SET UP GUIDE

Wi-Fi PROFESSIONAL

WEATHER STATION

MODEL NUMBER V51 (BP77970)

Table of Contents

RAINBASICS LA CROSSE VIEW

FORECAST

PRESSURE

EXTRA SENSORS

Positioning Your Sensor

Viewing Your Rain Data

Cleaning & Storage

Initial Setup

Station Settings

Buttons

LCD Display Brightness

Auto-Dim Settings

Connecting to the App

Connecting Your Station

Adding Your Sensor to

the App

Seasonal Trees

Standalone Forecast Icons

Enhanced Forecast Data

Daily/Hourly Forecast

Relative Pressure

Add-On TH Sensor

Add-On Sensor Info

Adding an Extra Sensor 02

Initial Setup

Power Up

TEMP. & HUMIDITY (TH)

Viewing Your TH Data

History Records

“Feels Like” Temp.

APPENDIX SUPPORT

Speciﬁcations

Warranty

Recycling & Disposal

Cautions/Statements

Patents

Support Information

Factory Reset

Stay in Touch

22-23

WIND

Positioning Your Sensor

Installation Options

Viewing Your Wind Data

History Records

Wind Speed Alert

Note: It may take up to 10 minutes for your sensor data to appear on your

station’s screen.

BASICS

1. Unlatch the Locking Tabs on the sides of the Rain Sensor to remove the Funnel.

Then install 2 “AA” batteries into the Battery Compartment.

Install 3 “AA” batteries into the Battery Compartment of your Breeze Pro Sensor.

Insert the 5V Power Adapter into an outlet, and then plug it into the Power Jack

on the back of the station. Next, remove the Insulation Tab from the station’s

Battery Compartment.

Bottom of Breeze Pro SensorInside of Rain Sensor Back of Station Power Jack

03 04

Connecting to the App Connecting Your Station

LA CROSSE VIEW LA CROSSE VIEW

Connecting to Your Wi-Fi Network

Download the La Crosse View App

Visit the App Store or Google Play Store to download the free La Crosse View

app onto your mobile device.

Stay connected to your home anytime, anywhere

with the La Crosse View app.

Monitor home conditions and set alerts so your home

can get ahold of you when something seems o.

Connecting your station is optional and the display

will function as a standalone unit without the Wi-Fi

connection. However, we recommend connecting

during the initial setup, as it will save you time and

unlock all of the advanced features right away.

Launch the App

Open the La Crosse View app and follow the on-screen setup instructions.

Stay Connected to Your Home

Anytime, Anywhere.

Checking Your Station’s Wi-Fi Status

Press the SET button on the top of the station to view your Wi-Fi Status.

ALL OK CONNECTED: Your station is connected to your

Wi-Fi and its data should be available on the station and

in the app.

SEE APP TO CONNECT: Check your La Crosse View

app for notiﬁcations.

NO WEATHER SERVICE: Your Internet weather and time

services are not connecting. These should resolve on

their own, please be patient.

LOST WIFI: Check your router and network

connections.

For more information, scan the QR code or visit:

www.lacrossetechnology.com/view

Now that you’ve created your La Crosse View account, it’s time to connect your station to

your home router using the La Crosse View app.

The La Crosse View app is required to connect the station to your Wi-Fi network. Download, install,

and log into your La Crosse View account ﬁrst.

New User Initial Setup: When ﬁrst setting up

your station, the app it will lead you through a

series of instructions to help get your station

added into your account and connected to

your home Wi-Fi network.

Manually Add & Connect Display: After the

initial walk-through, stations can be added and

connected via the Devices tab in the app’s

main menu. Simply tap the Add Device or Plus

(+) button at the bottom of the Devices page

in the app.

Follow the initial app instructions or manually add the display into your account.2.

When connected, the indicator on the display will become solid.3.

Station Settings

BASICS

** The default pressure reading is 29.92 INHg (1013 hPa). The station will acclimate on it’s own if the

pressure number is not set. Learn more on page 19

* Rain data will be displayed in Inches when Fahrenheit is selected, and in Millimeters when Celsius is

selected within the Settings Menu.

* This step is only required if you do not receive the Add Device notiﬁcation within the app.

Prior to connecting to Wi-Fi and mounting your sensor, make sure your station is receiving sensor data.

