Kramer VS-44DT Manuel utilisateur

USER MANUAL

MODEL:

VS-44DT

4x4 HDMI/HDBT Matrix Switcher with PoE

P/N: 2900-300470 Rev 1 www.KramerAV.com

VS-44DT – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 2

2.3 Shielded Twisted Pair/Unshielded Twisted Pair 3

2.4 Recycling Kramer Products 3

3Overview 4

3.1 About HDBaseT™ Technology 5

3.2 Defining the VS-44DT 4x4 HDMI/HDBT Matrix Switcher 5

4Installing in a Rack 9

5Connecting the VS-44DT 10

5.1 Connecting the VS-44DT to a Serial Controller 11

5.2 Connecting the VS-44DT to a Serial Data Source/Acceptor 11

5.3 Connecting to the VS-44DT via Ethernet 12

5.4 Wiring the RJ-45 Connectors 16

6Operating the VS-44DT 17

6.1 Switching Inputs to Outputs 17

6.2 Storing and Recalling Preset Configurations 18

6.3 Acquiring an EDID 19

6.4 Disconnecting One or All Outputs 19

6.5 Resetting the Device to Factory Default Configuration 20

6.6 Locking and Unlocking the Front Panel 21

7Configuring the VS-44DT 22

7.1 Using the Menu 22

7.2 Selecting DHCP 24

7.3 Configuring the IP Network Address 24

7.4 Resetting the VS-44DT to Factory Default Configuration 25

8Operating the VS-44DT Remotely Using the Web Pages 26

8.1 Switching Page 27

8.2 Device Settings Page 31

8.3 Authentication Page 32

8.4 EDID Page 34

8.5 RS-232 Routing Page 36

8.6 Audio Settings Page 37

8.7 Switching Timeout Page 38

8.8 About Page 39

9Updating the Firmware 40

10 Technical Specifications 42

10.1 Default IP Parameters 43

11 Protocol 3000 44

11.1 Understanding Protocol 3000 45

11.2 Kramer Protocol 3000 Syntax 46

11.3 Protocol 3000 Commands 47

11.4 Kramer Protocol 3000 Commands 48

VS-44DT - Contents

Figures

Figure 1: VS-44DT 4x4 HDMI/HDBT Matrix Switcher Front Panel 6

Figure 2: VS-44DT 4x4 HDMI/HDBT Matrix Switcher Rear Panel 7

Figure 3: Connecting the VS-44DT 4x4 HDMI/HDBT Matrix Switcher 10

Figure 4: Local Area Connection Properties Window 13

Figure 5: Internet Protocol Version 4 Properties Window 14

Figure 6: Internet Protocol Properties Window 15

Figure 7: TP PINOUT 16

Figure 8: Switching Page 27

Figure 9: Switching Button Details 28

Figure 10: Input Edit Window 29

Figure 11: HDBaseT Output Properties Window 30

Figure 12: HDMI Output Properties Window 30

Figure 13: Device Settings Page 31

Figure 14: Authentication Page 32

Figure 15: Login Page 33

Figure 16: EDID Page 34

Figure 17: Copying the EDID 35

Figure 18: EDID Copied 36

Figure 19: RS-232 Routing Page 36

Figure 20: Audio Settings Page 37

Figure 21: Switching Timeout Page 38

Figure 22: About Page 39

VS-44DT – Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly defined by

function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:

Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and

GROUP 14: Collaboration.

Congratulations on purchasing your Kramer VS-44DT 4x4 HDMI/HDBT Matrix

Switcher. This product, which incorporates HDMI™ technology, is ideal for:

Event rooms

Large conference rooms

Lecture halls

Advertising applications

VS-44DT - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to www.kramerav.com/downloads/VS-44DT to check for up-to-date

user manuals, application programs, and to check if firmware upgrades

are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighbouring electrical appliances that may

adversely influence signal quality

Position your VS-44DT away from moisture, excessive sunlight and dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the power cord that is supplied with the unit

Warning:

Do not open the unit. High voltages can cause

electrical shock! Servicing by qualified personnel only

Warning:

Disconnect the power and unplug the unit from the

wall before installing

VS-44DT – Getting Started

2.3 Shielded Twisted Pair/Unshielded Twisted Pair

For optimum range and performance use the recommended Kramer cables

available at www.kramerav.com/product/VS-44DT.

2.4 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims

to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country go

to our recycling pages at www.kramerav.com/support/recycling/.
