VS-211HDxl

3G HD-SDI Automatic Standby Switcher

Contents

1Introduction 1

2Getting Started 1

2.1 Quick Start 2

3Overview 3

4Your VS-211HDxl 3G HD-SDI Automatic Standby Switcher 4

5Using the VS-211HDxl 5

5.1 Connecting the VS-211HDxl 3G HD-SDI Automatic Standby Switcher 5

5.2 Selecting the Default Master Source Signal 6

5.3 Connecting the REMOTE Terminal Block Connector 7

6Technical Specifications 8

Figures

Figure 1: VS-211HDxl 3G HD-SDI Automatic Standby Switcher 4

Figure 2: VS-211HDxl 3G HD-SDI Automatic Standby Switcher Connections 6

Figure 3: REMOTE Terminal Block Connector 7

Tables

Table 1: VS-211HDxl 3G HD-SDI Automatic Standby Switcher Features 4

Table 2: Technical Specifications of the VS-211HDxl 8

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront the video, audio, presentation, and

broadcasting professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

1,000-plus different models now appear in 11 groups1that are clearly

defined by function.

Congratulations on purchasing your Kramer DigiTOOLS®VS-211HDxl

3G HD-SDI Automatic Standby Switcher. This product is ideal for

providing backup switching for broadcast and post-production applications.

The package includes the following items:

•VS-211HDxl 3G HD-SDI Automatic Standby Switcher

•Power adapter (5V DC Input)

•This user manual2

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high-performance high-resolution cables3

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;

GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;

GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products

2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

Overview

3 Overview

The VS-211HDxl is a high-performance automatic standby switcher for

SD/HD-SDI and 3G HD-SDI video signals. The VS-211HDxl

automatically switches to the secondary input whenever the primary video

signal is interrupted. If the primary signal reappears, the unit automatically

switches back to the primary input.

In addition, the VS-211HDxl features:

•Maximum data rate of up to 2.97Gbps

•Multi-standard operation – SMPTE 259M, 292M and 424M

compliance and support for data rates of 270Mbps, 1483.5Mbps,

1485Mbps and 2970Mbps

•A DEFAULT INPUT switch for selecting the default SDI master

source signal

•Contact closure remote control for forced operation

•Active switching and has flexible sync detection and

reconstruction circuitry

To achieve the best performance:

•Use only good quality connection cables1to avoid interference,

deterioration in signal quality due to poor matching, and elevated

noise levels (often associated with low quality cables)

•Avoid interference from neighboring electrical appliances that

may adversely influence signal quality and position your Kramer

VS-211HDxl away from moisture, excessive sunlight and dust

1 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VS-211HDxl 3G HD-SDI Automatic Standby Switcher

4 Your VS-211HDxl 3G HD-SDI Automatic Standby

Switcher

Figure 1 and Table 1 define the VS-211HDxl:

Figure 1: VS-211HDxl 3G HD-SDI Automatic Standby Switcher

Table 1: VS-211HDxl 3G HD-SDI Automatic Standby Switcher Features

# Feature Function

1 IN 1, IN 2 BNC Connectors Connect the SDI input sources 1 and 2

2 OUT 1, OUT 2 BNC Connectors Connect the SDI output acceptors 1 and 2

3 DEFAULT INPUT Switch Switch to select the default input (IN 1 or IN 2)

4 REMOTE IN 1 and IN 2 Terminal Block Connectors Connect to a contact closure switch

5 5V DC +5V DC connector for powering the unit

6 INPUT SIGNAL 1,2 LEDs Illuminates when input is active

7 ON LED Illuminates when receiving power

Using the VS-211HDxl

5 Using the VS-211HDxl

This section describes how to:

•Connect the VS-211HDxl (see section 5.1)

•Select the default master source signal (see section 5.2)

•Connect the REMOTE connector (see section 5.3)

5.1 Connecting the VS-211HDxl 3G HD-SDI Automatic Standby

Switcher

To connect the VS-211HDxl, as illustrated in the example in Figure 2, do the

following1:

1. Connect SDI input source 1 (for example, SDI video camera 1) to the IN 1

BNC connector.

2. Connect SDI input source 2 (for example, SDI video camera 2) to the IN 2

BNC connector.

3. Connect SDI acceptor 1 (for example, SDI display 1) to the OUT 1 BNC

connector.

4. Connect SDI acceptor 2 (for example, SDI display 2) to the OUT 2 BNC

connector.

5. Set the DEFAULT INPUT switch to whichever input is the master input, as

described in section 5.2.

6. If needed, connect remote switches to the REMOTE IN 1 and IN 2

terminal block connectors, as described in section 5.3.

7. Connect the 5V DC power adapter to the power socket and connect the

adapter to the mains electricity.

1 Switch OFF the power on each device before connecting it to your VS-211HDxl. After powering up your VS-211HDxl,

switch on the power on each device

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Using the VS-211HDxl

Figure 2: VS-211HDxl 3G HD-SDI Automatic Standby Switcher Connections

5.2 Selecting the Default Master Source Signal

When active input sources are connected to IN 1 and IN 2, the DEFAULT

INPUT switch setting determines the default master input source.

•If the master input signal is not detected, the VS-211HDxl

automatically activates the standby input

•If IN 1 is the default input and it fails, IN 2 activates

•If IN 2 is the default input and it fails, IN 1 activates

•If the master input reactivates while the standby input is active,

the unit automatically switches back to the master input

•If IN 2 is active while IN 1 is the default input and IN 1

reactivates, IN 1 reactivates

•If IN 1 is active while IN 2 is the default input and IN 2

reactivates, IN 2 reactivates

Using the VS-211HDxl

5.3 Connecting the REMOTE Terminal Block Connector

Regardless of the default input switch setting, you can force the switching

of the active input by remote control. To do this, connect the appropriate

REMOTE input terminal block connector pins to a contact closure switch1

(see Figure 3).

•To force IN 1: connect REMOTE IN1 to PIN G (ground)

•To force IN 2: connect REMOTE IN2 to PIN G (ground)

Do not connect both the REMOTE IN1 and the REMOTE IN2

to PIN G simultaneously

Attach PIN IN1 to

PIN G to activate

INPUT 1

Attach PIN IN2 to

PIN G to activate

INPUT 2

Figure 3: REMOTE Terminal Block Connector

1 Note that the connection should be permanent, since the VS-211HDxl reverts to an automatic switcher when the connection

is removed

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Technical Specifications

6 Technical Specifications

Table 2 includes the technical specifications:

Table 2: Technical Specifications1of the VS-211HDxl

INPUTS: 2 x 3G HD-SDI video on BNC connectors

OUTPUTS: 2 x 3G HD-SDI video on BNC connectors

MAX. OUTPUT LEVEL: 800mVpp /75Ω

DATA RATE: Up to 2.97Gbps

CONTROLS: Contact closure remote control, input default selection switch

COUPLING: AC

POWER SOURCE: 5V DC, 400mA

DIMENSIONS: 12cm x 7.2cm x 2.4cm (4.7" x 2.8" x 1.0") W, D, H

WEIGHT: 0.3kg (0.7lbs)

ACCESSORIES: Power supply, mounting bracket

OPTIONS: 19" rack adapter

1 Specifications are subject to change without notice
