Network Storage White Paper

Data Sharing Solutions From LaCie

Data Sharing Solutions from LaCie | Page 2

Data Sharing Solutions From LaCie

As the extensive use of digital

consumer electronics contin-

ues to accelerate exponential-

ly, consumers and profession-

als are increasingly looking

for data storage and sharing solutions.

It’s clear why internal hard drives are rou-

tinely ﬁlled and servers stagger as storage archi-

tects struggle to keep up with the ever-evolv-

ing needs of digital consumers. Capacity and

compatibility limitations often contribute to

intractable workﬂow restrictions, and common

network storage solutions are prohibitively ex-

pensive and infamously diﬃcult to integrate

into existing networks.

Solutions from LaCie

Meet the solution to your data-sharing needs:

the LaCie Ethernet Disk and Ethernet Disk

mini. Sharing huge amounts of data eﬀort-

lessly between Windows, Apple and Linux en-

vironments is a breeze for the Ethernet Disk

and Ethernet Disk mini.

More Than Hard Drives

ink of the Ethernet Disk and Ethernet Disk

mini as “more than hard drives.” One of the

advantages of network storage is that you don’t

need to place the storage device near to your

computer. Simply power on the drive, plug the

Ethernet chord into a router or a switch on the

network, and begin sharing ﬁles.

e beauty of the Ethernet Disk and Eth-

ernet Disk mini lies in their simplicity. Once

the Ethernet Disk or Ethernet Disk mini is

connected to your network, all you need to

do is type http://edmini or the drive’s IP ad-

dress in your browser’s address ﬁeld to access

the conﬁguration page. Finding your drive’s

IP address couldn’t be easier; simply download

LaCie’s free IP Conﬁgurator.

Accessible to any computer via a Web

browser, administration and control can be

managed remotely or on-site, and doesn’t re-

quire a degree in network administration.

In this Article:

Solutions from LaCie

More than hard drives

Flexible cross-platform solution

Gigabit Ethernet Disk:

e professional solution

Ethernet Disk mini:

e home oﬃce solution

Gigabit Ethernet Disk or

Ethernet Disk mini?

Secure data storage

Who will use it?

❖

LaCie Ethernet Disk

Data Sharing Solutions from LaCie | Page 3

Flexible Cross-Platform Solution

Operating seamlessly in Windows, Apple

Macintosh and Linux environments, both

products feature an auto-sensing 10BaseT

and 100BaseTX connection to local area net-

works (the most common Ethernet-based

network connections) and support DHCP for

eﬀortless setup. Both solutions are compatible

with TCP/IP, SMB/CIFS, Apple Talk, FTP

and HTTP ﬁle sharing protocols to easily in-

tegrate into your operating conﬁguration.

e ExtremeZ-IP File Server (compatible

with the Ethernet Disk only) oﬀers support

for Apple’s latest version of the Apple ﬁle

sharing protocol, AFP v3.1, as well as all the

important new Mac OS X features like sup-

port for long ﬁle names, ﬁle sizes over 2GB on

the server, single sign-on authentication us-

ing Kerberos, and true compatibility between

Mac OS 9** and Mac OS X ﬁles.

e Ethernet Disk supports up to 100 us-

ers – 25 connected simultaneously – on the

same network protocol. Modifying permis-

sions is a breeze, ensuring that ﬁle access is

controlled and sensitive ﬁles are protected

from prying eyes.

Web browser accessibility means that data

can be accessed from any internet-connected

browser.

LaCie Ethernet Disk:

The Professional Solution

Fortunately, small and mid-sized companies

and organizations have an alternative that

simpliﬁes data management, enhances pro-

ductivity and improves data access, all without

the need for an expensive network administra-

tor. Simply connect the LaCie Ethernet Disk

to your Ethernet-based network, turn on the

power, and within minutes you’ll beneﬁt from

a dedicated network storage solution that un-

burdens your server of storage tasks and leaves

your workstations’ hard drives all the capacity

they need to function eﬃciently.

e Ethernet Disk also beneﬁts from

its embedded Windows XP operating sys-

Data Sharing Solutions from LaCie | Page 4

tem, which allows eﬃcient integration with

Windows domain, thanks to its AD (Active

Directory) compatibility.

Ethernet Disk mini:

The Home Office Solution

is external hard drive oﬀers Ethernet net-

working at a price that matches your budget.

Simply plug in the user-friendly Ethernet

Disk mini and instantly share documents, im-

Mac OS 10.2 & Higher

Windows 2000/XP

Ethernet Disk mini Ethernet Disk mini

As External Hard Drive

Hi-Speed USB 2.0

Connection

Hi-Speed USB 2.0

Connection

portant data or photos from any networked

computer, or plug it in via a USB cable for use

as a personal storage device (no need to install

drivers). e original, sturdy metal design is

portable for shuttling between home and of-

ﬁce. Support for multiple share gives users

the ﬂexibility to intelligently control access to

sensitive data.

