Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront the video, audio, presentation, and

broadcasting professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

1,000-plus different models now appear in 11 groups

that are clearly

defined by function.

Thank you for purchasing the Kramer Pico TOOLS PT-110 XGA Line

Transmitter, Kramer Wall Plate WP-110 XGA Line Transmitter, Kramer

Pico TOOLS PT-120 XGA Line Receiver, and/or Kramer TOOLS TP-120

XGA Line Receiver, which are ideal for:

Presentation and multimedia applications

Long range graphics distribution for schools, hospitals, security, and

stores

The package includes the following items:

PT-110 XGA Line Transmitter or WP-110 XGA Line Transmitter

or PT-120 XGA Line Receiver or TP-120 XGA Line Receiver

Power adapter (12V DC Input) and this user manual

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

Review the contents of this user manual

Use Kramer high-performance high-resolution cables

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;

GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;

GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products

2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

3 Overview

This section describes:

A summary of the PT-110 XGA Line Transmitter, see section 3.1

A summary of the WP-110 XGA Line Transmitter,see section 3.2

A summary of the PT-120 XGA Line Receiver, see section 3.3

A summary of the TP-120 XGA Line Receiver, see section 3.4

The power connect feature, see section 3.5

Using shielded twisted pair (STP) / unshielded twisted pair (UTP), see

section 3.6

Recommendations for achieving the best performance, see section 3.7

3.1 PT-110 XGA Line Transmitter

Using an XGA Line Transmitter—the PT-110 or WP-110—with the

PT-120 or TP-120 constitutes a VGA/XGA-to-Twisted Pair Transmitter

and Receiver.

The Kramer Pico TOOLS PT-110 is an XGA line transmitter that receives

an XGA signal and transmits it over a CAT 5 cable to the PT-120 or

TP-120 receiver. In particular, the PT-110:

Has a resolution of up to UXGA

Can use the simplest UTP CAT 5 cables, and performs even better

with higher quality cables

Has the Power Connect feature

Is 12V DC fed

3.2 WP-110 XGA Line Transmitter

The Kramer Wall Plate WP-110 is an XGA line transmitter—available in

three versions: one for the USA, one for Belgium and Germany, and one for

the UK and most of Europe

—that receives an XGA signal and transmits it

over a CAT 5 cable to the PT-120 or TP-120 receiver. In particular, the

WP-110:

Has a resolution of up to UXGA

Can use the simplest UTP CAT 5 cables, however, it benefits

from better quality cables

Has the power connect feature

Is powered via a standard 12V DC feed

1 Excluding Belgium and Germany

Overview

3.3 PT-120 XGA Line Receiver

The Kramer Pico TOOLS PT-120 is an XGA line receiver that receives a

coded CAT 5 signal transmitted by either the WP-110 or the PT-110,

decodes it and converts it to an XGA output. In particular, the PT-120:

Has an operating range of more than 300ft (more than 100m)

using standard CAT 5 cable and the WP-110 or the PT-110

Includes EQ. and level controls

Has the power connect feature

Is 12V DC fed

3.4 TP-120 XGA Line Receiver

The Kramer TOOLS TP-120 is an XGA line receiver that receives a coded

CAT 5 signal transmitted by either the WP-110 or the PT-110, decodes it

and converts it to an XGA output. In particular, the TP-120:

Has an operating range of more than 300ft (more than 100m)

using standard CAT 5 cable and the WP-110 or the PT-110

Includes EQ. and level controls

Has the power connect feature

Is 12V DC fed

3.5 About the Power Connect Feature

The Power Connect feature applies as long as the cable can carry power. The

distance does not exceed 50 meters on standard CAT 5 cable, for longer

distances, heavy gauge cable should be used

For a CAT 5 cable exceeding a distance of 50 meters, separate power supplies

should be connected to the transmitter and to the receiver simultaneously.

1 Powering via the CAT 5 cable from either the receiver or the transmitter is good for 60 meters. Above it, both sides should

be fed with power

2 CAT 5 cable is still suitable for the video/audio transmission, but not for feeding power at these distances

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

3.6 Shielded Twisted Pair (STP) / Unshielded Twisted Pair (UTP)

We recommend that you use shielded twisted pair (STP) cable. There are

different levels of STP cable available, and we advise you to use the best

quality STP cable that you can afford. Our STP skew-free cable, Kramer

BC-SXTP, is intended for transmitting VGA signals. Our non-skew-free

cable, Kramer BC-STP, is intended for digital signals.

