CA85152 FAQS

The links below will work in most PDF viewers and link to the topic area by clicking the

link. We recommend Adobe Reader version 10 or greater available at:

http://get.adobe.com/reader

CONTENTS

CA85152 FAQS........................................................................................................................... 1

Batteries ..................................................................................................................................... 2

Wireless Thermometer Factory Restart ........................................................................................ 2

Outdoor Temperature Transmitter ............................................................................................... 3

Compatible Outdoor Transmitters ............................................................................................ 3

Outdoor Temperature Signal Strength ..................................................................................... 3

Dashes shown for Outdoor Temperature ................................................................................. 3

Power requirements ................................................................................................................ 3

Outdoor Temperature changes constantly ............................................................................... 3

Inaccurate Outdoor Temperature reading ................................................................................ 4

Intermittent Outdoor Temperature ........................................................................................... 4

Outdoor Temperature is stuck or HHH, LLL.............................................................................. 4

Outdoor transmitter fell and no longer works............................................................................ 5

Outdoor Transmitter drains batteries quickly ............................................................................ 5

Temperature Trend Arrows...................................................................................................... 5

MIN/MAX Temperature readings.............................................................................................. 5

Mounting/Positioning Outdoor Transmitter ............................................................................... 6

Position Wireless Thermometer ............................................................................................... 7

Distance/Resistance/Interference............................................................................................. 7

Wireless Thermometer................................................................................................................ 8

How tall are the time numbers?................................................................................................ 8

Power requirements ................................................................................................................ 8

12-Hour or 24-Hour time format................................................................................................ 8

Dashes, HH.H, LL.L or stuck Indoor Temperature ..................................................................... 8

Inaccurate Indoor Temperature reading ................................................................................... 8

Fahrenheit/Celsius................................................................................................................... 9

Time is off by hours ................................................................................................................. 9

Manually Set Time/Date: Program Menu.................................................................................. 9

Wireless Thermometer has missing segments .......................................................................... 9

Wireless Thermometer is dim................................................................................................... 9

La Crosse Technology, Ltd. Page 2

Wireless Thermometer has distorted display ...........................................................................10

Wireless Thermometer display is frozen ..................................................................................10

Batteries

•Half of all warranty issues can be resolved with fresh batteries of the appropriate

voltage.

•We suggest name brand alkaline batteries for indoor displays such as Wireless

Thermometers.

•Use batteries dated at least six years in advance of the current year. Batteries dated

earlier than six years from now may still work, but may be unstable in performance.

•Alkaline batteries manufactured this year will have an expiration date 10 years in the

future. Battery technology has improved and batteries will maintain voltage longer in

storage. However, the environment the batteries reside in for the 10 years can deplete

the power.

•Good name brand batteries make less noise, which reduces the chance of RF (radio

frequency) interference from the battery compartment. A minimum voltage of 1.48V for

each battery is necessary for proper performance.

•Wireless Thermometers: Use alkaline batteries. Overpowered or underpowered

batteries may cause loss of indoor readings, missing segments, dim display etc.

Wireless Thermometer Factory Restart

FACTORY RESTART:

•DISTANCE: Bring the transmitter and Wireless Thermometer together inside and place

both 5-10 feet apart with nothing between them.

•REMOVE POWER: Remove batteries from transmitter and Wireless Thermometer.

•DISCHARGE ELECTRICITY: Press one of the buttons on the Wireless Thermometer at

least 20 times to clear all memory. Verify that the Wireless Thermometer is blank

before proceeding.

•UNPOWERED 10 MINUTES: Let the Wireless Thermometer and transmitter sit with

power removed for at least 10 minutes.

•WIRELESS THERMOMETER: Insert fresh alkaline batteries in the Wireless

Thermometer.

•TRANSMITTER: Insert fresh batteries into the transmitter, observing the correct polarity.

•PRESS TX BUTTON: Press the TX button on the back of remote Transmitter to transmit

RF (radio frequency) signal. Keep the transmitter 5-10 feet from the Wireless

Thermometer.

•WAIT: Wait for 5 minutes for the outdoor temperature to appear.

•CONNECTION: When RF (radio frequency) connection is established, the respective

temperature will appear on the main unit. Allow the transmitter and Wireless

Thermometer to sit together for 15 minutes to establish a strong connection.

La Crosse Technology, Ltd. Page 3

•PLACE TRANSMITTER OUTSIDE: For optimum 433MHz transmission, place the outdoor

transmitter a distance of no more than 200 feet (60 meters, open air) from the Wireless

Thermometer.

