Overview

Congratulations on purchasing your Kramer VS-88UT 8x8 HDMI/HDBT Matrix Switcher

and/or VS-84UT 8x4 HDMI/HDBT Matrix Switcher.

The devices described in this user manual are generally referred to as VS-88UT. A device is

named specifically only when a device-specific feature is described.

VS-88UT is a high-performance 4K@60Hz (4:2:0) Audio-Video presentation system with

integrated range extension and an integrated control system master. The unit switches the

video, embeds the audio and outputs the signal to both HDMI™and HDBaseT 2.0 with USB

extension and PoE. Outstanding audio support includes balanced stereo audio, unbalanced

stereo audio and de-embedded audio sources that output to embedded audio, balanced

stereo audio as well as a power amplified audio output.

VS-88UT includes a master room controller that can operate over Ethernet (LAN) with control

ports that include: one bidirectional RS-485, four RS-232, four IR, four GPI/O, and eight relays

to control a wide variety of AV devices. It includes a KNET™ connector interface that enables

access to the master controller from auxiliary room controllers such as control keypads. The

unit can also provide power to auxiliary room controllers via the KNET™ connectors. The

VS-88UT includes an Ethernet gateway to control and manage remote I/O ports.

The VS-88UT provides exceptional quality, advanced and user-friendly operation, and flexible

control.

Exceptional Quality

•Max. Data Rate –10.2Gbps (3.4Gbps per graphic channel).

•Max. Resolution –4K@60Hz (4:2:0).

•Audio Level control.

•HDMI, HDCP and DVI compliance.

•HDBaseT certified –V2.0 support.

•HDBaseT Extension Reach –Up to 100m at 4K @60Hz (4:2:0), up to 130m (430ft) at full

HD (1080p @60Hz 36bpp), up to 180m (590ft) at ultra-mode and full HD

(1080p @60Hz 24bpp).

•USB Support –USB 1.1 and USB 2.0 (up to 127Mbps) channelled through HDBaseT.

Kramer Electronics Ltd.

VS-88UT –Introduction

•HDMI Support –Deep color, 3D, 7.1 PCM as specified in HDMI 2.0.

•Kramer reKlocking™ and equalization technology – Rebuilds the digital signal to travel

longer distances.

Advanced and User-friendly Operation

•Advanced EDID management per input.

•Active source and acceptor detection.

•Control options –RS-232 serial commands transmitted by a PC, touch screen system or

other serial controller, Ethernet port via LAN.

•Simple and Powerful Maestro 1.5 Room Automation –Intuitive user interface enables

you to fully automate your meeting room elements. Configure lights, shades, devices

and more to be activated by an extensive range of triggers, including scheduling,

input/output connectivity, routing, and button pressing. By minimizing user intervention,

Maestro room automation saves meeting prep time and minimizes human error before

presentations.

•Kramer K-Config™ Compatible – Windows®-based control program for easy

configuration and upload to room controller over customer IP network.

•Kramer Network Compatible –Remote control and management over customer IP

network.

•Programmable Step-In over HDMI and HDBT –When used in conjunction with

compatible step-in devices, such as the SID-X3N and DIP-31 (using an HDMI cable that

supports HEC, the HDMI Ethernet Channel).

•Simultaneous IP control communication –With up to 15 IP control clients.

•Auto-switching and auto-scanning of inputs.

•Audio breakaway and AFV (audio-follow-video) operation support.

•Global mute for both video and audio outputs –Allowing easy integration of the audio

system with a public announcement audio system in case of an emergency event.

•Firmware Upgrade –Ethernet-based, via a user-friendly software upgrade tool.

•Kramer protocol 3000 support.

•Advanced EDID management per input.

•Includes non-volatile memory that retains the last settings after switching the power off

and then on again.

Flexible Connectivity

•For VS-88UT:

▪4 HDMI and 4 HDMI/HDBT (selectable) inputs.

