La Crosse Technology BBB86088 Manuel utilisateur

Model: BBB86088

Instruction Manual

DC: 103017

Atomic Digital Wall Clock with

Indoor/Outdoor Temperature

Table of Contents

Page | 1 www.lacrossetechnology.com/support BBB86088

Let’s Get Started

Basic Settings

Fahrenheit | Celsius

LCD Features

Daylight Saving Time Indicator

Atomic Time - WWVB Signal

Time Alarm

Activate | Deactivate Alarm

Snooze

Sensor Reception and Search

Temperature Trend Arrows

Position TX141-Bv2 Sensor

Low Battery

Let’s Get Social

Care and Maintenance

Warranty and Support

Speciﬁcations

FCC Statement

Welcome to the La Crosse Technology® family!

We hope you enjoy your new Atomic Clock.

Lets Get Started

BBB86088 www.lacrossetechnology.com/support Page | 2

1. Insert 2 AA batteries into

your sensor.

∙The red LED light will ﬂash

when your sensor transmits.

∙The TX button lets you

manually transmit a signal.

LED

TX Button

2. Insert 2 AA batteries into

your clock.

3. Conﬁgure basic settings.

4. After 5 minutes, place

your sensor outside in a

shaded location.

Wall Hang

Pullout Stand

∙ Mount your clock on the wall with the 3 holes on the back, or

use the pullout stand to place your clock on a desk or

counter.

Time Zones

Zone AST - Atlantic

Zone EST - Eastern

Zone CST - Central

Zone MST - Mountain

Zone PST - Paciﬁc

Zone AKT - Alaska

Zone HAT - Hawaii

Page | 3 www.lacrossetechnology.com/support BBB86088

Basic Settings

1. Hold the °F/°C button 3 seconds to enter settings mode.

2. Press the + or - button to adjust the ﬂashing values, hold to

adjust quickly.

3. Press the °F/°C button to conﬁrm adjustments and move to

the next item.

4. Press the SNOOZE button at any time to exit.

Settings menu order:

• Language (English, Español, Francais)

• Beep ON/OFF

• Atomic ON/OFF

• DST ON/OFF

• Time Zone

• 12/24 Hour Format

• Hour

• Minutes

• Year

• Month

• Date

Note: When Español or Francais

are selected, the settings

menu will continue in the

language selected.

BBB86088 www.lacrossetechnology.com/support Page | 4

Language Beep ON | OFF Atomic ON | OFF

DST ON | OFF Time Zone 12/24 Hour Format

DST

Hour Minutes

Year Month Date

Fahrenheit | Celsius

Press and release the °F/°C button to select Fahrenheit or

Celsius temperature display.

Fahrenheit Celsius

LCD Features

AM | PM

Alarm Bell

DST Indicator

Atomic Time

Sensor Reception

Low Battery

Fahrenheit | Celsius

Temperature Trend

Daylight Saving Time (DST) Indicator

The letters DST will show when your clock has received the

atomic time signal and Daylight Saving Time is being

observed.

Page | 5 www.lacrossetechnology.com/support BBB86088

Atomic Time -WWVB Signal

• Your clock will search for the atomic signal at UTC 7:00, 8:00,

9:00, 10:00, and 11:00.

• If there is no WWVB signal reception, your clock will search

every 2 hours until the WWVB time is received.

• The atomic time signal icon (tower) will ﬂash while searching,

and be solid when connected.

• Hold the MINUS button for 3 seconds to manually search for

the WWVB atomic time signal.

• For information about WWVB visit: http://bit.ly/AtomicTime

Time Alarm

1. Hold the ALARM button 3 seconds to enter alarm mode.

2. Press the + or - button to adjust the ﬂashing values, hold to

adjust quickly.

3. Press the ALARM button to conﬁrm adjustments and move

to the next item.

4. Press the SNOOZE button at any time to exit.

BBB86088 www.lacrossetechnology.com/support Page | 6

• The alarm is active when set. From normal time display,

press and release the ALARM button to deactivate or

activate the alarm.

• Alarm icon (bell) will show then active.

Activate | Deactivate Alarm

• When your alarm sounds, press the SNOOZE button to

silence alarm for 10 minutes. The alarm bell will ﬂash.

• Press any button except SNOOZE to silence the alarm

for 24 hours.

Snooze

Sensor Reception & Search

• If the signal is lost, your clock will display the LAST DATA

recorded from the sensor for 10 minutes.

• After that 10 minutes if the signal does not come back

dashes will show for outdoor temperature.

• After 30 minutes, your clock will automatically search

for the sensor.

• Hold the PLUS button for 3 seconds to manually search for

your outdoor sensor.

• The sensor reception icon will ﬂash while searching.

• The icon will be solid when the sensor is connected.

Page | 7 www.lacrossetechnology.com/support BBB86088

Position TX141-Bv2 Sensor

• Mount your sensor with the hole at the top:

Either hang it from the back using a nail, or

insert one mounting screw through the front.

• Mount your sensor on a north-facing wall or

in any shaded area. Under an eave or deck

rail is preferred.

• The maximum wireless transmission range

to your clock is over 330 feet (100 meters)

in open air, not including walls or ﬂoors.

• Be sure the sensor is mounted vertically, to

allow moisture to drain out properly.

• Watch sensor mounting video:

http://bit.ly/TH_SensorMounting

• The trend arrows indicate changes in your

temperature (2°F, 1°C) over the past hour.

• They update every 15 minutes and compare

data from exactly one hour prior.

Temperature Trend Arrows

Low Battery

• When the low battery icon appears by the time, replace

the batteries in your clock.

• When the low battery icon appears by the outdoor

temperature, replace the batteries in your sensor.

BBB86088 www.lacrossetechnology.com/support Page | 8

Page | 9 www.lacrossetechnology.com/support BBB86088

Let’s Get Social

JOIN THE CONVERSATION

Ask questions, watch detailed setup videos, and provide

feedback on our social media channels!

• Do not mix old and new batteries

• Do not mix Alkaline, Standard, Lithium or Rechargeable Batteries

• Always purchase the correct size and grade of battery most suitable

for intended use.

• Replace all batteries of a set at the same time.

• Clean the battery contacts and also those of the device prior to

battery installation.

• Ensure the batteries are installed with correct polarity ( + and - ).

• Remove batteries from equipment when it is not to be used for an

extended period of time.

• Promptly remove expired batteries.

Care and Maintenance

La Crosse Technology, Ltd. provides a 1-year limited time warranty

(from date of purchase) on this product relating to manufacturing

defects in materials & workmanship.

Before returning a product, please contact our friendly customer

support or visit our online help:

Phone: 1-608-782-1610

Online: www.lacrossetechnology.com/support

Warranty and Support
