms are shown on the tool:

Read instruction manual before use.

Do not stare directly into the light source.

DATE CODE POSITION

The date code, which also includes the year of manufacture, is printed

into the housing surface that forms the mounting joint between tool and

battery.

English

Example:

2014 XX XX

Year of Manufacture

Important Safety Instructions for All Battery

Chargers

SAVE THESE INSTRUCTIONS: This manual contains important

safety and operating instructions for the DCB105, DCB107 and

DCB112 battery chargers.

 • Beforeusingcharger,readallinstructionsandcautionarymarkings

on charger, battery pack, and product using battery pack.

WARNING: Shock hazard. Do not allow any liquid to get

inside charger. Electric shock may result.

CAUTION: Burn hazard. To reduce the risk of injury,

charge only DeWALT rechargeable batteries. Other types of

batteries may burst causing personal injury and damage.

CAUTION: Children should be supervised to ensure that

they do not play with the appliance.

NOTICE: Under certain conditions, with the charger

plugged in to the power supply, the charger can be

shorted by foreign material. Foreign materials of a

conductive nature such as, but not limited to, grinding

dust, metal chips, steel wool, aluminum foil, or any buildup

of metallic particles should be kept away from charger

cavities. Always unplug the charger from the power supply

when there is no battery pack in the cavity. Unplug charger

before attempting to clean.

WARNING:

 • DONOTattempttochargethebatterypackwithanychargers

other than the ones in this manual. The charger and battery

pack are specifically designed to work together.
