USER MANUAL

Model:

PL-50

Power Controller - Monitor

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

Contents

1Introduction 1

2Getting Started 1

2.1 Quick Start 1

3Overview 3

3.1 Terminology Used in this User Manual 4

4Your PL-50 Power Controller - Monitor 4

5Installing in a Rack 7

6Connecting the PL-50 Power Controller - Monitor 8

6.1 Connecting the Relays 9

6.2 Controlling the PL-50 via the Ethernet Port 9

6.2.1 Connecting the ETHERNET Port Directly to a PC (Crossover Cable) 9

6.2.2 Connecting via a Straight-Through Cable 10

6.2.3 Configuring the Ethernet Port Initially 11

6.3 Controlling via the Embedded Web Pages 13

6.3.1 Setting the Embedded Web Page 13

6.3.2 The Panel Screen 15

6.3.3 The Scheduler Screen 16

6.3.4 The Channel Settings Screen 18

6.3.5 The Alerts Screen 19

6.3.6 The Power Measurement Screen 21

6.3.7 The Power ON/OFF Order Screen 22

6.3.8 The Configurations Screen 24

6.3.8.1 The Security System 26

6.4 DIP-switch Settings 27

7Operating Your PL-50 Power Controller – Monitor 27

7.1 Calibrating via the Front Panel Buttons 27

8Flash Memory Upgrade 29

8.1 Upgrading the Firmware 29

8.1.1 Download the Firmware 29

8.1.2 Connect a PC to the PL-50 29

8.1.3 Update the Firmware 30

8.2 Changing the Device Parameters 35

9Technical Specifications 35

10 Kramer Protocol 3000 36

10.1 Protocol 3000 Syntax 36

10.2 Command Terms 37

10.3 Common Commands 38

10.4 Result and Error Codes 40

10.5 Security Commands 40

10.6 Network Setting Commands 41

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Contents

10.7 Instruction Codes 43

Figures

Figure 1: PL-50 Power Controller – Monitor Front Panel 5

Figure 2: PL-50 Power Controller – Monitor (for Europe) Rear Panel 5

Figure 3: PL-50 Power Controller – Monitor (for USA) Rear Panel 5

Figure 4: Connecting the PL-50 8

Figure 5: Relay Wiring 9

Figure 6: Local Area Connection Properties Window 10

Figure 7: Internet Protocol (TCP/IP) Properties Window 10

Figure 8: K-UPLOAD Main Screen 11

Figure 9: Connect Screen 12

Figure 10: Device Properties Screen 12

Figure 11: Typing the IP Number 13

Figure 12: Loading the Embedded Web Pages 13

Figure 13: Running the Application 14

Figure 14: HOME Embedded Web Page 15

Figure 15: Selecting a Channel 15

Figure 16: The Scheduler Screen 16

Figure 17: Scheduling the Outlets 17

Figure 18: The Channel Settings Screen 18

Figure 19: The Alerts Screen 19

Figure 20: Setting the Alarms 20

Figure 21: The Power Measurement Screen 21

Figure 22: The Power ON/OFF Order Screen 22

Figure 23: Power ON Order Example 23

Figure 24: Switching ON Sequence Example 23

Figure 25: Configurations Embedded Web Page 24

Figure 26: Enable Security System 25

Figure 27: Security System Enabled 25

Figure 28: User Login 26

Figure 29: SETUP DIP-switches 27

Figure 30: K-UPLOAD Screen 30

Figure 31: Connect Ethernet by IP Number 30

Figure 32: Connection Time Out Message 31

Figure 33: K-UPLOAD Connected 32

Figure 34: Open the Firmware File 32

Figure 35: Warning Window 33

Figure 36: Upload Progress 33

Figure 37: Restart Message 34

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

Contents

iii

Tables

Table 1: Terminology Used in this User Manual 4

Table 2: PL-50 Power Controller – Monitor Features 6

Table 3: Relay PINOUT 9

Table 4: The Scheduler Screen Features 16

Table 5: The Channel Settings Screen Features 18

Table 6: The Alerts Screen Features 19

Table 7: The Power Measurement Screen Features 21

Table 8: The Power ON/OFF Order Screen Features 22

Table 9: DIP-switch Definitions 27

Table 10: Technical Specifications of the PL-50 35

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront the video, audio, presentation, and

broadcasting professional on a daily basis. In recent years, we have redesigned

and upgraded most of our line, making the best even better! Our 1,000-plus

different models now appear in 11 groups1

Congratulations on purchasing your Kramer PL-50 Power Controller Monitor.

that are clearly defined by

function.

The PL-50 is ideal for power monitoring and security systems.

The package includes the following items:

•PL-50 Power Controller Monitor

•A power cord and an infrared remote control transmitter (including the

required battery and a separate user manual2)

•This user manual2

•P3K Wizard Software

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high performance high resolution cables3

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:

Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories

and Rack Adapters; GROUP 11: Sierra Products

2 Download up-to-date Kramer user manuals from the Internet at http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

Overview

3 Overview

The PL-50 Power Controller Monitor can control up to five power channels at

a total load of 10A. The PL-50, by measuring and then monitoring the

standby and active modes of the connected units, can detect whether a unit is

in the standby mode, the active mode or is disconnected.

Two versions of the PL-50 are available, a European version and a version for

the USA.