Use the +/- buttons on the

top of the station to adjust

the values.

Press the SET button to

conﬁrm selection and move

to next step.

You may exit the Settings

Menu at any time by pressing

the LIGHT button.

Settings Menu Order*

Greeting • Language • Beep On/O • 12/24 Hour Time • Hour • Minute • Year

Month • Date • Calendar Order (Month/Date or Date/Month) • Fahrenheit/Celsius

Pressure Units (InHg/hPa) • Pressure Number Setting** • Wind Speed Units (MPH

or KMH) • Wind Direction (Letters or Degrees) • Thank You

When the station is ﬁrst powered on, it will begin searching for your outdoor

sensors, which should connect shortly.

To manually set your time, date, and other settings, hold the SET button to

enter the Settings Menu.

Notes: Weekday will set automatically after year, month, & date settings are adjusted.

If you’re connected to the Wi-Fi, the time and date will automatically update from the

Internet. See pages 3-4 for more information.

Adding Your Sensor to the App

LA CROSSE VIEW

Upon getting the station connected to your Wi-Fi network, the next app screen

will explain how your connected sensor(s) should be brought in. Within the next

15 minutes, you should receive an Add Device notiﬁcation in your app. This is

indicated by the Red Cloud and the numbers inside of it. Tap this icon to begin

adding your sensor(s) into the app.

123456-ABC

Manually Add Sensor Into the App*

Open your La Crosse View app. On the Main Menu, go to ADD/EDIT

and select DEVICES.

Scan the Barcode on your Breeze Pro Sensor or type in the

Device ID manually.

Conﬁrm the sensor image and Device ID and add a Device

Name and Location Name. Select DONE.

On the Devices page, select the ADD DEVICE or PLUS (+) button.

Buttons

BASICS

1. WIND ALERTS

Hold to enter Wind Alert Settings. Press to turn

Wind Alert on/o.

2. WIND

Press to view Wind Speed History. While viewing,

hold the MINUS button to reset the history value.

3. TEMP.

Press to view Temperature and Humidity History.

While viewing, hold MINUS button to reset the

history value. Hold to search for TH reading.

6. EXTRA

Press to toggle through rain, pressure, and extra

sensor data. Hold to add sensors. While viewing,

hold the MINUS button delete the sensor.

9. DAILY/HOURLY

Press to see Daily or Hourly Forecast.

Hold to auto-scroll Forecast data.*

4. SET

Press to view Wi-Fi status. Hold to enter Settings

Menu.

7. SENSOR

Press to view sensor ID numbers. While

viewing, hold the MINUS button delete the

sensor.

5. PLUS/MINUS (+/-)

Use to adjust values.

8. LIGHT

Press to adjust backlight. Hold to enter

Auto-Dim settings.

6 8

Side View Back View

* Your display must be connected to Wi-Fi to receive Daily/Hourly forecast information.

Please Note: Only the hour can be set.

LCD Display Brightness

Adjusting the LCD Display Brightness

Auto-Dim Settings

Press the LIGHT button to adjust the backlight intensity.

There are 4 brightness levels, plus an o option.

Hold the LIGHT button to enter

the Auto-Dim Settings Menu.

Program your display to automatically

dim during preselected times.

Press the +/- buttons to turn the

Auto-Dim feature on or o. Press

LIGHT to conﬁrm.

Press the +/- buttons to adjust

the starting hour. Press LIGHT to

conﬁrm.

Press the +/- buttons to adjust the

stopping hour. Press LIGHT to

conﬁrm and exit.

The icon will appear on the LCD when the Auto-Dim feature activated.

BASICS

10. WIFI

Press during initial setup for Wi-Fi

Connection (see app). Hold to re-enter

Conﬁguration Mode and clear previous

Wi-Fi settings.

Positioning the Rain Sensor

For Accurate Measurements Cleaning Your Rain Sensor

Winter Storage Options

•Mount the Rain Sensor horizontally and ensure it’s level.

•The sensor should be mounted more than 3 feet (91.4 cm)

above ground.

•Your Rain Sensor needs to be in an open area for

accurate readings.

•Ensure the base of your Rain Sensor is not in a depression.

•This sensor has drainage holes in its base that allow it to

self empty.

•View sensor mounting video at: bit.ly/Rain_SensorMounting

•Leaves, grass, or other debris may need

to be removed periodically from the funnel

of your Rain Sensor.

