Kramer VS-808TP Manuel utilisateur

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

VS-808TP

8x8 Twisted Pair Matrix

Switcher

P/N: 2900-300147 Rev 2

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 2

2.3 Using Twisted Pair Cable 3

2.4 Recycling Kramer Products 3

3Overview 4

4Defining the VS-808TP 8x8 Twisted Pair Matrix Switcher 5

5Installing the VS-808TP in a Rack 7

6Connecting the VS-808TP 8

6.1 Connecting a Serial Data Source to the VS-808TP RS-232 Data Port 9

6.2 Connecting a Serial Controller to the VS-808TP 9

6.3 Connecting to the VS-808TP via Ethernet 11

6.4 Connecting the Balanced/Unbalanced Stereo Audio Output 13

7Operating the VS-808TP Locally via the Front Panel Buttons 15

7.1 Using the Menu 16

8Operating the VS-808TP Remotely via the Web Pages 20

8.1 Accessing the VS-808TP Web Pages 20

8.2 Connections Page 21

8.3 Setup Page 21

8.4 User Management 24

8.5 Firmware 24

9Wiring the CAT 5 Line In/Line Out RJ-45 Connectors 25

10 Technical Specifications 26

11 Default Parameters 27

11.1 Default Communication Parameters 27

11.2 Default Logon Credentials 27

12 Kramer Protocol 28

12.1 Kramer Protocol 2000 28

Figures

Figure 1: VS-808TP 8x8 Twisted Pair Matrix Switcher Front Panel 5

Figure 2: VS-808TP 8x8 Twisted Pair Matrix Switcher Rear Panel 6

Figure 3: Connecting the VS-808TP 8x8 Twisted Pair Matrix Switcher 8

Figure 4: Crossed Cable RS-232 Connection 10

Figure 5: Straight Cable RS-232 Connection with a Null Modem Adapter 10

Figure 6: Wiring for an RS-485 Serial Data Source 11

Figure 7: Wiring for an RS-422 Serial Data Source 11

Figure 8: Local Area Connection Properties Window 12

Figure 9: Internet Protocol (TCP/IP) Properties Window 13

Figure 10: Balanced Stereo Audio Connection 14

Figure 11: Unbalanced Stereo Audio Connection 14

Figure 12: Web Browser Address Bar 20

Figure 13: Connections Page 21

VS-808TP - Contents

Figure 14: Web Page 22

Figure 15: Serial Page 22

Figure 16: Port Name Page 23

Figure 17: Data and Audio Processing Page 23

Figure 18: User Management Page 24

Figure 19: Firmware Page 24

Figure 20: CAT 5 Pinout 25

VS-808TP - Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP

5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP

7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:

Sierra Products; GROUP 12: Digital Signage; GROUP 13: Audio; and GROUP 14:

Collaboration.

Congratulations on purchasing your Kramer VS-808TP 8x8 Twisted Pair Matrix

Switcher which is ideal for long range graphics distribution and multimedia

applications.

VS-808TP - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to http://www.kramerelectronics.com/support/product_downloads.asp

to check for up-to-date user manuals, application programs, and to check

if firmware upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cable) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

Position your Kramer VS-808TP away from moisture, excessive sunlight and

dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

2.2 Safety Instructions

Caution:

No operator serviceable parts inside the unit

Warning:

Use only the Kramer Electronics input power wall adapter

that is provided with the unit

Warning:

Disconnect the power and unplug the unit from the wall

before installing

VS-808TP - Getting Started

2.3 Using Twisted Pair Cable

Kramer engineers have developed special twisted pair cables to best match our

digital twisted pair products; the Kramer: BC-DGKat524 (CAT 5 24 AWG), the

Kramer: BC-DGKat623 (CAT 6 23 AWG cable), and the Kramer: BC-DGKat7a23

(CAT 7a 23 AWG cable). These specially built cables significantly outperform

regular CAT 5/CAT 6/CAT 7a cables.

2.4 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country

go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

VS-808TP - Overview

3 Overview

Thank you for purchasing the Kramer VS-808TP 8x8 Twisted Pair Matrix Switcher.