▪4 balanced stereo audio inputs or 8 microphone inputs (selectable) as well as 4

unbalanced stereo inputs.

▪6 HDMI and 2 HDBT outputs.

▪6 IR ports for HDBT tunneling.

Kramer Electronics Ltd.

VS-88UT –Introduction

•For VS-84UT:

▪6 HDMI and 2 HDBT inputs.

▪4 balanced stereo audio inputs or 8 microphone inputs (selectable) as well as 4

unbalanced stereo inputs.

▪2 HDMI and 2 HDBT outputs.

▪4 IR ports for HDBT tunneling.

•2 line-out balanced stereo audio outputs and one audio amplified output.

•2 USB type-A hubs and 2 USB Type-B ports.

•1 Ethernet port –Connects to control gateways for I/O port extending, and controls

IP-enabled controlled devices.

•1G Ethernet port –For tunneling data via HDBT ports.

•1 K-NET™ connector – Carrying both power and control communication; connects to

room control system, either master room controller, or auxiliary control keypads.

•1 RS-485 and 2 RS-232 bidirectional control ports –Control devices via bidirectional

serial control protocols.

•4 IR emitter control ports –Control devices via IR control protocols.

•4 GPI/O control ports –Control devices via general purpose I/O ports, individually

configurable as digital input, digital output or analog input interface for controlling

sensors, door-locks, audio volume and light dim level, or lighting control devices.

•8 Relay control ports –Control devices via relay contact closure, such as scrolling up

and down screens, drapes, shades, and blinds.

•IR Sensor and IR input ports –Learn commands from IR remotes.

Typical Applications

The VS-88UT is ideal for the following typical applications:

•Projection systems in conference rooms, boardrooms, hotels and churches.

•Divisible conference rooms in hotels.

•Classroom, lecture theatres and education applications.

Controlling your VS-88UT

Control your VS-88UT via:

•By RS-232 serial commands transmitted by a touch screen system, PC, or other serial

controller (see Connecting to VS-88UT via RS-232 on page 16).

•Ethernet using built-in user-friendly Web pages (see Using the Web Pages on page 19).

Kramer Electronics Ltd.

VS-88UT –Defining the VS-88UT and VS-84UT

Defining the VS-88UT and

VS-84UT

This section defines the VS-88UT and VS-84UT.

Figure 1: VS-84UT 8x4 HDMI/HDBT Matrix Switcher Front Panel

Figure 2: VS-88UT 8x8 HDMI/HDBT Matrix Switcher Front Panel

Feature

Function

ON LED

Lights when receiving power.

STATUS

LED

Multi-color LED lights uponstartup, flashes green upon boot and lights green when

ready to use. The LED lights red to indicate internal errors.

Kramer Electronics Ltd.

VS-88UT –Defining the VS-88UT and VS-84UT

Figure 3: VS-88UT 8x8 HDMI/HDBT Matrix Switcher Rear Panel

Figure 4: VS-84UT 8x4 HDMI/HDBT Matrix Switcher Rear Panel

Feature

Function

Room Controller Functionality

IR IN 1 3.5mm Mini Jack

Connect to an external IR receiver (1 and 2).

IR OUT Terminal Block

Connectors

Connect to IR emitter cables (from 1 to 4).

GPI/O Terminal Block

Connectors

Connect to various analog and digital sensors (from 1 to 4).

RELAYS Terminal Block

Connectors

Connect to low-voltage relay-driven devices (from 1 to 8).

RS-232 Terminal Block

Connectors

Connect to RS-232 controlled devices (from 1 to 4).

RS-485 Terminal Block

Connector

Connect to the RS-485 port on a switcher or PC.

Pins B (-) and A (+) are for RS-485; Pin G may be connected to

the shield (if required).

K-NET Terminal Block

Connector

Use with the K-Config control system. PIN GND is for the

Ground connection; PIN B (-) and PIN A (+) are for RS-485, and

PIN +12V is for powering other devices.