The compliance to electromagnetic interference was tested using STP

cables, therefore we recommend using those cables.

Although unshielded twisted pair (UTP) cable might be preferred for long

range applications, the UTP cable should be installed far away from electric

cables, motors and so on, which are prone to create electrical interference.

However, since the use of UTP cable might cause inconformity to

electromagnetic standards, Kramer does not commit to meeting the standard

with UTP cable.

3.7 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables

to avoid interference,

deterioration in signal quality due to poor matching, and elevated

noise levels (often associated with low-quality cables).

Avoid interference from neighboring electrical appliances that

may adversely influence signal quality and position your Kramer

XGA Line Transmitter(s) / Receiver away from moisture,

excessive sunlight and dust

Caution – No operator-serviceable parts inside unit.

Warning – Use only the Kramer Electronics input power

wall adapter that is provided with this unit

Warning – Disconnect power and unplug unit from wall

before installing or removing device or servicing unit.

1 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com

2 For example, part number 2535-000251

Your XGA Line Transmitter(s) / Receiver

4 Your XGA Line Transmitter(s) / Receiver

This section defines the XGA Line Transmitter(s) / Receiver:

PT-110 XGA Line Transmitter (see section 4.1)

WP-110 XGA Line Transmitter (see section 4.2)

PT-120 XGA Line Receiver (see section 4.3)

TP-120 XGA Line Receiver (see section 4.4)

4.1 Your PT-110 XGA Line Transmitter

Figure 1 and Table 1 define the PT-110:

Figure 1: PT-110 XGA Line Transmitter

Table 1: PT-110 Features

Feature Function

1 12V DC +12V DC connector for powering the unit

2 XGA INPUT 15-pin HD F Connector

Connect to the XGA source

3 LINE OUT RJ-45 Connector Connects to the LINE IN RJ-45 connector on the PT-120 or

TP-120 XGA Line Receiver

4 VS Switch Slide down to set the V SYNC to negative polarity (NEGATIVE);

slide up

to set the V SYNC to positive polarity (NORM)

5 HS Switch Slide down to set the H SYNC to negative polarity (NEGATIVE);

slide up

to set the H SYNC to positive polarity (NORM)

6 ON LED Illuminates when receiving power

1 Using a UTP cable with CAT 5 connectors at both ends (the PINOUT is defined in Table 6 and Figure 7)

2 By default, both switches are set down (for a negative V SYNC and H SYNC polarity)

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your XGA Line Transmitter(s) / Receiver

4.2 Your WP-110 XGA Line Transmitter

The WP-110 is available in three versions: one for the US, one for Belgium

and Germany, and one for the UK and most of Europe

, as Figure 2 and

Table 2 define:

Figure 2: WP-110 XGA Line Transmitter

1 Excluding Belgium and Germany

Your XGA Line Transmitter(s) / Receiver

Table 2: WP-110 XGA Line Transmitter Features

# Feature Function

1 XGA IN 15-pin HD (F)

Connector

Connect to the XGA source

2 ON LED Illuminates when receiving power

3 HS

Switch Slide the switch to the left

to change the HS polarity to (NEG.) negative

polarity

; slide the switch to the right (NORM.) to retain the polarity

4 VS

Switch Slide the switch to the left

to change the VS polarity to (NEG.) negative

polarity

; slide the switch to the right (NORM.) to retain the polarity

5 LINE OUT RJ-45 Connector

Connects to the LINE IN RJ-45 connector on the PT-120 or TP-120

XGA Line Receiver

GND PIN Connect (-) to the Ground6

POWER

SUPPLY

+12V DC PIN Connect (+) to the connector for powering the unit

4.3 Your PT-120 XGA Line Receiver

This section describes the PT-120 XGA Line Receiver.

