Larson Electronics LEDHWP-900-DNMS Manuel utilisateur

LEDHWP-900-DNMS

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com 1of 3

90 Watt Traditional LED Wall Pack

Motion + Day/Night Sensor - IP65 Rated

Instruction Manual

Thank you for your purchase of the Larson Electronics LEDHWP-900-DNMS.

WARNING:

READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.

CRITICAL SAFETY INSTRUCTIONS:

•INSTALLATION SHOULD ONLY BECONDUCTED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH NEC AND ANY

RELEVANT LOCAL BUILDING CODES.

•RISK OFFIRE OR ELECTRIC SHOCK. FIXTURE INSTALLATION REQUIRES KNOWLEDGE OF FIXTURE'S ELECTRICAL

SYSTEMS. IFNOTQUALIFIED, CONTACT A QUALIFIED ELECTRICIAN.

•BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.

•MAKE SURE THE SUPPLY VOLTAGE IS THE SAME AS THE FIXTURE'S RATED VOLTAGE.

•TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR SHARP

OBJECTS. SUITABLE FOR DAMP LOCATIONS.

IMPORTANT

READ CAREFULLY BEFORE INSTALLING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE

REFERENCE. THE LEDWP-600E MUST BE WIRED IN ACCORDANCE WITH NATIONAL ELECTRICAL CODE AND

ALL APPLICABLE LOCAL CODES. PROPER GROUNDING IS REQUIRED FOR SAFETY.

WE STRONGLY ENCOURAGE ONLY A LICENSED ELECTRICIAN INSTALL, OPERATE AND MAINTAIN THIS

PRODUCT. IF YOU ARE NOT QUALIFIED OR UNFAMILIAR WITH ANY ASPECT OF THIS INSTRUCTION SHEET,

CONSULT AN ELECTRICIAN. THERE ARE NO SERVICEABLE PARTS INSIDE.

WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE

INSTALLATION OR PERFORMING ANY MAINTENANCE.

RISK OF FIRE/ELECTRIC SHOCK –DISCONNECT POWER AT BREAKER BEFORE INSTALLING OR SERVICING.

RISK OF PERSONAL INJURY –FIXTURE MAY BECOME UNSTABLE OR DAMAGED IF NOT INSTALLED PROPERLY.

RISK OF BURN –ALLOW FIXTURE TO COOL BEFORE SERVICING.

The LEDHWP-900-DNMS Traditional Style LED Wall Pack Light offers high light output from a compact form factor and is

designed to provide a more durable and long lived alternative to halogen and metal halide units. This 90 watt LED light is

designed to replace 400 watt metal halide wall packs and produces a wide flood beam without the high heat, fragile

construction, or high energy costs of traditional lighting. The LED LEDHWP-900-DNMS provides 100,000 hours of reliability

and up to 87% savings compared to traditional 400 watt metal halide wall pack fixtures.

WIRING

Standard pigtail(flying leads) wiring

We strongly encourage a licensed electrician install this product,in all locations especially in outdoor areas

where weatherproofing may be required. Universal voltage driver permits operation at 110V - 277V AC, 50 or 60Hz.

Warning: Check product label for correct input voltage!

Attach supply line wires to the appropriate light fixture wires as shown

in thediagram 

Secure each pair of wires according to the diagram. Utilize a junction box or

similar device and take precautionary steps for weatherproofing all

connections if installed in a location where water may come in contact with the

unit. Ensure the unit is properly grounded and that wiring is done according to

all local and national electrical/building codes.

LEDHWP-900-DNMS

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com 2of 3

MOUNTING

The LEDHWP-900-DNMS consists of an integrated LED assembly housed within a waterproof die cast aluminum housing

that is powder coated for added durability and resistance to corrosion. The 2-part hinged housing allows for easy wall mount

installation and future servicing. Use the mounting holes on the back of the unit for wall or surface mounting.

GLARE SHIELD

The LEDHWP-900-DNMS comes with a glare shield meant to help direct the light to the target area. The glare shield is

mounted to the unit using the existing screw holes found on the sides of the fixture.

SENSOR TECHNOLOGY

The LEDHWP-900-DNMS is equipped with an innovative and powerful day/night + motion sensor. This sensor, which is

located inside the light fixture itself, allows the LEDHWP-900-DNMS to operate in one of several different and versatile

modes. This LED light fixture can be set to be motion activated, day/night activated or in a combination of motion sensing

and day/night modes. This high-tech sensor is also highly adjustable and allows operators to modify the following settings:

motion sensor sensitivity, motion sensor time-delay and the intensity output level of the fixture. Having this degree of

flexibility in operation and settings offers operators an incredibly versatile light fixture.

SENSOR OPERATION

On the bottom of the motion sensor there are three knobs. One is labeled "SENS", one is labeled "TIME", and one is labeled

"LUX".

•The "SENS" knob adjusts the motion sensor sensitivity. All the way turned down is the OFF state, and all the way turned

up is maximum sensitivity.

•The "TIME" knob adjusts the hold time. Once either the daylight or motion sensor triggers this, adjust the amount of time

the load stays on. All the way turned down is the minimum hold time, and all the way turned up is the maximum hold

time.

•The "LUX" knob adjusts the sensitivity of the daylight sensor. All the way turned down is the OFF state, and all the way

turned up is the maximum sensitivity.

LEDHWP-900-DNMS

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com 3of 3

USE AND CARE

Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.

Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of

children when not in use.Inspect for good working condition prior to storage and before re-use.

REPLACEMENT PARTS

The LEDHWP-900-DNMS is designed to provide years of reliable performance. Should the need for replacement parts

arise, please contact Larson Electronics.

THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.

SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT

SALES@LARSONELECTRONICS.COM OR BY PHONE AT 1-800-369-6671 FOR FURTHER ASSISTANCE.

PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.

MAINTENANCE

Caution: To avoid personal injury, disconnect power to the light and allow the unit to cool down before

performing maintenance.

Warning: No user serviceable parts inside of fixture. Risk of electric shock. Removal of the lens will void

the warranty.

1. Perform visual, mechanical and electrical inspections on a regular basis. We recommend routine

checks to be made on a yearly basis. Frequency of use and environment should determine this. It is

recommended to follow an Electrical Preventive Maintenance Program as described in NFPA 70B:

Recommended practice for Electrical Equipment.

2. The lens should be cleaned periodically as needed to ensure continued photometric performance.

Clean the lens with a damp, non-abrasive, lint-free cloth. If not sufficient, use mild soap or a liquid

cleaner.

3. Inspect the cooling fins on the luminaire to ensure that they are free of any obstructions or

contamination (i.e. excessive dust build-up). Clean with a non-abrasive cloth if needed.

4. Do not operate if the lens is cracked or damaged. All fasteners should be properly seated.