RS-485 TERM Switch

Slide down for RS-485 termination with 120; slide up for no

RS-485 line termination.

The first and the last units on the RS-485 line should be

terminated (ON). Other units should not be terminated (OFF).

K-NET TERM Switch

Use with the K-Config control system.

Slide down (in the direction of the arrow) for K-NET termination;

slide up for bus to not be terminated. The last physical device on

a K-NET bus must be terminated.

PROG Switch

For factory use only.

PROG Mini USB Connector

For factory use only.

Kramer Electronics Ltd.

VS-88UT –Defining the VS-88UT and VS-84UT

Feature

Function

Matrix Functionality

REMOTE MUTE 2-pin Terminal

Block Connector

Remote switch to mute all video and audio signals. Enables easy

integration of the audio system with a PA system, usually used

for alarms or other public audio messages.

GPIO 5-pin Terminal Block

Connectors

For future use.

PROGRAM DIP-switches

For future use.

Power Connector with Switch

and Fuse

AC connector, enabling power supply to the unit.

Power switch for turning the unit on or off.

AUDIO

INPUT (MIC/line)

5-pin Terminal

Block Connectors

Connect to stereo audio balanced sources (from 1 to 4) and/or

microphone inputs (from 1 to 8).

INPUT 3.5mm

Mini Jack

Connect to an unbalanced audio source (from 5 to 8).

LINE OUT 5-pin

Terminal Block

Connectors

Connect to a stereo balanced audio acceptor (1 and 2).

POWER AMP

OUT 4-pin

Terminal Block

Connectors

Connect to a pair of loudspeakers.

VIDEO

HDMI IN

Connector

VS-88UT: connect to an HDMI source (from 1 to 4).

VS-84UT: connect to an HDMI source (from 1 to 6).

HDMI IN—HDBT

IN Connectors

VS-88UT: connect a source to the HDMI IN 5 and/or HDMI IN 6

inputs, or connect a transmitter to the HDBT IN (5) and/or HDBT

IN (6) inputs. The same applies to the HDMI IN 7/8 and HDBT IN

(7)/(8) pairs. For each input pair (HDMI or HDBT), only one type of

connector can be enabled (via the RoutingSettings Web page);

by default, the HDBT pair is active. The HDBT Transmitter (for

example, the Kramer TP-590Txr) can pass audio and video

signals as well as USB, Ethernet, power and serial commands.

HDBT IN

Connectors

VS-84UT: connect to an HDBT transmitter (from (7) to (8)).

HDMI OUT

Connectors

VS-88UT: connect to an HDMI acceptor (1, 2, 3, 4, 7 and 8).

VS-84UT: connect to an HDMI acceptor (1 to 2).

OUT (HDBT)

Connectors

VS-88UT: connect OUT 5 and/or OUT 6 to HDBT receivers (for

example, the Kramer TP-590Rxr) to pass audio and video signals

as well as USB, Ethernet, power and serial commands.

HDBT OUT

Connectors

VS-84UT: connect to HDBT receivers (for example, the Kramer

TP-590Rxr) to pass audio and video signals as well as USB,

Ethernet, power and serial commands.

HDBT IR

3.5mm Mini

Jack

VS-88UT: connect to an external IR sensor to send IR signals (5,

6, 7 and 8) via HDBT inputs 5, 6, 7 and 8 respectively.

VS-84UT: connect to an external IR sensor to send IR signals (7

and 8) via HDBT inputs 7 and 8 respectively.

OUT

VS-88UT: connect to an external IR emitter to receive IR signals

(5 and 6) via HDBT outputs 5 and 6, respectively.

VS-84UT: connect to an external IR emitter to receive IR signals

(3 and 4) via HDBT outputs 3 and 4, respectively.

RS-232 HDBT DATA Terminal

Block Connectors (G, Rx, Tx)

Connect to the PC or the remote controller and pass data

between this RS-232 port and the HDBT OUT ports or one of the

HDBT IN ports.

