USER MANUAL

Model:

VA-1

UXGA Sync Processor

Contents

Introduction 1

Getting Started 1

2.1

Quick Start 2

Overview 3

Your VA-1 UXGA Sync Processor 4

Connecting the VA-1 UXGA Sync Processor 5

Technical Specifications 6

Figures

Figure 1: VA-1 UXGA Sync Processor Functions 4

Figure 2: Connecting the VA-1 UXGA Sync Processor 5

Tables

Table 1: VA-1 UXGA Sync Processor Functions 4

Table 2: VA-1 Technical Specifications 6

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront the video, audio, presentation, and

broadcasting professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

1,000-plus different models now appear in 11 groups

that are clearly

defined by function.

Thank you for purchasing the Kramer Pico TOOLS™ VA-1 UXGA Sync

Processor, which is ideal for:

Delivering presentation graphics

Using a display at a distance from the computer

Using in graphics production studios for image stabilization

Each package includes the following items:

The VA-1 UXGA Sync Processor

Power adapter (12V DC Input)

This user manual

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

Review the contents of this user manual

Use Kramer high-performance high-resolution cables

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;

GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;

GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products

2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

Overview

3 Overview

The VA-1 UXGA Sync Processor is a high-performance sync corrector that

can be used for any UXGA computer graphics video signal. The low-

voltage sync signal is cleaned up and brought to the TTL voltage level

while passing color signals transparently. This is especially useful when

sending a video signal over a long display line.

To achieve the best performance:

Use only good quality connection cables

to avoid interference,

deterioration in signal quality due to poor matching, and elevated

noise levels (often associated with low quality cables).

Avoid interference from neighboring electrical appliances that

may adversely influence signal quality and position your Kramer

VA-1 away from moisture, excessive sunlight and dust

Caution – No operator-serviceable parts inside unit.

Warning – Use only the Kramer Electronics input power

wall adapter that is provided with this unit

Warning – Disconnect power and unplug unit from wall

before installing or removing device or servicing unit.

1 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com

2 For example, part number 2535-000251

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VA-1 UXGA Sync Processor

4 Your VA-1 UXGA Sync Processor

Figure 1 and Table 1 define the unit.

Figure 1: VA-1 UXGA Sync Processor Functions

Table 1: VA-1 UXGA Sync Processor Functions

# Feature Function

1 12V DC Connector +12V DC for powering the unit

2 ON LED Illuminates green when receiving power

3 UXGA OUTPUT Connects to a UXGA acceptor

4 UXGA INPUT Connects to a UXGA computer graphics source

Connecting the VA-1 UXGA Sync Processor

5 Connecting the VA-1 UXGA Sync Processor

To connect the VA-1, as the example in Figure 2 illustrates, do the following

1. Connect the source, for example, a computer graphics card to the UXGA

INPUT connector.

2. Connect the OUTPUT connector to the acceptor, for example, a display.

3. Connect the 12V DC power adapter to the power socket and connect the

adapter to the mains electricity.

The VA-1 begins operating when connected and powered ON.

Figure 2: Connecting the VA-1 UXGA Sync Processor

1 Switch OFF the power on each device before connecting it to your VA-1. After connecting your VA-1, switch on its power

and then switch on the power on each device

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Technical Specifications

6 Technical Specifications

The VA-1 technical specifications are shown in Table 2:

Table 2: VA-1 Technical Specifications

INPUT: 1 XGA on an HD-15 connector

OUTPUT: 1 XGA on an HD-15 connector

MAX. OUTPUT LEVEL: 5Vpp video syncs

BANDWIDTH (-3dB): 680MHz

DIFF. GAIN: 0.03%

DIFF. PHASE: 0.03%

K-FACTOR: <0.1%

S/N RATIO: 73dB @ 5MHz

COUPLING: DC

POWER SOURCE: 12V DC, 21mA Fuse: 200mA

DIMENSIONS 6.2cm x 5.2cm x 2.4cm (2.4" x 2.1" x 1") W, D, H

WEIGHT: 0.14kg (0.3lbs)

ACCESSORIES: 12V DC power supply, 19-inch rack adapters

1 Specifications are subject to change without notice

Kramer Electronics, Ltd.

Web site: www.kramerelectronics.com

E-mail: [email protected]

P/N: 2900-000369 REV 2

For the latest information on our products and a list of Kramer

distributors, visit our Web site: www.kramerelectronics.com

where updates to this user manual may be found.

We welcome your questions, comments and feedback.

Caution

Safety Warning:

Disconnect the unit from the power supply before

opening/servicing.
