Kramer PT-571HDCP Manuel utilisateur

Kramer Electronics, Ltd.

Preliminary

USER MANUAL

Models:

PT-571HDCP DVI Line Transmitter

PT-572HDCP DVI Line Receiver

Contents

1Introduction 1

2Getting Started 1

2.1 Quick Start 2

3Overview 2

3.1 Summarizing the DVI Line Transmitter / Receiver System 3

3.2 About the Power Connect™ Feature 3

3.3 Using Twisted Pair Cable 4

3.4 About HDCP 4

3.5 Achieving the Best Performance 4

4Your PT-571HDCP / PT-572HDCP 5

4.1 Your PT-571HDCP DVI Line Transmitter 5

4.2 Your PT-572HDCP DVI Line Receiver 6

5Connecting the PT-571HDCP and PT-572HDCP 7

5.1 Wiring the CAT 5 LINE IN / LINE OUT RJ-45 Connectors 8

6Technical Specifications 8

Figures

Figure 1: PT-571HDCP DVI Line Transmitter 5

Figure 2: PT-572HDCP DVI Line Receiver 6

Figure 3: Connecting the PT-571HDCP / PT-572HDCP DVI Line Transmitter/Receiver 8

Figure 4: CAT 5 PINOUT 8

Tables

Table 1: PT-571HDCP DVI Line Transmitter Features 5

Table 2: PT-572HDCP DVI Line Receiver Features 6

Table 3: CAT 5 PINOUT 8

Table 4: Technical Specifications 8

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront the video, audio, presentation, and

broadcasting professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

1,000-plus different models now appear in 11 groups1

Thank you for purchasing the Kramer PicoTOOLS™ PT-571HDCP DVI

Line Transmitter and the PT-572HDCP DVI Line Receiver, which are ideal

for

that are clearly

defined by function.

•Board, conference, and training rooms

•Presentation systems

•Signal distribution and home theater

Each package includes the following items:

•PT-571HDCP DVI Line Transmitter or PT-572HDCP DVI Line Receiver

•Power adapter (12V DC Input)

•This user manual3

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high-performance high-resolution cables4

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;

GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;

GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products

2 Ultra-Compact PicoTOOLS™ - 4 units can be rack mounted side-by-side in a 1U rack space with the optional RK-4PT rack

adapter

3 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com

4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

3 Overview

This section summarizes:

•The DVI Line Transmitter / Receiver System13.1,see section

•The power connect feature, see section 3.2

•Using Twisted Pair Cable, see section 3.3

•The HDCP standard, see section 3.4

•Recommendations for achieving the best performance, see section 3.5

1 For details of the PT-571HDCP DVI Line Transmitter and PT-572HDCP DVI Line Receiver, see sections 4.1 and 4.2,

respectively

Overview

3.1 Summarizing the DVI Line Transmitter / Receiver System

Using the PT-571HDCP DVI Line Transmitter with the PT-572HDCP DVI

Line Receiver constitutes a DVI-to-twisted pair transmitter and receiver

system. The DVI Line Transmitter / Receiver system features:

•System Range1

•Cables – For optimum range and performance, use Kramer's

BC-DGKat524, BC-DGKat623 and BC-DGKat7a23

- Up to 90m (295ft) at SXGA, or up to 30m (98ft) at

UXGA on shielded BC-DGKat524 cable; 90m (295ft) at SXGA, or up to

70m (230ft) at UXGA on shielded BC-DGKat623 cable; 100m (330ft)

at SXGA or up to 80m (265ft) at UXGA on shielded BC-DGKat7a23

cable

•Max Data Rate/Bandwidth up to 1.65Gbps

•HDTV compatibility

•HDCP compliance

•The passing of EDID2and HPD3

•Power Connect™ feeding 12V DC over the CAT 5 cable from

transmitter to receiver (see section

signals from the source to the

display device using the CAT 5 cable

3.2)

•Two DVI-I connectors, that are compatible with all types of DVI cables

Note that only the digital signal (DVI D) is available on the DVI connector.

3.2 About the Power Connect™ Feature

The Power Connect™ feature here means that only one unit in a system, the

transmitter, can be connected to a power source when the devices are within

270 feet (90 meters) of each other. The Power Connect™ feature applies as

long as the cable can carry power. The distance does not exceed 90 meters on

standard CAT 5 cable, for longer distances, heavy gauge cable should be used4

1 Note that the transmission range depends on the signal resolution, graphics card and display used. The distance using non-

Kramer CAT 5, CAT 6 and CAT 7a cables may not reach these ranges

2 Extended Display Information Data

3 Hot Plug Detect

4 CAT 5 cable is still suitable for the video/audio transmission, but not for feeding the power at these distances

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

3.3 Using Twisted Pair Cable

Kramer engineers have developed special twisted pair cables to best match

our digital twisted pair products; the Kramer: BC-DGKat524 (CAT 5 24

AWG), the Kramer: BC-DGKat623 (CAT 6 23 AWG cable), and the

Kramer: BC-DGKat7a23 (CAT 7a 23 AWG cable). These specially built

cables significantly outperform regular CAT 5 / CAT 6 / CAT 7a cables.