•See the section on mounting and distance/resistance/interference for details on

mounting the outdoor transmitter.

Outdoor Temperature Transmitter

Compatible Outdoor Transmitters

•A TX141-B outdoor transmitter comes packaged with this Wireless Thermometer.

•The TX141-B and TX141-A (433MHz) transmitters are compatible with this Wireless

Thermometer.

Outdoor Temperature Signal Strength

•The Wireless Thermometer will search for the outdoor temperature transmitter for 3

minutes.

•The antenna symbol will flash during reception, and temperature display will be dashes

“---“.

•If synchronization fails once, the antenna will lose one bar.

•If synchronization fails twice, the antenna will lose two bars.

•If RF (radio frequency) reception fails five times, the antenna symbol will show without

bars.

•The antenna will show full display with successful RF (radio frequency) reception.

Dashes shown for Outdoor Temperature

•Dashes mean the connection is lost between the Wireless Thermometer and the

outdoor transmitter.

•Batteries often resolve the connection.

•Distance/Resistance can cause loss of connection between the transmitter and the

Wireless Thermometer.

•Reorientation of the Wireless Thermometer 90 degrees towards the outdoor

transmitter may provide better reception. This allows more antenna surface to face the

transmitter signal.

•Try the factory restart.

Power requirements

•2-AA batteries power the outdoor transmitter.

•We recommend alkaline batteries for the transmitter.

•You may choose to use lithium batteries for temperatures below - 20°F/-28.8°C.

Outdoor Temperature changes constantly

La Crosse Technology, Ltd. Page 4

•You may have an additional compatible outdoor transmitter within range.

•Occasionally a neighbor will have a compatible outdoor transmitter that is within range.

Inaccurate Outdoor Temperature reading

•The outdoor transmitter reads the environment. When mounted in the home, it will read

inside temperature.

•When the transmitter reads high during the day, but not at night, it is a positioning

problem.

•Side-by-side test: Bring the outdoor transmitter in the house and place it next to the

Wireless Thermometer for 2 hours.

•Compare indoor and outdoor temperature. The temperatures should be within 4

degrees to be within tolerance.

•If the transmitter reads correctly when next to the Wireless Thermometer, then try a

different location outside.

•Look for heat sources such as sunlight, door or window frames, or reflected heat.

Intermittent Outdoor Temperature

•RF (radio frequency) communication may come and go occasionally. This can be

normal in some environments (e.g. moister climates). If transmitter signal is lost, please

wait 2-4 hours for the signal to reconnect on its own.

•Move the outdoor transmitter to a closer location.

•Freezer test: Confirm the Wireless Thermometer is reading the correct outdoor

transmitter. Place the transmitter in the freezer for an hour and watch the temperature

drop on the Wireless Thermometer.

•Indoor distance test: Please complete the Restart with transmitter and Wireless

Thermometer 5-10 feet apart and inside to establish a strong connection.

•After 15 minutes, if there is a reading in the outdoor temperature area, move the

transmitter to another room with one wall between the transmitter and the Wireless

Thermometer. Observe to see if the temperature remains on consistently for 1-hour.

•If the temperature remains on while in the house, then it is likely a distance/resistance

issue. Move the transmitter to different locations outside to find a location where the

temperature reading will hold.

•Distance/Resistance can cause loss of transmitter signal.

•Check Batteries.

Outdoor Temperature is stuck or HHH, LLL

•The last outdoor reading may remain (not change) for several hours when connection

is lost.

•The outdoor temperature reading will flash when the connection is first lost or

intermittent between the Wireless Thermometer and the outdoor transmitter.

•Check Batteries. Overpowered or underpowered batteries can cause this reading.

•Replace outdoor transmitter.

La Crosse Technology, Ltd. Page 5

Outdoor transmitter fell and no longer works

•If there is no physical damage to the outdoor transmitter, the fall may not have caused

internal damage.

•An outdoor transmitter that has fallen into a puddle, snow, or other standing water, it

may have water damage.

•Transmitters are water resistant, not waterproof.

•A fall can shock the transmitter or the batteries in the transmitter. Batteries that have

fallen on a hard surface may be damaged and unable to function properly.

•Complete a Restart with fresh batteries.

•Use Batteries dated at least six years in advance of the current year. Batteries dated

earlier than six years from now may still work, but may be unstable in performance.

