USER MANUAL







Model:

VP-436

Presentation Switcher / Scaler

Contents

Introduction 1

Getting Started 1

2.1

Quick Start 1

Overview 3

3.1

About HDMI 4

3.2

Recommendations for Best Performance 5

Your VP-436 Presentation Switcher / Scaler 5

Installing the VP-436 in a Rack 9

Connecting the VP-436 Presentation Switcher / Scaler 10

Controlling the VP-4312

7.1

Controlling via the Front Panel Buttons 12

7.2

Using the OSD Menu 12

7.2.1

The MAIN MENU 13

7.2.2

The FINETUNE Menu 14

7.2.3

The AUDIO Menu 14

7.2.4

The OSD Menu 14

7.3

Connecting a PC 15

7.4

Controlling via the Infrared Remote Control Transmitter 16

Technical Specifications 17

RS-232 Communication Protocol 18

Figures

Figure 1: VP-436 Presentation Switcher / Scaler 6

Figure 2: Connecting the VP-436 Presentation Switcher / Scaler 11

Figure 3: Connecting a PC without using a Null-modem Adapter 15

Figure 4: Infrared Remote Control Transmitter 16

Tables

Table 1: VP-436 Presentation Switcher / Scaler Front Panel Features 7

Table 2: VP-436 Presentation Switcher / Scaler Rear Panel Features 8

Table 3: The MAIN MENU Features 13

Table 4: The FINETUNE Menu Features 14

Table 5: The AUDIO Menu Features 14

Table 6: The OSD Menu Features 14

Table 7: Infrared Remote Control Transmitter Functions 16

Table 8: Technical Specifications of the VP-436 Presentation Switcher /Scaler 17

Table 9: Input Resolutions 17

Table 10: RS-232 Protocol 18

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range

of problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better! Our 1,000-plus different models

now appear in 11 groups

that are clearly defined by function.

Congratulations on purchasing your Kramer VP-436

Presentation Switcher /

Scaler. This product is ideal for:

Projection systems in conference rooms, boardrooms, hotels and churches

Home theater up-scaling

The package includes the following items:

VP-436

Presentation / Switcher Scaler

Power cord and Null-modem adapter

Infrared remote control transmitter

This user manual

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Use Kramer high performance high resolution cables

2.1 Quick Start

This Quick start chart summarizes the basic setup and operation steps.

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:

Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories

and Rack Adapters; GROUP 11: Sierra Products

2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

Overview

3 Overview

The Kramer VP-436 is a high quality presentation switcher and scaler. It

accepts one of seven inputs: a component video

on RCA connectors, computer

graphics on a 15-pin HD connector, composite video on an RCA connector,

s-Video on a 4-pin connector and two HDMI signals. It scales the video,

embeds the audio, and outputs the signal to the HDMI output as well as to a

computer graphics output, an RGBHV video output together with a digital audio

output and an analog stereo audio output.

The VP-436 is HDTV compatible and the resolution can be up- or down-

scaled as follows:

Native, VGA, SVGA, XGA, SXGA, UXGA, 480i, 480p, 576i, 576p, 720p

, 1080i

1080p

, WXGA, WSXGA, WUXGA, 1280x800, 1440x900, 1400x1050

The VP-436

Presentation Switcher / Scaler:

Has analog audio inputs and digital (S/PDIF) and analog stereo audio

outputs

Automatically detects and selects the audio source for the HDMI input.

Default selection is HDMI – if this is not present, then the machine uses

the audio from the analog input

Comes with an On-Screen Display (OSD) for easy setup and adjustment,

accessible via the IR remote control and via the front-panel buttons

Has a non-volatile memory that retains the last settings used

Supports firmware upgrade

via RS-232

Control your VP-436:

Directly, via the front panel push buttons

By RS-232 serial commands transmitted by a touch screen system, PC, or

other serial controller

Remotely, from the infrared remote control transmitter

The VP-436

is housed in a 19” 1U rack mountable enclosure, with rack “ears”

included, and is fed from a 100-240 VAC universal switching power supply.

1 Also known as Y, Pb, Pr, Y, Cb, Cr and YUV; compatible with both SD and HD component

2 At 50Hz and 60Hz

3 To check if firmware upgrades are available, go to our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

3.1 About HDMI

High-Definition Multimedia Interface (HDMI) is an uncompressed all-digital

audio/video interface, widely supported in the entertainment and home cinema

industry. It delivers the maximum high-definition image and sound quality in use

today. Note that Kramer Electronics Limited is an HDMI Adopter

and an HDCP

Licensee

In particular, HDMI

Provides a simple

interface between any audio/video source, such as a

set-top box, DVD player, or A/V receiver and video monitor, such as a

digital flat LCD / plasma television (DTV), over a single lengthy

cable

Supports standard, enhanced, high-definition video, and multi-channel

digital audio

on a single cable

Transmits all ATSC HDTV standards and supports 8-channel digital audio,

with bandwidth to spare to accommodate future enhancements and

requirements

Benefits consumers by providing superior, uncompressed digital video

quality via a single cable

, and user-friendly connector

Is backward-compatible with DVI (Digital Visual Interface)

Supports two-way communication between the video source (such as a

DVD player) and the digital television, enabling new functionality such as

automatic configuration and one-button play

Has the capacity to support existing high-definition video formats (720p,

1080i, and 1080p/60), standard definition formats such as NTSC or PAL,

as well as 480p and 576p.

