Kramer 602T Manuel utilisateur

KRAMER ELECTRONICS LTD.

USER MANUAL

MODELS:

602T

Two-fiber Detachable Optical

DVI Transmitter

602R

Two-fiber Detachable Optical

DVI Receiver

P/N: 2900-000646 Rev 3

602T, 602R – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 3

2.3 Recycling Kramer Products 3

3Overview 4

3.1 Powering the 602T and the 602R 5

3.2 Your Two-fiber Detachable Optical DVI Transmitter/ Receiver 5

4Using the Two-fiber Detachable Optical DVI System 6

4.1 Capturing the EDID 6

4.2 Connecting the Detachable Optical DVI Transmitter/Receiver 7

4.3 Avoiding Pitfalls During Operation 9

5Technical Specifications 10

Figures

Figure 1: 602 Two-fiber Detachable Optical DVI Transmitter and Receiver 5

Figure 2: The Auto EDID Button on the 602T 7

Figure 3: Connecting the Fiber Optic Cables 8

Figure 4: Connecting the 602T/602R Two-fiber Detachable Optical DVI Transmitter/Receiver 8

602T, 602R - Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:

Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and

GROUP 14: Collaboration.

Congratulations on purchasing your Kramer 602T Two-fiber Detachable Optical

DVI Transmitter and 602R Two-fiber Detachable Optical DVI Receiver, which are

ideal for the following typical applications:

Digital flat panel and plasma displays used in medical, commercial and travel

applications

Conference rooms and auditoriums

Kiosks with digital flat panel displays for presenting information

LED signboards in streets and stadiums

602T, 602R - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to http://www.kramerelectronics.com/support/product_downloads.asp

to check for up-to-date user manuals, application programs, and to check if

firmware upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

Position your Kramer 602T, 602R away from moisture, excessive sunlight

and dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

602T, 602R - Getting Started

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the Kramer Electronics input power wall

adapter that is provided with the unit

Warning:

Disconnect the power and unplug the unit from the wall

before installing

Warning:

Class 1 Laser Product

Invisible laser radiation present

Avoid long-term viewing of laser

Avoid the use of magnifying viewing aids or instruments (such

as binoculars, telescopes, microscopes and magnifying lenses,

but not spectacles or contact lenses)

Avoid placing optical devices in the emitted beam that could

cause the concentration of the laser radiation to be increased

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country

go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

602T, 602R - Overview

3 Overview

The 602T and 602R are a small and lightweight fiber optic transmitter and receiver

pair for DVI signals. The 602T converts electrical signals to optical signals and the

602R decodes the optical signals back to electrical signals.

The 602T and 602R feature:

Max. Data Rate - 1.65Gbps

Max. Resolution - Up to WUXGA (1920x1200) @60Hz, 1080p

Range - Up to 400m (1312ft) (multimode); up to 1500m (5000ft) (single-

mode)

Cable - 2LC single or multi-mode fiber optic cable

EDID Capture - Copies and stores the EDID from a display device

Advanced Solution - Small and lightweight, indispensable asset in any digital

signage application

Standards Compliance - Supports DVI1.0 and DDC2B, fully implemented by

fiber-optic communication

Compliance with the limits for a Class A digital device, pursuant to part 15

and 2 of FCC and CE

Laser standards compliance - IEC 60825-1, FDA 21CFR1040;

Laser Class 1: Safety of laser products

Not HDCP Compliant

No EMI/RFI

Size - NanoTools

602T, 602R - Overview

3.1 Powering the 602T and the 602R

Your 602T/602R pair comes with two 5V DC power adapters. The 602R must

always be powered via the external power adapter. The 602T can take power from

the external power adapter or from the 5V pin on the DVI card in the computer.

However, when using most laptops or a computer with an express graphic card,

an external power adapter is required. The 602T automatically detects if it is being

powered via the external power adapter, and if so, the internal power supply cuts

off.

3.2 Your Two-fiber Detachable Optical DVI Transmitter/

Receiver

Figure 1 illustrates the 602T and 602R two-fiber detachable optical DVI extension

system:

Figure 1: 602 Two-fiber Detachable Optical DVI Transmitter and Receiver

602T, 602R - Using the Two-fiber Detachable Optical DVI System

4 Using the Two-fiber Detachable Optical DVI

System

This section describes how to:

Capture the EDID of the display device (see Section 4.1)

Connect the detachable optical DVI transmitter and receiver (see Section 4.2)

Avoid pitfalls when using the 602T and 602R (see Section 4.3)

4.1 Capturing the EDID

The 602T and 602R are connected via two channels that transmit R, G, B and

clock signals. The EDID of the display device is captured onto the transmitter for

the computer to read.

The factory default EDID is set to UXGA (1600x1200) at 60Hz vertical refresh rate.

If your display has this resolution, you do not need to capture the EDID.

You can capture the EDID of the display device on the 602T so that when the

computer connects to the 602T, it reads the virtual EDID information and identify

the display device. This procedure is performed only once for the connected

display device. After storing the EDID, the system can be connected and

disconnected without having to set the EDID again. If you decide to use a different

display, then you need to set the EDID again.

To capture the EDID of a display device, do the following:

1. Connect the power to the display.

2. Connect the 5V power adapter to the power socket of the 602T, and connect

the adapter to the mains electricity.

3. Push the EDID button (illustrated in Figure 2), using a small screwdriver.

The EDID LED flashes twice and turns off.

4. Connect the 602T unit directly to the display device (while it is powered

ON).

602T, 602R - Using the Two-fiber Detachable Optical DVI System

The EDID LED flashes several times while reading the EDID. The LED turns

OFF after about eight seconds.

5. Disconnect the transmitter from the display.

The LED lights

6. Disconnect the 602T.

The EDID information is now stored and the Indication LED is on.

Figure 2: The Auto EDID Button on the 602T

4.2 Connecting the Detachable Optical DVI

Transmitter/Receiver

To connect the 602T Two-fiber Detachable Optical DVI Transmitter with the 602R

Two-fiber Detachable Optical DVI Receiver, as the example in Figure 4 illustrates,

do the following:

1. Set the EDID of the display device (see Section 4.1).

2. Connect the 602R to the 5V DC power adapter and connect the adapter to

the mains electricity. The blue LED lights.

3. Connect the duplex LC fiber cables to the 602T and 602R modules, one

cable at a time, as illustrated in Figure 3.

Single-mode and multi-mode fiber are applicable up to 500 meters. For distances over

500 meters, use single-mode fibers.

4. Plug the 602T DVI connector directly to the DVI connector of the computer.

Do not use any intermediate cable or adapter between them, and connect cables 1 and

2 as indicated in Figure 3

5. Connect the 602R DVI connector directly to the DVI connector of the display

device.