Outdoor Transmitter drains batteries quickly

•Test a new set of alkaline batteries. Write down the date of installation and the voltage

of the batteries.

•When the batteries fail, please note the date and voltage again.

•Check the distance and resistance between the transmitter and Wireless

Thermometer. Transmitters at the end of the range may work while batteries are fresh

but not after they drain a bit.

•Check for leaking batteries, which may damage the transmitter.

•Battery life is over 24 months when using reputable battery brands for both Alkaline

and Lithium batteries.

Temperature Trend Arrows

The indoor and outdoor temperature trend indicators will update every 30 minutes or less.

These trends represent temperature changes over the past three hours.

•UP ARROW: Temperature rose more than 1°C/ 2°F in the past three hours.

•RIGHT ARROW: Temperature has not changed more than 1°C/ 2°F in the past three

hours.

•DOWN ARROW: Temperature fell more than 1°C/ 2°F in the past three hours.

MIN/MAX Temperature readings

The Wireless Thermometer will show the daily minimum and maximum temperatures each

day starting at midnight (12:00 AM). The Wireless Thermometer automatically resets the

min/max temperatures at midnight (12:00 AM).

•View MIN data: Press and release the MIN/MAX button to view the minimum Indoor

and Outdoor Temperatures.

La Crosse Technology, Ltd. Page 6

•Reset MIN data: Hold the MIN/MAX button for 5 seconds and the Indoor and Outdoor

Minimum Temperatures will reset. The temperature area will show dashes briefly then

return to current temperatures.

•View MAX data: Press and release the MIN/MAX button to view the maximum Indoor

and Outdoor Temperatures.

•Reset MAX data: Hold the MIN/MAX button for 5 seconds and the Indoor and all

Outdoor Maximum Temperatures will reset. The temperature area will show dashes

briefly then return to current temperatures

Mounting/Positioning Outdoor Transmitter

•Mount outdoor temperature transmitters vertically and under a bit of an overhang.

•Protect the outdoor transmitter from standing rain or snow, and from the overhead sun,

which can cause it to read incorrectly. Mounting under an eave or deck rail works well.

•Construct a small roof or box for the transmitter if you do not have an overhang. Please

be sure it is well vented.

•Mount the transmitter on the North side to prevent sun from causing incorrect readings.

•Mount at least 6 feet in the air for a strong RF (radio frequency) signal.

•Outdoor transmitters are water resistant but not water proof.

•Avoid more than one wall between the transmitter and the Wireless Thermometer.

•Do not mount near electrical wires, transmitting antennas or other items that will

interfere with the signal.

•RF (radio frequency) signals do not travel well through moisture or dirt.

•Place the outdoor transmitter and the Wireless Thermometer in the desired shaded

locations and wait approximately one hour before permanently mounting the

transmitter to ensure that there is proper reception.

•Do not mount the transmitter on a metal fence. This significantly reduces the effective

range.

MOUNT

•Choose a location for the transmitter that is within range of the Wireless Thermometer

and under an overhang for accuracy.

Option 1:

Install one mounting screw (included) into a wall leaving approximately ½ of an inch

(12.7mm) extended.

Place the transmitter onto the screw using the hanging hole on the backside.

Gently pull the transmitter down to lock the screw in place.

Option 2:

•Insert the mounting screw through the front of the transmitter and into the wall.

•Tighten the screw to snug (do not over tighten).

•To achieve a true temperature reading, mount where direct sunlight cannot reach the

outdoor transmitter.

La Crosse Technology, Ltd. Page 7

•Mount the outdoor transmitter on a North-facing wall or in any well shaded area. Under

an eave or deck rail work well.

•The maximum transmitting range in open air is over 200 feet (60 meters).

•Obstacles such as walls, windows, stucco, concrete, and large metal objects can

reduce the range.

•Place the transmitter at least 6 feet in the air to improve signal transmission.

Position Wireless Thermometer

•The Wireless Thermometer has a wide base to sit on a desk or table.

•Place within range of the outdoor transmitter.

•Choose a location 6 feet or more from electronics such as cordless phones, wireless

gaming systems, televisions, microwaves, routers, baby monitors, etc., which can

prevent signal reception.

•Be aware of electrical wires and plumbing within a wall. This will interfere with RF (radio

frequency) signal reception.

•The maximum transmitting range in open air is 200-feet (60 meters).

•Obstacles such as walls, windows, stucco, concrete, and large metal objects can

reduce the range.