1 Ensuring an all-digital rendering of video without the losses associated with analog interfaces and their unnecessary digital-

to-analog conversions

2 See http://www.hdmi.org/about/adopters_founders.asp

3 See http://www.digital-cp.com/list/

4 HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI

licensing LLC

5 With video and multi-channel audio combined into a single cable, the cost, complexity, and confusion of multiple cables

currently used in A/V systems is reduced

6 HDMI technology has been designed to use standard copper cable construction at up to 15m

7 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to

support Dolby 5.1 audio and high-resolution audio formats

8 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a

simple, cost-effective manner

Your VP-436 Presentation Switcher / Scaler

3.2 Recommendations for Best Performance

To achieve the best performance:

Connect only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise-

levels (often associated with low quality cables)

Avoid interference from neighboring electrical appliances and position

your Kramer VP-436 away from moisture, excessive sunlight and dust

4 Your VP-436 Presentation Switcher / Scaler

Figure 1, Table 1 and Table 2 define the VP-436 Presentation Switcher /

Scaler:

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VP-436 Presentation Switcher / Scaler

Figure 1: VP-436 Presentation Switcher / Scaler

Your VP-436 Presentation Switcher / Scaler

Table 1: VP-436 Presentation Switcher / Scaler Front Panel Features

# Feature Function

1 POWER Switch Illuminated switch for turning the unit ON or OFF

2 IR Receiver Receives signals from the remote control transmitter

3 CV Press to select the composite video input

4 YC Press to select the s-Video input

5 COMPONENT Press to select the component video input (from 1 to 2)

6 VGA Press to select the computer graphics input

INPUT

SELECTOR

Buttons

HDMI Press to select the HDMI input (from 1 to 2)

8 BLANK Button Press to toggle between a blank screen (blue or black screen) and

the display

9 MUTE Button Press to toggle between muting (blocking out the sound) and

enabling the audio output

10 FREEZE Button Press to freeze/unfreeze the output video image

11 MENU Button Displays the OSD menu (see section 7.2)

12 ENTER Button Press to accept changes and change the SETUP parameters

13 - Button Press to decrease numerical values or select from several definitions.

For convenience and speed—when not working in the OSD—press

to reduce volume

14 Button Press to move up the menu list values

15 + Button Press to increase numerical values or select from several definitions.

For convenience and speed—when not working in the OSD—press

to increase volume

16 Button Press to move down the menu list

17 PANEL LOCK Button Press and hold

to lock/unlock the front panel buttons

18 RESET TO XGA/720p

Button Press to reset the video resolution to XGA or 720p

1 Can be programmed to follow MUTE (see section 7.2.3)

2 See section 7.2

3 For about 2 seconds

4 Press and hold for about 2 seconds to reset to XGA; or press and hold for about 5 seconds to reset to 720p

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VP-436 Presentation Switcher / Scaler

Table 2: VP-436 Presentation Switcher / Scaler Rear Panel Features

# Feature Function

19 HDMI Connector Connect to the HDMI source (from 1 to 2)

20 VGA 15-pin HD Connector Connect to the computer graphics source

21 CV RCA Connector Connect to the composite video source

22 YC 4-pin Connector Connect to the s-Video source

23 P

RCA

Connector

24 P

RCA

Connector Connect to the component video source

(from 1 to 2)

VIDEO INPUTS

Y RCA

Connector

26 R BNC Connector

27 G BNC Connector

28 B BNC Connector Connect to the RGBHV video acceptor

29 H BNC Connector

30 V BNC Connector

31 HDMI Connector Connect to the HDMI acceptor

VIDEO OUTPUTS

VGA 15-pin HD Connector Connect to a VGA acceptor

33 HDMI Connect to the analog audio HDMI source (from 1 to 2)

VGA Connect to the analog audio computer graphics source

COMP Connect to the analog audio component video source (from 1

to 2)

CV Connect to the analog audio composite video source

AUDIO IN

Unbalanced Stereo

Terminal Block

Connectors

YC Connect to the analog audio s-Video source

34 RS-232 9-pin D-sub Port Connect to the PC or the remote controller

35 LEFT Connect to the left stereo analog audio acceptor

36 RIGHT Connect to the right stereo analog audio acceptor

OUT RCA Connectors

S/PDIF Connect to a digital audio acceptor

38 Power Connector with Fuse AC connector, enabling power supply to the unit

1 For component video, connect all three connectors: Y, Pr/Cr, Pb/Cb (also known as YUV)

Autres manuels pour VP-436

Table des matières

Autres manuels Kramer Changer

Kramer

Kramer VS-311H Manuel utilisateur

Kramer

Kramer VS-41H Manuel utilisateur

Kramer

Kramer VP-311DVI Manuel utilisateur

Kramer

Kramer ASPEN-1616UX Manuel utilisateur

Kramer

Kramer VP-444 Manuel utilisateur

Kramer

Kramer WP-20CT Manuel utilisateur

Kramer

Kramer ProScale VP-728 Manuel utilisateur

Kramer

Kramer VP-740 ProScale Manuel utilisateur

Kramer

Kramer VS-211UHD Manuel utilisateur

Kramer

Kramer WP-5VH2 Manuel utilisateur

Kramer

Kramer TOOLS VP-211K Manuel utilisateur

Kramer

Kramer VM-114H4C Manuel utilisateur

Kramer

Kramer TP-900UHD Manuel utilisateur

Kramer

Kramer VS-28 Manuel utilisateur

Kramer

Kramer VP-23xl Manuel utilisateur

Kramer

Kramer VS-2016 Manuel utilisateur

Kramer

Kramer ProScale VP-728 Manuel utilisateur

Kramer

Kramer 6241N Manuel utilisateur

Kramer

Kramer VP-734 Manuel utilisateur

Kramer

Kramer VS-801USB Manuel utilisateur

Kramer

Kramer VP-773A Manuel utilisateur

Kramer

Kramer VP-720DS Manuel utilisateur

Kramer

Kramer SWT3-31-HU Manuel utilisateur

Kramer

Kramer VP-558 Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
