Kramer TP-590Rxr Manuel utilisateur

P/N: 2900-300500 Rev 2 www.kramerAV.com

USER MANUAL

MODEL:

TP-590RxrHDMI Line Receiver

TP-590Rxr – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 2

2.3 Recycling Kramer Products 3

3Overview 4

3.1 Using Twisted Pair Cable 5

3.2 About the Power over Ethernet Feature 5

4Defining the TP-590Rxr HDMI Line Receiver 6

5Connecting the TP-590Rxr HDMI Line Receiver 8

6Principles of Operation 10

6.1 Output Timeout 10

6.2 Controlling A/V Equipment via an IR Remote Control 10

7Configuring the TP-590Rxr HDMI Line Receiver 13

7.1 Setting the DIP-switch on the TP-590Rxr 13

8Operating the TP-590Rxr Remotely Using the Web Pages 14

8.1 Browsing the TP-590Rxr Web Pages 14

8.2 The Video Settings Page 16

8.3 The Device Settings Page 17

8.4 The EDID Management Page 21

8.5 The Firmware Upgrade Page 23

8.6 The Authentication Page 24

8.7 The About Page 25

9Technical Specifications 26

9.1 Default Parameters 27

9.2 Default EDID 27

10 Protocol 3000 30

10.1 Kramer Protocol 3000 Syntax 30

10.2 Kramer Protocol 3000 Commands 33

TP-590Rxr - Contents

Figures

Figure 1: TP-590Rxr Front Panel 6

Figure 2: TP-590Rxr Rear Panel 7

Figure 3: Connecting the TP-590Rxr HDMI Line Receiver 8

Figure 4: Controlling a Blu-ray Disk Player via the TP-590Txr 11

Figure 5: Controlling a Projector via the TP-590Rxr 12

Figure 6: TP-590Rxr DIP-switch 13

Figure 7: Entering Logon Credentials 15

Figure 8: The Default Page 15

Figure 9: The Main Page 16

Figure 10: The Video Settings Page 16

Figure 11: The Device Settings Page 18

Figure 12: Turning DHCP On Communication Warning 19

Figure 13: Turning DHCP Off Dialog Box 20

Figure 14: The EDID Management Page 22

Figure 15: The Firmware Upgrade Page 23

Figure 16: The Authentication Page 24

Figure 17: The About Page 25

TP-590Rxr – Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:

Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and

GROUP 14: Collaboration.

Congratulations on purchasing your Kramer TP-590Rxr HDMI Line Receiver

which is part of the Kramer Audio Distribution System and is ideal for:

•Conference rooms, boardrooms, auditoriums, hotels, churches, classrooms

and production studios

•Rental and staging

Note that the TP-590Rxr HDMI Line Receiver and the TP-590Txr

HDMI Line Transmitter are purchased separately. Both can be

connected to other HDBT-certified transmitters and receivers.

TP-590Rxr - Getting Started

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

Go to http://www.kramerav.com/downloads/TP-590Rxr to check for up-to-

date user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

•Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

•Do not secure the cables in tight bundles or roll the slack into tight coils

•Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

•Position your TP-590Rxr HDMI Line Receiver away from moisture,

excessive sunlight and dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the power cord that is supplied with the unit

Warning:

Disconnect the power and unplug the unit from the

wall before installing

TP-590Rxr – Getting Started

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country

go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

TP-590Rxr - Overview

3 Overview

The TP-590Rxr HDMI Line Receiver is a high-performance, extended range,

HDBaseT-technology receiver for HDMI, USB, audio, bidirectional RS-232, and IR

signals. The TP-590Rxr converts an HDBaseT signal back into HDMI, USB, audio,

RS-232, and IR signals.

The TP-590Rxr can be used together with a compatible transmitter to form an

extended HDMI/data-line transmission and reception system.

The TP-590Rxr receiver features:

•A bandwidth of up to 10.2Gbps (3.4Gbps per graphic channel) in normal

mode; up to 4.95Gbps (1.65Gbps per graphic channel) in extended range

mode (in which the aggregate budget on the Auxiliary Channel is halved)

•System Range—Up to 130m (430ft) in normal mode and up to 180m (590ft)

in extended range mode (1080p @60Hz @24bpp) when using BC−HDKat6a

cables

For optimum range and performance, use Kramer's BC−HDKat6a or

equivalent cable. Note that the transmission range depends on the signal

resolution, source, and display used. The distance using non−Kramer

CAT 6 cable may not reach these ranges.

•Up to 4K UHD @60Hz (4:2:0) support in normal range mode

•Up to 130m (430ft) at normal mode (2K), up to 100m at normal mode (4K);

up to 180m (590ft) ultra mode (1080p @60Hz @24bpp) when using

BC−HDKat6a cables

•HDTV compatibility and HDCP compliance

•Support for HDBaseT V2

•HDMI support - HDMI (deep color, x.v.Color™, lip sync, HDMI

uncompressed audio channels, Dolby TrueHD, DTS−HD, CEC, 2K, 4K, 3D)

•USB pass-through for connecting a peripheral device, such as, a mouse or a

keyboard

•Support for isochronous USB cameras

TP-590Rxr – Overview

•Stereo, analog audio transmission

•EDID pass through, passes EDID signals from the source to the display

•Bidirectional RS-232 interfaces—data flows in both directions allowing data

transmission and control of devices

•Bidirectional infrared interface for remote control of peripheral devices (see

Section 6.2)

•Power over Ethernet—the receiver can receive power over the HDBT link

from a PoE compatible provider, (for example, the TP-590Txr)

•LED status indicators for input, output, HDBT link, and PoE

•Remote control using RS-232 or an Ethernet LAN

•MegaTOOLS®enclosures of which two can be rack-mounted in a 1U rack

space with the optional RK-T2B rack adapter

3.1 Using Twisted Pair Cable

Kramer engineers have developed special twisted pair cables to best match our

digital twisted pair products; BC−HDKat6a (CAT 6 23 AWG cable) significantly

outperforms regular CAT 5/CAT 6 cables.

We strongly recommend that you use shielded twisted pair cable.

3.2 About the Power over Ethernet Feature

Power over Ethernet passes electrical power along with data on Ethernet cabling.

This allows a single cable to provide both data connection and electrical power to

compatible devices.