Distance/Resistance/Interference

Distance:

•The maximum transmitting range in open air is over 200-feet (60 meters) between the

outdoor transmitter and the Wireless Thermometer. This range is in open air with ideal

conditions.

•Consider what is in the signal path between the Wireless Thermometer and the

transmitter.

•Consider the distance the Wireless Thermometer is located away from electronics in

the home.

Resistance:

•Obstacles such as walls, windows, stucco, concrete, and large metal objects can

reduce the range.

•When considering the distance between the transmitter and the Wireless Thermometer

(200 feet open air) cut that distance in half for each wall, window, tree, bush or other

obstruction in the signal path.

•Closer is better.

•Windows reflect the RF (radio frequency) signal.

•Metal absorbs the signal and reduces the range.

•Stucco attaches to the wall with a metal mesh that absorbs the signal.

•Do not mount the transmitter on a metal fence. This significantly reduces the effective

range.

Interference:

La Crosse Technology, Ltd. Page 8

•Consider items in the signal path between the transmitter and the Wireless

Thermometer.

•Sometime a simple relocation of the transmitter or the Wireless Thermometer will

correct the interference issue.

•Windows can reflect the radio signal.

•Metal will absorb the RF (radio frequency) signal.

•Stucco is backed by a metal mesh that holds it to the wall.

•Transmitting antennas (ham radio, emergency dispatch center, airports, military bases,

etc.)

•Electrical wires (utilities, cable, etc.)

•Vegetation is full of moisture and reduces signal.

•Dirt: Trying to receive a signal through a hill is difficult.

Wireless Thermometer

How tall are the time numbers?

The time numbers are 0.5 inches tall.

Power requirements

•2-AA alkaline batteries power the Wireless Thermometer.

12-Hour or 24-Hour time format

•Display the time in 12-hour or 24-hour format.

•Default is 12-hour time.

•Use the Program Menu to switch time formats.

Dashes, HH.H, LL.L or stuck Indoor Temperature

•This is generally a power related issue.

•Batteries may be overpowered or underpowered. Remove batteries from Wireless

Thermometer.

•Press any button 20 times. Leave the Wireless Thermometer unpowered for 1-2 hours.

•Install fresh alkaline batteries with correct polarity.

•If the indoor temperature is still dashes or OFL, the Wireless Thermometer may need

replacement.

Inaccurate Indoor Temperature reading

•Side-by-side test: Bring the outdoor transmitter in the house and place it next to the

Wireless Thermometer for 2 hours.

•Compare indoor and outdoor temperature. The temperature should be within 4

degrees to be within tolerance.

La Crosse Technology, Ltd. Page 9

•Look for heat sources such as sunlight, door or window frames, or reflected heat of

cold.

Fahrenheit/Celsius

Wireless Thermometer: Press the SET/°F/°C button to select Fahrenheit or Celsius

temperature readout.

Time is off by hours

•This Wireless Thermometer has manual set time.

•Use the program menu to set the time.

Manually Set Time/Date: Program Menu

The SET/°F/°C button moves through the program menu. The MIN/MAX/+ button

changes the value.

•12/24-HOUR TIME: Hold the SET/°F/°C button for 2 seconds. 12H will flash. Press and

release the MIN/MAX/+ button to select 24-hour time format. Press and release the

SET button once to move to the hour.

•HOUR: The Hour will flash. Press and release the MIN/MAX/+ button until the correct

hour is shown. Press and release the SET button once to move to the minutes.

•MINUTES: The Minutes will flash. Press and release the MIN/MAX/+ button until the

correct minutes are displayed. Press and release the SET button once more to exit the

program menu.

Note: When no buttons are pressed for ten seconds, the Wireless Thermometer will save

the last change and default back to normal mode.

Wireless Thermometer has missing segments

•This is generally a power related issue.

•Batteries may be overpowered or underpowered. Remove batteries from Wireless

Thermometer.

•Press any button 20 times. Leave the Wireless Thermometer unpowered for 1-2 hours.

•Install fresh alkaline batteries with correct polarity.

Wireless Thermometer is dim

•Most Wireless Thermometers have a gray background. Place the Wireless

Thermometer at eye level. Is it still dim?

•Wireless Thermometers that sit in the sunlight can develop a cloudy film over time.

•This is generally a power related issue.

•Batteries may be overpowered or underpowered. Remove batteries from Wireless

Thermometer.