Ethernet Disk or Ethernet Disk mini?

e Ethernet Disk was developed as a data-

sharing solution for small- to mid-size busi-

nesses or organizations, featuring an interface

that transfers data 10 times faster than the

Ethernet Disk mini. Shipped with capacities

of up to 2TB (1TB = 1000GB) with the op-

tion to increase to nearly limitless capacities

via USB-connected external hard drives, your

business can backup its ﬁles over the network

and archive massive blocks of data.

e Ethernet Disk mini was designed for

small oﬃce and home oﬃce users, and can

be used as a personal USB hard drive or as a

shared drive. With capacities up to 500GB,

the Ethernet Disk mini can handle any of

your small oﬃce or home oﬃce needs.

Secure Data Storage

In this age of security concern, your employees

can transfer ﬁles with conﬁdence to their Eth-

ernet Disk and Ethernet Disk mini. anks

to the intuitive conﬁguration interface, non-

technical personnel can easily grant or with-

draw read and write permissions to ﬁles at an

Data Sharing Solutions from LaCie | Page 5

individual user level. For example, tempo-

rary employees can be given read-only ac-

cess to ﬁles.

e Ethernet Disk also comes with a

backup program to help guard against the

unexpected. Connect an external hard drive

to the Ethernet Disk via the USB 2.0 port

and schedule regular backups, and enjoy the

peace of mind that comes from the knowl-

edge of fully backed up data.

To further simplify data backup, LaCie

oﬀers ‘1-Click’ Backup Software (Win-

At Home For Multimedia Content

Home Oﬃces & Small Businesses

Corporate Departments

Publishing, Design or Architectural

Firms

❖

dows users only) for free download. Sim-

ply set up backup proﬁles, and you’re a click

away from backing up your data onto the

Ethernet Disk or the Ethernet Disk mini.

Who Will Use It?

Teams working on joint projects,in environ-

ments with little or no technical expertise.

IP Configurator Sofware Web-Based Administration Page

1GB = 1,000,000,000 bytes. Total accessible capacity varies depending upon operating environment

(typically 10–15% less).

Data Sharing Solutions from LaCie | Page 6

LaCie Shared Storage Solution Product Family Comparison

LaCie Ethernet Disk LaCie Ethernet Disk mini

Capacity 1TB 2 TB 250GB 320GB 500GB

Item number 300963 900961 301136 301137 301138

Interface Gigabit Ethernet 10/100/1000 Gigabit Ethernet 10/100/1000 & USB 2.0

Interface transfer rate Gigabit Ethernet: 1000 Mbits/s Ethernet: 100 Mbits/s / USB 2.0: 480 Mbits/s

Rotational speed /

cache

7200 RPM / 8MB 7200 RPM / 8MB (16MB for 500GB Drive)

Processor / memory VIA C3 800Mhz / 256MB DDRAM 400Mhz / 64MB DDRAM

Operating system Windows® XP Embedded Linux Kernel 2.4

Expandability 2 x Hi-Speed USB 2.0 ports for:

Expanding the network storage

Scheduling Backup on USB storage

devices

❖

1 x USB 2.0 for additional storage &

photo sharing (compatible with USB mass storage

cameras)

Network Protocols TCP/IP

Windows: CIFS/SMB

MAC: AFP v3.1/NetTalk

FTP, http

❖

File Server: SMB (Windows/Linux), AFP (Mac)

FTP Server

HTTP for online browsing

Multimedia server: UPnP™ A/V

Apple Bonjour

❖

Network

Compatibility

Apple Bonjour Protocol

Microsoft Active Directory (ADS)

DNS, WINS

File Level Security (ACLs)

❖

Easy setup &

Management

LaCie IP congurator with setup wizard DHCP auto IP assignment

Web-based management

❖

Supported OS Windows® 98SE, 2000, Me, XP, Vista

Mac® OS 9**, Mac OS X

Linux 2.4 & higher or UNIX

**Not compatible with Mac OS 9 in

all double-byte character languages.

❖

Windows® 98SE*, 2000, Me*, XP, Vista

Mac® OS 9**, Mac OS X

Linux 2.4 & higher

*Only on the network

**Not compatible with Mac OS 9 in all

double-byte character languages.

❖

Data Sharing Solutions from LaCie | Page 7

LaCie creates external storage solutions and color monitors

that help professionals and everyday people easily manage

their digital lives. Powerful technology combined with unique

designs by the internationally acclaimed Philippe Starck, Neil

Poulton and Porsche Design GmbH make LaCie the world

leader in storage innovation. Established in France in 1989,

LaCie is now headquartered in North America, Europe and

Asia and listed on the Paris Nouveau Marché (code 5431).

For more information, visit www.lacie.com.

LaCie • 22985 NW Evergreen Parkway, Hillsboro, OR 97124 USA

LaCie • 17 rue Ampère 91349 Massy Cedex FRANCE