•Be sure to check inside your Rain Sensor

as well. Insects or dirt can begin to restrict

the movement of the Rocker.

•Unlatch the Locking Tabs on the side

of the Rain Sensor to remove the Funnel.

This will allow you to easily clean each part

separately.

•Remove batteries and store in a safe place.

•Remove batteries and cover in place.

•Leave outside, uncovered. While the Rain

Sensor cannot accurately record snowfall,

when the snow melts the water will be

counted as rain.

•The Rain Sensor is self-emptying, so water

should not freeze inside.

Rain Sensor Cleaning & Storage

Viewing Your 24 Hour Rain Data

•Your rain data will show in the Extra Sensor area.

Its values will reset to zero after 24 consecutive

hours of no additional rainfall.

•Press the EXTRA button to cycle through the

Pressure, Rain, or Extra Sensor data displayed

on the LCD.

•The Auto Scroll Icon ( ) indicates the display

will automatically switch between extra sensor

readings.

Rain Data Example Pressure Example

RAINRAIN

Locking Tabs

Rocker

Battery

Compartment

Funnel

•This Rain Sensor is designed for outdoor

use and will withstand temperatures below

freezing.

Please Note: Rainfall data can only be erased

with a factory restart or by manually deleting the

rain sensor from the display. For this reason, we

recommend waiting for 24 hours of no rainfall for

the unit to reset to zero on its own.

Positioning the Breeze Pro Sensor

For Accurate Measurements

Included Mounting Accessories

•Ensure the sensor is mounted level with the Solar Panel facing

directly to the south. This will help optimize battery life and transmit

correct wind direction readings.

•Ideally, the Breeze Pro Sensor should be mounted on the tallest

object in your area. Avoid positioning the sensor in line or below

eaves, rooﬂines, trees, or other objects that may obstruct wind

readings.

•Make sure all screws on the Mounting Bracket, Winds Cups,

Wind Vane, and Battery Compartment are securely fastened.

•The sensor should be mounted with the Wind Cups on top.

Mast

The horizontal conduit where the sensor

attaches. This piece will connect to either

the Adjustable Base or Pole Adapter.

Adjustable Base

The main bracket used for mounting onto ﬂat surfaces or with

added U-bolts (not included). The grooves and Hand Screw allow

the bracket to secure to angled surfaces while still ensuring the

Mast and sensor are level.

Hand Screw

Used to lock down and secure the Mast

to the Adjustable Base or Pole Adapter.

Alignment Arrows

Provide exact 90 or 180 degree

angles when aligned with the arrow

on the Mast.

Pole Adapter

Used in place of the Adjustable Base

for mounting on top of cylindrical

conduits.

1-Inch Maximum Pole Diameter 12

Installation Options

For Accurate Measurements

Basic Assembly

Advanced Installation Options

Fence posts, poles, decks, and even mailboxes are all common mounting options due to their convenience.

Many users prefer these types of locations as the data they provide is accurate from their ground level

perspective. However, because wind in these spots is often aected by obstructions, the readings may

dier compared to local reporting stations.

Some advanced installation options include tripods, wall mounts, eave cross mounts, chimney mounts,

and many others. Any of these can be combined with U-bolts for attachment onto a tall cylindrical conduit

using our Adjustable Base. Please note that these advanced options will require additional equipment and

possibly professional help for best results.

The illustrations above are

not to scale and are for

informative purposes only.

La Crosse Technology is not

responsible for any damages

or injury that may occur during

installation.

U-Bolt Adapters

1B Pole

Adapter

1A.

1B.

Mount the Adjustable Base onto a ﬂat surface

using the four long screws provided.

Secure the Pole Adapter to a cylindrical

conduit using the two smaller screws provided.

Insert the Mast into the Breeze Pro Sensor and

tighten the provided screws on the sides.

Use the Hand Screw to attach the Mast to either the Adjustable

Base or Pole Adapter. Ensure the sensor is level, facing south,

and securely fastened at all mounting points.