3.4 About HDCP

The High-Bandwidth Digital Content Protection (HDCP) standard1

3.5 Achieving the Best Performance

, protects

digital video and audio signals transmitted over DVI or HDMI connections

between two HDCP-enabled devices to eliminate the reproduction of

copyrighted material. To protect copyright holders (such as movie studios)

from having their programs copied and shared, the HDCP standard provides

for the secure and encrypted transmission of digital signals.

To achieve the best performance:

•Use only good quality connection cables2

•Avoid interference from neighboring electrical appliances that may

adversely influence signal quality and position your Kramer devices

away from moisture, excessive sunlight and dust

to avoid interference,

deterioration in signal quality due to poor matching, and elevated

noise levels (often associated with low quality cables).

Caution – No operator-serviceable parts inside unit.

Warning – Use only the Kramer Electronics input power

wall adapter that is provided with this unit3

Warning – Disconnect power and unplug unit from wall

before installing or removing device or servicing unit.

1 Developed by Intel

2 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com

3 For example, part number 2535-000251

Your PT-571HDCP / PT-572HDCP

4 Your PT-571HDCP / PT-572HDCP

This section describes the:

•PT-571HDCP DVI Line Transmitter, see section 4.1

•PT-572HDCP DVI Line Receiver, see section 4.2

4.1 Your PT-571HDCP DVI Line Transmitter

The PT-571HDCP DVI Line Transmitter receives a DVI signal, encodes it, and

transmits it over a CAT 5 cable to the PT-572HDCP.The PT-571HDCP has:

•A DVI input connector

•An RJ-45 CAT 5 output connector

•One power status LED

Figure 1and Table 1define the PT-571HDCP:

Figure 1: PT-571HDCP DVI Line Transmitter

Table 1: PT-571HDCP DVI Line Transmitter Features

Feature

Function

1 12V DC +12V DC connector for powering the unit

2 DVI IN Connector Connect to the DVI source

3 OUT RJ-45 Connector Connect to the IN RJ-45 connector on the PT-572HDCP

4 ON LED Lights red when receiving power only, orange when input and power are

attached, and yellow when both an active input and output are attached

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your PT-571HDCP / PT-572HDCP

4.2 Your PT-572HDCP DVI Line Receiver

The PT-572HDCP DVI Line Receiver receives an encoded signal over a

CAT 5 cable transmitted from the PT-571HDCP, decodes it, and converts

it to a DVI output.

The PT-572HDCP has:

•A DVI output connector

•An RJ-45 CAT 5 input connector

•One power status LED

Figure 2and Table 2define the PT-572HDCP:

Figure 2: PT-572HDCP DVI Line Receiver

Table 2: PT-572HDCP DVI Line Receiver Features

# Feature Function

1 DVI OUT Connector Connect to the DVI acceptor

2 ON LED Lights red when receiving power only, orange when output and power are

attached, and yellow when both an active input and output are attached

3 IN RJ-45 Connector Connect to the OUT RJ-45 connector on the PT-571HDCP

Connecting the PT-571HDCP and PT-572HDCP

5 Connecting the PT-571HDCP and PT-572HDCP

You can use the PT-571HDCP DVI Line Transmitter with the PT-572HDCP

DVI Line Receiver to configure a DVI transmitter/receiver system.

To connect the PT-571HDCP to the PT-572HDCP, as illustrated in the

example in Figure 3, do the following:

1. Connect the CAT 5 OUT RJ-45 connector on the PT-571HDCP to the

CAT 5 IN RJ-45 connector on the PT-572HDCP via a CAT 5 cable (see

section 5.1).

2. On the PT-571HDCP, connect a DVI source (for example, a computer

graphics source) to the DVI IN connector.

3. On the PT-572HDCP, connect the DVI OUT connector to a DVI acceptor

(for example, a display).

4. Connect the 12V DC power adapter to the power socket on the

PT-571HDCP and connect the adapter to the mains electricity (not shown

in Figure 3).