La Crosse Technology, Ltd. Page 10

•Press any button 20 times. Leave the Wireless Thermometer unpowered for 1-2 hours.

•Install fresh alkaline batteries with correct polarity.

Wireless Thermometer has distorted display

•On a brand new Wireless Thermometer, check for thin plastic films of printed scratch

guard that may be on the upper and lower screen of the Wireless Thermometer. This

thin piece of plastic has printed numbers for store displays.

•With all power removed, the Wireless Thermometer should be blank.

•If numbers still appear, please check for scratch guard.

•This is generally a power related issue.

•Batteries may be overpowered or underpowered.

•Press any button 20 times. Leave the batteries out of the display for 2 hours.

•Insert fresh batteries into the Wireless Thermometer.

Wireless Thermometer display is frozen

•On a brand new Wireless Thermometer, check for thin plastic films of printed scratch

guard that may be on the upper and lower screen of the Wireless Thermometer. This

thin piece of plastic has printed numbers for store displays. This can make the Wireless

Thermometer display appear “frozen”.

•With all power removed, the Wireless Thermometer should be blank.

•If numbers still appear, please check for scratch guard.

•Check that the batteries are installed correctly.

•This is generally a power related issue.

•Batteries may be overpowered or underpowered.

•Remove batteries from Wireless Thermometer.

•Press any button 20 times. Leave the batteries out of the display for 2 hours.

•Insert fresh into the Wireless Thermometer.

Table des matières

Autres manuels La Crosse Technology Thermomètre

La Crosse Technology

La Crosse Technology T83622v2 Manuel utilisateur

La Crosse Technology

La Crosse Technology 308-1409BTV4 Manuel utilisateur

La Crosse Technology

La Crosse Technology 306-645 Manuel

La Crosse Technology

La Crosse Technology 914-604 Dimensions

La Crosse Technology

La Crosse Technology T83622 Manuel utilisateur

La Crosse Technology

La Crosse Technology T83622 Dimensions

La Crosse Technology

La Crosse Technology 308-179 Manuel utilisateur

La Crosse Technology

La Crosse Technology 308-1910 Manuel utilisateur

La Crosse Technology

La Crosse Technology InfraScan IR 101TWC Manuel utilisateur

La Crosse Technology

La Crosse Technology CA84411 Manuel utilisateur

La Crosse Technology

La Crosse Technology 308-1910 Manuel utilisateur

La Crosse Technology

La Crosse Technology 308-1409BTV3 Dimensions

La Crosse Technology

La Crosse Technology WS-1025 Manuel utilisateur

La Crosse Technology

La Crosse Technology LTV-POOL Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-9160Uv3 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-9160U-IT Manuel utilisateur

La Crosse Technology

La Crosse Technology 308-1410GR Manuel utilisateur

La Crosse Technology

La Crosse Technology 922-818 Dimensions

La Crosse Technology

La Crosse Technology WT-62U Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-1025U Manuel utilisateur

La Crosse Technology

La Crosse Technology TX151 Manuel utilisateur

La Crosse Technology

La Crosse Technology 314-152-BL Manuel utilisateur

La Crosse Technology

La Crosse Technology 314-152B Manuel utilisateur

La Crosse Technology

La Crosse Technology 308-1409BTV4 Manuel utilisateur

Manuels Thermomètre populaires d'autres marques

Delton

Delton 981A Manuel utilisateur

Baker

Baker MM2P Manuel utilisateur

Tarmo

Tarmo 320281 Manuel utilisateur

Citizen

Citizen CTD 504 Manuel utilisateur

TFA

TFA 14.1500 Manuel utilisateur

Vive

Vive DMD1010 Manuel utilisateur

Gotemp

Gotemp THB4002 Manuel utilisateur

GREISINGER

GREISINGER G 1202 Manuel utilisateur

Amprobe

Amprobe TMD-53W Manuel utilisateur

Trotec

Trotec BP10 Manuel utilisateur

Radiance instruments

Radiance instruments RT616 Series Manuel utilisateur

Eurolec

Eurolec IR151 Manuel utilisateur

Scaneo

Scaneo TS42B Manuel utilisateur

Sper scientific

Sper scientific 800043 Manuel utilisateur

Microlife

Microlife NC 200 Mode d’emploi

Motorola

Motorola MBP69SN Guide de configuration

The MeatStick

The MeatStick The MeatStick Manuel utilisateur

Hama

Hama TH35-A Manuel utilisateur