1A Adjustable Base

Tripod

Setup

Chimney

Mount

WIND WIND

Viewing Your Wind Data

WIND

1. WIND SPEED TREND

INDICATOR

Shows wind speed trends

over the past 60 minutes

2. COMPASS ROSE

Displays cardinal direction

with animated arrows

(16 directions total)

Indicates if the station is

receiving data from the

sensor

8. WIND DIRECTION

3. CURRENT WIND SPEED

Appears when the sensor’s

batteries needs to be

replaced

6. BREEZE PRO SENSOR

LOW BATTERY ICON

The top wind speed in the

past 31 seconds

Choose between cardinal

points (letters) or degrees

in the Settings Menu for

Current Wind Direction

7. RECEPTION ICON

5. TOP WIND SPEED

The top wind speed in

the past 60 minutes

4. WIND SPEED ALERT

Appears if a wind speed

alert is set & active

Prevailing Wind Direction

over the past hour

9. PREVAILING DIRECTION

Wind Speed History and Alerts

WIND

Viewing Wind Speed History Records

Activate/Deactivate Wind Speed Alert Important Notes:

Press the WIND button to toggle

through wind speed history records

with time and date stamps.

The wind speed records include:

past 24 hours, 7 days, 1 month, & 1 year.

Press the WIND ALERTS button to activate/

deactivate the alert. WIND SPEED ALERT ON or

OFF will appear on the bottom of the LCD.

•The alert is defaulted to be o.

•When the armed alert value is reached, the station

will beep and the icon will ﬂash. Press any button

to stop the alert sound.

•The Alert Icon will remain ﬂashing until out of the

alert range.

•This Wind Speed Alert is for the station only

and will not aect the app.

1. Hold the WIND ALERTS button to enter the Alert Settings Menu.

2. Use the +/- buttons adjust wind speed alert settings. Press the WIND ALERTS

button to conﬁrm your selection.

3. Your wind speed alert is active when the icon on.

Setting the Wind Speed Alert Monthly Wind Speed Record Example

1. FORECASTED HIs & LOs*

(or Outdoor Records)

Daily Forecasted Highs & Lows

from AccuWeather*

2. “FEELS LIKE”

TEMPERATURE

Based on current temp. & wind

speed (heat index & wind chill)

3. OUTDOOR TEMPERATURE

4. BREEZE SENSOR ICON

Current Outdoor Temperature

6. TH SENSOR ICON**

Indicates readings are provided

by an add-on TH sensor

Indicates TH readings are

provided by the Breeze Pro

Sensor

7. INDOOR TEMPERATURE

Current Indoor Temperature

5. OUTDOOR HUMIDITY

Current Outdoor Humidity

8. INDOOR HUMIDITY

Current Indoor Humidity

* Your station must be connected to Wi-Fi to receive AccuWeather forecast data. If you’re not connected, outdoor

history records will be displayed.

** An add-on Thermo-Hygro (TH) Sensor must be connected to view readings separate from you Breeze Pro Sensor. 16

Temperature & Humidity Records

TEMPERATURE & HUMIDITY

Viewing Records

Resetting Individual Temperature &

Humidity Records

Records Viewing Order

“Feels Like” Temperature

Press the TEMP button to toggle through indoor/

outdoor temperature & humidity history records

with time and date stamps.

Press the TEMP button to view the

individual temperature & humidity values

you’d like to reset.

Next, hold the MINUS (-) button until

dashes appear on the LCD.

This reading is now reset to your

current temperature or humidity value.

This reading indicates both Wind Chill and Heat index values when

conditions are met.

•Outdoor High Temperature

•Outdoor Low Temperature

•Outdoor High Humidity

•Outdoor Low Humidity

•Indoor High Temperature

•Indoor Low Temperature

•Indoor High Humidity

•Indoor Low Humidity

•“Feels Like” High Temperature

•“Feels Like” Low Temperature

•Dew Point

•Wind Chill: When temperature is below 50°F and there is 5 MPH sustained wind speed.

•Heat Index: When temperature is above 80°F.

•Current Temperature: When the temperature is between 51°F and 79°F, the reading will

remain the same as the outdoor value regardless of humidity or wind speed.

Viewing Your Forecast Data

FORECAST

Forecast Icons

Please Note: The Forecast Icons may not represent your current weather. They are a future prediction

of the weather to come over the next 12 hours.

When using this station without Wi-Fi connection, the

display will use changes in barometric pressure to

predict your weather to come in the next 12 hours.

This is represented by the 6 forecast scenes below.

However, when connected to Wi-Fi, the station

will receive additional weather icons, chance of

precipitation values, and future forecast information.

