Lantronix SecureLinx Spider Manuel utilisateur
SecureLinx Spider Duo
Quick Start Guide
SecureLinx Spider Duo
Quick Start Guide
SecureLinx Spider Duo
QUICK START GUIDE CONTENTS
Overview ......................................................................................................................... 2
What’s In The Box.......................................................................................................... 3
Installation and Network Settings...................................................................... 3-6
Spider Duo Web Conguration........................................................................... 7-9
Target Computer Setup........................................................................................9-10
Client System Requirements..................................................................................10
Connection to Target Computer and Basic Operation........................... 11-12
Exit and Logout...........................................................................................................13
Power Control Unit (PCU).........................................................................................13
Contact Information..................................................................................................15
Quick Start Guide
SecureLinx Spider Duo
2
OVERVIEW
SecureLinx Spider Duo
The SecureLinx Spider Duo™is a distributed KVM/IP device designed to securely
provide monitoring and control of one (target) computer system locally and by
one or more remote users. The remote user (client) accesses the Spider Duo over
a local or wide area network connection using a standard web browser.
There are two models: one with both PS/2 and USB keyboard/mouse interfaces
(software selectable), and one for USB-only systems. The color coded plugs on the
ends of the cables for the keyboard, mouse, USB port and video are designed to
plug directly into the target system’s corresponding connector. Hang the Spider
Duo by the cables or secure it out of the way.
Typical
Spider Duo
Conguration
This Quick Start Guide will step you through the hardware installation and
conguration in a typical environment.
s
Quick Start Guide
SecureLinx Spider Duo
3
WWW.LANTRONIX.COM
In addition to the Spider Duo distributed KVM/IP module, the box contains
the following items:
•Local KVM cable
•Computer input cable
•Mounting kit
•Quick Start Guide
•CD-ROM containing documentation and utilities
•External AC/DC Power Supply
Note: An optional power control unit is available (part number
PCU100-01). See page 13 for details.
Local port, computer input
connectors, USB, Serial/
PCU CTRL port
Serial RS-232 / PCU CTRL Pinouts
WHAT’S IN THE BOX
INSTALLATION AND NETWORK SETTINGS
USB Serial / PCU Ctrl
Pin # Pin Name
1 RTS (Out)
2 +5V (Out)
3 TX (Out)
4 PCU Sense (In)
5 GND (Out)
6 RX (In)
7 PCU Drive (Out)
8 CTS (In)
Local
KVM
Computer
Input
Quick Start Guide
SecureLinx Spider Duo
4
INSTALLATION AND NETWORK SETTINGS CONTINUED
Ethernet and Power Port
10/100
Ethernet (RJ45)
Power
Spider Duo LED indicators
Quick Start Guide
SecureLinx Spider Duo
5
WWW.LANTRONIX.COM
1. Plug the RJ45 end of the included serial cable into the Spider Duo’s serial
port. Plug the DB9F end into the serial (COM) port of a PC/laptop running a
terminal emulation (e.g. HyperTerminal). The default serial port settings are
9600 bits per second, 8 data bits, no parity, 1 stop bit, no ow control.
Plug the power adaptor into the Spider Duo’s power connector.
2. Insert color coded plugs into connectors with matching border on the Spider
Duo. Plug the Video, USB, and PS/2 keyboard/mouse (if applicable) cables
into the target computer. For transparent local access, connect cables to
local keyboard, video and mouse. The blue Sys OK LED will illuminate and
ashes to indicate that it is booting up. Bootup is complete within
approximately one minute. The blue LED stops ashing and remains
illuminated.
3. Upon bootup, the terminal window displays the IP Conguration screen.
At the command prompt type cong and press Enter.
4. To change the default IP auto conguration from DHCP to a static IP address,
at the IP autoconguration prompt type none and press Enter.
INSTALLATION AND NETWORK SETTINGS CONTINUED
Quick Start Guide
SecureLinx Spider Duo
6
5. Follow the prompts to enter the unit’s IP address, subnet mask, default
gateway, and LAN interface information.
6. Press Enter, to accept the changes. The system takes about 20
seconds to complete. Press Enter once again at the prompt to display the
updated IP address.
7. Plug an Ethernet cable connected to your network into the Ethernet port.
The Link LED illuminates.
INSTALLATION AND NETWORK SETTINGS CONTINUED
[172.18.100.17 spider]> config
IP autoconfiguration (none/dhcp/bootp) [dhcp]: none
IP [172.18.100.17]:
NetMask [255.255.0.0]:
Gateway (0.0.0.0 for none) [172.18.0.1]:
LAN interface speed (auto/10/100) [auto]:
LAN interface duplex mode (auto/half/full) [auto]:
Are the entered values correct? Enter y for Yes, n for No or c to Cancel y
Configuring device ...
Welcome!
Choose a command for the following features:
-Initial IP configuration: "config".
-Reset device: "reset".
[172.18.100.17 spider]>
Quick Start Guide
SecureLinx Spider Duo
7
WWW.LANTRONIX.COM
1. Access the Spider Duo over the network using a favorite web browser by
entering https:// for a secure SSL connection or http:// for an insecure
connection and its IP address in the address bar.
2. Enter your user name (default is sysadmin) and password (default is PASS)
at the prompt. The Spider Duo home page displays.
SPIDER DUO WEB CONFIGURATION
Quick Start Guide
SecureLinx Spider Duo
8
3. The following are a few key congurations:
Keyboard/Mouse:
a. Select InterfacesgKeyboard/Mouse from the web page.
b. To change the target interface keyboard/mouse settings from the
default (Auto) to force PS/2 or USB target interface, select the
appropriate option from the Host Interface drop-down menu.
c. To change the USB mouse type, select the appropriate operating
system option from the USB Mouse Type drop-down menu.
d. Click Save to store your settings in nonvolatile memory.
Security:
a. Select ServicesgSecurity from the web page.
b. To require SSL encryption, select Force HTTPS for Web access.
c. Click Save to store your settings in nonvolatile memory.
Network TCP Ports and Services:
a. Select Interfaces from the web page. The Network page displays.
b. Under Network Miscellaneous Settings, modify the TCP ports as
necessary. The client system requires the ability to access the Spider
Duo’s IP address as well as have port 80 (HTTP) and 443 (HTTPS) open.
Consult your system administrator if your system’s rewalls and NAT
device requires reconguration or change to these values.
SPIDER DUO WEB CONFIGURATION CONTINUED
