LaCie D2 Quadra Manuel utilisateur

LaCie d2 Quadra Hard Disk

eSATA 3Gbits, FireWire 800, FireWire 400 and USB 2.0

Quadruple Interface

For Professional Use

Design by Neil Poulton

Clever, Advanced Design

The d2 Quadra’s new design is sturdy, compact and

versatile, making it ideal for intensive professional use. The

unique, fanless aluminum heat sink design with 60% more

surface area for heat dissipation keeps it quiet and as safe

as possible at all times. The d2 Quadra can stand upright,

be stacked horizontally with other drives or rackmounted to

save desktop space.

High-End Features

With fast burst transfer rates of up to 105-115MB/s** via eSATA,

this industry-leading hard disk delivers superior performance.

Setup and use is quick and easy; the preloaded LaCie Setup

Assistant helps format the hard disk according to your needs.

With the LaCie Shortcut Button*, you can easily launch any

application with one push such as the included Genie Backup

Assistant software with data restore for Windows users or Intego

Backup Assistant software with data restore for Mac users.

The Professional Choice

Perfect for digital content creation, audio/video editing, DVD

authoring, web animation, etc., the d2 Quadra can handle multiple

demanding professional tasks. It can be daisy-chained via FireWire

or connected to your DV camera and is even bootable in FireWire

for Mac and in eSATA for Mac/PC. Advanced features include

3-level power management (Auto/On/Off)* and software RAID 0/

RAID 1 potential when daisy-chained with other drives.

Perfect All-In-One Solution

The LaCie d2 Quadra Hard Disk provides up to an incredible

1TB capacity in a relatively compact device. Fully loaded with

all the best interfaces – eSATA 3Gbits, FireWire 800, FireWire

400, and USB 2.0 – it offers complete universal connectivity

for PC and Mac users. Use it to easily store all of your ﬁles or

back up your computer or small server regularly, whether at

home or the ofﬁce.

• Quadruple interface for full PC/Mac compatibility

• Superior burst transfer rates up to 105-115MB/s (eSATA 3Gbits)

• Space-saving versatility - stack, rackmount or stand upright

• Sturdy, aluminum d2 heat sink design

Power switch

FireWire 400 port

FireWire 800 ports

USB 2.0 port

eSATA port

Power adatror connection

Chain lock option

Heat Sink

Design

Standard

Design

100GB***=

7 hours of DV video or

35,000 songs or

100,000 photos****

USB 2.0

MEGABYTES PER SECOND

BURST READ TRANSFER RATE BENCHMARK**

PERFORMANCE COMPARISON

0306090120

FIREWIRE 400

FIREWIRE 800

eSATA 3Gbits

Apple® Time Machine and Leopard Compatible

The LaCie d2 Quadra Hard Disk is compatible with Mac OS X v10.5 Leopard, including Time Machine,

making it an ideal partner for your Mac. Time Machine automatically backs up your Mac’s system ﬁles,

applications, accounts, preferences, music, photos, movies, and documents to an external hard drive

and you can easily go back in time to recover anything.

Features

• eSATA, FireWire 800, FireWire 400, and USB 2.0

• Superior heat dissipation

• Triple (Auto/On/Off) power management*

• Stack, rackmount, or stand upright

• Daisy-chainable (FireWire)

• Plug & play

• LaCie Shortcut Button*

• Advanced backup software

Box Content

• LaCie d2 Quadra Hard Disk

• eSATA-to-eSATA cable

• FireWire 800 (9-pin) cable

• FireWire 400 (6-pin) cable

• Hi-Speed USB 2.0 cable

• Drive stand for upright use

• External power supply

• Utilities with User Manual (preloaded on the drive):

- LaCie Setup Assistant

- Genie Backup Assistant software with data restore for

Windows 2000, XP, Vista

- Intego Backup Assistant software with data restore for

Mac OS X 10.4

• Quick Install Guide

System Requirements

• Computer with an eSATA, FireWire 800,

FireWire 400, or USB 2.0 port

• Windows®2000, Windows XP, Windows VistaTM;

500MHz processor or higher

• Mac®OS 10.2.8 (Mac OS 10.3 for eSATA) or later;

G4, G5, Mac Intel 500MHz processor or higher

• Minimum 128MB RAM

(512MB or greater recommended)

LaCie 2big

LaCie d2 Hard Disk

LaCie Little Big Disk

LaCie 4big

LaCie Big Disk

*The Shortcut Button and Auto/On/Off features are available via FireWire and USB but are not available from an eSATA bus.

**Burst transfer rates vary from one computer to another and may vary slightly from one drive to another. Average speed is usually lower, depending on host conﬁguration.

***The Shortcut Button and Auto/On/Off features are available via FireWire and USB but are not available from an eSATA bus.

***1GB = 1,000,000,000 bytes. Total accessible capacity varies depending upon operating environment (typically 5–10% less).

****Calculations are based on approximately 13GB/hour of DV video, 2.85MB/MP3 song, and 1MB/JPEG photo.

owners. Speciﬁcations and appearance are given as guidelines and may change without notice. www.lacie.com 081230

LaCie d2 Quadra Hard Disk

301440 301441 301442 301425

500GB 750GB 1TB 1.5TB

1 x eSATA 3Gbits port

2 x FireWire 800 ports (9-pin)

1 x FireWire 400 port (6-pin)

1 x Hi-Speed USB 2.0 port (USB 1.1-compatible)

eSATA: up to 3Gbits/s (300MB/s)

FireWire 800: up to 800Mbits/s (100MB/s)

FireWire 400: up to 400Mbits/s (50MB/s)

Hi-Speed USB 2.0: up to 480Mbits/s (60MB/s)

eSATA: up to 105-115MB/s

FireWire 800: up to 75-85MB/s

FireWire 400: up to 35-40MB/s

Hi-Speed USB 2.0: up to 30-35MB/s

7200rpm

16MB or greater

launch any application with one push

“Auto” for energy efﬁciency; “On” for instant access; “Off” for data protection

3.31 lbs. / 1500 g

1.7 x 6.3 x 6.8 in. / 44 x 160 x 173 mm

3-year limited

Item Number

Capacity***

Interface

Interface Transfer Rates

(maximum bus speed)

Read Burst Transfer Rates:**

(maximum theoretical bus speed)

Rotational Speed

Cache Size

Shortcut Button*

Triple Power Management*

Weight

Dimensions (WxHxD)

Warranty

Premium 3 Year Warranty

The d2 Quadra Hard Disk comes with a 3 Year Limited

Warranty. For superior service, it also comes with an

optional Advance Replacement Warranty, which can be

purchased separately online within 30 days of the purchase

date. Under the Advance Replacement Warranty, LaCie

will immediately swap out the product without it needing to

be returned ﬁrst for minimal interruption of your workﬂow.

LaCie covers all freight costs. Availability depends on the

sales area. See www.lacie.com for details.

OPTIONAL

ADVANCE

REPLACEMENT

WARRANTY