Figure 3 and Table 3 define the topside of the PT-120 XGA Line Receiver:

Figure 3: PT-120 XGA Line Receiver

1 By default, both switches are set to the right

2 Downgoing syncs

3 SYNC

4 Using a UTP cable with CAT 5 connectors at both ends (the PINOUT is defined in Table 8 and Figure 9)

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your XGA Line Transmitter(s) / Receiver

Table 3: PT-120 XGA Line Receiver Features

# Feature Function

1 12V DC +12V DC connector for powering the unit

2 XGA OUTPUT 15-pin HD (F)

Connector

Connect to the XGA acceptor

3 ON LED Illuminates when receiving power

4 LEVEL Trimmer Adjusts

the output signal level

5 EQ.

Trimmer Adjusts

the cable compensation equalization level

6 LINE IN RJ-45 Connector Connects to the LINE OUT RJ-45 connector on the PT-110 or

WP-110 XGA Line Receiver

4.4 Your TP-120 XGA Line Receiver

This section describes the TP-120 XGA Line Receiver and its underside.

Figure 4 and Table 4 define the topside of the TP-120 XGA Line Receiver:

Figure 4: TP-120 XGA Line Receiver

1 Use a screwdriver to carefully rotate the trimmer, adjusting the appropriate level

2 Degradation and VGA/XGA signal loss can result from using long cables (due to stray capacitance), sometimes leading to a

total loss of sharpness in high-resolution signals

3 Using a UTP cable with CAT 5 connectors at both ends (the PINOUT is defined in Table 6 and Figure 7)

Autres manuels pour PT-110

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Kramer Récepteur

Kramer

Kramer 621T Manuel utilisateur

Kramer

Kramer 602T Manuel utilisateur

Kramer

Kramer 708 Manuel utilisateur

Kramer

Kramer VP-427X2 Manuel utilisateur

Kramer

Kramer TOOLS TP-122 Manuel utilisateur

Kramer

Kramer PT-120 Manuel utilisateur

Kramer

Kramer DigiTOOLS TP-552 Manuel utilisateur

Kramer

Kramer PT-110 Manuel utilisateur

Kramer

Kramer DigiTOOLS TP-580RA Manuel utilisateur

Kramer

Kramer VP-427X1 Manuel utilisateur

Kramer

Kramer TP-200 Manuel utilisateur

Kramer

Kramer DigiTOOLS KW-11T Manuel utilisateur

Kramer

Kramer TOOLS TP-46 Manuel utilisateur

Kramer

Kramer PT-571 Manuel utilisateur

Kramer

Kramer DigiTOOLS 672T Manuel utilisateur

Kramer

Kramer TOOLS TP-9 Manuel utilisateur

Kramer

Kramer 708 Manuel utilisateur

Kramer

Kramer 640T Manuel utilisateur

Kramer

Kramer TP-752T Manuel utilisateur

Kramer

Kramer DigiTOOLS 672T Manuel utilisateur

Kramer

Kramer C-A35M/IRRW Manuel utilisateur

Kramer

Kramer TP-19 Manuel utilisateur

Kramer

Kramer Cobra R1300A Manuel utilisateur

Kramer

Kramer 611T Manuel utilisateur

Manuels Récepteur populaires d'autres marques

Garmin

Garmin GA 23 Manuel utilisateur

Aiphone

Aiphone PS-12F Manuel utilisateur

IMES

IMES TCS-01CA-PMI Manuel utilisateur

BWI Eagle

BWI Eagle AIR-EAGLE SR Manuel

AMIMON

AMIMON AMN12310 WHDI Manuel utilisateur

Dual

Dual DMCPA79BT Mode d'emploi

Sound Associates

Sound Associates SA652P Manuel utilisateur

Sherwood

Sherwood NewCastle R-772 Manuel utilisateur

Audio

Audio A10-RX Series Manuel utilisateur

AllSee

AllSee PushShare PSRV1.1 Manuel utilisateur

DEMAG

DEMAG DRC-DR D2 Manuel utilisateur

Teleco

Teleco TVRCL868A02 Manuel utilisateur

Bosch

Bosch RF3222E Manuel utilisateur

Xpress

Xpress xmc10 Manuel utilisateur

JVC

JVC KD-MR1BTS Manuel utilisateur

Omega Engineering

Omega Engineering UWTC-REC3 Manuel utilisateur

e-survey

e-survey E300 Pro Manuel utilisateur

Dish Network

Dish Network Satellite Television Manuel utilisateur