Figure 3: Connecting the PT-571HDCP / PT-572HDCP DVI Line Transmitter/Receiver

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Technical Specifications

5.1 Wiring the CAT 5 LINE IN / LINE OUT RJ-45 Connectors

Table 3and Figure 4define the CAT 5 pinout, using a straight pin-to-pin

cable with RJ-45 connectors (note, that the cable Ground shielding must be

connected / soldered to the connector shield):

Table 3: CAT 5 PINOUT Figure 4: CAT 5 PINOUT

7812 5

145 78632

EIA /TIA 568A EIA /TIA 568B

Wire Color

1 Green / White 1 Orange / White

2 Green 2 Orange

3 Orange / White 3 Green / White

4 Blue 4 Blue

5 Blue / White 5 Blue / White

6 Orange 6 Green

7 Brown / White 7 Brown / White

8 Brown 8 Brown

Pair 1 4 and 5 Pair 1 4 and 5

Pair 2 3 and 6 Pair 2 1 and 2

Pair 3 1 and 2 Pair 3 3 and 6

Pair 4 7 and 8 Pair 4 7 and 8

6 Technical Specifications

The PT-571HDCP/PT-572HDCP technical specifications are shown in

Table 4.

Table 4: Technical Specifications1

PT-571HDCP PT-572HDCP

INPUTS: 1 DVI, 1.2Vpp on a DVI Molex

24pin female connector; DDC

signal 5Vpp (TTL)

1 RJ-45 connector

OUTPUTS: 1 RJ-45 connector 1 DVI, 1.2Vpp on a DVI Molex 24pin female

connector; DDC signal 5Vpp (TTL)

BANDWIDTH: Supports up to 1.65Gbps

POWER SOURCE: 12V DC, 250mA (transmitter and receiver together)

DIMENSIONS: 6.2cm x 5.2cm x 2.4cm (2.4" x 2.1" x 1") W, D, H.

WEIGHT: 0.14kg (0.3lbs)

ACCESSORIES: Power supply, mounting bracket

OPTIONS: 19” RK-4PT rack adapter, Kramer DVI cables

1 Specifications are subject to change without notice

and BC-DGKat524 (CAT 5 24

AWG), BC-DGKat623 (CAT 6 23 AWG) and BC-DGKat7a23 (CAT 7a 23AWG)

cables

2 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

Autres manuels pour PT-571HDCP

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Kramer Récepteur

Kramer

Kramer WP-120 Manuel utilisateur

Kramer

Kramer PT-110xl Manuel utilisateur

Kramer

Kramer TP-578H Manuel utilisateur

Kramer

Kramer TP-588D Manuel utilisateur

Kramer

Kramer C-A35M/IRR-03 Manuel utilisateur

Kramer

Kramer 621T Manuel utilisateur

Kramer

Kramer TP-594Txr Manuel utilisateur

Kramer

Kramer DigiTOOLS KW-11T Manuel utilisateur

Kramer

Kramer KDS-EN2T Manuel utilisateur

Kramer

Kramer 611T Manuel utilisateur

Kramer

Kramer KW-14T Manuel utilisateur

Kramer

Kramer Cobra R1300A Manuel utilisateur

Kramer

Kramer PT-571 Manuel utilisateur

Kramer

Kramer 706XL Manuel utilisateur

Kramer

Kramer DigiTOOLS KW-11T Manuel utilisateur

Kramer

Kramer VP-427H2 Manuel utilisateur

Kramer

Kramer KIT-400 Manuel utilisateur

Kramer

Kramer TP-873xr Manuel utilisateur

Kramer

Kramer 621R Manuel utilisateur

Kramer

Kramer TP-121xl Manuel utilisateur

Kramer

Kramer TP-752T Manuel utilisateur

Kramer

Kramer 708 Manuel utilisateur

Kramer

Kramer TOOLS TP-10 Manuel utilisateur

Kramer

Kramer MegaTOOLS TP-575 Manuel utilisateur

Manuels Récepteur populaires d'autres marques

Garmin

Garmin GA 23 Manuel utilisateur

Aiphone

Aiphone PS-12F Manuel utilisateur

IMES

IMES TCS-01CA-PMI Manuel utilisateur

BWI Eagle

BWI Eagle AIR-EAGLE SR Manuel

AMIMON

AMIMON AMN12310 WHDI Manuel utilisateur

Dual

Dual DMCPA79BT Mode d'emploi

Sound Associates

Sound Associates SA652P Manuel utilisateur

Sherwood

Sherwood NewCastle R-772 Manuel utilisateur

Audio

Audio A10-RX Series Manuel utilisateur

AllSee

AllSee PushShare PSRV1.1 Manuel utilisateur

DEMAG

DEMAG DRC-DR D2 Manuel utilisateur

Teleco

Teleco TVRCL868A02 Manuel utilisateur

Bosch

Bosch RF3222E Manuel utilisateur

Xpress

Xpress xmc10 Manuel utilisateur

JVC

JVC KD-MR1BTS Manuel utilisateur

Omega Engineering

Omega Engineering UWTC-REC3 Manuel utilisateur

e-survey

e-survey E300 Pro Manuel utilisateur

Dish Network

Dish Network Satellite Television Manuel utilisateur