These enhanced Internet features are powered by

AccuWeather.*

Seasonal Trees

Foliage Scenes

The foliage scene in the forecast section changes

seasonally. The dates are pre-programmed.

*Your display must be connected to Wi-Fi to receive AccuWeather forecast data.

Available Forecast Icons on Standalone Station

Sunny Clouds T-StormPartly Sunny Rain Snow

Spring (March 20th to June 20th)

Summer (June 21st to Sept. 20th)

Fall (Sept. 21st to Dec. 20th)

Winter (Dec. 21st to March 19th)

17 18

Viewing Your Forecast Data

FORECAST

Daily & Hourly Forecast Buttons

When connected to Wi-Fi, use the DAILY & HOURLY buttons on the side of the station to view

future forecast information.

Tip: The icon will appear in the top right corner of the forecast section when your display is

connected and receiving AccuWeather forecasts.

Sunny

Light Snow

Clouds

Wintry Mix

Rain

Ice

Partly Sunny

Snow

Light Rain

Windy

T-Storm

Fog

Available Forecast Icons when Connected*

Daily Forecast: Press the DAILY

button on the side of the station

to view individual Daily Forecasts.

Hold to automatically scroll

through all 7 days.

Hourly Forecast: Press the

HOURLY button to view

individual hourly forecasts.

Hold to automatically scroll

through all 12 hours.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels La Crosse Technology Station météorologique

La Crosse Technology

La Crosse Technology C85845V5 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-8300U Manuel utilisateur

La Crosse Technology

La Crosse Technology 308-1417v3 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-9740U-IT-NRC Manuel utilisateur

La Crosse Technology

La Crosse Technology S88785 Manuel utilisateur

La Crosse Technology

La Crosse Technology 308-1412-3TXV2 Manuel utilisateur

La Crosse Technology

La Crosse Technology Wireless Weather Station Manuel utilisateur

La Crosse Technology

La Crosse Technology 724-1409 Manuel d'utilisation et d'entretien

La Crosse Technology

La Crosse Technology C85845v4 Manuel utilisateur

La Crosse Technology

La Crosse Technology 302-604 Fiche technique

La Crosse Technology

La Crosse Technology S86842 Manuel d'utilisation et d'entretien

La Crosse Technology

La Crosse Technology 308-1451v2 Manuel utilisateur

La Crosse Technology

La Crosse Technology 308-1425CV2 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-3610-SAL Manuel utilisateur

La Crosse Technology

La Crosse Technology WEATHER DIRECT WD-3103U Manuel utilisateur

La Crosse Technology

La Crosse Technology 327-1417BW Dimensions

La Crosse Technology

La Crosse Technology WS-9065TWC Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-9630TWC-IT Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-6010U-IT Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-7049 Manuel utilisateur

La Crosse Technology

La Crosse Technology 308-1415BWV2 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-9004U Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-8015U Manuel utilisateur

La Crosse Technology

La Crosse Technology WW85777 Manuel d'utilisation et d'entretien

Manuels Station météorologique populaires d'autres marques

Auriol

Auriol AHFL 433 A1 Manuel utilisateur

NexSens

NexSens G2-HYDROMET Manuel utilisateur

Hyundai

Hyundai WS 2202 Manuel utilisateur

IROX

IROX HBVR761 UV-X Manuel utilisateur

ADE

ADE WS 1711 Manuel utilisateur

Auriol

Auriol z29592 Manuel utilisateur

Auriol

Auriol 296289 Manuel utilisateur

Hyundai

Hyundai WS 2266 Manuel utilisateur

Ventus

Ventus W177 Manuel utilisateur

National Geographic

National Geographic VA Colour RC Manuel utilisateur

Renkforce

Renkforce 1208067 Manuel utilisateur

Levenhuk

Levenhuk Discovery Report WA40 Manuel utilisateur

Instant Transmission

Instant Transmission MA 10410 Manuel utilisateur

Lutron Electronics

Lutron Electronics PHB-318 Manuel utilisateur

WAREMA

WAREMA EWFS Weather station eco Manuel utilisateur

TFA

TFA 30.3013.IT Manuel utilisateur

Alecto

Alecto WS-1200 Manuel utilisateur

Oregon Scientific

Oregon Scientific RMR966PA Manuel utilisateur