The PL-50 features include:

•PRESET LEVEL buttons, for measuring the STANDBY mode and the

ACTIVE mode for reference

•A green ACTIVE LED and an orange STANDBY LED per channel,

indicating the status of the outlet

•The ability to detect a change in the state of any of the channels and then

trigger an alarm via the RELAY and Digital control terminal blocks that

can be connected to an alarm or any other room activity

•Control via embedded Web pages, letting you schedule the activity of the

outlet, set a response in case of an event, set the status of each channel

separately, set the power ON/OFF order and delay, and so on

•An Ethernet port and a USB port for unit configuration and control

Control the PL-50 using the front panel buttons, or remotely via:

•USB, RS-485 or RS-232 serial commands transmitted by a touch screen

system, PC, or other serial controller

•ETHERNET

•The Kramer Infrared Remote Control Transmitter

To achieve the best performance:

•Connect only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise

levels (often associated with low quality cables)

•Avoid interference from neighboring electrical appliances that may

adversely influence signal quality and position your PL-50 away from

moisture, excessive sunlight and dust

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your PL-50 Power Controller - Monitor

3.1 Terminology Used in this User Manual

Table 1defines some terms that are used in this user manual:

Table 1: Terminology Used in this User Manual

Term

Definition

802.3

The standard specification for ETHERNET that is maintained by the Institute of Electrical and

Electronics Engineers (IEEE).

Dynamic Host Configuration

Protocol (DHCP)

Allows the network administrator to distribute IP addresses from a central point and

automatically send a new IP address when an Ethernet point is plugged into a different

network location.

Gateway

A network position serving as an entry to another network. On the Internet, a node or

stopping point can be either a gateway node or a host (end-point) node.

IP Address

A 32-binary digit number that identifies each sender or receiver (within a network via a

particular server or workstation) of data (HTML pages or e-mails) that is sent in packets

across the Internet. Every device connected to an IP network must have a unique IP

address. This address is used to reference the specific unit.

Local Area Network (LAN)

Computers sharing a common communications line or wireless link, which often share a

server within a defined geographic area.

Media Access Control

(MAC) Address

A computer's unique hardware number (or address) in a LAN or other network. On an

Ethernet LAN, the (MAC) address is identical to the Ethernet address.

Transmission Control

Protocol/Internet Protocol

(TCP/IP)

The basic communication language or protocol of the Internet that breaks the message into

appropriately sized packets for the network, and can be used as a communications protocol

in an intranet or an extranet.

4 Your PL-50 Power Controller - Monitor

Figure 1and Table 2define the PL-50 Power Controller - Monitor:

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

Your PL-50 Power Controller - Monitor

Figure 1: PL-50 Power Controller – Monitor Front Panel

Figure 2: PL-50 Power Controller – Monitor (for Europe) Rear Panel

Figure 3: PL-50 Power Controller – Monitor (for USA) Rear Panel

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your PL-50 Power Controller - Monitor

Table 2: PL-50 Power Controller – Monitor Features

Feature

Function

1 IR Receiver Window The red LED lights when receiving signals from the Kramer

Infrared remote control transmitter

2 POWER LED The red LED lights when the main power is ON

3 OUT Channel

(from 1 to 5)

STANDBY LED The orange LED lights when the channel outlet is in the

standby mode, and blinks when reading the standby level

4 ACTIVE LED The green LED lights when an outlet is connected to that

power channel and active, and blinks when reading the preset

active level

5 OUT Button Press one or more buttons to select the power channel for

calibrating

6 PRESET LEVEL

Buttons

STANDBY Press to read the standby mode

7 ACTIVE Press to read the active mode

8 PROGRAM USB connector For configuring and programming the unit

9 ETHERNET Connector Connects to the PC or other Serial Controller through computer

networking

10 RESET Press to reset the standby and active values for all the

channels, as well as the security passwords

11 RS-232 9-pin D-sub Port Connect to the PC or other Serial Controller

12 DIP-switches Program, for technical use only

RS-485 TERM, for RS-485 termination

13 RS-485 Terminal Block Connector Connect to the PC or other Serial Controller

14 RELAY terminal block connector Connect to an alarm or other item (see section 6.1)

15 DIGITAL CONTROL (G, OC

Connect to an alarm or other item)

Terminal Block Connector

16 Power Outlets (from 1 to 5) 220-240V AC for European version (see Figure 2)

100-120V AC for USA version (see Figure 3)

17 POWER IN Connector with FUSE AC connector enabling power supply to the unit

18 POWER Switch Illuminated switch supplying power to the unit

1 OC means Open Collector

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

Autres manuels pour PL-50

Table des matières

Autres manuels Kramer Contrôleurs

Kramer

Kramer PT-12 Manuel utilisateur

Kramer

Kramer FC-18 Manuel utilisateur

Kramer

Kramer SL-1N Manuel utilisateur

Kramer

Kramer RC-63DLN Manuel utilisateur

Kramer

Kramer RC-13TC Manuel utilisateur

Kramer

Kramer RC-76R Manuel utilisateur

Kramer

Kramer RC-52N Manuel utilisateur

Kramer

Kramer SL-280 Manuel utilisateur

Kramer

Kramer SL-12 Manuel utilisateur

Kramer

Kramer PT-12 Manuel utilisateur

Kramer

Kramer RC-7LC Manuel utilisateur

Kramer

Kramer FC-18 Manuel utilisateur

Kramer

Kramer RC-7B Manuel utilisateur

Kramer

Kramer KC-Virtual Brain5 Manuel utilisateur

Kramer

Kramer SL-280 Manuel utilisateur

Kramer

Kramer FC-22ETH Manuel utilisateur

Kramer

Kramer RC-74DL Manuel utilisateur

Kramer

Kramer RC-8RKL Manuel utilisateur

Kramer

Kramer RC-63DLN Manuel utilisateur

Kramer

Kramer RC-7RL Manuel utilisateur

Kramer

Kramer FC-10ETH Manuel utilisateur

Kramer

Kramer SL-10 Manuel utilisateur

Kramer

Kramer RC-6 Manuel utilisateur

Kramer

Kramer VA-4H Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