RS-232 CONTROL Port

Terminal Block Connectors (G,

Rx, Tx)

Connect to the PC or the remote controller to control the

VS-88UT via Protocol 3000 commands.

Kramer Electronics Ltd.

VS-88UT –Defining the VS-88UT and VS-84UT

Feature

Function

HDBT USB Device Port Pairs

Connect up to two USB clients to each pair (1 and 2) to pass

data via the HDBT inputs or outputs.

HDBT USB HOST Ports

Connect to a USB host (1 and 2) to pass data via the HDBT

inputs or outputs.

ETH

RJ-45 Ports

CONTROL

Connect to the PC or other controller through computer

networking.

DATA 1G

Connect to the PC or other controller via the Ethernet to pass

data between HDBT ports and the controller.

RESET Recessed Button

Press briefly to restart the system. Press for about 5 seconds to

reset settings to factory default values and then restart the

system.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Kramer Commutateur matriciel

Kramer

Kramer VS-2042 Manuel utilisateur

Kramer

Kramer Sierra Video 1204V5S Manuel utilisateur

Kramer

Kramer Sierra Pro XL 1616V5S Manuel utilisateur

Kramer

Kramer VS-606xl Manuel utilisateur

Kramer

Kramer VS-44HDCP Manuel utilisateur

Kramer

Kramer MV-4X Manuel utilisateur

Kramer

Kramer Sierra Video 3216V3S Manuel utilisateur

Kramer

Kramer Sierra Video 6432V5Sxl Manuel utilisateur

Kramer

Kramer VP-729 Manuel utilisateur

Kramer

Kramer XL 1616V4 Manuel utilisateur

Kramer

Kramer XL 1208V4 Manuel utilisateur

Kramer

Kramer VS-169TP Manuel utilisateur

Kramer

Kramer VP-211DS Manuel utilisateur

Kramer

Kramer XL 1608V2S Manuel utilisateur

Kramer

Kramer VP-8x8 Manuel utilisateur

Kramer

Kramer LASSEN XL 3216S Manuel utilisateur

Kramer

Kramer VS-6EII Manuel utilisateur

Kramer

Kramer VS-3232DN-EM Manuel utilisateur

Kramer

Kramer VS-88HDCPxl Manuel utilisateur

Kramer

Kramer VP-1608 Manuel utilisateur

Kramer

Kramer VS-44UHD Manuel utilisateur

Kramer

Kramer VP-436N Manuel utilisateur

Kramer

Kramer VS-88UHD Manuel utilisateur

Kramer

Kramer Sierra Pro XL 1616V5 Manuel utilisateur

Manuels Commutateur matriciel populaires d'autres marques

Broadcast Tools

Broadcast Tools SS 8.2 Manuel utilisateur

Altimium

Altimium MATF32 Manuel utilisateur

ALFAtron

ALFAtron ALF-MUK44N Manuel utilisateur

Monoprice

Monoprice Blackbird 15377 Manuel utilisateur

PTN

PTN FMX12 Manuel utilisateur

CYP

CYP nT15GX01 Manuel utilisateur

TESmart

TESmart HMA0402A40 Manuel utilisateur

Octava

Octava HD4XSTPMX Manuel utilisateur

Intelix

Intelix FLX-88 Mode d'emploi

Roland

Roland XS-1HD Manuel utilisateur

Atlona

Atlona AT-HDMI-22M Manuel utilisateur

Link

Link HD8X8 Manuel utilisateur

AMX

AMX AVS-OP-2020-117 Instructions et recettes

Lindy

Lindy 38042 Manuel utilisateur

Extron electronics

Extron electronics MTPX Plus Series Manuel utilisateur

Key Digital

Key Digital Champion KD-16x16CS Manuel utilisateur

Shinybow USA

Shinybow USA SB-8811 Manuel utilisateur

Optimus

Optimus Compact Manuel utilisateur