This unique matrix switcher which utilizes economical TP (Twisted Pair) cabling

often pre-installed in buildings these days, routes and distributes signals both from

a local and/or remote source, and at extended ranges. It is designed especially for

installations where a high level of control possibilities is required from extended

distances. Typical uses include presentation and multimedia applications, as well

as long-range graphics distribution and control for schools, hospitals, security, and

stores.

The VS-808TP features:

Eight inputs and eight outputs for remote connection to compatible TP

transmitters and receivers

A switchable local input (built-in transmitter) and output (built-in receiver)

allowing direct connection of the signals (up to WUXGA, audio and RS-232)

for the units located near to the switcher (TP-133/TP-134 only)

Follow or breakaway switching for audio signals

Baud rate of up to 115200 for full-duplex RS-232

Two-line LCD display for separate route indication of video, audio or RS-232

Control via front panel buttons, RS-232, RS-485 and Ethernet

15 user-programmable presets for quick-change configurations

Kramer 2000 communication protocol (limited)

100-230V AC worldwide power supply

Standard 1U 19” rack mount size

4 Defining the VS-808TP 8x8 Twisted Pair Matrix Switcher

Figure 1 defines the front panel of the VS-808TP.

Figure 1: VS-808TP 8x8 Twisted Pair Matrix Switcher Front Panel

Feature

Function

AUDIO Button

Press to display/switch audio status. Press again to display/switch video/RS-232 status

MENU Button

Press to display the menu. Press again to escape the menu and display video switching

Arrow keypad

When switching is displayed: press the left (◄) and right (►) arrows to move forward and backward to select

the output of a switched pair. Press the up (▲) and down (▼) arrows to move up or down through available

input channels.

When the menu is displayed: press the up (▲) and down (▼) arrows to move up or down through available

sub-menus. Press the left (◄) and right (►) arrows to move through parameter values

ESC Button

When the menu is displayed: press to move up one menu level or press repeatedly to exit the menu.

When audio switching is displayed: press to display video switching

ENTER Button

When audio switching is displayed: press to accept the selected out/in channels.

When the menu is displayed: press to accept the selected parameter value

LCD Readout

IN Display

Displays the selected switched inputs

OUT Display

Displays the selected switched outputs

VS-808TP –Defining the VS-808TP 8x8 Twisted Pair Matrix Switcher

Figure 2 defines the rear panel of the VS-808TP.

Figure 2: VS-808TP 8x8 Twisted Pair Matrix Switcher Rear Panel

Feature

Function

AUDIO

Connectors

Unbalanced

IN 3.5mm mini jack

Connect to the output of the unbalanced stereo audio source (for example, the audio output

of the laptop)

OUT 3.5mm mini jack

Connect to the input of the unbalanced stereo audio acceptor (for example, the audio input of

the AV system)

Balanced

IN 5-pin terminal block

Connect to the output of the balanced stereo audio source

OUT 5-pin terminal block

Connect to the input of the balanced stereo audio acceptor

RS-485/RS-422 5-Pin Terminal Block

Connect to the serial controller

RS-232 (DATA) 9-pin D-sub Connector

Connect to the serial data source

ETHERNET RJ-45 Connector

Connect via a LAN to the Ethernet port on the PC controller

INPUTS 1 ~ 8 RJ-45 Connectors

Connect to the TP transmitters (for example, the TP-133)

OUTPUTS 1 ~ 8 RJ-45 Connectors

Connect to the TP receivers (for example, the TP-134)

Chassis Ground Terminal

Terminal for grounding the chassis to the common ground of the system

AC Mains Module

Mains socket

Connect the mains power cord

Mains fuse holder

Fuse for protecting the device

Mains switch

Turn the device on and off

PC IN 15-pin HD VGA Connector

Connect to the output of the VGA (up to WUXGA) source (for example, PC graphics card)

PC OUT 15-pin HD VGA Connector

Connect to the input of the VGA acceptor (for example, LCD monitor)

RS-232 (CONTROL) 9-pin D-sub Connector

Connect to the serial controller

VS-808TP –Defining the VS-808TP 8x8 Twisted Pair Matrix Switcher
