• Huge capacities – up to 7.5TB and scalable

• Easy setup – simply plug into a SATA host

• Reliable – provides enhanced data security

• Fast – ideal for audio/video, creative pros

LaCie Biggest S2S

with SATA II 3Gbits/s PCI-X/PCI-E Card 4E

5-DISK SATA II RAID SYSTEM TOWER

7.5TB

The Power of the Tower

The second product in our powerful new RAID range, the

LaCie Biggest S2S is an extraordinary combination of high

capacity (up to 7.5TB), RAID security, and speed in a sleek

5-drive tower. The LaCie Biggest S2S is coupled with a

new processing architecture that provides enhanced data

protection, high capacity storage, and a convenient plug

& play user experience. Supporting RAID levels 0, 1, 0+1,

and JBOD, this high-volume solution at a fraction of the

cost for traditional RAID systems is comparatively more

affordable and more reliable.

Reliable and Versatile Data

Management

Multiple appliances can be used with this scalable device. For

added versatility, use it across operating systems, whether PC

or Mac based. A simple and affordable answer to all of your

storage needs, it transparently replicates your data, eliminating

a vulnerability that is too often overlooked or considered too

expensive to solve. Volumes can be created with mirrored drives

providing automated protection along with notiﬁcations to let

you know when a drive needs replacement. It also delivers

exceptional sequential access performance.

Advanced SATA II 3Gbits/s

Technology

This innovative storage device is powered by the newest

industry-leading Serial ATA (SATA II) 3Gbits/s technology.

For easy set-up, simply plug it into a SATA II 3Gbits/s

host and enjoy a rapid sustained transfer rate of up to

187MB/s***. This technological powerhouse comes bundled

with the LaCie SATA II 3Gbits/s PCI-X/PCI-E Card 4E.

SATA + RAID: Perfect For Professionals

The LaCie Biggest S2S is designed for business professionals

who require security and speed in external storage. Safely store

databases and ﬁles on a network, or use for Web servers, email

and imaging systems. It provides enhanced data security from

loss due to disk failure. Supporting HD Video streams of up to

HDTV 1080i and 1080p (non-compressed) makes it ideal for

audio/video and creative professionals. Audio/video editors

can stripe the drives to immediately store and access clips in

real-time without dropping frames.

*1 GB = 1,000,000,000 bytes. Total accessible capacity varies depending upon operating environment (typically 5–10% less).

**Windows XP will not recognize single volumes greater than 2TB.

***Sustained transfer rates can vary for a RAID product in function of several elements like: the host interface, the selected RAID conﬁguration (storage policy), etc.

Other product and brand names mentioned herein may be trademarks or registered trademarks of their respective owners.

Speciﬁcations and appearance are given as guidelines and are subject to change without notice. www.lacie.com

090106

7.5TB (PCI-X) 7.5TB (PCI-E)

301471 301472

SATA II 3Gbits/s

5 bays x SATA 3.5”

Mac: up to 187MB/s; 64-bit PC: up to 160MB/s; 32-bit PC: up to 99MB/s

0, 1, 0+1, JBOD

0-35 °C / 32-95 °F

Up to HDTV 1080i and 1080p (non-compressed)

20-80% non-condensing

10-90% non-condensing

5.8 x 8 x 10.3 in. / 14.4 x 20 x 25.7 cm

18.5 lbs. /8.4 kg (with drives installed)

150 W maximum (unit with 5 drives)

110-240VAC, 50/60 Hz

For each drive, host connection, fault indication, and power indication

Console (GUI)

3-year limited

Capacity*

Item Number

Host Interface

Disk Interface

Sustained Transfer Rates**

Supported RAID Levels

Operating Temperature

Supported HD Video

Operating Humidity

Storage Humidity

Dimensions (WxHxL)

Weight

Power Consumption

Power Connection

LEDs

Software Management

Warranty

LaCie Biggest S2S with SATA II 3Gbits/s PCI-X/PCI-E Card 4E

Features

New generation SATA II 3Gbits/s technology•

Very high sustained transfer rates: up to 187MB/s***•

5 bays with hot-swappable drives•

Supports RAID levels 0, 1, 0+1, JBOD•

Automatic online rebuilding•

Supports non-compressed video stream up to HDTV 1080i•

and 1080p

Cross-platform for PC and Mac•

Automatic volume expansion•

Comes with the LaCie SATA II 3Gbits/s PCI-X/PCI-E•

Card 4E

Box Contents

LaCie Biggest S2S with eSATA 3Gbits/s host adapter•

Power cable, SATA II 3Gbits/s external cable (2 meters),•

LaCie Biggest S2S Utilities CD-ROM with User Manual,

LaCie eSATA host adapter with CD-ROM including driver

and Quick Install guide

LaCie SATA II 3Gbits/s PCI-X Card 4E; CD-ROM with User•

Manual; Quick Install Guide

Minimum System Requirements

Supported OS: Windows 2000, Windows Server 2003,•

Windows XP**, Windows VistaTM / Mac OS 10.3.9 or later
